3G-SDI/HD-SDI
FULL HD CMOS High Sensitivity Color Camera
VCC-HD1000A
Product Specifications
& Operational Manual
CIS Corporation

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
Table of Contents
1. Precautions.........................................................................................................................................................1
1.1. Handling Precautions.................................................................................................................................1
1.2. Restrictions on Applications........................................................................................................................1
1.3. Disclaimers (Exception Clause)...................................................................................................................1
2. Product Outline...................................................................................................................................................2
2.1. Features...................................................................................................................................................2
2.2. Accessories...............................................................................................................................................2
3. Specifications......................................................................................................................................................3
3.1. General Specifications ...............................................................................................................................3
3.2. Part Names and Functions .........................................................................................................................5
4. Camera Functions................................................................................................................................................7
4.1. GenLock...................................................................................................................................................7
4.2. LTC (Longitudinal Time Code)....................................................................................................................7
4.3. Defective Pixel Correction ..........................................................................................................................8
4.3.1 Defective Pixel Data Type .....................................................................................................................8
4.3.2 Notes for Defective Pixel Correction.......................................................................................................8
5. Serial Communication..........................................................................................................................................9
5.1. Serial Communication Settings ...................................................................................................................9
5.1.1 Changing Speed of Serial Communication ............................................................................................10
5.2. Command List.........................................................................................................................................11
5.3. Quick Reference Table.............................................................................................................................20
5.3.1 Quick Reference Table for Gain Settings...............................................................................................20
5.3.2 Quick Reference Table for Shutter Settings...........................................................................................21
6. How to Operate Camera with OSD Function.........................................................................................................22
6.1. How to Control OSD Menu by Remote Controller........................................................................................22
6.2. Indication of OSD Menu...........................................................................................................................22
6.3. OSD Menu Hierarchical Structure..............................................................................................................22
7. Dimensions.......................................................................................................................................................24
8. Case for Indemnity (Limited Warranty)................................................................................................................25
8.1. Product Warranty....................................................................................................................................25
8.2. CMOS Defective Pixels.............................................................................................................................25
8.3. Product Support......................................................................................................................................25

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
1
1. Precautions
1.1. Handling Precautions
□Do not use or store camera in dusty or humid places.
□Do not apply excessive force or static electricity that could damage camera. Handle camera with care.
□Do not shoot direct images that are extremely bright (e.g., light source, sun, etc.). When extremely strong light
source is shot, smear or blooming may occur. When camera is not in use, please put the lens cap on.
□Follow the instructions in Chapter 3.2. “ Part Names and Functions”for connecting camera. Improper connection
may cause damages not only to the camera but also to the connected devices.
□Confirm mutual ground potential carefully and connect camera to monitors or computers. AC leak from the
connected devices may cause damages or destroy the camera.
□Do not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply voltage
may cause damages or malfunction of the camera.
□Since VCC-HD1000A is a compact and dense camera, camera temperature rises. Please take appropriate heat
dissipation measures, such as installing the camera to a metal plate etc.
□Our warranty does not apply to damages or defects caused by irregular and/or abnormal use of the product.
Our warranty does not apply to damages or malfunctions caused by neglecting instructions and precautions explained in
this manual.
1.2. Restrictions on Applications
□The camera must not be used for any nuclear equipment or aerospace equipment with which mechanical failure
or malfunction could result in serious bodily injury or loss of human life.
□The camera must not be used under conditions or environments other than those specified in this manual.
1.3. Disclaimers (Exception Clause)
CIS should not be liable for any damages or losses if;
□damages or losses are caused by earthquake, lightning strike, fire, flood, or other acts of God.
□damages or losses are caused by deliberate or accidental misuse by user, or failure to observe information and
instructions explained in this manual.
