Cisco AS5800 User manual

CHAPTER
3-1
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
3
Channelized T3 Trunk Card
The Cisco AS5800 universal access server supports a channelized T3 (CT3) ingress interface that
provides asynchronous aggregation of channelized interfaces and multiplexing on a single T3 facility.
The CT3 trunk card is installed in the Cisco 5814 dial shelf chassis in slots 0 to slot 5. The
Cisco AS5800 currently supports as many as two CT3 trunk cards.
This chapter explains how to remove and replace a CT3 trunk card in the Cisco 5814 dial shelf chassis,
and also includes steps for verifying and troubleshooting your trunk card installation and configuring
your software.
CT3 Trunk Card Overview
The CT3 trunk card contains an onboard M13 multiplexer, which multiplexes 28 separate T1 lines into
a single T3 line. Each CT3 trunk card installed in the Cisco 5814 dial shelf contains all necessary
functionality to terminate link signaling and incoming digital calls.
Figure 3-1 shows the CT3 trunk card.

3-2
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
CT3 Trunk Card Overview
Figure 3-1 CT3 Trunk Card
Each CT3 trunk card performs the following functions:
•Provides physical termination for as many as 672 sessions.
•Provides digital termination for as many as 256 DS0 connections (calls) using onboard High-Level
Data Link Control (HDLC) controllers. Note that the D-channel of a PRI consumes a single channel
of an HDLC controller.
•Removes framing and embedded signaling bits (or inserts them, depending on the direction of the
flow), demultiplexing the calls. The framer CPU sends the data stream to onboard time-division
multiplexing (TDM) resources, which break out each call and pass each call to an appropriate call
termination resource. Digital or ISDN-originated calls are terminated onboard the CT3 trunk card
on HDLC controllers.
Note Each D-channel consumes an HDLC controller.
Analog modem-originated calls are passed over the dial shelf backplane TDM bus to an available
modem resource. The system software controls modem and HDLC resource management.
•Responds to time-sensitive signaling. Each CT3 trunk card can supply two clocks from any two of
its 28 ports. You can assign priorities to these clocks or accept the default values assigned by the
software.
12125
CHANNELIZED T3
PWR
MAINT
FCPU
HCPU
MONITOR #
RALM
LALM
NLOOP
AIST3LOOP
T3EN
LOS
FERF
OOF
RCVR
XMTR
TX (OUT)
RX (IN)
AIST3LOOP
T3EN
LOS
FERF
OOF
PWR
MAINT
FCPU
HCPU
MONITOR #
RALM
LALM
NLOOP
Receive BNC connector
Transmit BNC connector
Receive DSx1 connector
Transmit DSx1 connector

3-3
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card CT3 Trunk Card Overview
•Processes counting information for performance monitoring.
•Supports online insertion and removal (OIR), a feature that allows you to remove and replace a trunk
card in the Cisco 5814 dial shelf while the system is operating without disrupting other cards and
their associated calls. If you remove a trunk card while the system is operating, all calls associated
with the CT3 lines on that card are dropped. Calls being handled by other trunk or modem cards,
however, are not affected. For more information, see the “Online Insertion and Removal” section on
page 1-1.
Figure 3-2 shows two trunk cards installed in a fully-configured Cisco 5814 dial shelf chassis.
Figure 3-2 Cisco 5814 Dial Shelf Chassis Fully Configured with Trunk Cards Installed
Cisco AS5800
SERIES
POWER FAIL
POWER
LED
Captive
screw
FAULT
LED
Captive
screw
PWR
MAINT
FCPU
HCPU
MONITOR #
RALM
LALM
NLOOP
AIST3LOOP
T3EN
LOS
FERF
OOF
RCVR
XMTR
TX (OUT)
RX (IN)
CHANNELIZED E1/T1
PWR
MAINT
FCPU
HCPU
MONITOR #
RALM
LALM
NLOOP
AIST3LOOP
T3EN
LOS
FERF
OOF
RCVR
XMTR
TX (OUT)
RX (IN)
CHANNELIZED E1/T1
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
MODEM
PWR
HCPU
CALLS
MAINT
MODEMS
PWR MIN
MAJACO
CUTOFF
DIAL SHELF INTERCONNECT
MBUS
HIST
ALARM
ALARM
DISP
CLEAR
SET
CLK
SLOT0
SLOT1
MAST
DISP
PCMCIA CONSOLE NETWORK CLOCK ALARMS 10 BASET
DSI
DIAL SHELF CONTROLLER
ATTEN
PWR MIN
MAJACO
CUTOFF
DIAL SHELF INTERCONNECT
MBUS
HIST
ALARM
ALARM
DISP
CLEAR
SET
CLK
SLOT0
SLOT1
MAST
DISP
PCMCIA CONSOLE NETWORK CLOCK ALARMS 10 BASET
DSI
DIAL SHELF CONTROLLER
ATTEN
12266
Blower assembly
Trunk cards Modem cards Dial shelf
controller cards

