Cisco Catalyst 9400 Series Module Installation Note
Table 1: Product Numbers:
C9400-LC-48U, C9400-LC-48U= (Spare)C9400-LC-48T, C9400-LC-48T= (Spare)
C9400-LC-24XS, C9400-LC-24XS= (Spare)C9400-LC-48UX, C9400-LC-48UX= (Spare)
C9400-LC-24S, C9400-LC-24S= (Spare)C9400-LC-48S, C9400-LC-48S= (Spare)
C9400-LC-48H, C9400-LC-48H= (Spare)C9400-LC-48P, C9400-LC-48P= (Spare)
This document provides instructions for installing switching modules in Cisco Catalyst 9400 Series Switches.
Statement 1071—Warning Definition
IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Use the statement number provided at the end of
each warning to locate its translation in the translated safety warnings that accompanied this device.
Statement 1071
SAVE THESE INSTRUCTIONS
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan
veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij
elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van de standaard praktijken
om ongelukken te voorkomen. Gebruik het nummer van de verklaring onderaan de waarschuwing als
u een vertaling van de waarschuwing die bij het apparaat wordt geleverd, wilt raadplegen.
BEWAAR DEZE INSTRUCTIES
Waarschuwing
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin
käsittelet laitteistoa, huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu onnettomuuksien
yleisiin ehkäisytapoihin. Turvallisuusvaroitusten käännökset löytyvät laitteen mukana toimitettujen
käännettyjen turvallisuusvaroitusten joukosta varoitusten lopussa näkyvien lausuntonumeroiden
avulla.
SÄILYTÄ NÄMÄ OHJEET
Varoitus
2

IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant entraîner
des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez conscient des
dangers liés aux circuits électriques et familiarisez-vous avec les procédures couramment utilisées pour
éviter les accidents. Pour prendre connaissance des traductions des avertissements figurant dans les
consignes de sécurité traduites qui accompagnent cet appareil, référez-vous au numéro de l'instruction
situé à la fin de chaque avertissement.
CONSERVEZ CES INFORMATIONS
Attention
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen
kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und
den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder
Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
Warnung
IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone.
Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai
circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti. Utilizzare il numero
di istruzione presente alla fine di ciascuna avvertenza per individuare le traduzioni delle avvertenze
riportate in questo documento.
CONSERVARE QUESTE ISTRUZIONI
Avvertenza
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du
begynner å arbeide med noe av utstyret, må du være oppmerksom på farene forbundet med elektriske
kretser, og kjenne til standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten av hver
advarsel for å finne oversettelsen i de oversatte sikkerhetsadvarslene som fulgte med denne enheten.
TA VARE PÅ DISSE INSTRUKSJONENE
Advarsel
INSTRUÇÕES IMPORTANTES DE SEGURANÇA .
Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de lesões
corporais. Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos perigos
envolvidos no manuseio de circuitos elétricos e familiarize-se com as práticas habituais de prevenção
de acidentes. Utilize o número da instrução fornecido ao final de cada aviso para localizar sua tradução
nos avisos de segurança traduzidos que acompanham este dispositivo
GUARDE ESTAS INSTRUÇÕES
Aviso
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular
cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese con los procedimientos
estándar de prevención de accidentes. Al final de cada advertencia encontrará el número que le ayudará
a encontrar el texto traducido en el apartado de traducciones que acompaña a este dispositivo.
GUARDE ESTAS INSTRUCCIONES
¡Advertencia!
3

VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada.
Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och
känna till vanliga förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av
varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna
anordning.
SPARA DESSA ANVISNINGAR
Varning!
Cisco Catalyst 9400 Series Module Features
These tables provide a brief description of each module, the per slot bandwidth, maximum rated power of the modules (where
applicable), minimum and maximum port densities, chassis support information, and restrictions (if any).
4

Gigabit and Multigigabit Ethernet Switching Modules
Cisco Catalyst 9400 Series 48-Port 10/100/1000 Module (C9400-LC-48T)
48-port, 10/100/1000 BASE-T Gigabit Ethernet switching module.
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports Energy Efficient Ethernet (EEE)
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
Description
48 Gbps, full duplex non-blocking trafficPer Slot Bandwidth
• Catalyst 9404R Switch—48 / 96
• Catalyst 9407R Switch—48 / 240
• Catalyst 9410R Switch—48 / 384
Minimum / Maximum Port
Density1
Can be installed in any non-supervisor module slot. There are no other restrictions.Support and Restrictions
1The number of ports available on a single switch
5

Figure 1: Front View of the C9400-LC-48T Switching Module
Switching module Radio Frequency Identifier (RFID)5STATUS LED1
Captive installation screws6LOCATE (blue beacon) LED2
Ejector levers7PORT LINK LED for the port in the top row3
Model or product number8PORT LINK LED for the port in the bottom row4
6