□damages or losses are caused by repair or modification conducted by user or any unauthorized party.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
2
2. Product Outline
VCC-HD1000A is a Full HD color camera with 0.0005 lx super sensitivity. Using a 35mm full size CMOS
image sensor, the maximum frame rate achieves 60fps. 3G-SDI interface and features CIS proprietary ISP,
“ClairvuTM” image processing engine for superb imaging quality and high speed processing. Complies with
BT.2020 (Wide color gamut) and BT2100 (Hybrid Log-Gamma). Suitable for wide variety of applications
such as ITS, security, medical imaging systems, and life science systems.
2.1. Features
□Features CIS proprietary ISP, state-of-the-art “ClairvuTM” for superb imaging quality.
□Infrared-level of high sensitivity (0.0005 lx, F1.2)
□GenLock function (Black burst or 3-values SYNC signals)
□Supports RS-232C control and RS-422 control.
□LTC (Longitudinal Time code)
□Supports OSD (On Screen Display) function with an optional remote controller, RU-100.
2.2. Accessories
□Standard accessory
Lens cap
□Optional accessories
RS-232C remote controller: RU-100
□Free software
※CIS control software is available for evaluation purpose only.
CIS should be held harmless for any damage arising from the use of this control software.
The purpose of this control software is restricted to evaluation and testing of this product only, and is not
intended for commercial use by customer.
CIS will not customize the program nor provide the source code.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
3
3. Specifications
3.1. General Specifications
Electrical Specifications
sensor
Sensor type
35mm full size color CMOS sensor
Effective pixels
2160(H) × 1280(V)
Unit cell size
19µm(H) × 19µm(V)
Resolution 1080p, 1080i:
720p:
1920(H) × 1080(V)
1280(H) × 720(V)
Aspect ratio
16 : 9
Video output format 1920 x 1080p @60fps (Level A)
1920 x 1080p @60fps (Level B)
1920 x 1080p @59.94fps (Level A)
1920 x 1080p @59.94fps (Level B)
1920 x 1080p @50fps (Level A)
1920 x 1080p @50fps (Level B)
1920 x 1080i @60fps
1920 x 1080i @59.94fps
1920 x 1080i @50fps
1920 x 1080p @30fps
1920 x 1080p @29.97fps
1920 x 1080p @25fps
1920 x 1080p @24fps
1920 x 1080p @23.98fps
1280 x 720p @60fps
1280 x 720p @59.94fps
1280 x 720p @50fps
3G-SDI
3G-SDI
3G-SDI
3G-SDI
3G-SDI
3G-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
HD-SDI
Sync. system
Internal sync. / External sync.
Video output standard
3G-SDI/HD-SDI: Y/Pb/Pr(4:2:2 10bit) BNC 75Ω termination
Sensitivity
F13 2000 lx
Minimum illumination F1.2 0.0005 lx
Conditions: VIDEO 50%, AGC +78dB, theoretical value when electric shutter setting
is 1/30s.
Gain variable range AGC (Max. gain: 0dB ~ +78dB)
MANUAL: 0dB ~ +78dB
Shutter speed MANUAL: 1/11200s ~ 1s
AUTO: 1/11200s ~ 1s
White balance MANUAL, AUTO, Preset
MANUAL: Red Gain, Blue Gain, One Push
AUTO: Standard/Outdoor/Fluorescent
Preset: Custom(Color temperature settings)/Tungsten(3200K)/Daylight(5500K)/
Cloudy(6500K)/Shade(8000K)
Auto exposure detection
Average/Center-Weight/Spot(per 1/256)/Backlight Compensation
Flicker cancellation
ON, OFF(typ.)
Edge enhancement
OFF, 1~7(typ.2)
Color correction
Auto, Standard, Fluorescent Light, Tungsten Lamp
Chroma adjustment
0%(B/W) ~ 100%(typ.) ~ 200%
Color saturation suppression
OFF, 1~7(typ.5)
Noise reduction
OFF, 1~6
Gamma correction
ITU-R BT.709, BT.2100(HLG)

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
4
Color gamut
Complies with ITU-R BT.709 and BT.2020
Master pedestal
-100 ~ 0 ~ +100
Pedestal (R,G,B)
RGB independent, -100 ~ 0(typ.) ~ +100
Color balance
RGB independent, 0 ~ 100(typ.) ~ 200
Defective pixel (white points)
correction
Corrected upon shipment.
