Christie CCM-LX User manual

CCM-LX
USER MANUAL
020-000326-01
Downloaded from ProjectorsManual.com Manuals

Downloaded from ProjectorsManual.com Manuals

LINK ACT
CCM-LX
Network Capture 3
Network Viewer 3
Network Communication
User Manual
020-000326-01
Downloaded from ProjectorsManual.com Manuals

2CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Compliance
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular instal-
lation. If this equipment causes harmful interference to radio or television reception which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of
FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in
the instructions. If such changes or modifications should be made, you could be required
to stop operation of the equipment.
Model Numbers : 103-115108-02
Trade Name : Christie
Responsible party : CHRISTIE DIGITAL SYSTEMS, Inc.
Address : 10550 Camden Drive Cypress, CA 90630 U.S.A.
Downloaded from ProjectorsManual.com Manuals

3
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
CAUTION
CHRISTIE DIGITAL SYSTEMS, Inc. assumes no responsibility for the loss or damage of data
or damage of the computer caused by using this product.
CAUTION ON USE IN NETWORK
- When you receive an alert e-mail from the projector, you must check the projector
immediately. Fire or accident may result if the projector is used in an abnormal
condition.
- When you install the projector at remote location and use it through the network, you
must perform the safety inspections periodically. In this case you must pay attention to
the change of environment in which you installed the projector. It may cause fire or an
accident depending on the change of environment.
The CE Mark is a Directive conformity mark of the European Community (EC).
NOTES ON Lithium Battery (CALIFORNIA USA ONLY)
This product uses a Lithium Battery which contains Perchlorate Material - special han-
dling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate
Notas acerca de pilas de litio (SOLO PARA CALIFORNIA, EE.UU.)
Este producto usa una pila de litio que contiene el material perclorato – puede ser nece-
sario una manipulación especial.
Consulte la página www.dtsc.ca.gov/hazardouswaste/perchlorate
Compliance and Caution
Downloaded from ProjectorsManual.com Manuals

4CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Compliance ..........................................................................................................................................................................2
Federal Communications Commission Notice ....................................................................................2
Chapter 1 Preparation ................................................................................................7
Features...................................................................................................................................................................................8
Operating environment of CCM-LX....................................................................................................................11
Before use........................................................................................................................................................................... 12
Chapter 2 Installation............................................................................................... 15
Flow of installation........................................................................................................................................................ 16
[1] Name and function of each part................................................................................................................... 17
[2] Installation and network configuration.................................................................................................... 18
Mounting .................................................................................................................................................................. 18
Connection of LAN cable ............................................................................................................................... 19
Network configuration.....................................................................................................................................20
Network PIN code setting ..............................................................................................................................22
How to enter the numbers with the remote control 10-key buttons................................23
Notice about system construction...........................................................................................................24
[3] Installing the software.........................................................................................................................................25
Network Viewer & Capture 3 installation..............................................................................................25
File Converter 2 Installation...........................................................................................................................27
Chapter 3 Basic Setting and Operation............................................................. 29
Login the setting page of the projector.........................................................................................................30
1. Enter the IP address .......................................................................................................................................30
2. Select a display mode and login...........................................................................................................30
3. Display of main setting page................................................................................................................... 31
How to use the setting page .................................................................................................................................32
Initial setting.....................................................................................................................................................................34
Network PIN cord setting ...............................................................................................................................35
PJLink and password setting.........................................................................................................................35
Date and time setting .......................................................................................................................................36
Network configuration...............................................................................................................................................37
E-mail setting ...................................................................................................................................................................38
Examples: Type and contents of alert mail..........................................................................................40
SNMP setting....................................................................................................................................................................42
Chapter 4 Controlling the Projector ................................................................... 45
Power control and status check...........................................................................................................................46
Controls................................................................................................................................................................................48
Input.............................................................................................................................................................................48
System.........................................................................................................................................................................49
Image adjustment..............................................................................................................................................50
Sound .........................................................................................................................................................................51
Menu ...........................................................................................................................................................................51
PC adjustment.................................................................................................................................................................52
Setting up the projector ...........................................................................................................................................53
Save the controls and settings..............................................................................................................................56
Store/free the settings......................................................................................................................................56
Check the saved items......................................................................................................................................57
Load a control set ................................................................................................................................................57
Timer setting ....................................................................................................................................................................58
How to set the timer..........................................................................................................................................58
Check the timer events....................................................................................................................................59
Change the event mode.................................................................................................................................59
Projector information..................................................................................................................................................61
Multi-control.....................................................................................................................................................................63
Controlling and setting the multi-projectors.....................................................................................63
Contents
Downloaded from ProjectorsManual.com Manuals

