CipherLab RS35 User manual

RS35 Mobile Computer
Android™ 10
Version 1.00

Copyright © 2020 CIPHERLAB CO., LTD.
All rights reserved
The software contains proprietary information of its owner; it is provided under a license
agreement containing restrictions on use and disclosure and is also protected by copyright
law. Reverse engineering of the software is prohibited.
Due to continued product development, this information may change without notice. The
information and intellectual property contained herein is confidential between the owner
and the client and remains the exclusive property of the owner. If having any problems
in the documentation, please report them to us in writing. The owner does not warrant
that this document is error-free.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording or otherwise
without the prior written permission of the owner.
For product consultancy and technical support, please contact the local sales representative.
Also, visit our website for more information.
All brand, logo, product and service, and trademark names are the property of their
registered owners.
Google, Android, Google Play and other marks are trademarks of Google LLC.
The editorial use of these names is for identification as well as to the benefit of the owners,
with no intention of infringement.
CIPHERLAB logo is a registered trademark of CIPHERLAB CO., LTD. All other brands,
products and services, and trademark names are the property of their registered owners.
The editorial use of these names is for identification as well as to the benefit of the owners,
with no intention of infringement.
CIPHERLAB CO., LTD.
Website: http://www.CipherLab.com

-1 -
Important Notices
IMPORTANT NOTICES
FOR USA
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Find the certificate information from:
Setup →About Phone →Regulatory information
Tested to Comply with FCC Standards
FOR HOME OR OFFICE USE

-2 -
RK25 Mobile Computer
FOR PRODUCT WITH LASER
This laser component emits FDA / IEC Class 2 laser light at the exit
port. Do NOT STARE INTO BEAM DIRECTLY.
Do not aim the beam at the eyes.
Any adjustments or performance excluding those specified herein may
result in hazardous laser light exposure.
ENVIRONMENT
Operate the mobile computer at ambient temperatures from -20 to 50 and with
humidity range from 10% to 90%.
Store the device at ambient temperatures from -30 to 70 and with humidity range
from 5% to 95%.
Charge the device at ambient temperatures from 0 to 40 .
This device is built with a dust-proof and splash-proof structure that conforms to
protection class IP65.
SPECIFIC ABSORPTION RATE (SAR) INFORMATION
The product complies with the FCC / Canada portable RF exposure limit set forth for
an uncontrolled environment and are safe for intended operation as described in this
manual. The further RF exposure reduction can be achieved if the products can be kept
as far as possible from the user body or set the device to lower output power if such
function is available.
For body-worn operating conditions please use belt-clips, holsters, and/or accessories
that have no metallic component in the assembly and must provide at least 10mm
separation between the device and the user's body.
FCC SAR Value (Standard limit is 1.6 W/Kg)
USA (1g): Max. 1.193 W/Kg
A minimum separation distance of 0.5 cm must be maintained between the user’s
body and the device, including the antenna during body-worn operation to comply with
the RF exposure requirements in Europe.
To compliance with RF Exposure requirements in Europe, third-party belt-clips, holsters
or similar accessories used by this device should not contain any metallic components.
The use of accessories that do not satisfy these requirements may not comply with RF
exposure requirements, and should be avoided.
CE SAR Value (Standard limit is 2 W/Kg)
EU (10g): Max. 1.440W/Kg

-3 -
Important Notices
SAFETY PRECAUTIONS
Warning statement:
A pleine puissance, l’écoute prolongée du baladeur peut
endommager l’oreille de l’utilisateur.
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE
OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
For people’s safety
Do not listen at high volume levels for long periods to prevent possible hearing damage.
Do not operate this device while walking, cycling or car driving.
For the equipment
Do not use any batteries or charging devices which are not originally sold or
manufactured by CIPHERLAB CO., LTD.
Do not replace the battery with an incorrect type, to avoid the risk of heat generation,
fire, or explosion.
Do not disassemble, incinerate or short circuit the battery.
Do not touch the contact pins of the battery pack.
Do not expose the mobile computer or battery to any flammable sources.
Do not expose the mobile computer to extreme temperatures or soak it in water.
Do not use any pointed or sharp objects against the screen surface.
Do not use the styluses which are not supplied or approved by CIPHERLAB CO., LTD.,
to prevent possible scratches to the touch screen.
Water residue on the touch screen may cause abnormal behaviors or the fall of its
sensitivity levels.
On the surface of the terminal and the barcode reading window, the fog or water drops
caused by low temperatures may influence barcode reading.
Do not use bleaches or cleaners to clean the device. Use a clean, wet cloth instead.