LTC OFF, ON
Accepts external SMPTE Time code in the LTC IN terminal.
(Supports resetting internal time code.)
Camera preset settings
1, 2, 3, and 4 (Four kinds of preset to store.)
Remote communications Supports RS-232C signals via φ3.5 (4 poles), and RS-
422 signals via 12pins
connector to control camera settings.
Supports camera settings on OSD (On Screen Display) with
the optional remote
controller, RU-100, and camera settings from PC with control software.
Power requirements
DC+11 ~ +17V
Power consumption (typ.)
12.6W with DC+12V IN
Mechanical Specifications
Dimensions H: 75mm W: 75mm D: 85mm excluding projection.
Please refer to Section 7. Dimensions for details.
Weight
Approx. 650g
Lens mount EF mount
Please refer to Section 7. Dimensions for details.
Environmental Specifications
Safety/Quality standards
UL: Conform to UL Standard including materials.
FCC: CFR 47 part15 subpart B Class A Digital Device
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
CE: EMC: 2014/30/EU
Emission: EN61000-6-4:2007+A1:2011
Immunity: EN61000-6-2:2005
RoHS: 2011/65/EU +(EU)2015/863
EN50581 (RoHS2)
Durability Vibration
Acceleration:
98m/s
2
(10G)
Frequency:
20 ~ 200Hz
Direction:
X, Y, and Z 3 directions
Testing time:
120min each
Shock No malfunction with 980m/s2 (100G) for ±X, ±Y, and ±Z, in 6 directions (without
packaging).
Operational temperature -5 ~ +45°C
Humidity: 20 ~ 80%RH with no condensation.
Storage temperature -25 ~ +60°C
Humidity: 20 ~ 80%RH with no condensation.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
5
[3G-SDI output Level A and Level B]
The difference between Level A and Level B is a way of mapping Y signal and Cb/Cr signal onto 3G-SDI standard signal.
The difference does not affect the resolution of the video signal.
Some 3G-SDI receivers correspond to either Level A or B, whereas other receivers correspond to both Levels, so please
set the camera mode to match your 3G-SDI receiver.
3.2. Part Names and Functions
①EF mount
There is no electric contact. Please use a lens that you can operate manually.
②4pin XLR connector (For power input)
Supply power via XLR cable.
Please use XLR4-11C (female plug) or equivalent for cable side.
③BNC connector (For video signal output)
With BNC cable, connect to a 3G-SDI input monitor or HD-SDI input monitor.
Use high-frequency BNC cable that comply with 3G-SDI or HD-SDI.
1
2
④BNC connector (For GENLOCK signal input)
Input analog external sync signals (black burst or 3-values SYNC) via BNC cable.
1
2
Pin No. Signals
1 GND
2 N.C.
3 N.C.
4 EXT DC +12V
Pin No. Signals
1 3G-SDI/HD-SDI output
2 GND
Pin No. Signals
1 Analog external sync. signal input
2 GND
①
②
③ ④
⑤ ⑥
⑦
⑦

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
6
⑤12pins circular connector (For RS-422 communication)
Please use HR10-10P-12S (73) or equivalent for cable side.
⑥φ3.5 (4 poles) connector (For RS-232C communication)
Do not connect any audio equipment such as earphones to avoid failure and malfunction.
1
2
3
4
Connection of φ3.5 (4 poles) connector (For RS-232C communication)
N.C.
RXD
T XD
GND
1 2 3 4
1
2
3
4
5
6
7
8
9
9pin D-Sub(female)
RXD
T XD
GND
1
2
3
4
N.C.
1
2
3 4
PC
⑦Screw holes for camera installation (Six positions in total)
Front and rear: UNC1/4 Depth 5.5
Center: UNC3/8 Depth 5.5
Please refer to Section 7. Dimensions for details on the screw hole positions.
Please note that screws longer than 5.5mm may damage the internal PCB.