Cisco Catalyst 9400 Series 48-Port UPOE 10/100/1000 Module (C9400-LC-48U)
48-port, 10/100/1000 BASE-T Gigabit Ethernet module supporting up to 60W Cisco UPOE on
each of its 48 RJ45 ports.
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports Cisco Phone Discovery and IEEE802.3af and IEEE802.3at.
• Supports Energy Efficient Ethernet (EEE)
• Supports PoE Cable Loss Management
• Saves power with direct power delivery from backplane
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
• The following switching module features are configured in software. See the software
configuration guide for more information:
• Provides per port power consumption measurement
• Enables you to specify maximum power consumption on every port
• Supports PoE Power Configuration
Description
48 Gbps, full duplex non-blocking trafficPer Slot Bandwidth
• Catalyst 9404R Switch—48 / 96
• Catalyst 9407R Switch—48 / 240
• Catalyst 9410R Switch—48 / 384
Minimum / Maximum Port
Density2
• Can be installed in any non-supervisor module slot.
• Ensure that the chassis power supply configuration supports the PoE budget adequately. Use
the Cisco Power Calculator for power budgeting estimates and to determine power supply
requirements for a specific PoE configuration.
Support and Restrictions
2The number of ports available on a single switch
7

Figure 2: Front View of the C9400-LC-48U Switching Module
Switching module Radio Frequency Identifier (RFID)5STATUS LED1
Captive installation screws6LOCATE (blue beacon) LED2
Ejector levers7PORT LINK LED for the port in the top row3
Model or product number8PORT LINK LED for the port in the bottom row4
8

Cisco Catalyst 9400 Series 48-Port UPOE Multigigabit Module (C9400-LC-48UX)
48-port, UPOE Multigigabit Ethernet Module with:
• 24 ports (Ports 1 to 24) 1G POE/POE+/UPOE
• 24 ports (Ports 25 to 48) Multigigabit (mGig) POE/POE+/UPOE
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports Cisco Phone Discovery and IEEE802.3af and IEEE802.3at.
• Supports Energy Efficient Ethernet (EEE)
• Supports PoE Cable Loss Management
• Saves power with direct power delivery from backplane
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID on Cisco Catalyst 9000 Family Switches).
• The following switching module features are configured in software. See the software
configuration guide for more information:
• Provides per port power consumption measurement
• Enables you to specify maximum power consumption on every port
• Supports PoE Power Configuration with up to 60W power per port on each of its 48
ports.
Description
Per slot bandwidth depends on the supervisor module:
80 Gbps with C9400-SUP-1XL ten-slot chassis or C9400-SUP-1.
120 Gbps with C9400-SUP-1XL seven-slot chassis.
Per Slot Bandwidth
• Catalyst 9407R Switch—48 / 96
• Catalyst 9407R Switch—48 / 240
• Catalyst 9410R Switch—48 / 384
Minimum / Maximum Port
Density3
• Can be installed in any non-supervisor module slot.
• Ensure that the chassis power supply configuration supports the PoE budget adequately. Use
the Cisco Power Calculator for power budgeting estimates and to determine power supply
requirements for a specific PoE configuration.
Support and Restrictions
3The number of ports available on a single switch
9

Figure 3: Front View of the C9400-LC-48UX Switching Module
Switching module Radio Frequency Identifier (RFID)5STATUS LED1
Captive installation screws6LOCATE (blue beacon) LED2
Ejector levers7PORT LINK LED for the port in the top row3
Model or product number8PORT LINK LED for the port in the bottom row4
10

Cisco Catalyst 9400 Series 48-Port 1G SFP Module (C9400-LC-48S)
48-port, 1 Gigabit Ethernet SFP module.
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports full duplex traffic.
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
Description
48 Gbps, full duplex non-blocking trafficPer Slot Bandwidth
• Catalyst 9404R Switch—48 / 96
• Catalyst 9407R Switch—48 / 240
• Catalyst 9410R Switch—48 / 384
Minimum / Maximum Port
Density4
Can be installed in any non-supervisor module slot. There are no other restrictions.Support and Restrictions
4The number of ports available on a single switch
11

Figure 4: Front View of the C9400-LC-48S Switching Module
Switching module Radio Frequency Identifier (RFID)5STATUS LED1
Captive installation screws6LOCATE (blue beacon) LED2
Ejector levers7PORT LINK LED for the port in the top row3
Model or product number8PORT LINK LED for the port in the bottom row4
12

Cisco Catalyst 9400 Series 24-Port 1G SFP Module (C9400-LC-24S)
24-port, 1 Gigabit Ethernet SFP module.
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports 10/100/1000BASE-T with Cu-SFP module.
• Supports full duplex traffic.
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
Description
24 Gbps, full duplex non-blocking trafficPer Slot Bandwidth
• Catalyst 9404R Switch—24 / 48
• Catalyst 9407R Switch—24 / 120
• Catalyst 9410R Switch—24 / 192
Minimum / Maximum Port
Density5
Can be installed in any non-supervisor module slot. There are no other restrictions.Support and Restrictions
5The number of ports available on a single switch
13