3-4
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
CT3 Trunk Card Overview
Clocking
All Cisco AS5800 access server trunk cards use the same transmit clock. This clock can originate from
the following sources:
•TDM clock source—A priority value from 1 to 50 that is applied to a clock source when multiple
clock sources are used
•External clock source—A clock source external to the access server
Clocks are prioritized by slot number (slots 0 to 5). The highest-priority clock is selected from the card
in slot 0 and used as the default clock. If this clock fails, the highest-priority clock from the card in slot 1
becomes the default clock, and so forth.
The trunk card then forwards the clocks to the dial shelf controller. The dial shelf controller selects the
highest-priority clock as the system primary clock, and the rest of the clocks remain in a prioritized
backup queue.
Instead of using the default algorithm for clock selection, you can specify clocks through global
configuration and select a maximum of two clocks per trunk card.
If you configure fewer than two clocks on a trunk card and all other configured clocks fail, clock
selection resorts to the default algorithm on that card and the second clock will be selected automatically.
CT3 Clocking
CT3 trunk cards are usually attached to an external device, such as a Digital Access and Crossconnect
System (DACS) or Add-Drop Multiplexer (ADM). This point-to-point link requires a single clock source
to which the CT3 link is timed. You must determine whether you want the CT3 trunk card or an external
device to be used as the primary clock source and configure it accordingly during the software
configuration process, which is discussed in the “Configuration Commands” section on page 3-12.
CT1 Clocking
The CT3 trunk card has 28 T1 framers that always get their clock from the line. As a result, configuration
of T1 clock sources is not allowed.
LED and Alphanumeric Indicators
The CT3 trunk card front panel is designed with LED and alphanumeric displays to provide trunk card
status. (See Figure 3-3.)

3-5
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card CT3 Trunk Card Overview
Figure 3-3 CT3 Trunk Card Front Panel LED and Alphanumeric Indicators
Table 3-1 lists the CT3 trunk card LEDs and their functions.
CHANNELIZED T3
PWR
MAINT
FCPU
HCPU
MONITOR #
RALM
LALM
NLOOP
AIST3LOOP
T3EN
LOS
FERF
OOF
RCVR
XMTR
TX (OUT)
RX (IN)
12240
AIST3LOOP
T3EN
LOS
FERF
OOF
PWR
MAINT
FCPU
HCPU
MONITOR #
RALM
LALM
NLOOP
Alphanumeric display
Table 3-1 CT3 Trunk Card LED Indicators
LED Color Description
PWR Green Power—Lights when power is ON.
MAINT Yellow Maintenance—Lights to indicate that the feature card is ready for OIR.
HCPU Green Host CPU—Lights when the associated host CPU is determined to be in
good working condition; shuts off when there is an error condition or code
is being downloaded.
FCPU Green Framing data link—Lights when the associated FDL CPU is determined to
be in good working condition; shuts off when there is an error condition
or code is being downloaded.
LALM Yellow Local alarm—Lights to indicate a T1 alarm condition was encountered by
software for a particular port; remains OFF when the operating condition
is normal.

