EDCS - 441268 Revision 7
Application Note
Siemens HiPath 4000 Release 1 and Siemens Hicom 330E
Release 3.1 to Cisco IOS Voice Gateway using E1 QSIG with
H.323
October 30, 2007 Revision 7
Table of Contents
Introduction ..............................................................................................................................................................................................................1
Network Topology....................................................................................................................................................................................................2
System Components.................................................................................................................................................................................................2
Hardware Requirements......................................................................................................................................................................................2
Software Requirements .......................................................................................................................................................................................2
Features ....................................................................................................................................................................................................................3
Features Supported..............................................................................................................................................................................................3
Features Not Supported.......................................................................................................................................................................................3
Limitations................................................................................................................................................................................................................3
Configuration............................................................................................................................................................................................................4
Configuring the Siemens HiPath 4000 ................................................................................................................................................................4
Configuring the Siemens Hicom 330E..............................................................................................................................................................17
Configuring the Cisco 1760...............................................................................................................................................................................28
Configuring the Cisco 2851...............................................................................................................................................................................33
Acronyms ...............................................................................................................................................................................................................39
Introduction
•Although specific gateway router models were used to validate its content, this application note also applies to all Cisco
1700/2600/3600/3700/2800/3800 series Cisco IOS voice gateways.
•This application note provides configuration guidelines for a toll-bypass network using Cisco IOS voice gateways to connect Siemens
HiPath 4000 Release 1 and Siemens Hicom 330E Release 3.1 PBXs. The PBXs are connected to the Cisco IOS voice gateways by E1
QSIG trunk circuits. The Cisco IOS voice gateways “extend” the E1 QSIG trunk circuits with VoIP, using the H.323 protocol.
•A Siemens HiPath 4000 Release 1 PBX and a Siemens Hicom 330E Release 3.1 PBX were each connected via E1 QSIG trunk circuits a
Cisco IOS voice gateway. The two voice gateways were connected via IP over Ethernet, and configured for VoIP using H.323. End-to-
end calls were placed between the PBXs to exercise and test basic calls as well as QSIG supplementary services such as call transfer, call
conference, and call forward.
•Using the Siemens PBX configurations and Cisco IOS voice gateway configurations in this application note, successful toll bypass
integration was achieved. This includes basic call, call transfer, call conference, and call forward, with some limitations on Caller ID
features during transfer scenarios. These limitations are detailed in the following sections and all were found to be inherent to the
Siemens PBXs. Thus, H.323 toll bypass introduced no new restrictions to the available features or performance.

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 2 of 41
Network Topology
Figure 1. Network Topology or Test Setup
System Components
Hardware Requirements
•(2) Cisco IOS voice gateways with E1 VWICs (voice/WAN interface cards)
•(1) Siemens HiPath 4000 PBX
•(1) Siemens Hicom 330E PBX
•(2) Siemens HiPath digital station telephones
•(2) Siemens Hicom digital station telephones
Software Requirements
•Siemens HiPath PBX: V1.0 SA12 Patch0.
•Siemens Hicom PBX: Release 3.1 SA5 Rev14
•Cisco IOS voice gateways: Cisco IOS Release Version 12.4(1.8)T or later.

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 3 of 41
Features
Features Supported
•Basic Call (ENBLOC and Overlap)
•Call Transfer: Supervised Local Transfer
•Call Transfer: Supervised Network/External Transfer
•Call Conference: Local
•Call Conference: Network/External
•Call Forward: Local
•Call Forward: Network/External
Features Not Supported
•Call Hold
•MWI
Limitations
•On basic calls, Connected Number was supported in lieu of Called (Alerting) Number. This is inherent to the PBXs and also occurs with
the PBXs connected directly via an E1 QSIG trunk.
•On Supervised Transfers, the original Calling Name and Number were displayed on the final destination phone only after the destination
answered and the transfer was completed. This is inherent to the PBXs and also occurs with the PBXs connected directly via an E1
QSIG trunk.
•On Supervised Transfers, the Called Name/Number were displayed on the originating phone only after the destination answered and the
transfer was completed. This is inherent to the PBXs and also occurs with the PBXs connected directly via an E1 QSIG trunk.
•Call Hold was not tested as a separate feature. The call is held automatically during Transfers or Conferences, and the call hold is
facilitated in NOTIFY message from Siemens HiPath/Hicom PBX. Aside from Transfers or Conferences, it is not possible to put a call
on hold from one of the Siemens HiPath/Hicom digital station phones. This is inherent to the PBXs and also occurs with the PBXs
connected directly via an E1 QSIG trunk.
•MWI was not tested, as a local voice mail system was not available on the PBXs at the time of testing.