Pin No. Signals
1 GND
2 EXT_422_RX-
3 EXT_422_RX+
4 EXT_422_TX-
5 EXT_422_TX+
6 N.C.
7 LTC_IN
8 N.C.
9 Test terminal (Do not connect.)
10 Test terminal (Do not connect.)
11 Test terminal (Do not connect.)
12 GND
Pin No. Signals
1 Power(+5V) *Optional
2 TXD(Camera)
3 RXD(Camera)
4 GND

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
7
4. Camera Functions
4.1. GenLock
GenLock function is available by inputting analog external sync signals (black burst or 3-values SYNC) into the BNC
terminal for GenLock. Corresponding external sync signals vary depending on camera output format. Please refer to the
chart below for details.
EXT SYNC
IN
CAMERA FORMAT
1080p60A
1080i60
720p60
1080p30
1080p59.9A
NTSC
1080i59.9
720p59.9
1080p29.9
1080p50A
PAL
1080i50
720p50
1080p25
1080p60B
1080i60
720p60
1080p30
1080p59.9B
NTSC
1080i59.9
720p59.9
1080p29.9
1080p50B
PAL
1080i50
720p50
1080p25
1080i60
1080i60
720p60
1080p30
1080i59.94
NTSC
1080i59.9
720p59.9
1080p29.9
1080i50
PAL
1080i50
720p50
1080p25
1080p30
1080i60
720p60
1080p30
1080p29.9
NTSC
1080i59.9
720p59.9
1080p29.9
1080p25
PAL
1080i50
720p50
1080p25
1080p24
1080p24
1080p23
1080p23.9
720p60
1080i60
720p60
1080p30
720p59.9
NTSC
1080i59.9
720p59.9
1080p29.9
720p50
PAL
1080i50
720p50
1080p25
[Note]
Input Black Burst signals for NTSC/PAL signal. Input 3-values SYNC signals for other than NTSC/PAL signal.
Terminate EXT SYNC IN with 75Ω. (It becomes high impedance when turning off camera power).
When an external signal specified above is input, the camera will automatically be in external sync. mode.
When there is no external signal input, the camera will operate in internal sync. mode.
Disturbance images occur immediately after inputting external signals. However, this is normal.
Disturbance images may occur or there will be no image when inputting signals other than those specified
in the above chart to the EXT SYNC IN terminal.
4.2. LTC (Longitudinal Time Code)
□Supports time code insertion to 3G/HD SDI signals.
□Input LTC signals (time code) to the LTC IN terminal of the 12pins connector to insert external time code. When
there is no signal input to the LTC IN terminal, user can insert internal time code. Internal time code starts
with 00:00:00.00 when power is ON, and when signals are input to the LTC IN terminal, time code switches to
external time code. Under this condition, if no signal is input to the LTC IN terminal, internal time code starts.
Signal format: SMPTE Time code Signal level: 0.5~2 [Vp-p]

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
8
4.3. Defective Pixel Correction
In addition to the correction of defective pixel data registered upon shipment, we provide a method to update the
defective pixel data. The maximum number to register is 128 points. Please refer to Section 5.2. Command List for
details.
4.3.1 Defective Pixel Data Type
There are two types of defective pixel data.
Defective data registered at factory
Data registered upon shipment from our factory. These data cannot be over-written.
Defective data registered by user
Data registered by user.
4.3.2 Notes for Defective Pixel Correction
To save the data registered or deleted with defective pixel correction command (SU 200~203), execute SAVE
command (SU 705).
Init command (SU 700) does not restore defective pixel correction data. Use SU 203 to delete all data.
Defective pixel correction data is not subject to Camera Setting Store/Load command (SU 100/101).
Factory data and user-register data cannot be the same. Therefore, if user detects the same defective points,
this function ignores those points.
If user specifies the same coordinates as factory setting data, error will occur.
Specify coordinates with standard 1920×1080 regardless of video format settings.
Please note that the detected results may not always be the same due to temperature, noise, and other
conditions.