3-6
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
CT3 Trunk Card Overview
Trunk Card Connectors
The CT3 front panel is designed with two types of cable connectors (see Figure 3-4). The BNC
connectors are used to connect the cables carrying the T3 signals. The bantam jacks are used for local
BERT circuit testing to the DS1 level.
RALM Yellow Remote alarm—Lights to indicate a T1 alarm condition was encountered
by software for a particular port; remains OFF when the operating
condition is normal.
NLOOP Yellow Network loop—Lights to indicate that at least one T1 is unavailable (status
indicator); remains OFF when the operating condition is normal.
T3EN Green1Enable—Lights to indicate a CT3 card line connection enabling normal
operation.
T3LOOP2Yellow3Loopback—Lights to indicate that a loopback condition exists on the CT3
line; software controlled.
LOS Yellow3Loss-of-signal—Lights to indicate that the CT3 framer is experiencing a
loss of signal (175 successive zeros).
AIS Yellow3Alarm indication signal—Lights to indicate the presence of AIS in the
received CT3 line. Lights to indicate that a T3 alarm condition exists;
remains OFF when the operating condition is normal.
FERF Yellow3Far-end receive failure—Lights to indicate a far-end receive failure on the
CT3 line.
OOF Yellow3Out-of-frame—Lights to indicate an out-of-frame condition on the CT3
line.
1. This LED must be lit for proper CT3 operation.
2. When in loopback mode, enables diagnostics to perform local CT3 testing without external support. The CT3 line is not
affected by this condition, thus remaining disconnected and open.
3. This LED must remain off for proper CT3 operation.
Table 3-1 CT3 Trunk Card LED Indicators (continued)
LED Color Description

3-7
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card Using the Test Port
Figure 3-4 CT3 Trunk Card Front Panel Connectors
Cables
The CT3 trunk card receives and transmits 45 Mbps signals through a 75-ohm cable, using common
BNC coaxial cable connectors (see Figure 3-5). There are two female BNC connectors: one for T3
transmit data and one for T3 receive data.
Figure 3-5 CT3 75-Ohm Coaxial Cable
Using the Test Port
The CT3 trunk card front panel is designed with an alphanumeric display to provide trunk card status
and port monitoring information (see Figure 3-3).
Test-port functionality is supported by Cisco IOS Release 12.0(6)T and later releases.
CHANNELIZED T3
RCVR
XMTR
TX (OUT)
RX (IN)
12241
Receive BNC connector
Transmit BNC connector
Transmit DSx1 bantam
jack connector
Receive DSx1 bantam
jack connector
12951