Figure 5: Front View of the C9400-LC-24S Switching Module
14

Cisco Catalyst 9400 Series 48-Port Gigabit Ethernet POE/POE+ Module (C9400-LC-48P)
48-port, 10/100/1000 BASE-T Gigabit Ethernet switching module supporting up to 30W per port
on each of its 48 ports .
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports Energy Efficient Ethernet (EEE)
• You can speicfy maximum power consumption on every port.
• Supports POE cable loss management.
• Supports EnergyWise 3.0
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
Description
48 Gbps, full duplex non-blocking trafficPer Slot Bandwidth
• Catalyst 9404R Switch—48 / 96
• Catalyst 9407R Switch—48 / 240
• Catalyst 9410R Switch—48 / 384
Minimum / Maximum Port
Density6
Can be installed in any non-supervisor module slot. There are no other restrictions.Support and Restrictions
6The number of ports available on a single switch
15

Figure 6: Front View of the C9400-LC-48P Switching Module
Switching module Radio Frequency Identifier (RFID)5STATUS LED1
Captive installation screws6LOCATE (blue beacon) LED2
Ejector levers7PORT LINK LED for the port in the top row3
Model or product number8PORT LINK LED for the port in the bottom row4
16

Cisco Catalyst 9400 Series 48-Port UPOE+ 10/100/1000 Module (C9400-LC-48H)
48-port, 10/100/1000 BASE-T Gigabit Ethernet, IEEE 802.3bt compliant module supporting up
to 90 W Cisco UPOE+ on each of its 48 RJ45 ports.
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Supports Cisco Phone Discovery and IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt.
• Supports Energy Efficient Ethernet (EEE)
• Supports PoE Cable Loss Management
• Saves power with direct power delivery from backplane
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
• The following switching module features are configured in software. See the software
configuration guide for more information:
• Provides per port power consumption measurement
• Enables you to specify maximum power consumption on every port
• Supports PoE Power Configuration
• The 10-slot (Catalyst 9410R Switch) chassis has a maximum of 384 1Gbps ports but
can support up to 260 90W PoE ports concurrently.
Description
48 Gbps, full duplex non-blocking trafficPer Slot Bandwidth
• Catalyst 9404R Switch—48 / 96
• Catalyst 9407R Switch—48 / 240
• Catalyst 9410R Switch—48 / 384
Minimum / Maximum Port
Density7
17

• Can be installed in any non-supervisor module slot.
• Ensure that the chassis power supply configuration supports the PoE budget adequately. Use
the Cisco Power Calculator for power budgeting estimates and to determine power supply
requirements for a specific PoE configuration.
• Some legacy Cisco powered devices (like 7910, 7940, 7960 IP phones and AP350 wireless
access points) are incompatible with Type 4 Power Supply Equipments (PSEs), as defined
in the IEEE 802.3bt standard. If connected, the PSE reports a ‘Tstart’ or ‘Imax’ fault with
each periodic attempt at providing power to the powered device. For continued use of these
legacy Cisco powered devices, connect them to Cisco PoE+/UPOE PSEs.
•C9400-LC-48H module is supported only on Cisco IOS XE Release 16.12.1 and later releases.
Before inserting the module, ensure that the device software is Cisco IOS XE Release 16.12.1
or a later release.
Before downgrading the software on the device from Cisco IOS XE 16.12.1 to earlier releases,
ensure that you remove the C9400-LC-48H module.
Support and Restrictions
7The number of ports available on a single switch
18

Figure 7: Front View of the C9400-LC-48H Switching Module
Switching module Radio Frequency Identifier (RFID)5STATUS LED1
Captive installation screws6LOCATE (blue beacon) LED2
Ejector levers7PORT LINK LED for the port in the top row3
Model or product number8PORT LINK LED for the port in the bottom row4
19

Ten Gigabit Ethernet Switching Modules
Cisco Catalyst 9400 Series 24-Port SFP/SFP+ Module (C9400-LC-24XS)
24 Port SFP/SFP+ 10 Gigabit Ethernet Module. These ports can be interchangeably used as 1G
and 10G ports.
• Hardware ready for IEEE 1588/802.1as— A Precision Time Protocol (PTP) used for time
synchronization across the network for video and audio applications.
• Bandwidth is allocated across four 6-port groups, providing 20 Gbps per port group.
• Has a built-in, front-facing, passive RFID tag that uses Ultra High Frequency (UHF) RFID
technology and requires an RFID reader with compatible software. It provides
auto-identification capabilities for asset management and tracking. The RFID tags are
compatible with the Generation 2 GS1 EPC Global Standard and are ISO 18000-6C compliant.
They operate in the 860- to 960-MHz UHF band. For more information, see Radio Frequency
Identification (RFID) on Cisco Catalyst 9000 Family Switches.
Description
Per slot bandwidth is enabled by the software and the supervisor module:
80Gbps with C9400-SUP-1.
120 Gbps for C9400-SUP-1XL on a seven-slot chassis.
Per Slot Bandwidth
• Catalyst 9404R Switch—24/48
• Catalyst 9407R Switch—24/120
• Catalyst 9410R Switch— 24/192
Minimum / Maximum Port
Density8
Can be installed in any non-supervisor module slot. There are no other restrictions.Support and Restrictions
8The number of ports available on a single switch
20
