Cisco NCS 1010 Instruction sheet

Install Cisco NCS 1010 Modules
This chapter describes the tasks to install Cisco NCS 1010 modules.
Always populate the modular slots in the Cisco NCS 1010 chassis with respective modules (line card, controller,
PSU, and fan trays). Perform the replacement or upgrade of the modules (Online Insertion or Removal ( OIR))
only when the ambient temperature is below 30 degree Celsius. Complete the OIR of modules within five
minutes to prevent overheating of the components.
Caution
•Install PSU, on page 1
•Install Controller, on page 6
•Install Line Card, on page 7
•Install Fan Tray, on page 9
•Install Fan Filter, on page 11
•Install Protection Cover, on page 12
Install PSU
Use this task to install PSU into the Cisco NCS 1010 chassis. You can install two AC PSUs or two DC PSUs
in a chassis.
Procedure
Step 1 Orient the PSU correctly before inserting.
Install Cisco NCS 1010 Modules
1

Step 2 Using the handle, slide the PSU into the slot (support the PSU at the bottom with your hand) and push it in
until you hear a click sound; direction of insertion is shown in the following figure. The click sound indicates
that the unit has been latched. .
The locking latch must be pressed and released only for removing the PSU.
Note
Figure 1: Installing the PSU
PSU unit1
Connect AC Power to Cisco NCS 1010
Cisco NCS 1010 relies on the protective devices in the building installation to protect against short circuit,
overcurrent, and ground faults. Ensure that the protective devices comply with local and national electrical
codes.
Caution
Install Cisco NCS 1010 Modules
2
Install Cisco NCS 1010 Modules
Connect AC Power to Cisco NCS 1010

Figure 2: Rating Label for AC Power
AC power ratings: The voltage rating value for AC power ranges either 200–240 or 100–127 V depending
on the standards in various countries.
• Input: 100-120Vac, 12A, 50-60HzDC
Outputs: +12V, 67A Max. +12Vsb, 3A Max. Total output power 800W.
• Input: 200-240Vac, 7A, 50-60HzDC
Outputs: +12V, 87.5A Max. +12Vsb, 3A Max. Total output power 1050W.
A dual pole breaker is needed for the installation. The rating of the dual pole breaker for each feed is 16A for
input voltage 200–240 Vac, and 20A for input voltage 100–127 Vac.
Note
Procedure
Step 1 Verify that the AC cable is installed in the correct AC source panel. Ensure that either the fuse is removed or
the circuit breaker is in the off position and locked out.
Step 2 Attach the AC power cable to the cable connector in the AC power module. See Power Cable Specifications
for the supported AC power cables.
Install Cisco NCS 1010 Modules
3
Install Cisco NCS 1010 Modules
Connect AC Power to Cisco NCS 1010

Figure 3: Connecting AC Power Cable
AC power cable1
Step 3 Close the cable retention clips to secure the power cables and to prevent their accidental removal.
Connect DC Power to Cisco NCS 1010
Cisco NCS 1010 relies on the protective devices in the building installation to protect against short circuit,
overcurrent, and ground faults. Ensure that the protective devices comply with local and National Electrical
Codes.
Caution
Install Cisco NCS 1010 Modules
4
Install Cisco NCS 1010 Modules
Connect DC Power to Cisco NCS 1010

Figure 4: Rating Label for DC Power
DC power ratings:
• Input: 48-60Vdc, 30A.
• DC output: +12V, 87.5A Max. +12Vsb, 3A Max. Total output power must not exceed 1050W.
Procedure
Step 1 Verify that the correct fuse panel is installed in the top mounting space.
Step 2 Measure and cut the cables as required to reach Cisco NCS 1010 from the fuse panel.
Step 3 Connect the office battery and return cables according to the fuse panel engineering specifications.
Step 4 Attach the DC power cable to the cable connector in the DC power module.
Use the CAB-48DC-40A-8AWG or NCS1010-DC-CBL-ET= cable. We recommend using
NCS1010-DC-CBL-ET= with the ETSI 300-mm cabinet to remain compliant with the 300-mm footprint. See
Power Cable Specifications.
Ensure to ground the green colored cable.
Note
Install Cisco NCS 1010 Modules
5
Install Cisco NCS 1010 Modules
Connect DC Power to Cisco NCS 1010