3-8
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
Using the Test Port
Trunk Card Bantam Jacks
The test port is a set of bantam jack connectors located at the bottom of the CT3 front panel (see
Figure 3-4). The bantam jacks allow the connection of an external test device (for example, a
FIREBERD test device) to test any of the 28 individual T1 circuits in drop-and-insert mode or to monitor
an individual T1 circuit in monitor mode.
•In drop-and-insert mode, the T1 line is dropped out of service. To prevent accidental use of the push
button in drop-and-insert mode, use the test trunk drop-insert privileged EXEC command to
disable the drop-and-insert mode on the specified T3 controller.
•In monitor mode, you can monitor only the ingress side of the T1 line. The T1 line being monitored
is not disrupted, and the line maintains its HDLC and modem connections through TDM.
Drop-and-Insert Mode
The test trunk drop-insert privileged EXEC command is used to enable or disable drop-and-insert
mode on a T3 controller. When the system initially boots up, the drop-and-insert mode is disabled on all
T3 controllers.
To drop a particular T1 line to the test port, follow these steps:
Step 1 Enable drop-and-insert mode by entering the test trunk drop-insert on privileged EXEC command as
follows:
AS5800# test trunk drop-insert on shelf/slot/unit
Note The shelf/slot/unit identifies the T1 to the CT3 controller.
Step 2 Push and quickly release the push button below the LED to toggle to the port number. The push button
is labeled “MONITOR #” in Figure 3-3.
Note You must release the push button within 2 seconds to advance through the port
numbers (from 1 to 28). After port 28, the display returns to port 1.
Step 3 Push and hold the push button for two or more seconds.
The letter “D” (indicating drop-insert) is displayed in the front panel LED, indicating that the particular
T1 line has been dropped to the test port.
Note To select another port number, press the push button again and hold it for two or
more seconds. You can now toggle to another port number.
Step 4 Disable the drop-and-insert mode after testing the T1 lines. We recommend that you disable
drop-and-insert mode to prevent accidental use of the push button on the CT3 board.
To disable drop-and-insert mode, enter the test trunk drop-insert off privileged EXEC command as
follows:
AS5800# test trunk drop-insert off shelf/slot/unit

3-9
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card Using the Test Port
Monitor Mode
To monitor a particular T1 line at the test port, follow these steps:
Step 1 Verify that drop-and-insert mode is disabled on the CT3 controller by entering the show command, as
follows:
AS5800# sh controller t3 shelf/slot/unit
The following is sample output from the sh controller t3 command if drop-and-insert mode is disabled:
AS5800# show controller t3 1/1/0
T3 1/1/0 is up.
Applique type is Channelized T3
No alarms detected.
FEAC code received: No code is being received
Framing is M23, Line Code B3ZS, Clock Source is Internal
Drop-insert is disabled
Data in current interval (90 seconds elapsed):
0 Line Code Violations, 0 P-bit Coding Violation
0 C-bit Coding Violation, 0 P-bit Err Secs
0 P-bit Severely Err Secs, 0 Severely Err Framing Secs
0 Unavailable Secs, 0 Line Errored Secs
0 C-bit Errored Secs, 0 C-bit Severely Errored Secs
AS5800#
Note If the display shows Drop-insert is enabled, repeat Step 4 in the
“Drop-and-Insert Mode” section on page 3-8.
Step 2 Push and quickly release the push button below the LED to toggle to the port number. The push button
is labeled “MONITOR #” in Figure 3-3.
Note You must release the push button within two seconds to advance through the port
numbers (from 1 to 28). After port 28, the display returns to port 1.
Step 3 Push and hold the push button for two or more seconds.
The letter “M” (indicating monitor) is shown in the front panel display, indicating that you can monitor
the particular T1 line at the test port.
Note To select another port number, press the push button again and hold it for two or
more seconds. You can now toggle to another port number.

3-10
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
Using the Test Port
Specifications
Table 3-2 lists the CT3 trunk card specifications.
Connecting Trunk Card Cables
The CT3 trunk card receives and transmits 45-Mbps signals through a 75-ohm cable, using common
female BNC coaxial cable connectors. There are two female BNC connectors: one for T3 transmit data
and one for T3 receive data. Use a 75-ohm coaxial cable to connect the T3 lines (see Figure 3-5).
To connect the T3 lines, follow these steps:
Step 1 Attach the end of the T3 cable directly to the BNC receptacle on the trunk card (see Figure 3-6).
Table 3-2 CT3 Trunk Card Specifications
Description Specification
Dimensions H x W x L 15.4 x 0.08 x 18.7 in. (39.12 x 0.203 x 47.5 cm)
without the carrier
15.5 x 1.23 x 19 in. (39.37 x 3.12 x 48.26 cm) with the
carrier
Weight 8 lb (3.6 kg)
Transmission bit rate 44,736 Mbps
MTBF1
1. MTBF = Mean time between failures.
Exceeds 50,000 hr
Power requirements +3.3 VDC, 8A, 5%
+5.0 VDC, 15A, 5%
Regulatory compliance Safety: UL 1950, CSA 22.2 No. 950, EN60950,
AUSTEL TS001, AS/NZS 3260, IEC 950
Emissions: CFR 47 Part 15 Class B(FCC), CISPR22
Class B, EN55022 Class B, AS/NRZ 3548 Class B,
ICES003, VCCI Class B
Immunity: IEC 1000-3-2, IEC 1000-3-3,
IEC-1000-4-2, IEC-1000-4-3, IEC-1000-4-4,
IEC-1000-4-5, IEC-1000-4-6, IEC-1000-4-11,
EN50082-1, EN50082-2
For additional compliance information, refer to the
Regulatory Compliance and Safety Information
document that accompanied this device.

