SLIDE RAIL INSTALLATION INSTRUCTIONS
For Cisco C170, M170, and S170
Appliances
and
Cisco 5512-X, 5515-X, 5525-X, 5545-X,
5555-X Adaptive Security Appliances
and
Cisco IPS 4345 and 4360
1Verify the Box Contents
2Disassemble the Slide Rail
3Attach Inner Rails to the Chassis
4Verify the Rack Type
5Round Hole Racks
6Threaded Hole Racks
7Attach the Outer Slide Rail to Round and Square
Hole Racks
8Attach the Outer Slide Rail to Threaded Hole Racks
9Install the Chassis
10 Secure the Chassis
Obtaining Documentation and Submitting a
Service Request

2
1 Verify the Box Contents
Remove the contents from the box and verify that it contains the
following items for all rack types:
•Slide Rails (x2) (preconfigured for square hole racks)
•Phillips flat-head screws for Inner Slide (x2)
For round hole racks, you also need the following:
•Round Hole Inserts (x4)
For threaded hole racks, you also need the following:
•Threaded Hole Brackets (x2)
•Threaded Hole Standoffs (x2)
•Phillips pan-head screws for threaded hole racks (x8)
Tools Required:
•Phillips screwdriver
•Flat-head screwdriver (for threaded hole racks)
A
B
C
D
E
F
300885
A
B C D E F

3
2 Disassemble the Slide Rail
Pull the inner slide rail from the outer slide rail.
Slide the plastic tab forward, and pull the inner slide rail to
disconnect it from the outer slide rail.
Repeat the steps on this page for the other slide rail.
Front
330908

4
3 Attach Inner Rails to the Chassis
Align one of the inner slide rail key holes over the chassis
shoulder screw on one side. Slide the inner slide rail forward so
that the shoulder screw is securely in place.
Use a Phillips screwdriver to secure the inner slide rail with one
Phillips flat-head screw .
Secure the other inner slide rail to the chassis by repeating the
previous steps on this page.
330907
B
330905
330904

5
4 Verify the Rack Type
The slide rails are pre-assembled for square hole racks. See the
following steps for the different rack types:
•Square hole racks. Go to “Attach the Outer Slide Rail to
Round and Square Hole Racks” on page 8.
•Round hole racks. Go to “Round Hole Racks” on page 6.
•Threaded hole racks. Go to “Threaded Hole Racks” on
page 7.
The following figure shows the slide rail with square hole rack
inserts.
330903

6
5 Round Hole Racks
Using a Phillips head screwdriver, remove the square insert from
the rear of the rail. Keep the two Phillips head screws.
Remove the square insert from the front of the rail. Keep the
two Phillips head screws.
Align the round hole insert to the rear of the rail, and secure
it with two of the saved screws.
Align the round hole insert to the front of the rail over the
hooks, and secure it with two of the saved screws.
See “Attach the Outer Slide Rail to Round and Square Hole
Racks” on page 8.
330884
330882
C
330881
C
330880

7
6 Threaded Hole Racks
Using a Phillips head screwdriver, remove the square hole insert
from the rear of the rail.
Remove the square hole insert from the front of the rail.
Align the threaded hole bracket to the front of the rail over
the hooks. Secure it with the threaded hole standoff using a
flat-head screwdriver.
No additional hardware is necessary for the rear adapter.
Repeat these steps page for the other slide rail. Go to the“Attach
the Outer Slide Rail to Threaded Hole Racks” section on
page 9.
330884
330882
D
E
330878
330876

8
7 Attach the Outer Slide Rail to
Round and Square Hole Racks
Align the front of one of the outer slide rails with the rack
upright, push it forward, and click it into place. Align the rear
of the outer slide rail with the rack upright, pull the release tab,
push the slide rail toward the rack, release the tab, and click it
into place.
Note For racks shorter than 24 inches in depth, remove the
rear bracket with a Phillips head screwdriver, pull the
release tab, and adjust the slide rail to the appropriate
length for the rack.
Secure the other outer slide rail to the rack by repeating the
previous steps.
Go to the “Install the Chassis” section on page 10.
Front of
Rack
Rear of
Bracket
Rear of
Rack
330901
330872

9
8 Attach the Outer Slide Rail to
Threaded Hole Racks
Align the slide rail to the front rack post. Secure it with two of
the included Phillips pan-head screws .
Align the slide rail to the rear rack post. Secure it with two of
the included Phillips pan-head screws .
Align the other slide rail to the rack by repeating the previous
steps on this page.
Go to the “Install the Chassis” section on page 10.
F
330883
F
330875
330872

10
9 Install the Chassis
Align the inner slide rails to the outer slide rails. Install the inner
slide rails into the outer slide rails until they lock into place.
Pull the side release tabs to unlock the inner slide rail, and push
the chassis assembly into the rack.
330889
330898

11
10 Secure the Chassis
Secure the chassis to the rack with the front captive screws.
Obtaining Documentation and Submitting a
Service Request
For information on obtaining documentation, submitting a
service request, and gathering additional information, see the
monthly What’s New in Cisco Product Documentation, which
also lists all new and revised Cisco technical documentation, at:
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.ht
ml
Subscribe to the What’s New in Cisco Product Documentation as
an RSS feed and set content to be delivered directly to your desktop
using a reader application. The RSS feeds are a free service. Cisco
currently supports RSS Version 2.0.
330890