5
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Contents
Start/stop the multi control...........................................................................................................................64
Register the projector .......................................................................................................................................65
Confirmation of registered projector......................................................................................................65
Change the mode of the registered projector .................................................................................66
Status ...........................................................................................................................................................................66
Check & Change page in the light mode.............................................................................................67
Controlling all together....................................................................................................................................67
Setting all together.............................................................................................................................................67
Viewer auto setting all together.................................................................................................................68
Chapter 5 Network Capture................................................................................... 69
About Network Capture function.......................................................................................................................70
Launching the Network Capture 3...........................................................................................................70
Commands on the task bar ...........................................................................................................................70
Parameter set up ..................................................................................................................................................71
Using the Real Time Capture..................................................................................................................................72
Registering the computers............................................................................................................................72
[1] Control by the computer..........................................................................................................................73
[2] Control by the web browser..................................................................................................................74
[3] Control by the projector...........................................................................................................................75
Advanced using example...............................................................................................................................76
Using the Network Communication.................................................................................................................77
Settings before using the Network Communication....................................................................78
Description of capture editing window................................................................................................79
How to use the Network Communication....................................................................................................81
Start the communication................................................................................................................................81
Join the communication (only for Sub PC)..........................................................................................81
Exit from the communication (only for Sub PC) ..............................................................................81
End the communication..................................................................................................................................81
Acquire and release of editing authority ..............................................................................................81
Edit capture image..............................................................................................................................................82
Network Communication operation and change of state .................................................................84
Executing the forcing mode ..................................................................................................................................85
Error information............................................................................................................................................................86
Chapter 6 Network Viewer..................................................................................... 87
Creating the available data [Network Viewer 3].........................................................................................88
[1] How to use the Network Viewer 3 (File Converter 1)..............................................................88
[2] How to use the Network Viewer 3 (File Converter 2).............................................................92
Creating a program file [Program Editor].......................................................................................................93
Procedure of making program....................................................................................................................93
Setting up the display order and time of the images...................................................................95
Using the Network Viewer function..................................................................................................................98
[1] Control by the web browser ..................................................................................................................98
[2] Control by the projector.........................................................................................................................102
Chapter 7 Appendix ..............................................................................................105
Examples of connection ........................................................................................................................................ 106
Use of telnet................................................................................................................................................................... 108
Web browser setting.................................................................................................................................................110
Examples: OS/Browsers ........................................................................................................................................... 111
Product specification................................................................................................................................................115
Port specification.........................................................................................................................................................116
Q&A ......................................................................................................................................................................................117
Downloaded from ProjectorsManual.com Manuals

6CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Downloaded from ProjectorsManual.com Manuals

ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
7
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
1
Chapter 1
Preparation
Describes features and operating environment of this product.
Downloaded from ProjectorsManual.com Manuals

8CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 1 Preparation
Real Time Capture function (p.72)
To display the screen image of
the computer by the projec-
tor through the network in real
time.
Features
Network Viewer function (p.88)
To acquire the JPEG image data
from the file servers placed in
the network and project them
by the projector.
PC4PC3 PC6
Capture
PC5
PC1 PC2
PC4PC3 PC6
PC5
PC1 PC2

JPEG
Prog.
JPEG
PJ2 PJ1
Network Communication function (p.77)
To communicate by sharing the
captured image of a computer
with multiple computers and
a projector. User can draw the
text and figure on the captured
image by using a drawing tool.
PC2
PC6
Capture
PC5
PC1
PJ1
Capture a screen
image of PC5 and
make marking with
a tool.
Downloaded from ProjectorsManual.com Manuals

