TotalVIEW™DLV1920‐DX
1080HDDLP™REARSCREENTILINGPROJECTOR(104‐017101‐01)


DisplayTechnologyandResolution
•3chipDLP®
•0.95”DarkChip3™,12º
•1080HD(1920x1080)resolution

IlluminationTechnology
•Single500WXenon

Brightness
•2800ANSIlumens@500W
•1960ANSIlumens@350W

BrightnessUniformity
•>90%,upto100%withuniformcontrol
feature

ContrastRatio
•Upto2000:1fullfield;450:1ANSI
minimum

ColorTemperatureRange
•3200Kto9600K

ExpectedLampLife(24/7operation)
•Upto4,000hrsstarting@350W
•Upto2,500hrs@500W

LensType
•1.15:1LowdistortionLens
•067:1LowdistortionLens

LensOffset
•Motorized‐Horizontal:upto50%,
Vertical:upto100%

ScreenSize/Range
•0.67:1lens:60”to175”diagonal
•1.15:1lens:60”to100”diagonal

PowerRequirements
•100VACto240VAC±10%@50/60Hz
•Powerconsumption:879W
•Thermaldissipation:3000BTU/hr
•Rating:10A@100V,5A@240V

Weight
•72lb(32.1kg)(excludingoptionallens)
•Shippingweight:115lb(52kg)

Horizontal/VerticalFrequency
•Horizontal‐15kHzto120kHz
•Vertical‐23.97Hzto150Hz

PixelClock
•210MHz

StandardInputs
•RGBHV/YPbPr;5BNC
•DVI‐I:digital/analogRGB/YPbPr(HDCP)
•Onecompositevideo,oneS‐Video
•2RS‐232portsand1RS‐422port
•On‐boardChristieNET™connectivity
(RJ45)
•IRremotecontrol

SourceCompatibility
•Christiedisplaywallcontrollers
•CompatibilitywithVGAthroughtoQXGA
•Separate,compositesyncandsync‐on‐
greencompatible



ProductS
p
ecificationsDocument
©2008ChristieDigitalSystems,Inc.Allrightsreserved.Productspecificationsaresubjecttochange
withoutnotice.Forthemostcurrentspecificationinformation,pleasevisitwww.christiedigital.com
•AllcurrentknownHDTVformats(1080i,
720p,576i/p,480i/p)
•Acceptscompositevideo,S‐Video(Y/C),
componentvideo(YUV)andHDTV(YPbPr)

AdvancedTilingFeatures
•ComprehensiveColorAdjustment(CCA™)
fortruecolormatching
•BrightnessUniformityControl‐provides
upto100%uniformitycapabilityfor
criticalapplications
•Lowdistortiontilinglens(soldseparately
on“DX”models)

ColorProcessing
•True10bitdigitalcolorprocessing
•13bitcolorcorrection

Control/Networking
•2RS‐232portsand1RS‐422port
•On‐boardChristieNET™connectivity
(RJ45)
•Built‐inblacklitkeypad(“DX”modelsonly)
•Intuitive,easytousegraphicaluser
interface
•FieldupgradeablesoftwareviaRS‐232
network
•IRremotecontrol
•GPIOport

OptionalAccessories
•DualSD/HD‐SDI,DVI
•WireremotecontrolandRS‐422TwoWay
Controller
•RemoteIRsensor
•Ethernet,RS‐232,RS‐422cables
•Highfrequencyremotecontrol
•SerialDigitalinputmodule
•Servicemanual
•KoRE™10‐bitlibrariancommunication
software

OperatingEnvironment
•Temp:5to35ºC(40to95ºF)
•Humidity:20‐80%non‐condensing
•Altitude:0‐3000m(0to10,000ft)
•Storage:‐20‐50ºC,20‐80%RH,NC

Reliability
•MTBF:>30,000hrs(formajormodules)
•ExpectedlifeofDMD:100,000hours
•Continuousdiagnosticmonitoringwith
notification

Serviceability
•Modulardesign
•MTTR:<15minutes
•Lampchange:<5minutes

RegulatoryApprovals
•IEC60950‐1:2001;UL60950‐11stEdition;
CAN/CSAC22.2No.60950‐1‐031stedition
•EMC‐emissions:FCCpart15and
EN55022(CISPR22)ClassA
•EMC‐immunity:EN55024
•CE,RoHS,WEEE•CCC,eK,PSE(pending)
•Thisproductconformstoallrelevant
Europeandirectives,safety,healthand
environmentalconcerns

Warranty
•2yearspartsandlabor(excludinglamp)
•Lamp‐prorated

NotesonSpecifications
•Contrastratiomayvarydependingon
brightnessmode(maximumspecifications
shown).



ProductS
p
ecificationsDocument
©2008ChristieDigitalSystems,Inc.Allrightsreserved.Productspecificationsaresubjecttochange
withoutnotice.Forthemostcurrentspecificationinformation,pleasevisitwww.christiedigital.com
•ForUHPlamps,expectedlamplifeis
basedonlampmanufacturer’srating.
Typicalexpectationisthatgreaterthan
50%oflampswillreachlampliferating
whenoperatedasspecified.
•Maynotbefunctionalonsingle‐chip
modelsoninitialunitsshipped,butwillbe
availableviafieldupgradethrough
softwarewhenavailable.Contactyour
Christierepresentativeformoredetails.
•Nominallensthrowratiosshown.Actual
throwdistancemaybewithin5%of
nominalvalue.ContactyourChristie
representativefordetails.
•Forbestcolormatchingbetweenadjacent
displays,itisrecommendedthatWhite
Boostbeat0%setting.