Neglecting these instructions may cause not only incorrect pixel defect correction, but also failure of acquiring
proper images.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
9
5. Serial Communication
5.1. Serial Communication Settings
(1) Please refer to the chart below for serial communication settings.
I/F
RS-232C or RS-422
Baud rate
9600bps (factory setting), 38400bps, 115200bps
Data
8bit
Stop bit
1bit
Parity
None
XON/XOFF
Not controlled
RS-232C and RS-422 are mutually exclusive.
(2) Control code
・Text-based communication executes camera control. Only ASCII 0x20~0x7E, 0x0A (LF=¥n), and 0x0D
(CR=¥r) must be used. Please do not use other than these codes.
・By sending command, parameter, and CR(0x0D) from host to camera, you can change camera settings and
acquire camera-setting parameters. Either CR or LF can be a linefeed code.
・There are two types of commands. One is SU command to send settings and instructions to the camera (“S”
for “Set”), and the other is GU command (“G” for “Get”) to obtain information from the camera.
Command
Parameter 1
Parameter 2
Function
GU Address Normally None
(There are exceptions in some cases)
To obtain camera setting information.
SU
Address
Data (There may be more than one)
To change camera settings.
(3) How to input a command
・“>” must be output from the camera as a prompt.
・Commands are not case-sensitive.
・Separate between a command and a parameter by single space (0x20).
・From the head of the input character to the linefeed code (CR) is defined as a single serial command.
・Parameters start with 0x are regarded as hexadecimal, parameters start with 0b are regarded as binary, and
others are regarded as decimal.
・Commands analyze parameters from the head to identifiable letters.
・Please refer to Section 5.2 “Command List” for details on address and data.
・Do not input values and letters other than those explained in the above and those mentioned in Section 5.2
“Command List”.
・Camera receives the returned command from Host and echo the command back. At this time, camera
converts the linefeed code (CR) to CR LF and echo the code back.
(4) Setting examples
[Example of GU command]
To get information of address 10
[Send] GU[sp]10[¥r]
[Returned value] GU[sp]10[¥r][¥n] [Echo back]
[Returned value] 50[¥r] [¥n] [Acquired data + Linefeed]
[Returned value] [¥r] [¥n] [Linefeed]
[Returned value] >[sp] [Prompt (> and space)]
[¥r]=CR(0x0D)
[¥n]=LF(0x0A)
[sp]=Space(0x20)

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
10
[Example of SU command]
To set 30 to address 10
[Send] SU[sp]10[sp]30[¥r]
[Returned value] SU[sp]10[sp]30[¥r][¥n] [Echo back]
[Returned value] [¥r] [¥n] [Linefeed]
[Returned value] >[sp] [Prompt (> and space)]
5.1.1 Changing Speed of Serial Communication
Baud rate command (SU 725) changes transfer rate of serial communication out of 9600bps, 38400bps, and
115200bps.
The changes made are reflected after re-booting camera, not immediately after executing the command.
Execute SAVE command (SU 705) to save the setting values.
Baud rate command is not subject to Init command (SU 700) so that executing Init command does not restore
settings.
Baud rate command is not subject to Camera Setting Store/Load command (SU 100/101).
Only when baud rate setting is 9600bps, user can use the optional remote controller RU-100.
Transfer rate of serial communication for RS-232C and RS-422 must be the same.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
11
5.2. Command List
Video Format
Function
Address
Setting value
Initial value
Description
Video Format 1
0: 1080p 60fps (Level A)
1: 1080p 59.94fps (Level A)
2: 1080p 50fps (Level A)
3: 1080p 60fps (Level B)
4: 1080p 59.94fps (Level B)
5: 1080p 50fps (Level B)
6: 1080i 60fps
7: 1080i 59.94fps
8: 1080i 50fps
9: 1080p 30fps
10: 1080p 29.97fps
11: 1080p 25fps
12: 1080p 24fps
13: 1080p 23.98fps
14: 720p 60fps
15: 720p 59.94fps
16: 720p 50fps
4
This is to set video output format.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
12
AE Related
Function
Address
Setting value
Initial value
Description
Gain Mode 2 0: Manual
1: Auto
1 This is to set gain control mode.
Gain Value 3 Maginification×0x10000
(0x10000~0x20000000) 0x10000 (65536)
This is to set gain value when gain mode is
Manual. (1*)
1.0 magnification(0[dB]): 0x00010000
※Please refer to Section 5.3.1 Quick
Reference Table.