9
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
E-Mail Alert function (p.38)
The projector (Network Unit)
sends messages to the regis-
tered e-mail addresses when
a lamp abnormality or power
failure occurs with the projec-
tor. This message describes
how to solve the cause of the
problems. You can take efficient
action for quick recovery.
PC4PC3 PC6
PC5
PC1 PC2
You’ve got
Mail.
PJ2 PJ1
Web Management function (p.46)
With this function, you can
monitor projector functions
such as power status, lamp
status, input mode, signal
condition, lamp-use time, etc.
through the network by using
the web browser installed on
your computer.
PC4PC3 PC6
PC5
PC1 PC2
Turn ON PJ2
PJ2 PJ1
Features
SNMP Agent function (p.42)
To send the information of
the projector to the SNMP
manager. Enables you to
manage the projector con-
dition with the supplied
SNMP manager software.
PJ1
PC6
PC4
PJ2 PJ3 PJ4
PC5
You received
a Trap.
SNMP Manager
Trap
Trap
Downloaded from ProjectorsManual.com Manuals

10 CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 1 Preparation
Multi-control function (p.63)
A single computer can con-
trol and set up the multiple
projectors at the same time.
PJ1
PC6
PC4PC5
Select Input2 for
PJ1 to PJ4.
PJ2 PJ3 PJ4
Automatic On/Off using Clock function (p.58)
Automatically turn on or off the
projectors at specified date/
day and time by using the clock
function.
Now it’s 11:30
I am ready to turn ON,
and select Input 3 (Video)
SNMP Manager function (refer to the separated booklet)
A function to manage the
condition of projectors in
the network by using the
SNMP protocol. The man-
aging computer needs to
provide an SNMP manag-
ing software. Refer to the
owner's manual of the "PJ
Network Manager" supplied
separately for further details.
PJ1
PC6
PC4
PJ2 PJ3 PJ4
PC5
You received
a Trap.
SNMP Manager
Trap
Trap
Downloaded from ProjectorsManual.com Manuals

11
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Operating environment of CCM-LX
To perform the managing and setting of the projector by using this product, the environ-
ment described below is required.
* The "Light Mode" and "Standard Mode" will be explained on item "Display Mode" (p.30-32)
Operating Environment
PDA restriction
The PDA can be used for the Light mode* only. The operating system of the PDA is
PocketPC2002 or higher. The version of the
Adobe Flash Player is 6,0,81,0 or higher.
Standard mode*
Operating System Windows 2000, Windows XP (32bit version), Windows Vista (32bit
version), Windows 7 (32bit version)
Computer environment
Recommended CPU Higher than Pentium III 900MHz
Memory
64MB (Minimum)/ 128MB or more (Recommended)
128MB or more for Windows XP
1GB or more for Windows Vista or Windows 7
Free disk space 100MB or more
Drive equipment CD-ROM drive
Display settings
Support one of following resolutions;
VGA (640 x 480), SVGA(800 x 600), XGA(1,024 x 768) Number of col-
ors: Either of 16 bit (65,536 color 24/32 bit (16.77 million colors))
Network card The computer must provide a 10Base-T or 100Base-TX network
card.
Web Browser
Internet Explorer version 6.0 , 7.0 or 8.0
Netscape Navigator version 7.1 or 9.0
Used to control and set up the projector. The layout of pages in the
browser may slightly differ from each type of application or operat-
ing system you use.
Plug-Ins Adobe Flash Player version 6,0,79,0(6.0r79) or later
Recommended Internet
Mailer
- Microsoft Outlook - Microsoft Outlook Express
- Netscape Mail
Required the internet e-mail application software to receive an
e-mail alert sent from this product. If you do not use the function
E-mail Alert, this application is not required.
FTP Service
- FTP server
The FTP service provided with the Windows is required when using
the Network Viewer function.
Downloaded from ProjectorsManual.com Manuals