-4 -
RK25 Mobile Computer
BATTERY
The main battery may not be charged to full for shipment. Charge the main battery to
full before using the mobile computer for the first time.
Main battery: The main battery powers the mobile computer to work. It takes
approximately 4 hours to charge an empty main battery to full. For the first time
charging the main battery, please charge it for at least 8 to 12 hours. The charging LED
above the screen will light up in red while charging and will turn green when charging
is complete.
Backup battery: The backup battery is mounted on the main board. Its role is to
temporarily keep the mobile computer in suspension when the main battery is drained
out so data in DRAM will be retained. The backup battery can be charged by the main
battery or the power adapter, and takes approximately 4 hours to charge to full under
the condition that it is always be charged except of power off and no external power.
RTC battery: RTC battery is a 3V, 1mAh rechargeable SMT type Li-battery which takes
about 12 hours to be fully charged. RTC retention will be maintained for at least 72
hours when the main battery is removed.
The allowed battery charging ambient temperature is between 0 to 40 . It is
recommended to charge the battery at room temperature (18 to 25 ) for optimal
performance.
Please note that battery charging stops when ambient temperature drops below 0 or
exceeds 40 .
In order to prevent system from shutting down after the battery is drained out, keep a
fresh battery for replacement at all times, or connect the mobile computer to an external
power.
If there are drippings or dust on the device or battery pack, wipe them away with a soft
clean cloth before battery replacement.
Turn off the power before battery replacement.
If you want to put away the mobile computer for a period of time, remove the battery
pack from the mobile computer’s battery compartment. Store the mobile computer and
battery pack separately.
Recycle batteries in a proper way for the green-environment issue.

-5 -
Important Notices
SCANNER
Scan a 1D barcode
1) Open ReaderConfig and tap Scan Test on the menu bar.
2) Aim the scanning window at the barcode to read. Move the device, having the barcode
located in the center of the scanning area.
3) Press any of the two side triggers. The scanning light beams to read the printed
barcodes. The buzzer beeps after scanning. The scanning light goes off once the data
is decoded, or when the decode timeout period has passed.
Scan a 2D barcode
1) Open ReaderConfig and tap Scan Test on the menu bar.
2) Aim the scanning window at the barcode to read. Move the device, having the barcode
located in the center of the scanning area.
3) Press any of the two side triggers. The scanning light beams to read the printed
barcodes. The buzzer beeps after scanning. The scanning light goes off once the data
is decoded, or when the decode timeout period has passed.
CONNECTION
Via Bluetooth or WLAN
Connection may fail when the mobile computer is around other wireless machines or
power cables as the radio frequencies of those may cause interferences.
If communication fails, move the devices much closer to each other, and try to
communicate again
After turning on, Bluetooth power is sustained even when the mobile computer is
suspended. However, if the power mode is switched to Airplane Mode, Bluetooth power
will be turned off regardless of the settings.
To a Charging & Communication Cradle
Do not insert the mobile computer to a Charging & Communication Cradle if water or
drippings are staying on the device.
The LED indicator on a Charging & Communication Cradle shows the status of battery
charging only; the status of terminal charging is shown on the device itself.
Not Charging could be the result of battery damage, battery’s failure to touch the
connector or AC plug coming off.
Charging error could be due to high battery temperature.