Gain Max. Value 4 Magnification×0x10000
(0x10000~0x20000000) 0x20000000 This is to set the maximum gain value when
gain mode is Auto. (1*)
1.0 magnification(0[dB]): 0x00010000
Shutter Mode 5 0: Manual
1: Auto
1 This is to set shutter control mode.
Shutter Value 6 Exposure time [sec]×0x100000
(0x5E~0x100000)
0x4444
(17476)
1/60s
This is to set shutter value when shutter mode
is Manual. With longer shutter value than
frame rate, mode becomes slow shutter
operation. (1*)
※Please refer to Section 5.3.2 Quick
Reference Table.
Shutter Limit 7
The 1st param: Max. value
Exposure time
[sec]×0x100000
(0x5E~0x100000)
0x4444
(17476)
1/60s
This is to set shutter limit when shutter mode
is Auto. With longer shutter value than
frame rate, mode becomes slow shutter
operation. (1*)
Ex.) To set Max=1/60s, Min=1/8000s.
SU 7 0x4444 0x83
※Max < Min is invalid.
※Please refer to Section 5.3.2 Quick
Reference Table.
The 2nd param: Min. value
Exposure time
[sec]×0x100000
(0x5E~0x100000)
0x5E
(94)
1/11200s
Metering Mode 8
0: Average
1: Center-weighted
2: Spot
3: Backlight compensation
1 This is to set metering mode.
Spot Block 9
The 1st param:
X value: 0~15
7 This is to set X, Y, W, and H value for spot
metering.
X: Far left of metering field Block, X
coordinate
Y: Top of metering field Block, Y coordinate
W: Width of metering field (number of block)
H: Height of metering field (number of block)
Ex.) SU 9 7 7 2 2
The 2nd param:
Y value: 0~15
7
The 3rd param:
W value: 1~16
2
The 4th param:
H value: 1~16
2
AE Speed
10
0~15
10
This is to set AE convergence speed.
Exposure
Compensation
Value
11 0(-12dB)~12(0dB)~24
(+12dB)/per 1dB 12 This is to set exposure compensation value.
Flicker Cancel 12 0: Off
1: On 0 This is to set ON/OFF of flicker cancel.
Valid only when video format is 60fps,
59.94fps, 30fps, and 29.97fps.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
13
Gain Value,
Plus Minus 13 -1: decrease 1dB 1 : increase 1dB None
This is to change gain value by ±1dB from the
current setting. Valid when gain mode is
Manual.
(Dedicated to SU.)
Shutter Speed,
Plus Minus 14 -1: decrease 1step (1/4EV) 1 : increase 1step (1/4EV) None
This is to change shutter speed by ±1 step
(1/4EV) from the current value. When shutter
speed decreases by 1step, shutter value
becomes bigger. (*1)
Valid when shutter mode is Manual.
(Dedicated to SU)
Current Gain 55 None None This is to acquire the current gain.
(Dedicated to GU.) (*1)
Current Shutter 56 None None This is to acquire the current shutter value.
(Dedicated to GU.) (*1)
(*1) Due to physical limitation of the sensor and circuit, there are some cases that user cannot control values and limits of gain
and shutter as designated by commands. User can check the actual values with CurrentGain and Current Shutter commands.
AE may become unstable with high gain settings (0 x4000000 and over). If you wish to use camera with slow shutter
operation, set gain to 0x4000000 and under.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
14
WB Related
Function
Address
Setting value
Initial value
Description
WB Mode 20 0: Manual 1: Auto
2: Preset
1 This is to set white balance mode (WB).
WB Manual
Memory
21 0~4 0 This is to choose the memory to store set
values when WB Mode is Manual. (*2)
Manual Red Gain 22 100~1600(%) 185 This is to set Red gain when WB mode is
Manual.
