Circutor AR5 User manual

SUPPLY NETWORK ANALYZER
AR5 and AR5-L
INSTRUCTION MANUAL
( M98151101-03-05A )
(c) CIRCUTOR S.A.

2
CONTENTS page
1.- BASIC INSTRUCTIONS........................................................................ 4
1.1.- Introduction: check the contents of your package................................. 4
1.2.- Safety conditions................................................................................... 4
1.3.- Connection instructions......................................................................... 4
1.4.- Operation instructions........................................................................... 5
2.- ANALYZER MAIN FEATURES.............................................................. 6
2.1.- Basic features....................................................................................... 6
2.2.- Other characteristics............................................................................. 6
3.- KEYBOARD FUNCTIONS..................................................................... 9
4.- Installation AND START-UP.................................................................. 9
4.1.- Steps necessary for the START-UP ..................................................... 9
4.2.- Connection diagram............................................................................ 10
4.3.- Starting the analyzer up...................................................................... 15
4.4.- Loading a new program...................................................................... 17
4.5.- Turn the analyzer off........................................................................... 18
4.6.- Back-light............................................................................................ 18
4.7.- Choice of the working program........................................................... 18
4.8.- Recharging the analyzer battery......................................................... 19
4.9.- Energy saving..................................................................................... 19
5.- DATA VISUALIZATION ON DISPLAY................................................. 20
5.1.- Base screen........................................................................................ 20
5.1.1.- Screen of instantaneous values.................................................... 20
5.1.2.- Screen of maximum and minimum values ................................... 21
5.2.- Other visualization screens................................................................. 22
5.2.1.- Visualization of 3 parameters in a big size mode.......................... 22
5.2.2.- Bar graphs .................................................................................... 23
5.2.3.- Oscilloscope.................................................................................. 24
5.2.3.1.- Three phases: Voltage - Current............................................. 24
5.2.3.2.- Zoom....................................................................................... 25
5.2.3.3.- Harmonic factorization. ........................................................... 26
5.2.4.- Setup visualization........................................................................ 28
5.3.- Warning messages............................................................................. 28

3
6.- PROGRAMMING THE ANALYZER..................................................... 29
6.1.- SETUP menu...................................................................................... 30
6.1.1.- MEASURE.................................................................................... 31
6.1.1.1.- WIRING: Circuit type............................................................... 31
6.1.1.2.- PT/CT : Transformation ratios................................................. 31
6.1.2.- RECORD menu ............................................................................ 31
6.1.2.1.- PERIOD: recording period ...................................................... 32
6.1.2.2.- TRIGGER: Trigger conditions................................................. 33
6.1.2.3.- NAME: recording file name..................................................... 36
6.1.2.4.- PARAM: Choosing the parameters to be saved...................... 37
6.1.3.- COMM: Communication parameters............................................. 38
6.1.4.- CLOCK: Internal clock .................................................................. 38
6.1.5.- PASSWORD: Safety setting. ........................................................ 39
6.1.6.- RECALL: Read configuration........................................................ 40
6.2.- DISPLAY menu................................................................................... 41
6.2.1.- BAR.GR........................................................................................ 41
6.2.2.- EXPAND....................................................................................... 41
6.2.3.- CONTRAST: Screen contrast....................................................... 41
6.2.4.- ANGLE.......................................................................................... 42
6.3.- RUN: data recording process status................................................... 42
6.4.- FILES Menu........................................................................................ 42
6.4.1.- DIR: Directory ............................................................................... 42
6.4.2.- DELETE: Deleting a file ................................................................ 42
6.4.3.- FORMAT: Formatting the analyzer internal memory..................... 42
6.5.- CLEAR menu: Deleting data............................................................... 43
6.6.- Menu OFF: Enable / Disable Password.............................................. 44
6.7.- Menu LANGUAGE.............................................................................. 44
7.- ANALYZER COMMUNICATIONS ....................................................... 44
8.- TECHNICAL SPECIFICATIONS.......................................................... 45
9.- SAFETY WARNINGS.......................................................................... 47
10.- MAINTENANCE................................................................................... 48
11.- CHANGING THE BATTERY................................................................ 48
12.- TECHNICAL SERVICE........................................................................ 49