-6 -
RK25 Mobile Computer
CARE & MAINTENANCE
This mobile computer is intended for industrial use. The mobile computer is rated IP65,
however, damage may be done to the mobile computer if it is exposed to extreme
temperatures or soaked in water.
When the body of the mobile computer gets dirty, use a clean, wet cloth to wipe off
dust and debris. DO NOT use bleaches or cleaners.
Use a clean, non-abrasive, lint-free cloth to wipe dust off the LCD touch screen. DO NOT
use any pointed or sharp objects against the surface. Always keep the LCD dry.
If you want to put away the mobile computer for a period of time, download the collected
data to a host computer, and then remove the battery pack from the mobile computer’s
battery compartment. Store the mobile computer and battery pack separately.
If you encounter malfunction on the mobile computer, write down the specific scenario
and consult your local sales representative.
RF Exposure Information (SAR)
This device meets the government’s requirements for exposure to radio waves. This
device is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the U.S.
Government.
The exposure standard employs a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted
using standard operating positions accepted by the FCC with the EUT transmitting at the
specified power level in different channels.
The FCC has granted an Equipment Authorization for this device with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information
on this device is on file with the FCC and can be found under the Display Grant section
of www.fcc.gov/eot/ea/fccid after searching on FCC ID: Q3N-RS35
Radio Frequency (RF) Exposure Information
The radiated output power of the Wireless Device is below the Innovation, Science and
Economic Development Canada (ISED) radio frequency exposure limits. The Wireless
Device should be used in such a manner such that the potential for human contact
during normal operation is minimized.
This device has been evaluated for and shown compliant with the ISED Specific
Absorption Rate (“SAR”) limits when operated in portable exposure conditions.
Informations concernant l'exposition aux fréquences radio (RF)
La puissance de sortie rayonnée du dispositif sans fil est inférieure aux limites
d'exposition aux radiofréquences d'Innovation, Sciences et Développement économique
Canada (ISED). Le dispositif sans fil doit être utilisé de manière à minimiser le potentiel
de contact humain pendant le fonctionnement normal.
Cet appareil a été évalué et montré conforme aux limites de DAS (Débit d'Absorption
Spécifique) de l'ISED lorsqu'il est utilisé dans des conditions d'exposition portables.

-7 -
Canada, Innovation, Science and Economic Development Canada (ISED) Notices
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to
the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Avis du Canada, Innovation, Sciences et Développement économique Canada (ISED)
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) L’appareil ne doit pas produire de brouillage;
(2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.

8
CONTENTS
IMPORTANT NOTICES ........................................................................................................... - 1 -
For USA .....................................................................................................................................- 1 -
For Product with Laser..............................................................................................................- 2 -
Environment..............................................................................................................................- 2 -
Specific Absorption Rate (SAR) information .............................................................................- 2 -
Safety Precautions....................................................................................................................- 3 -
Battery..................................................................................................................................- 4 -
Scanner................................................................................................................................- 5 -
Connection...........................................................................................................................- 5 -
Care & Maintenance............................................................................................................- 6 -
INTRODUCTION..................................................................................................................... 11
Features..................................................................................................................................... 12
Inside the Package .................................................................................................................... 12
Accessories ................................................................................................................................ 12
Related Documentation............................................................................................................. 13
QUICK START ........................................................................................................................ 14
1.1. Overview............................................................................................................ 15
1.1.1. Install/ Remove Battery .................................................................................... 17
1.1.2. Installing SIM Card, SAM Card and Memory Card............................................. 20
1.1.3. Power On/Off Mobile Computer ........................................................................ 23
1.2. Charging & Communication .............................................................................. 24
1.2.1. Charge Mobile Computer .................................................................................. 24
1.2.2. Wired Data Transmission .................................................................................. 30
1.2.3. Using Wireless Networks................................................................................... 31
USING RS35 MOBILE COMPUTER .......................................................................................... 32
2.1. Battery............................................................................................................... 33
2.1.1. Battery Status Indicators................................................................................... 34
2.1.2. Monitor Battery Level ........................................................................................ 36
2.1.3. Replace Main Battery........................................................................................ 42
2.1.4. Power Management .......................................................................................... 44
2.2. Memory ............................................................................................................. 46
2.2.1. Check Memory Usage........................................................................................ 47
2.2.2. Manage Storage Space ..................................................................................... 49