3-11
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card Using the Test Port
Figure 3-6 CT3 Trunk Card BNC Cable Connections
Step 2 Attach the network end of your CT3 cable to your external network.
Configuring Cable Length
When you configure your CT3 trunk cards, you must include the length of the cable connected to the
card. To specify this length, use the cablelength command and designate the length of the DS3 cable, as
shown in Table 3-3. Cable length is a number of feet from 0 to 450.
When you configure your system for CT3 lines, you must also include additional commands to define
framing, line code, clock source, signaling, and so forth. For additional software information, refer to
the Cisco AS5800 Universal Access Server Operation, Administration, Maintenance, and Provisioning
Guide that shipped with your system.
This completes the trunk card installation procedure. To verify the installation, proceed to the following
section “Verifying and Troubleshooting the Installation.”
Verifying and Troubleshooting the Installation
When you first power ON your Cisco AS5800, all LEDs light while the system runs a series of
diagnostics. After the system passes initial diagnostics, all LEDs shut off. The LEDs then light again as
described in Table 3-1.
CHANNELIZED T3
RCVR
XMTR
TX (OUT)
RX (IN)
12241
Receive BNC connector
Transmit BNC connector
Transmit DSx1 bantam
jack connector
Receive DSx1 bantam
jack connector

3-12
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
Configuring the CT3 Trunk Card
To complete the hardware installation, verify that the trunk card LEDs operate properly by observing the
following LED states:
•The power LED is ON.
If the power LED remains OFF, verify that the card is seated properly.
If the power LED lights on other trunk cards in the dial shelf, try inserting the trunk card in a
different slot. If none of the power LEDs lights, check your dial shelf power connections, power
entry modules, and AC-input power supplies (if present).
•The HCPU LED is ON.
If the HCPU LED is OFF but the power LED is ON, the software image might have failed to load
onto the card. The dial shelf controller attempts to reload the software automatically. After a
programmed number of attempts to reload the software image fails, the dial shelf controller powers
OFF the trunk card and all LEDs are shut off.
If this happens, assume that the failure is due to defective hardware. Return the card to the factory
for replacement. For information on how to contact Cisco, see the “Obtaining Documentation”
section on page xiv.
•The FCPU LED is ON.
If the FCPU LED is OFF while the HCPU LED is ON, either the hardware is defective or the framer
processor software has crashed. To determine if the failure is software related, wait while the
auto-reload feature on the dial shelf controller card attempts to reload the software image. If the
software fails to reload after the programmed number of times, assume that the failure is due to
defective hardware. Return the card to the factory for replacement.
Tips For further installation troubleshooting information, refer to the Cisco AS5800 Universal
Access Server Hardware Installation Guide.
Configuring the CT3 Trunk Card
The Cisco 5814 dial shelf recognizes trunk cards only in dial shelf slots 0 to 5. Therefore, install trunk
cards only in the first six slots.
If you are replacing a dial shelf card by installing a new dial shelf card of the same type in the same slot,
the system software recognizes the new dial shelf card interfaces and brings them up automatically. No
additional configuration is needed.
If you are installing a trunk card in a different slot than the trunk card you just removed, additional
configuration is needed. Refer to the Cisco AS5800 Universal Access Server Operation, Administration,
Maintenance, and Provisioning Guide that shipped with your system.
Configuration Commands
Table 3-3 lists commands to help you configure your CT3 card.
Note The / symbol is used in commands to specify a physical location. Thus 1/0/0 on a T3 port
tells you where you can plug something in to the dial shelf. The : symbol is used in
commands to specify a TDM channel within a physical port.