4
BASIC INSTRUCTIONS
This manual is aimed to familiarize de user with the operation of the portable power analyzers model
AR5-L and AR5 in order to get the best from its features.
These analyzers have been built with components incorporating the most advanced technology in
microelectronics and offer benchtop features over the market in measurement and recording of electrical
magnitudes in industrial power supply networks.
You are kindly requested to carefully read this manual before connecting and powering the
analyzer in order to avoid irreversible damage, which might be caused by an improper connection.
Introduction: check the contents of your package
After receiving the analyzer, please check the following points:
a) The analyzer model corresponds with your order specifications.
b) After unpacking, check that the instrument has not been damaged in transit.
c) The standard set includes the following items:
Kit AR5-L or AR5
1 Power supplier set 100 V a.c. – 240 V a.c. / 12 V d.c.
1 Connection cord between the power supplier set and the main.
1 Connection cable between the analyzer and the power supplier set.
1 RS-232 communication cable.
4 Voltage leads.
4 Alligator clamps (3 in AR5 model).
1 Instruction Manual.
CD with the PC program
Safety conditions
The manual you hold in your hands contains information and warnings about the
analyzer that the user should respect in order to guarantee a proper operation of all the
instrument functions and keep its safety conditions.
Connection instructions
Before powering and connecting the analyzer check the following points:
a) Supply voltage: Through and external power supplier set.
Input mains 100 V a.c. – 240 V a.c. / output to AR5/AR5-L 12V d.c.
b) Frequency : 45...65 Hz.
c) Maximum voltage at the voltage measuring circuit:
;500 V a.c. Phase-to-neutral (CAT III)

5
d) Current measuring range: according to the Current clamp used
Current clamps Measuring range
CP-2000-200 10 to 2000 A a.c. (switch at 2000)
1 to 200 A a.c. (switch at 200)
CPR-1000 5 to 1000 A a.c.
CPR-500 2,5 to 500 A a.c.
CP-100 (M1-U) 0, 5 to 100 A a.c.
CP-5 25 mA to 5 A a.c.
Flexible clamp Measuring range
C-FLEX 200-2000-20000 100 to 20000 A a.c (scale 20000
A)
10 to 2000 A a.c. (scale 2000 A)
1 to 200 A a.c. (scale 200 A)
NOTE: It is advisable to measure near of full-scale value to get better accuracy.
Operation instructions
The analyzer is a programmable instrument so offering diverse operation modes, which can be selected
from the available programming menus (0 PROGRAMMING THE ANALYZER).
Please read carefully the paragraphs involving (0 Installation AND START-UP 0 PROGRAMMING
THE ANALYZER) in order to select the most suitable operation mode for your requirements.
If the instrument is not used according to manufacturer’s
specifications, the protection of the instrument can be damaged.