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 4 of 41
Configuration
Configuring the Siemens HiPath 4000
DPLN
<dis-wabe:gen;
DIS-WABE:GEN;
H500: AMO WABE STARTED
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 0 |. .**** ..*** **... ..... .*| CO | R |
| 001 - 009 |* ..... ..... ..... ..... ..| NETRTE | |
| 111 |. .**** ***** **... ..... .*| TIE | |
| 12 - 14 |. .**** ***** **... ..... .*| TIE | |
| 21 |. ..... ..... ..... ....* ..| KNOVRKY | |
| 22 |. ..... ..... ..... ....* ..| DNDKY | |
| 222 |. .**** ***** **... ..... .*| TIE | |
| 23 |. ..... ..... ..... ....* ..| FWDKY | |
| 24 |. ..... ..... ..... ....* ..| MBKY | |
| 25 |. ..... ..... ..... ....* ..| MSGRKY | |
| 26 |. ..... ..... ..... ....* ..| DAKY | |
| 27 |. ..... ..... ..... ....* ..| DSSKY | |
| 28 |. ..... ..... ..... ....* ..| VCRKY | |
| 29 |. ..... ..... ..... ....* ..| VCKY | |
| 30 |. ..... ..... ..... ....* ..| CONFKY | |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 3000 - 3010 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 30 |
| | | |DNNO 0- 0-222 |
| 3011 - 3020 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 31 |
| | | |DNNO 0- 0- 31 |
| 3021 - 3030 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 32 |
| | | |DNNO 0- 0- 32 |
| 3031 - 3040 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 33 |
| | | |DNNO 0- 0- 33 |
| 3041 - 3050 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 35 |
| | | |DNNO 0- 0- 35 |
| 31 |. ..... ..... ..... ....* ..| NAMEKY | |
| 32 |. ..... ..... ..... ....* ..| PARKKY | |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 33 |. ..... ..... ..... ....* ..| CCKY | |
| 34 |. ..... ..... ..... ....* ..| HTKY | |
| 35 |. ..... ..... ..... ....* ..| STKY | |

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 5 of 41
| 36 - 37 |. .**** ..*** **... ..... .*| CO | |
| 38 |. ..... ..... ..... ....* ..| TIMEKY | |
| 39 |. .**** ***** **... ..... .*| TIE | |
| 4000 - 4050 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 111 |
| | | |DNNO 0- 0-111 |
| 4051 - 4566 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 222 |
| | | |DNNO 0- 0-222 |
| 4567 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 34 |
| | | |DNNO 0- 0-200 |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 4568 - 4999 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 222 |
| | | |DNNO 0- 0-222 |
| 5000 - 5040 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 0 |
| | | |DNNO 0- 0-555*|
| 5500 - 5501 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 56 |
| | | |DNNO 0- 0-560 |
| 555 |. .**** ***** **... ..... .*| OWNNODE | |
| 560 |. .**** ***** **... ..... .*| TIE | |
| 59 |. .**** ***** **... ..... .*| TIE | |
| 6000 - 6009 |. .**** ***** **... ..... .*| STN | R |
| | | |DESTNO 0 |
| | | |DNNO 0- 0-555*|
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 7000 - 7002 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 56 |
| | | |DNNO 0- 0-560 |
| 8000 - 8050 |. .**** ***** **... ..... .*| STN | |
| | | |DESTNO 222 |
| | | |DNNO 0- 0-222 |
| 8060 |. .**** ***** **... ..... .*| TIE | |
| 8070 |. .**** ***** **... ..... .*| TIE | |
| 83 |. .**** ..*** **... ..... .*| SPDC1 | |
| 84 |. .**** ..*** **... ..... .*| SPDC2 | |
| 88 |. ..... ..*.. ..... ..... .*| SCONSI | R |
| 89 |. ..... ...*. ..... ..... ..| SCONSCO | R |
| 9 |. .**** ***** **... ..... .*| TIE | |
| *13 |. ....* ..... ..... ..... ..| AHTVCE | |
| *15 |. *.... ..**. ..... ..... .*| SPLIT | |
| *16 |. ....* ..... ....* ..... ..| AREM | |
| *17 |. *.... ..**. ..... ..... ..| TRACE | |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| *18 |. ....* ..... ..... ..... ..| ACOSX | |
| *19 |. *.... ..... ..... ..... ..| KNOVR | |

