Chord Hugo2 User manual

User Manual
USB Compatibility:
Windows PC (Driver
available online),
Mac OS X, Linux, iOS
devices and Android.
Micro USB input
Bluetooth:
Select Bluetooth Input
(Blue) and pair with
device using
(Pairing code: 0000)
Crossfeed:
Gives a more-speaker-
like presentation with
three-stage DSP
spatial effect
Line level mode:
WARNING!
Line level
mode will set
maximum volume on
all outputs including
headphones. Please
disconnect before
continuing.
To activate, press and
hold the Crossfeed
(X-PHD) button when
turning the unit on.
To deactivate, switch
the unit off and confirm
that the volume has
reduced using the
colour chart supplied
within this manual
Charging:
A 5V 2-amp charger
is required to charge
Hugo 2 at maximum
speed. Chargers
between 1-2 amps will
charge Hugo 2 in half-
charge mode and will
decrease play/charge
length. Chargers
below 1 amp will fail to
charge Hugo 2.
WARNING!
If the batteries
are fully
depleted the unit will
not switch on. Please
connect to a charger
and wait 30mins
To activate your
warranty you must
register your
product at: chord
electronics.co.uk/
register-product
Frequency response: 20Hz – 20kHz +/- 0.2dB
Total Harmonic Distortion: <0.0001% 1kHz 3V
RMS 300 ohms
THD and noise at 3V RMS Ref 5.3V: 120dB @
1kHz 300 ohms A Wt
Noise 2.6 uV A Wt: no measurable noise floor
modulation
Signal to noise ratio: 126dB A-weighted
Channel separation: 135dB @ 1kHz 300 ohms
Maximum output level (to clipping at 1% distor-
tion): 94 mW 300 ohms; 740 mW 33 ohms; 1050
mW (8)
Output impedance: 25 milliohms (0.025 ohms)
@chordaudio /chordelectronics /chordelectronics
Power
USB
Source Select
Optical
Source Select
Bluetooth
Source Select
Crossfeed
Select
Filter Select
Light Dim
Coax 1
Source Select
Coax 2
Source Select
Mute
Volume Control
Hugo 2’s IR sensor is located within the viewing
glass, for optimal performance please do not
obstruct this area.
Requires
2x AAA
batteries
Please only use a dry
cloth to clean Hugo 2
Never directly spray
liquids, including
cleaners, onto Hugo 2
Do not allow Hugo 2 to
come into contact with
liquid
Never poke objects into
the exposed connectors
apart from the designated
connectors
Never drop or expose
Hugo 2 to mechanical
shock
No user serviceable parts,
do not disassemble Hugo
2. Doing so will void your
warranty. Please contact
your original dealer in the
event of a fault
Only operate within the
specified temperatures
5°C40°C
41°F104°F
Made in England
®
18 month limited warranty on internal batteries
MTHS
18 WARRANTY
3 year limited warranty on hardware
YRS
3 WARRANTY
USB
COAX1
OPT BT
COAX2
Mute
FILT X-PHD DIM
Vol -
Vol +
www.chordelectronics.co.uk
Digital To Analogue
Converter and
Headphone
Amplifier
Hugo2
07 Important information 05 Remote control function
08
06
Specifications
Care instructions

Charge
Charging (1amp / 2amps)
Charged
Desktop mode activated *
Micro USB input
Play and charge Hugo 2
at the same time
02
*After 24hrs on constant charge Hugo
2 will enter into Intelligent Desktop
Mode where the battery is neither
charged nor discharged. Hugo’s auto-
shutdown feature is now disabled
After a period of 15 minutes of
inactivity Hugo 2 will
automatically shutdown
6.35mm
1/4”
Headphone
output
Bluetooth 3.5mm
1/8”
Headphone
output
Right / Left
RCA analogue
3.5mm
Digi coax
24-BIT/
384kHz x2
***
Optical
24-BIT/
192kHz
Press & hold
to power on
** WARNING - Do not activate line level whilst operating headphones, you risk
damage to your equipment and your hearing.
Coax 1 configuration = Tip and sleeve, Coax 2 configuration = Ring and sleeve. The 3.5mm digital
coaxial jack input supports ‘dual data mode’, where 768kHz files can be input as two separate
384kHz data streams, should devices support this capability.
HD USB – 768kHz/Native DSD512
To suit your ambient lighting, Hugo 2 has two brightness
settings - High and Low. To cycle between them please
simultaneously press the FILTER and X-PHD buttons.
To activate 3v RMS line level mode
press X-PHD button during start-up
FILTER 01
FILTER 02
FILTER 03
FILTER 04
OFF
MIN
MED
MAX
FILTER INPUT CROSSFEED POWER
Viewing Glass
8hr charge
(1amp)
8hr playback
(Avg. time)
0% - 2% 2% - 20% 20% - 50% 50% - 80% 80% - 100%
SAMPLE FREQUENCIES IN kHz
44.1 48 88.2 96 176.4 192 352.8 384 705.6 768 DSD
Native DSD playback up to
DSD512 - Octa-DSD
Automatic sample
rate switching
44.1kHz to 768Khz
- 16bit to 32bit
Automatic sample
rate switching
Battery Indicator
MIN MAX
Line level =
4hr charge
(2amps)
Intelligent filtering
changes the
sonic presentation:
FILTER
01
256fs = Incisive Neutral
FILTER
02
256fs + HF
roll-off = Incisive Neutral
with high-frequency
roll-off
FILTER
03
16fs = Warm
FILTER
04
16fs+ HF roll-off = Warmer
with high-frequency
roll-off
HF filter is optimised
for DSD playback
HD USB
COAX 1
COAX 2
OPTICAL
BLUETOOTH
COAX DUAL
DATA MODE
(automatic - not user
selectable) ***
VOL
Min Max
**
01 03 04
How to charge and connect to power Connectivity Control options
Sample rate indicator - how to read sample rate