6
ANALYZER MAIN FEATURES
Basic features
The AR5 series analyzers are programmable instruments that measure, calculate and store to memory
the main parameters of three phase electrical supply networks.
IL1 I N IL2IL3
Clamp inputs (.. 2 V a.c.).
Power Supply: 12 V c.c. / Serial input
a.c. Voltage inputs
V
L1
V
L2
V
L3
N
A
UX
*
*
* INonly in AR5-L models
Setup: Analyzer’s setting is completed through a system of spreadable menus that provide a friendly-use and
intuitive configuration process.
Data visualization: By means of a liquid crystal graphical display, 160 x 160 pixels and with backlight ability,
the user can view instantaneous, maximum and minimum values of each parameter at each phase.
Internal battery: permits the user to accomplish with analysis works without the need of an external auxiliary
power supply. The analyzer is equipped with an intelligent battery charging system, which expands the battery
life span. For recharge the battery is necessary to connect the power supplier.
Installation: Analyzer is suitable for analysis works over any type of electric networks (single-phase, bi-phase,
3-wire and 4-wire).
Measuring: Measurement of average values of main electrical parameters, as well as, recording of maximum
and minimum values. To execute these measurements, the analyzer is equipped with three a.c. voltage inputs and
four a.c. current inputs (through current clamps ../ 2 V a.c.).
Data collection: The analyzer has a 1 Mb on-board memory to save into all the parameters measured or
calculated by the analyzer, in order to be further retrieved from a PC.
PC software: together with the analyzer, it is also factory supplied a friendly-use, powerful software that
permits data downloading from the internal memory to a PC and a further complex analysis of recorded data.
Other characteristics
-Small size, low weight, portable instrument.
-True R.M.S. measuring system.
-Instantaneous, maximum and minimum values of each discrete electric parameter.
-Electrical energy meters incorporated
-Harmonic measurement
-Neutral current measurement (only in AR5-L model)
-RS-232 communication to PC
-Ability of setting a recording threshold, so that data is only recorded in memory when measured
values are not within the defined threshold (see Section 0TRIGGER: Trigger conditions).
-Automatic data collection in memory at regular user-definable periods.
Depending on the type of circuit under analysis, following enumerated parameters are measured and can be
saved in memory:
NOTE: It’s not allow to save cos
data in memory. Only can be read on display.

7
4-wire three-phase system:
Parameter Symbol L1 L2 L3 Three-phase value
Phase-to-Neutral voltage Vxxx
Current Axxx x
Neutral current
(only in AR5-L model)
INx
Frequency Hz x
Active power kW xxx x
Reactive power L kvarL xxx x
Reactive power C kvarC xxx x
Apparent power kVA x
Power factor PF xxx x
Active energy kW h xxx x
Reactive-energy (inductive) kvaLh xxx x
Reactive-energy (capacitive) kvaCh xxx x
Voltage harmonics x x x
Current harmonics x x x
Current Neutral harmonics
(only in AR5-L model)
x

8
3-wire three-phase system:
Parameter Symbol L1-L2 L2-L3 L3-L1 Three-phase value
Phase-to-Phase voltage Vxxx
Current Axx x x
Frequency Hz x
Active power kW xxx x
Reactive power L kvarL xxx x
Reactive power C kvarC xxx x
Apparent power x
Power factor PF xxx x
Active energy kW h xxx x
Reactive-energy (inductive) kvahL xxx x
Reactive-energy (capacitive) kvahC xx x x
Voltage harmonics x x x
Current harmonics x x x
Single-phase system: Parameter Symbol L1
Voltage Vx
Current Ax
Frequency Hz x
Active power kW x
Reactive power L kvarL x
Reactive power C kvarL /(-C) x
Apparent power x
Power factor PF x
Active energy kW h x
Reactive-energy (inductive) kvahL x
Reactive-energy (capacitive) kvahC x
Voltage harmonics x
Current harmonics x
Bi-phase system:
Parameter Symbol L1-N L2-N Bi-phase value
L1-L2
Voltage Vxx x
Current Axx x
Neutral current* INx
Frequency Hz x
Active power kW xx x
Reactive power L kvarL xx x
Reactive power C kvarC xx x
Apparent power x
Power factor PF xx x
Active energy kW h x
Reactive-energy (inductive) kvahL xx x
Reactive-energy (capacitive) kvahC xx x
Voltage harmonics x x
Current harmonics x x
Neutral current harmonics x
*only in AR5-L model