3-13
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card Configuring the CT3 Trunk Card
Table 3-3 T3 Configuration Commands
Command Description
Step 1 AS5800> enable
Password: password
AS5800#
Enter the enable command.
Enter your password.
You are in privileged EXEC mode when the prompt
changes to AS5800#.
Step 2 AS5800# configure terminal
Enter configuration commands, one per
line. End with CNTL/Z.
AS5800(config)#
Enter global configuration mode by entering the
configure terminal command. The example uses the
terminal configuration option.
You are in global configuration mode when the prompt
changes to AS5800(config)#.
Step 3 AS5800(config)# interface loopback 0
%LINEPROTO-5-UPDOWN: Line protocol on
Interface Loopback0, changed state to
up
Enter interface loopback 0 to create interface
loopback 0, which is the logical IP subnet containing
all dial-in user addresses.
You are in interface mode when the prompt changes to
AS5800(config-if)#.
Step 4 AS5800(config-if)# loopback
local
Set the normal data path back to its source (either local
or network).
Step 5 AS5800(config-if)# no shutdown Enable the interface using the no shutdown
command.1
Step 6 AS5800(config)# controller t3
shelf/slot /0 Enter controller configuration mode to configure your
T3 controller port. The only legal port value is 0.
Step 7 AS5800(config-controller)# t3
description ascii-string
Enter an optional text description for the T3 controller.
Step 8 AS5800(config-controller)# cablelength
200
Enter the controller cablelength value, from 0to 450
(feet).
Step 9 AS5800(config-controller)# framing
c-bit
Enter the type of T3 framing used. C-bit specifies C-bit
parity framing. M23 (default) specifies M23
multiplexer framing.
Step 10 AS5800(config-controller)# t1
ds1
controller Create a logical T1 controller from each of the
specified T3 line time slots. The entry ds1 is a time slot
within the T3 line with a value from 1to 28.
Step 11 AS5800(config)# controller t1
shelf/slot/port:t1-num
Enter controller configuration mode to configure your
T3 controller port. T1-num is a T1 timeslot within the
T3 line with a value from 1to 28.
Step 12 AS5800(config-controller)# clock source
line
Configure the clock source as an internal clock
(internal) or a recovered clock (line).

3-14
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
Configuring the CT3 Trunk Card
To verify your software configuration, you can enter show commands to display clock (show dial-shelf
clock) and controller (show controller t3) settings. To enter show commands, you must be in
privileged EXEC mode. Some examples:
AS5800# show dial-shelf clock
Primary Clock:
--------------
Slot 12:
System primary is 1/1/0:2 of priority 213
TDM Bus Master Clock Generator State = NORMAL
Backup clocks:
Source Slot Port DS3-Port Priority Status State
-------------------------------------------------------------
Trunk 0 1 0 206 Bad Default
Trunk 0 2 0 212 Bad Default
Trunk 1 4 0 225 Good Default
Status of trunk clocks:
-----------------------
Ds3 2 2 2 2 2 2 2 2 2 1 1 1 1 1 1 1 1 1 1
Slot Port Type 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1
0 0 T3 G G G G G G G G G G G G G G G G G G G G G G G G G G G G
1 0 T3 B B B B B B B B B B B B B B B B B B B B G G G G G G G G
Step 13 AS5800(config)# dial-tdm-clock priority
{ 1 - 50 } { external | trunk-slot } { 0 - 5 }
ds3-port 0 port { 1 - 28 }
Configure clock priority, which is a value from 1to 50.
Select a clocking source by selecting an external
reference clock or a trunk card. If you are using an
external reference clock, no other CLI is needed. If you
are using a trunk card, select a dial shelf slot from
0to 5.
Select the T3 port number, which has a value of 0.
Step 14 AS5800# copy running-config
startup-config Save your changes when ready.
1. To deactivate a command functionality, type no before the command.
Table 3-3 T3 Configuration Commands (continued)
Command Description