9
CONTENTS
2.3. Touch Screen .................................................................................................... 58
2.3.1. Screen Brightness ............................................................................................. 58
2.3.2. Screen rotation.................................................................................................. 59
2.3.3. Screen Timeout Settings ................................................................................... 63
2.3.4. Text Size & Display Size..................................................................................... 64
2.4. Notifications ...................................................................................................... 65
2.4.1. Status LED......................................................................................................... 65
2.4.2. Audio ................................................................................................................. 65
2.4.3. Sounds and Vibration........................................................................................ 66
2.5. Date and Time................................................................................................... 71
2.6. Language & Keyboard Input.............................................................................. 73
2.6.1. Change Display Language................................................................................. 73
2.6.2. On-screen Keyboard.......................................................................................... 75
2.7. Sound and Volume............................................................................................ 77
2.8. Data Capture ..................................................................................................... 78
2.8.1. Barcode Reader ................................................................................................ 78
2.8.2. Digital Camera................................................................................................... 78
BASIC OPERATION................................................................................................................. 79
3.1. Home Screen..................................................................................................... 80
3.1.1. Application & Widget on Home Screen ............................................................. 81
3.1.2. Folder on Home Screen..................................................................................... 83
3.2. Navigation Method ............................................................................................ 84
3.2.1. Change the Navigation Method......................................................................... 84
3.2.2. Recently Used Applications............................................................................... 87
3.3. Status Bar.......................................................................................................... 88
3.3.1. Icons on Status Bar........................................................................................... 88
3.3.2. Open Quick Setting Menu ................................................................................. 90
3.3.3. Open Notifications Drawer ................................................................................ 93
3.4. Suspend & Lock ................................................................................................ 96
3.4.1. Suspend Device................................................................................................. 96
3.4.2. Lock Device ....................................................................................................... 97
3.5. OS Update ......................................................................................................... 99
3.5.1. Network Update................................................................................................. 99
3.5.2. SD Card Update...............................................................................................101
3.6. Back up Your Data...........................................................................................102
3.7. Reset to Factory Default..................................................................................104
3.7.1. Erase All Data (Factory Reset).........................................................................104
3.7.2. Welcome Wizard..............................................................................................105

10
RK25 Mobile Computer
WIRELESS RADIOS.............................................................................................................. 108
4.1. Use Wireless Local Area Network (Wi-Fi).........................................................109
4.1.1. Connect to Wi-Fi Network................................................................................109
4.1.2. Manually Add Wi-Fi Network............................................................................111
4.1.3. Advanced Wi-Fi Settings..................................................................................113
4.1.4. Modify Wi-Fi Network.......................................................................................115
4.1.5. Disconnect Wi-Fi Network ...............................................................................117
4.2. Use Bluetooth..................................................................................................118
4.2.1. Bluetooth Profiles............................................................................................118
4.2.2. Turn On Bluetooth ...........................................................................................119
4.2.3. Change Bluetooth Name .................................................................................121
4.2.4. Pair Bluetooth Devices....................................................................................122
4.2.5. Unpair Bluetooth Device..................................................................................123
4.3. Use Near Field Communications.....................................................................124
SPECIFICATIONS ................................................................................................................. 126
Platform, Processor & Memory ................................................................................................126
Communication & Data Capture..............................................................................................126
Electrical Characteristics .........................................................................................................127
Physical Characteristics...........................................................................................................128
Environmental Characteristics.................................................................................................129
Programming Support..............................................................................................................130
APPENDIX........................................................................................................................... 131
Open Source License ...............................................................................................................131