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 6 of 41
| *20 |. ....* ..... ..... ..... ..| ADND | |
| *25 |. ....* ..... ..... ..... ..| FWDTERM | |
| *29 |. ....* ..... ....* ..... ..| AFFWDVCE | |
| *91 |. ....* ....* ..... ..... ..| MBOFF | |
| #91 |. ....* ....* ..... ..... ..| MBON | |
| ##27 |. ***** ..**. ..... ..... ..| MWACT | |
| ##28 |. ....* ..... ..... ..... ..| MWANS | |
| ##29 |. ....* ..... ..... ..... ..| MWCAN | |
| ##30 |. ***** ****. ..*** .**** ..| MWCANORI | |
------------------------------------------------------------------------------
AMO-WABE -111 DIALLING PLANS, FEATURE ACCESS CODES
DISPLAY COMPLETED;

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 7 of 41
Overlap Sending Dial Plan
<DISPLAY-LDPLN:TYPE=LDP,LDP="8060"-"X";
DISPLAY-LDPLN:TYPE=LDP,LDP="8060"-"X";
H500: AMO LDPLN STARTED
+--------------+-------------------------------------------------+
| | |
| LDPNO : 16 | LDP : 8060-X |
| | SPC : 22 |
| | FDSFIELD : 0 SDSFIELD : 0 PINDP : N |
+------+-------+-------------------------------------------------+
| DPLN | LROUTE| LAUTH |
|------+-------+-------------------------------------------------+
| 0 | 806 | 1 |
| 1 | 806 | 1 |
| 2 | 806 | 1 |
| 3 | 806 | 1 |
| 4 | 806 | 1 |
| 5 | 806 | 1 |
| 6 | 806 | 1 |
| 7 | 806 | 1 |
| 8 | 806 | 1 |
| 9 | 806 | 1 |
| 10 | 806 | 1 |
| 11 | 806 | 1 |
| 12 | 806 | 1 |
| 13 | 806 | 1 |
| 14 | 806 | 1 |
| 15 | 806 | 1 |
+------+-------+-------------------------------------------------+
AMO-LDPLN-111 ADMINISTRATION LCR DIALPLAN
DISPLAY COMPLETED;
ENBLOC Sending Dial Plan
<DISPLAY-LDPLN:TYPE=LDP,LDP="8060"-"XXXX";
DISPLAY-LDPLN:TYPE=LDP,LDP="8060"-"XXXX";
H500: AMO LDPLN STARTED
+--------------+-------------------------------------------------+
| | |
| LDPNO : 16 | LDP : 8060-XXXX |
| | SPC : 22 |
| | FDSFIELD : 0 SDSFIELD : 0 PINDP : N |
+------+-------+-------------------------------------------------+
| DPLN | LROUTE| LAUTH |
|------+-------+-------------------------------------------------+
| 0 | 806 | 1 |
| 1 | 806 | 1 |
| 2 | 806 | 1 |
| 3 | 806 | 1 |
| 4 | 806 | 1 |
| 5 | 806 | 1 |
| 6 | 806 | 1 |
| 7 | 806 | 1 |
| 8 | 806 | 1 |
| 9 | 806 | 1 |
| 10 | 806 | 1 |
| 11 | 806 | 1 |
| 12 | 806 | 1 |
| 13 | 806 | 1 |
| 14 | 806 | 1 |
| 15 | 806 | 1 |
+------+-------+-------------------------------------------------+

