Chipsee CS19108F215P-C111 User manual
19
Horizontal Resolution
80 Means 800 Pixel
10 Means 1024 Pixel
12 Means 1280 Pixel
14 Means 1440 Pixel
19 Means 1920 Pixel
108
Vertical Resolution
480 Means 480 Pixel
600 Means 600 Pixel
768 Means 768 Pixel
800 Means 800 Pixel
900 Means 900 Pixel
102 Means 1024 Pixel
108 Means 1080 Pixel
F(T) Product based on Freescale (TI) CPU
215
LCD Dimension
050 Means 5.0 Inch
070 Means 7.0 Inch
080 Means 8.0 Inch
097 Means 9.7 Inch
101 Means 10.1 Inch
104 Means 10.4 Inch
120 Means 12.0 Inch
150 Means 15.0 Inch
170 Means 17.0 Inch
190 Means 19.0 Inch
215 Means 21.5 Inch
P
Means Embedded PC or Panel PC
E Means Embedded PC without Case
P Means Panel PC with Case
C
Means Touch Type
R Means Resistive Touch
C Means Capacitive Touch
1
Means LCD Brightness
1 Means Common Brightness
2 Means High Brightness
1PCB Version
Baseboard PCB Version Number
1PCB Version
SOM Module PCB Version Number
Hardware Features
Key Features:
CPU iMX6Q,Quad-A9,1GHz
RAM 2GB DDR3
eMMC 8GB
Storage TF card, supports up to 32GB SDHC
Display 21.5 Inch LCD,1920*1080 Pixel
Resolution,16:9
Touch Ten-Point Capacitive Touch
USB 2 x USB 2.0 Host,1 USB OTG
LAN 1 Channel 1000M LAN
Audio 3.5mm Audio In/Out Connector,2W Speaker
Internal
Buzzer 1
RTC Yes
RS232 2 Channels
RS485 3 Channels *
CAN 2 Channels
GPIO 8 Channels
WiFi/BT On Board WIFI/BT
HDMI 1 Channel
SATA II 1 Channel
4G/LTE Optional
Power Input 15~36V DC
Current @ 15V 2000 mA max
Power Consumption 25W Typical
Working Temperature -20°C to +70°C
OS Android, Ubuntu, Linux
Dimension 530*322*45mm
Weight 6000g
* This product has 5 channels of UART in total. The Bluetooth
used one channel UART by default, the default setting is
2*RS232+2*RS485+Bluetooth. The UART can be changed between
RS232 and RS485 easily. If you want different RS232 and RS485
settings, please contact us.
CS19108F215P-
C111
Figure 1 Top View (Android)
Figure 2 Back View
Power Input Connector
The product CS19108F215P-C111 uses a wide range power input:
DC 15~36V. The total power consumption is about 25W normally.
The Power Input Connector is 3 Pin 3.81mm Screw Terminal
Connector as Figure 3 shows. The Character “+” means power
Positive input, The Character “–” means power Negative input.
The Character “G” means system Ground. Table 1 has detailed
descriptions about the connector definition.
Figure 3 Power Input Connector
Table 1
Power Input Pin Definition:
Pin Number Definition Description
Pin 1 Positive Input Connect to DC Power Positive
Terminal
Pin 2 Negative Input Connect to DC Power Negative
Terminal
Pin 3 Ground Connect to Power System Ground
BE ATTENTION:
The system ground “G” has been connected to power negative “-”
on board.
Capacitive Touch
The product CS19108F215P-C111 uses ten-point capacitive touch.
ATTENTION:
Capacitive touch is very sensitive to power noise. Ripple
voltage/current from the power adapter will cause the LCD
ripples, and will also cause the capacitive touch malfunction:
If you use the APK Multi-Touch under Android to test, you can
find the touch point float. There are several ways to solve
this problem:
1) Use a high quality power adapter. Or use battery to
provide the power like cell phone or tablet PC.
2) If user power adapter can’t be good enough, there’s
another effective method to solve this problem: Make sure the
CS19108F215P-C111 power input connector Pin 3 really connect
to user “Power System Ground”. This method can eliminate the
problem totally. User can also use another method to test this
problem: touch the GND of CS19108F215P-C111 by one hand, the
other hand operates on the capacitive touch screen. In this
case, user’s body acts as the Power System Ground.
DB9 Connector
The product CS19108F215P-C111 has 4*DB9 connectors configured
as RS232 by default. as Figure 5 shows .COM3/COM4 can be
customized to RS485. If you need any other setting different
to the default setting, please contact us.
Figure 4 DB9 Connector
USB HOST Connector
The product CS19108F215P-C111 has two USB connectors as Figure
5 shows. These two USB can provide 500mA current each.
Figure 5 USB HOST Connector
USB OTG Connector
The product CS19108F215P-C111 has one USB OTG connector as
Figure 6 shows. It works as slave by default. User can connect
it to host PC by this connector.
Figure 6 USB OTG Connector
LAN Connector
The product CS19108F215P-C111 has one channel 1000Mbit
Ethernet Connector, as Figure 7 shows.
Figure 7 LAN Connector
Audio Connector
The product CS19108F215P-C111 has one Audio Input (“Line-in”)
and one Audio (“Line-out”) output, as Figure 10 shows. And the
product has an internal 2W speaker.
Figure 8 Audio Connector
WiFi+BT
The product CS19108F215P-C111 has one WiFi+BT. It uses
Realtech RTL8723 which integrates WiFi and BT. There is a
connector on the backside case which can connect external
WiFi/BT Antenna, as Figure 11 shows.
Figure 9 WiFi+BT Antenna
HDMI Connector
The product CS19108F215P-C111 has one HDMI connector as Figure
12 shows. The HDMI output resolution can be configured by
software.
Figure 10 HDMI Connector
Boot Switch
The product CS19108F215P-C111 has a boot switch which can be
used to change boot sequence, as Figure 13 shows. It is
defined as SW2 on the PCB. As for the details of the boot
switch, please refer to Table 3.
Figure 11 Boot Switch
Table 3
Boot Config Select:
Mode 1 2 3 4
TF Card 1 0 0 0
eMMC 1 1 01
Download 01 1 0
Expansion Connector
The product CS19108F215P-C111 has one Expansion Connector, as
Figure 12 shows. This connector is labelled as P28 on the PCB,
and it has connected to CPU GPIO/I2C signals. As for the
definition of every Pin, please refer to Table 4.
Figure 12 Expansion Connector
Table 4
GPIO
Pin
Pin 10 VCC_ISO
Pin 9 GND_ISO
Pin 8 OUTPUT1
Pin 7 OUTPUT2
Pin 6 OUTPUT3
Pin 5 OUTPUT4
Pin 4 INPUT1
Pin 3 INPUT2
Pin 2 INPUT3
Pin 1 INPUT4
ATTENTION:
All signals are optocoupler isolated. VCC_ISO supports 5V ~
24V input.
Measurements and Mounting
Measurements
The measurement of CS19108F215P-C111 is 537*328*55mm.
Mounting Method
This product CS19108F215P-C111 can be mounted using the
mounting set, as Figure 16 shows. Please make sure the display
is not exposed to high pressure when mounting into an
enclosure.
Figure 13 Mounting Method
How to Get Support
Please feel free to contact us with any questions, queries or
suggestions.
If your question is about technical support or troubleshooting
for one of our products, we kindly ask you to first check our
documentation for a possible solution.
If you cannot find the solution you are looking for then
details.