11
Introduction
INTRODUCTION
The RS35 mobile computer, powered by Android 10, is light-weight, easy to use, providing
powerful and handy tools for the purpose of delivering flexibility in customization.
Specifically designed to work as an industrial PDA, it provides rich options of data
collection, voice and data communication, long-lasting working hours, and so on. Its
large color transmissive display guarantees ease in reading in all lighting conditions.
Integrated with Bluetooth®Class II, V4.1 BLE, V2.1 with Enhanced Data Rate (EDR),
IEEE 802.11 a/b/g/n/ac networking technologies, the mobile computer also includes a
GSM/UMTS/WCDMA/HSPA/HSPA+/LTE/VOLTE module to gain greater speeds and optimal
mobility. In particular, an integrated GPRS/EGPRS receiver is made available for use with
third-party location-based applications.
This manual serves to guide you through how to install, configure, and operate the mobile
computer. The Care & Maintenance section is specifically crucial for those who are in charge
of taking care of the mobile computer.
We recommend you to keep one copy of the manual at hand for quick reference or
maintenance purposes. To avoid any improper disposal or operation, please read the
manual thoroughly before use.

12
RK25 Mobile Computer
FEATURES
Built tough to survive drop test and sealed against moisture/dust to industrial standard
IP65.
Android 10 operating system with a powerful Qualcomm SDM450 Octa-core 1.8GHz CPU
32GB eMMC flash memory to store OS and software programs
3GB LPDDR3 RAM to store and run programs, as well as store program data
One expansion slot for microSDHC card up to 32GB and microSDXC card up to 64GB-
2TB.
Built-in autofocus 13 megapixels rear camera with LED flash.
Left and right side triggers for ambidextrous scanning
Total wireless solution —connectivity includes Bluetooth®Class II, V4.1 BLE, V2.1
with Enhanced Data Rate (EDR), IEEE 802.11 a/b/g/n/ac networking technologies,
GPRS/EGPRS/GSM/UMTS/WCDMA/HSPA/HSPA+/LTE/VOLTE, and near field
communication (NFC)
A 5.45-inch, transmissive IPS LCD, Corning®Gorilla®Glass 3 display with 720x1400
pixels to deliver excellent visibility in all lighting conditions
Configurable feedback indicators including speaker and vibrator
Built-in scan engine setting tool Reader Configuration which serves out-of-the-box
keyboard wedge functionality
INSIDE THE PACKAGE
The following items are included in the kit package. Save the box and packaging material
for future use in case you need to store or ship the mobile computer.
RS35 Mobile Computer
Snap-on Cable (optional)
AC Power Adaptor (optional)
Quick Start Guide
ACCESSORIES
1-slot Charging + Communication Cradle
Pistol Grip
Protective Rubber Boot
Hand Strap
Pistol Grip
UHF RFID Reader

13
Introduction
RELATED DOCUMENTATION
Log in to GoBetween to access related documentation about the RS35 mobile computer
from the CipherLab Central Service (CCS) platform. Download the GoBetween desktop
or mobile device application, or launch the GoBetween Lite web application from the
following site: http://ccs.cipherlab.com/.

14
RK25 Mobile Computer
Chapter 1
QUICK START
This chapter helps you get ready for starting using the mobile computer.
IN THIS CHAPTER
1.1 Overview ................................................................... 15
1.2 Charging & Communication .......................................... 24

15
Quick Start
1.1. OVERVIEW

16
RK25 Mobile Computer
No.
Description
No.
Description
1
Power Button
2
Status LED
3
Touchscreen
4
Microphone
5
USB-C Port with Cover
6
Side-Trigger (Left)
7
Volume Down Buttons
8
Volume Up Buttons
9
Scan Window
10
Function Key
11
Side-Trigger (Right)
12
Battery Cover Latch
13
Battery with Cover
14
Hand Strap Cover
15
Camera
16
NFC Detection Area Speaker
17
Hand Strap Hole
18
Charging & Communication Pins
19
Receiver