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 8 of 41
AMO-LDPLN-111 ADMINISTRATION LCR DIALPLAN
DISPLAY COMPLETED;
BCSU
<DISPLAY-BCSU:TYPE=TBL,LTG=1,LTU=2,SLOT=49;
DISPLAY-BCSU:TYPE=TBL,LTG=1,LTU=2,SLOT=49;
H500: AMO BCSU STARTED
ADDRESS : LTG 1 LTU 2 SOURCE GROUP 1
-----+-----------+---------+---+---+-+------------+-----+--------+------------+
| ASSIGNED | MODULE |FCT|HWY| | INSERTED | | | MODULE |
PEN | MODULE | TYPE |ID |BDL| | MODULE |STATE| HW-INFO| STATUS |
-----+-----------+---------+---+---+-+------------+-----+--------+------------+
49 | Q2196-X DIU-N2 1 A | | Q2196-X | 1 | -06 - | READY |
AMO-BCSU -111 BOARD CONFIGURATION, SWITCHING UNIT
DISPLAY COMPLETED;
Class of Trunk, COT
<dis-cot:21
FORMAT = ;
DIS-COT:21,;
H500: AMO COT STARTED
COT: 21 INFO:
DEVICE: INDEP SOURCE: DB
PARAMETER:
PRIORITY FOR AC WILL BE DETERMINED FROM MESSAGE PRI
RECALL IF USER HANGS UP IN CONSULTATION CALL RCL
TRUNK CALL TRANSFER XFER
TRUNK SIGNALING ANSWER ANS
CHANGEOVER FROM HOLD TO RING TONE CHRT
KNOCKING OVERRIDE POSSIBLE KNOR
CALL EXTEND FOR BUSY, RING OR CALL STATE CEBC
NETWORKWIDE AUTOMATIC CALLBACK ON BUSY CBBN
NETWORKWIDE AUTOMATIC CALLBACK ON FREE CBFN
DON'T RELEASE CALL TO BUSY HUNT GROUP BSHT
CONNECTION TO ROUTE OPTIMIZATION NODE ROPT
TSC-SIGNALING FOR NETWORKWIDE FEATURES (MANDATORY) TSCS
INCOMING CDR BY ZONE OR FROM LINE ICZL
AOC PER CALL (AUTOMATICAL OR ON REQUEST), MAND. CORNET-NQ AOCC
LINE WITH IMPLICIT NUMBERS LINO
NO TONE NTON
AMO-COT -111 CLASS OF TRUNK FOR CALL PROCESSING
DISPLAY COMPLETED;
Class of Parameters for Device Handlers, COP
<DISPLAY-COP:COPNO=21;
DISPLAY-COP:COPNO=21;
H500: AMO COP STARTED
COP: 21 INFO:
DEVICE: INDEP SOURCE: DB
PARAMETER:
LINE WITH END-OF-DIAL EOD
SPECIAL MODE SFRM
CODE CALLING RELEASE AFTER EVERY TASK CCR
REGISTRATION OF LAYER 3 ADVISORIES L3AR
CO TRUNK ACCESS:
TRUNK ACCESS TA

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 9 of 41
TOLL ACCESS:
TRUNK ACCESS TA
AMO-COP -111 CLASS OF PARAMETER FOR DEVICE HANDLER
DISPLAY COMPLETED;

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 10 of 41
Class of Services, COSSU
<DISPLAY-COSSU:TYPE=COS,COS=10;
DISPLAY-COSSU:TYPE=COS,COS=10;
H500: AMO COSSU STARTED
+------+-----------------+---------------+-----------------+
| COS | VOICE | FAX | DTE |
+------+-----------------+---------------+-----------------+
| 10 |> |
| | TA | NOCO | NOCO |
| | TSUID | NOTIE | NOTIE |
| | TNOTCR | | |
| | RKOABS | | |
| | CDRINT | | |
| | CDRS | | |
| | CDRC | | |
| | COSXCD | | |
| | VCE | | |
| | FWDNWK | | |
| | MSN | | |
| | FWDECA | | |
| | CFB | | |
| | CFNR | | |
| | FWDEXT | | |
| | | | |
+------+-----------------+---------------+-----------------+
AMO-COSSU-111 CLASSES OF SERVICE
DISPLAY COMPLETED;
<DISPLAY-COSSU:TYPE=LCOSV,LCOSV=1;
DISPLAY-COSSU:TYPE=LCOSV,LCOSV=1;
H500: AMO COSSU STARTED
+----+----------------------------------------------------------------+-----+
|LCOS| LAUTH | |
| V | 1 2 3 4 5 6 | |
| |1234567890123456789012345678901234567890123456789012345678901234|COPIN|
| |>SERVICE INFORMATION | NUM |
+----+----+----|----+----|----+----|----+----|----+----|----+----|----+-----+
| 1|X...............................................................| 0 |
| |>LCR ATTENDANT FOR VOICE |
+----+----------------------------------------------------------------+-----+
AMO-COSSU-111 CLASSES OF SERVICE
DISPLAY COMPLETED;