3-15
Cisco AS5800 Universal Access Server Dial Shelf Card Guide
78-7097-03
Chapter 3 Channelized T3 Trunk Card Configuring the CT3 Trunk Card
AS5800# show controller t3
T3 1/0/0 is up.
Applique type is Channelized T3
No alarms detected.
FEAC code received: No code is being received
Framing is M23, Line Code is B3ZS, Clock Source is Line.
Data in current interval (751 seconds elapsed):
0 Line Code Violations, 0 P-bit Coding Violation
0 C-bit Coding Violation, 0 P-bit Err Secs
0 P-bit Severely Err Secs, 0 Severely Err Framing Secs
0 Unavailable Secs, 0 Line Errored Secs
0 C-bit Errored Secs, 0 C-bit Severely Errored Secs
Total Data (last 16 15 minute intervals):
34989 Line Code Violations, 16414 P-bit Coding Violation,
49331 C-bit Coding Violation, 0 P-bit Err Secs,
0 P-bit Severely Err Secs, 0 Severely Err Framing Secs,
12 Unavailable Secs, 0 Line Errored Secs,
10 C-bit Errored Secs, 10 C-bit Severely Errored Secs
T3 1/1/0 is up.
Applique type is Channelized T3
No alarms detected.
FEAC code received: No code is being received
Framing is M23, Line Code is B3ZS, Clock Source is Line.
Data in current interval (751 seconds elapsed):
0 Line Code Violations, 0 P-bit Coding Violation
0 C-bit Coding Violation, 0 P-bit Err Secs
0 P-bit Severely Err Secs, 0 Severely Err Framing Secs
0 Unavailable Secs, 0 Line Errored Secs
0 C-bit Errored Secs, 0 C-bit Severely Errored Secs
Total Data (last 16 15 minute intervals):
42579 Line Code Violations, 16421 P-bit Coding Violation,
49208 C-bit Coding Violation, 0 P-bit Err Secs,
0 P-bit Severely Err Secs, 0 Severely Err Framing Secs,
2 Unavailable Secs, 0 Line Errored Secs,
10 C-bit Errored Secs, 10 C-bit Severely Errored Secs

3-16
Cisco AS5800 Universal Access Server Dial Shelf Card Guide 78-7097-03
Chapter 3 Channelized T3 Trunk Card
Configuring the CT3 Trunk Card
A typical T3 controller configuration in a running-configuration file appears as follows:
T3 controller configuration:
----------------------------
controller T3 1/0/0
framing m23
clock source line
cablelength 224
t1 1 controller
t1 2 controller
t1 3 controller
t1 4 controller
t1 5 controller
t1 6 controller
t1 7 controller
t1 8 controller
t1 9 controller
t1 10 controller
t1 11 controller
t1 12 controller
t1 13 controller
t1 14 controller
t1 15 controller
t1 16 controller
t1 17 controller
t1 18 controller
t1 19 controller
t1 20 controller
t1 21 controller
t1 22 controller
t1 23 controller
t1 24 controller
t1 25 controller
t1 26 controller
t1 27 controller
t1 28 controller
A typical T1 controller configuration appears as follows:
T1 controller configuration:
----------------------------
controller T1 1/0/0:1
framing esf
pri-group timeslots 1-24
controller T1 1/0/0:2
channel-group 0 timeslots 1-24
.
.
.
controller T1 1/1/0:28
cas-group 0 timeslots 1-24