9
1.- KEYBOARD FUNCTIONS
The analyzer has a 9 buttons keyboard to perform configuration and control actions of all the instrument
options.
-[ON] to turn the analyzer on.
-[OFF] (Quick press) to turn on/off the display back-light.
-[OFF] (5 seconds press) to turn analyzer off.
-[6], [5], [4]& [3]. To select among several options.
-[SET] to access setting options.
-[ENTER] to validate a setting option or to program some parameters of the visualization screens.
-[ESC] to select different visualization screens or to exit the setting actions.
However, most of keys are double functional: The own instrument understands the meaning of the order at each
case.
Installation AND START-UP
The manual you hold in your hands contains information and warnings that the user should
respect in order to guarantee a proper operation of all the instrument functions and keep its safety
conditions.
If the instrument is not used according to manufacturer’s specifications, the protection of
the instrument can be damaged. Note that with the instrument powered on, cover opening or
elements removal actions may allow accessing dangerous parts. Therefore, before any adjustment, replacement,
maintenance or repairing operation is carried out, the instrument must be disconnected from any power supply
source.
When any protection failure is suspected to exist, the instrument must be
immediately put out of service. Contact then with a qualified service representative.
Steps necessary for the START-UP
For the Star-up of the equipment and to let it ready to begin to register is necessary to make the
following steps.
1) Plug the battery, see point 0CHANGING THE BATTERY
2) Format the memory, see 0FORMAT: Formatting the analyzer internal memory
3) Set the analyzer in hour, see point 0CLOCK: Internal clock
4) Charge the battery by a period of minimum 14 hours. .

10
Connection diagram
A.- CONNECTION DIAGRAM FOR THREE-PHASE - 4-WIRE – SYSTEM
This connection is only available for AR5-L model
( SET ---> SETUP ---> MEASURE ---> WIRING ---> 3Φ4 WIRES)
L2
L1
L3
N
IL1 I N IL2IL3
V
L1
V
L2
V
L3
N
A
UX

11
B.- CONNECTION DIAGRAM FOR THREE-PHASE - 3-WIRE - SYSTEM.
( SET ---> SETUP ---> MEASURE ---> WIRING ---> 3Φ3 WIRES )
L2
L1
L3
IL1 I N IL2IL3
V
L1
V
L2
V
L3
N
A
UX

12
C.- CONNECTION DIAGRAM FOR THREE-PHASE - 3-WIRE (ARON)
( SET ---> SETUP ---> MEASURE ---> WIRING ---> 3 PT – 2 CT
L2
L1
L3
IL1 I N IL2IL3
V
L1
V
L2
V
L3
N
A
UX

13
D.- CONNECTION DIAGRAM FOR SINGLE-PHASE - SYSTEM
( SET ---> SETUP ---> MEASURE ---> WIRING ---> 1Φ)
L1
N
IL1 I N IL2IL3
V
L1
V
L2
V
L3
N
A
UX

14
E.- CONNECTION DIAGRAM FOR BI-PHASE - SYSTEM
This connection is only available for AR5-L model
( SET ---> SETUP ---> MEASURE ---> WIRING ---> 1ΦSplit )
L2
L1
N
IL1 I N IL2IL3
V
L1
V
L2
V
L3
N
A
UX

15
Starting the analyzer up
Before connecting the instrument to the mains, please consider following points:
5) Supply voltage: 100 V a.c. – 240 V a.c. , 50... 60 Hz.
The instrument must be energized by a supply circuit with protection earth terminal.
6) Maximum input voltage at the voltage measuring circuit:
;500 V a.c. phase-neutral (CAT III)
Use always the voltage leads factory-shipped with the instrument.
7) Burden: 15 VA.
8) Operation conditions:
-Operation temperature: 0 ºC to 40 ºC.
-Operation humidity: 80% for temperatures up to 31ºC decreasing linearly to 50% relative
humidity at 40ºC.
9) Safety : Designed to meet protection category III 600V as per EN 61010.
10) Current measuring range: according to the current clamp used
Current clamps Measuring range
CP-2000-200 clamp 10 to 2000 A a.c. (scale 2000 A)
1 to 200 A a.c. (scale 200 A)
CPR-1000 clamp 5 to 1000 A a.c.
CPR-500 clamp 2,5 to 500 A a.c.
CP-100 (M1-U) clamp 0´5 to 100 A a.c.
CP-5 clamp 25 mA to 5 A a.c.
Flexible clamp Measuring range
C-FLEX 200-2000-20000 100 to 20000 A a.c. (scale 20000 A)
10 to 2000 A a.c. (scale 2000 A)
1 to 200 A a.c. (scale 200 A)
NOTE: It is always advisable to take measurements at the high range of the scale to obtain a better accuracy.
To start measurement works with the analyzer:
11) Connect to the main with the factory-shipped cables. Also connect the protection earth terminal to avoid
possible disturbances over the analyzer.
12) Connect the voltage leads at each phase of the monitored system, as well as the neutral when it exists.
13) Connect the Current clamps at each phase conductor. Each current phase must coincide with its voltage
phase.
14) Respect the connection modes shown at each diagram to correctly achieve powers, PF and energies
readouts.