Manual Blue Gain 23 100~1600(%) 163 This is to set Blue gain when WB mode is
Manual.
One Push Trigger 24 1: WxH 2: W/2 x H/2
3: W/4 x H/4 None
This is to execute One Push WB when WB
mode is
Manual. (*3) Choose a detection range
with setting values. (Dedicated to SU)
WB Auto Func 25 0: Standard 1: Outdoor
2: Fluorescent 0 This is to choose the condition when WB
Mode is Auto.
WB Preset Func 26
0: Custom
1: Tungsten (3200K)
2: Daylight (5500K)
3: Cloudy (6500K)
4: Shade (8000K)
2 This is to choose the environmental lighting condition when WB Mode is
Preset.
WB Preset Temp 27 2500~15000(K) 5500 This is to set color temperature when WB
Preset Func is Custom.
WB LB Shift 28 -10~10 0 This is to set the shifting amount of WB
gain toward black.
WB CC Shift 29 -10~10 0 This is to set the shifting amount of WB
gain toward green magenta.
Current Red Gain 58 None None This is to acquire the current Red Gain.
(Dedicated to GU)
Current Blue Gain 59 None None This is to acquire the current Blue Gain.
(Dedicated to GU)
(*2) Memory stores up to five types of settings (0 ~ 4).
(*3) Do not shield light to execute this command.
If execution of One Push WB is not properly processed, camera will return Runtime Error.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
15
Image Quality Related
Function
Address
Setting value
Initial value
Description
Detail 30 0: Off
1: (Low)~7(High)
2 This is to set the strength of edge
enhancement.
Gamma 35
0: BT.709 -2
1: BT.709 -1
2: BT.709
3: BT.709 +1
4: BT.709 +2
5: HLG75
2
This is to set gamma type and contrast.
0~4 are the curves comply with BT.709.
Contrast changes in the range of -2 ~ +2.
5 is for HLG75 that means 75% output
level is regarded as 100% input level.
Knee 36
0: Off
1: 100%
2: 95%
3: 90%
4: 85%
5: 80%
6: 75%
4
This is to set knee point.
Valid except when Gamma is BT.709 and
D-range is Low.
Knee slope varies according to the
selected maximum D-Range.
Master Pedestal
37
-100~+100
0
This is to set Master pedestal.
Red Pedestal
38
-100~+100
0
This is to set Red pedestal.
Green Pedestal 39 -100~+100 0 This is to set Green pedestal.
Blue Pedestal 40 -100~+100 0 This is to set Blue pedestal.
Red Balance
41
0~200
100
This is to set Red balance.
Green Balance
42
0~200
100
This is to set Green balance.
Blue Balance 43 0~200 100 This is to set Blue balance.
D-Range 44
0: Low
Equivalent to 120% for BT.709
Invalid for HLG (Handled as
Normal)
1: Normal
Equivalent to 200% for BT.709
Equivalent to 600% for HLG
2: High
Equivalent to 400% for BT.709
Equivalent to 1200% for HLG
3: Very High
Equivalent to 600% for BT.709
Invalid for HLG (Handled as
High)
1
This is to set Dynamic range.
Normal or High are selectable with HLG.
Low is regarded as Normal, and Very High
is regarded as High.
When Low, both D range and sensitivity
decrease, but noise level becomes the
lowest.
The minimum gain value will be limited to
0x20000 with High, and it will be limited to
0x30000 with Very High. (Even if a lower
value is set, gain value becomes 0x20000
or 0x30000.)
※ The D-range definition of BT.709 and
HLG are different, ref. below.
[BT.709]
100% output level (without Knee) is
regarded as 100% input level.
[HLG]
50% output level is regarded as 100%
input level.
Color Saturation 45 0~200 100 This is to set color saturation.