Figure 5: Connecting DC Power
DC power cable1
Install Controller
Use this task to install controller into the Cisco NCS 1010 chassis.
Procedure
Step 1 Orient the controller appropriately before inserting. Check for the This Side Up label.
Install Cisco NCS 1010 Modules
6
Install Cisco NCS 1010 Modules
Install Controller

Step 2 Hold the upper and lower surface of the controller with hands and insert the controller into the slot.
Figure 6: Installing the Controller
Controller1
Captive Screw2
Step 3 Using a screwdriver, tighten the two captive screws to a torque value of 0.65 N-m (5.75 lbs-in).
Install Line Card
Use this task to install the line card into the Cisco NCS 1010 chassis.
Procedure
Step 1 Orient the line card.
Step 2 Align the grooves in both sides of the line card with the slide guides available inside the chassis.
Install Cisco NCS 1010 Modules
7
Install Cisco NCS 1010 Modules
Install Line Card

Figure 7: Cisco NCS 1010 Chassis
Backplane connector1
Slide Guides2
Figure 8: Inserting the Line Card
Grooves1
Handle2
Captive Screws (Two captive screws on each side of
the line card)
3
Step 3 Insert the line card into the chassis.
Use the handle only to push and pull out the line card from the chassis. Do not use the handle to
carry the line card. To prevent any accidental drop, support the top and bottom of the line card with
your hand while you remove or insert it.
Caution
Install Cisco NCS 1010 Modules
8
Install Cisco NCS 1010 Modules
Install Line Card

Step 4 Tighten the captive screws available in the left and right side handles of the line card, using a screw driver
with a torque value of 1.5 N-m (13.3 lbs-in).
Install Fan Tray
Use this task to install the fan trays into the chassis. The chassis can accommodate two fan trays.
Procedure
Step 1 Orient the fan tray using the guide pin available in the fan tray, before inserting. Check for the This Side Up
label.
Figure 9: Front View of the Fan Tray
Install Cisco NCS 1010 Modules
9
Install Cisco NCS 1010 Modules
Install Fan Tray

Figure 10: Rear View of the Fan Tray
Guide pin1
Step 2 Holding the handles with both hands, insert the fan tray into the slot on the front side of the chassis.
Figure 11: Inserting a Fan Tray
Fan tray1
Captive screw2
Step 3 Using the screw driver, tighten the captive screws at the corners of the fan tray, to a torque value 0.65 N-m
(5.75 lbs-in).
Install Cisco NCS 1010 Modules
10
Install Cisco NCS 1010 Modules
Install Fan Tray

The left captive screw goes into the chassis and the right captive screw goes into the line card.
Step 4 Repeat the preceding steps to insert and fix the second fan tray.
Install Fan Filter
Use this task to assemble the fan filter on the Cisco NCS 1010 chassis.
Procedure
Step 1 Align the four captive screws in the fan filter with the respective standoffs in the fan trays. Check for the This
Side Up label.
Figure 12: Installing the Fan Filter
Fan filter1
Captive screw2
Step 2 Tighten the captive screws using the screwdriver to a torque value of 0.65 N-m`(5.75 lbs-in).
Install Cisco NCS 1010 Modules
11
Install Cisco NCS 1010 Modules
Install Fan Filter

Install Protection Cover
Use this task to install the transparent plastic protection cover to enclose the faceplate of the line card, after
the fibers are connected on the faceplate of the line card.
Procedure
Step 1 Align the guide pin available at the back side of the cover with the hole in the line card.
Figure 13: Rear View of the Protection Cover
Captive screws1
Guide pin2
Step 2 Align the standoffs with the holes available in the chassis mounting brackets, and fasten the standoffs into
the holes.
Install Cisco NCS 1010 Modules
12
Install Cisco NCS 1010 Modules
Install Protection Cover

Figure 14:
Protection cover1
Standoffs2
Captive screws3
Step 3 Tighten the captive screws available in the protection cover, such that the screws get fixed into the standoffs.
Remove the protection cover to access the line card faceplate and reinstall after the fibers are connected.