16
To turn the instrument on:
15) Press the switch <ON> at the analyzer frontal cover. The analyzer introduction screen appears. The user
can now select the operation mode program for the analyzer
16) After some seconds, a screen allowing the choice of the analyzer program to be used is shown up.
17) One the desired program has been selected, analyzer will check the type of ammeter clamps connected to
the analyzer. This process is only performed when analyzer is turn on, and in case that the connected
clamps does not matches with the programmed ones, then the analyzer will automatically give the option
to change the ammeter clamp setting:
-Press <ENTER> to validate the suggested clamp setting. The new transformation ratio
will be set at the ratio detected in the clamp L1.
-Press <ESC> to exit the auto-checking process with no change in the analyzer setup.
18) After some seconds the principal electrical parameters of the network are displayed.
NOTE : If nothing is shown on display, a discharged battery or any problem with the display contrast might
exist.
Initial considerations after the analyzer start-up:
-Format the memory if necessary (see section 0FILES Menu).
-Clear maximum & minimum values as well as energy counters if necessary (see section 0 CLEAR
menu: Deleting data).
-Open a file with the desired name (see section 0 NAME: recording file name). All data will be
automatically saved in this file until a new one is opened. The analyzer internal memory can contain
several files (different analysis).
Warning :
Take into account that when the memory is formatted all previously stored
data is lost. When opening a new file (a different name that the previous one) the
internal memory is not deleted.
When starting new measurements at any installation the meter programming must be checked and modified
if necessary (following steps attached at Section 0 PROGRAMMING THE ANALYZER) Otherwise, the
analyzer will work according the last used program (this is saved in memory even after powering the meter off).
Points to be mainly checked would be:
-Ratio of Current clamps (see section 0)
-Voltage transformer ratio (see section 0)
-Recording period (see section 0)

17
Loading a new program
The analyzer has an internal memory to save diverse operation mode
programs to be used by the user.
Before starting this action, check that analyzer is supplied through the power
supplier set.
To load any program, follow these instructions precisely:
Turn the meter off.
It is necessary to load a coprocessor that comes in a cartridge to part, and
that must settle only in the position of the coprocessor (the last position of
the list)
Connect the cartridge into the appropriate input placed in the power
supplier set.
Turn the meter on.
Select with the keys [5]& [6]that you want to perform a program loading
action (LOAD PROGRAM). Press [ENTER] or wait for a while to confirm
this operation.
Select the position to save the program into.
The analyzer will perform a test to check that the cartridge has been
properly connected.
If an inserted cartridge is detected, then the program will be loaded.
Once the loading is completed, reset the meter.
If no cartridge was found or a loading mistake occurred, reset the meter
and redo the above steps.
A cartridge will be only valid for the analyzer, which the
program was for the first time loaded into.
Note on the cartridge the serial number of its related
analyzer.