12 CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 1 Preparation
Before use
Package contains
The package contains following items. Check each item as you unpack the package. If you
have any of the following items missing, contact the sales dealer.
LINK ACT
QNetwork unit 1 piece
QSoftware CD-ROM 1 piece
Network Viewer & Capture 3 software
PJ Network Manager software
QQuick Setup Guide 1 piece
English/Japanese
QDocument CD-ROM 1 piece
CCM-LX User's Manual
PJ Network Manager User's manual
Quick Setup
Guide
The limitation*1 of connection between this product and hub or computer
Use an appropriate cable when connecting the projector and a hub or computer. And,
please use a shielded LAN cable.
Connection Type of usable LAN cable Maximum length
Network Unit - Hub STP Straight Cable with category 5 *2100m
Network Unit - Computer STP Cross Cable with category 5*2100m
*1 There may be other limitations depending on your network environment or LAN specification.
Please consult your network administrator for further details.
*2 Category of LAN cable indicates the cable quality.
Downloaded from ProjectorsManual.com Manuals

13
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Before use
Notice
Expression/Abbreviation
The word "projector" found in this manual means "projector provided with Network unit"
unless otherwise noted.
The OS of the computer and the Web browser described in this manual is Windows XP
Professional and Internet Explorer 6.0. In case of another OS or Web browser, some instruc-
tion procedures may differ from the actual operation depending on your computer envi-
ronment.
Use of this manual
This manual does not provide the description of basic operation and functions for com-
puter, web browser, projector and network. For instructions about each piece of equip-
ment or application software, please refer to the respective booklet.
Trademarks
Ethernet is a registered trademark of Xerox Corporation. Microsoft, Windows, Windows
2000, Windows XP, Windows Vista, and Windows 7 are either registered trademarks
or trademarks of Microsoft Corporation in the United States and/or other countries.
PowerPoint is a registered trademark of Microsoft Corporation. Internet Explorer is
a registered trademark of Microsoft Corporation. Netscape Navigator and Netscape
Communicator are trademarks or registered trademarks of Netscape Communications
Corporation. JavaScript is a registered trademark of Sun Microsystems, Inc. PJLink is a reg-
istered trademark of JBMIA (Japan Business Machine and Information System Industries
Association).
Other product or brand names in this manual are registered trademarks or trademarks of
their respective owners.
* Unauthorized use of a part or whole of the contents in this manual is prohibited.
* The contents of this manual are subject to change without notice.
Downloaded from ProjectorsManual.com Manuals

14 CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 1 Preparation
Downloaded from ProjectorsManual.com Manuals

ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
15
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 2
Installation
2
Describes how to install the network unit and software, and config-
ure the network.
Downloaded from ProjectorsManual.com Manuals

16 CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 2 Installation
The following are instructions for attaching this product to the projector and connecting it
to the network. Please review the entire procedure to become familiar with it.
Function of the network unit (p.17)
1
Installation and network configuration (p.18-24)
2
Installation of the software (p.25-27)
3
Set up is complete
1. Mount this product onto the projector.
2. Connect the LAN cable and join it to the network.
3. Configure the network of the network unit.
4. Set the Network PIN code.
Explains how to install the software Network Viewer & Capture 3 into your com-
puter.
Flow of installation
The preparation is completed to control the projector connected to the network. At next
step, set up and control the projector via the network by using the web browser installed
on your computer. Please see chapter 3 "Basic setting and operation". (p.29)
Explains the name and functions of each part of the network unit.
Downloaded from ProjectorsManual.com Manuals

17
ENGLISH
CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Name and function of each part
[1] Name and function of each part
LINK ACT
POWER indicator
This lights up red when the network
function is set ON in the projector
menu.
LAN port
Connecting the LAN cable. (p.19)
Connector plug
Connecting to the terminal on the pro-
jector. (p.18)
Mounting screws
Mount by using a coin etc. (p.18)
LINK indicator
This lights up red when the network unit is
connected to the network correctly.
ACT indicator
This turns on and off with green when
sending or receiving of data
(Top View)
(Bottom View)
Downloaded from ProjectorsManual.com Manuals

18 CCM-LX User Manual
020-000326-01 Rev.1 (10-2010)
Chapter 2 Installation
1. Disconnect the AC plug from the projector.
2. Remove the connector cover from the projector.
3. Attach this product to the option connector and tighten two screws by using a coin
etc.
Caution
!
Mounting
[2] Installation and network configuration
AC cord must be disconnected when mounting or removing this product otherwise it may dam-
age the product.
Connect the AC cord after connecting the LAN cable and computer.
Keep the connector cover and the screws
importantly.
Connector cover
Screw
Downloaded from ProjectorsManual.com Manuals