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
16
Noise Reduction 50 0: Off
1: (Low)~6(High)
3 This is to set the level of noise reduction.
(*4)
Color Correction 52
0: Auto
1: Standard
2: Fluorescent light
3: Tungsten lamp
0 This is to set color correction.
Color
Suppression
53 0: Off
1: (Low)~7(High)
5 This is to set color suppression.
Color Space 54
0: BT.709
0 This is to set color gamut.
1: BT.2020
(*4) When intensity increase, residual images may become evident.
OSD Related
Function
Address
Setting value
Initial value
Description
OSD Up button 90 0: One push
1: Continuous push
None
Commands to operate OSD.
Send commands every 60msec for
continuous push.
(Dedicated to SU).
OSD Down button 91 0: One push
1: Continuous push None
OSD Right button 92 0: One push
1: Continuous push
None
OSD Left button 93 0: One push
1: Continuous push
None
OSD Center button 94 0: One push
1: Continuous push
None
Text Color 95
0: Black
1: Blue
2: Red
3: Magenta
4: Green
5: Cyan
6: Yellow
7: White
7 This is to set the text color of OSD menu.
Highlight Color 96
0: Black
1: Blue
2: Red
3: Magenta
4: Green
5: Cyan
6: Yellow
7: White
5
This is to set the selected letter’s font color
of OSD menu.
If user specifies the same color as the text
color, error will occur because the selected
letters cannot be recognized.
OSD Off 99 1 (Fixed) None This is to close OSD menu.
(Dedicated to SU)

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
17
Others
Function
Address
Setting value
Initial value
Description
Camera Setting
Store 100 0~3
0
User can store four kinds of camera
settings. Execute SAVE (SU 705 1) to
save the registered values into the
non-volatile memory. The registered data
and address to store (the set value of this
address) are not subject to Init command
(SU 700 0).
Camera Setting
Load 101 0~3
This is to read out and reflect the
registered values set by Camera Setting
Store to camera. Selection of address to
store and address to load are common so
that this command keeps the last set value
with Store or Load.
(GU 100 and GU 101 always return the
same value).
LTC Mode 103 0: Off
1: On
0 This is to set OFF/ON of LTC signals
insertion.
LTC Reset 104 1: Reset None This is to reset the timer for internal
self-run of LTC. (Dedicated to SU)
GenLock V Offset 106 -1024~1023 0 Adjustment of V phase when mode is external sync.
Supports adjustment per 1H.
GenLock H Offset 107 -2047~2047 0
Adjustment of H phase when mode is
external sync.
Supports adjustment per approx. 6.7ns.
※There may be ±40ns differences
between the set value and the actual
value because of power restoration or
changes of format.
Test Pattern 120 0: Off
1: Cross Line
0 This is to set test pattern indication.
Cross Line Position 121
The 1st Param:
X coordinate 0~1919
960 This is to set the address of the crossing
point.
The 2nd Param:
Y coordinate 0~1079
540
Init 700 0 (Fixed) None
This is to restore camera settings to
factory settings. Camera store-data,
address to store, defective pixel correction
data, and baud rate are not subject to this
command. (Dedicated to SU)
Save 705 1 (Fixed) None
This is to save camera settings. After
storing the current camera settings by
Store (Equivalent to SU100), this
command saves the stored data, the
address to store, defective pixel correction
data, and baud rate. (Dedicated to SU)

VCC-HD1000A Rev.905-0220-00
©2022 CIS Corporation. All rights reserved.
18
Version
Information
721 1: Micro-computer version
2: FPGA version
None This is to acquire version information.
(Dedicated to GU)
Baud Rate 725 9600, 38400, 115200
(bps) 9600
This is to set the speed of serial
communication.
Please refer to Section 5.1.1 “Changing
Speed of Serial Communication”for
details.
SDI Compatibility
Mode 750 0: Off 1: On 0
With factory setting (Off), if user selects
HLG75 or BT.2020, changes made will be
reflected to SDI Payload ID. With SDI
compatibility mode ON however, changes
made are not subject to reflect.
Set this mode ON if you are using a
receiving equipment, which outputs no
image with HLG75 or BT.2020.