18
Turn the analyzer off
To turn the analyzer off proceed as follows:
If no password is set (Default option):
-Press the key [OFF] during 5 s
If a password is set:
-Press the key [OFF] during 5 s
-You will see in display: PASSWORD
-Enter the set password or, if this has not been previously modified, the default password
[3] [SET] [5] [SET].
-Press again the key [OFF]. (In case of a correct password, the analyzer will turn off).
Back-light
To turn the display backlight on/off just make a quick press on the key [OFF].
Choice of the working program
The analyzer can hold in memory different operation mode programs. The choice of the program to be
used is done when starting the meter up.
Turn the analyzer on.
A list of available programs will be shown on display.
Use keys [5]& [6]for the choice of the desired program.
Press [ENTER] or wait for a while to confirm this operation.
CHECK THE SETUP !!!!
All the programs have an independent disposition, therefore, the disposition
will be due to always verify, to assure an appropriate operation.
For instance, if the setup is modified at the “ANALYZER” program, these
modification will not be valid for the “HARMONIC” program, and so for any program.

19
Recharging the analyzer battery
The analyzer is equipped with an intelligent energy charging system. This
means that the instrument continuously checks in an automatic way the state of the
battery, thus the charging process stops when the battery is at its maximum charge
level. The span life of the battery is so increased.
To enable the battery charging proceed as follows:
Connect the power supplier set to the main.
Connect the analyzer to the power supplier set.
Turn the analyzer on by pressing button [ON].
Provided the analyzer is connected to the main through the power supplier set,
the battery is self-recharging.
If the battery is exhausted, the charging process should last at least 3 hours
with no interruption; although a charging period of 16 hours is advisable in order to
completely charge the battery.
The analyzer shows on screen a battery charge indicator:
NOTE: The battery charge is only used while the ANALYZER is turn on.
Energy saving
The ANALYZER has an energy saving system. So, if no key is pressed for at
least 5 minutes, the display is automatically off. The analyzer continues the recording
data process but nothing appears on display.
The display will automatically be active when any key is pressed (excepts for the key [ON] that causes
no effect).

20
DATA VISUALIZATION ON DISPLAY
All measured instantaneous values, as well as maximum and minimum, can
be read on a 160 x 160 pixel, liquid, crystal display (back-light ability).
An indication of the type of data being displayed is shown at the upper right
corner.
Base screen
Screen of instantaneous values
When powering the analyzer on, the display will show:
HARMONICS
INST L1 L2 L3 III
Vp-n
A
kW
kvarL
kvarC
P.F.
Hz
kVA
AN
220 221 223 221
kWh 0.000
kvarLh 0.000
kvarCh 0.000
25 / 10 / 04 17 : 31 : 29
Instantaneous value screen
Voltage: Readout of the instantaneous RMS value measured at each phase (L1, L2 & L3) and the average value
of the instantaneous values of the three phases (III).
Current : Readout of the instantaneous RMS value measured at each phase (L1, L2 & L3) and the average value
of the instantaneous values of the three phases (III).
Active power: The active power is calculated from instantaneous voltage and current data. The readout gives the
instantaneous values of the active power of each phase and also the three phase total instantaneous active power,
which is the addition of each phase value.
Inductive reactive power: The inductive reactive power is calculated from instantaneous voltage and current
data. The readout gives the instantaneous values of the inductive reactive power of each phase and also the three
phase total instantaneous inductive reactive power, which is the addition of each phase value.
Capacitive reactive power: The capacitive reactive power is calculated from instantaneous voltage and current
data. The readout gives the instantaneous values of the capacitive reactive power of each phase and also the three
phase total instantaneous capacitive reactive power, which is the addition of each phase value.
Power factor : Readout of the power factor of each phase and the three phase average value.
Frequency : Readout of the instantaneous value of the frequency (Hz).
Neutral Current : Readout the value measured of the neutral current. (only in AR5-L model)
Apparent power : Readout of the three phase total instantaneous apparent, which is the addition of each phase
value.
Energies: Readout of active, inductive reactive, and capacitive energy counters from the moment that the energy
counters were reset to zero (see section 0)
Time and Date. (time/date): Readout of present time and date. For any modification, see section 0 CLOCK:
Internal clock.