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 11 of 41
Trunk Group, BUEND
<DISPLAY-BUEND:TGRP=20;
DISPLAY-BUEND:TGRP=20;
H500: AMO BUEND STARTED
+------------------------------- FORMAT = L -----------------------------------+
| TGRP NUMBER : 20 TGRP NAME : PRI PSSV1 MAXIMUM NO. : 70 |
| CHARCON : NEUTRAL |
| SUBGROUP NO.: 3 DEVICE TYPE : S2CONN TRACENO : 0 |
| RESERVED : N SEARCH MODE : ASCENDING ACD THRESHOLD : * |
| NUMBER OF ASSOCIATED ROUTES : 2 PRIORITY : 2 |
| TDDRFLAG : ON TDDRTHRESHOLD: 3 SOURCEGROUPIDX : 1 |
| GDTRRULE : 0 ACDPMGRP : 0 |
| THE FOLLOWING TRUNKS (LTG-LTU-SLOT-CCT) HAVE BEEN ALLOCATED: |
+------------------------------------------------------------------------------+
| 1- 2- 49-0 1 | 1- 2- 49-0 2 | 1- 2- 49-0 3 |
| 1- 2- 49-0 4 | 1- 2- 49-0 5 | 1- 2- 49-0 6 |
| 1- 2- 49-0 7 | 1- 2- 49-0 8 | 1- 2- 49-0 9 |
| 1- 2- 49-0 10 | 1- 2- 49-0 11 | 1- 2- 49-0 12 |
| 1- 2- 49-0 13 | 1- 2- 49-0 14 | 1- 2- 49-0 15 |
| 1- 2- 49-0 16 | 1- 2- 49-0 17 | 1- 2- 49-0 18 |
| 1- 2- 49-0 19 | 1- 2- 49-0 20 | 1- 2- 49-0 21 |
| 1- 2- 49-0 22 | 1- 2- 49-0 23 | 1- 2- 49-0 24 |
| 1- 2- 49-0 25 | 1- 2- 49-0 26 | 1- 2- 49-0 27 |
| 1- 2- 49-0 28 | 1- 2- 49-0 29 | 1- 2- 49-0 30 |
+------------------------------------------------------------------------------+
AMO-BUEND-111 TRUNK GROUP
DISPLAY COMPLETED;
Trunk Configuration, TDCSU
<DISPLAY-TDCSU:PEN1=1-2-49-0;
DISPLAY-TDCSU:PEN1=1-2-49-0;
H500: AMO TDCSU STARTED
+------------------------ DIGITAL TRUNK (FORMAT=L) -------------------------+
| DEV = S2CONN PEN = 1-02-049-0 TGRP = 20 |
|---------------------------------------------------------------------------|
| PROTVAR = PSS1V2 INS = N SRCHMODE = ASC |
| COTNO = 21 COPNO = 21 DPLN = 0 |
| ITR = 1 COS = 10 LCOSV = 1 |
| LCOSD = 1 CCT = HICOM S2 DESTNO = 1 |
| SEGMENT = 1 DEDSCC = DEDSVC = NONE |
| FACILITY = DITIDX = SRTIDX = |
| TRTBL = GDTR SIDANI = N ATNTYP = TIE |
| CBMATTR = NONE NWMUXTIM = 10 TCHARG = N |
| SUPPRESS = 0 DGTPR = CHIMAP = N |
| ISDNIP = ISDNNP = |
| PNPL2P = PNPL1P = PNPAC = |
| TRACOUNT = 31 SATCOUNT = MANY NNO = 1 -1 -300 |
| ALARMNO = 0 FIDX = 1 CARRIER = 1 |
| ZONE = EMPTY COTX = 21 FWDX = 5 |
| DOMTYPE = DOMAINNO = TPROFNO = |
| INIGHT = CCHDL = |
| UUSCCX = 16 UUSCCY = 8 FNIDX = 1 |
| CLASSMRK = EC & G711 & G729OPT SRCGRP = |
| TCCID = |
|---------------------------------------------------------------------------|
| BCNEG = N BCGR = 1 LWPAR = 1 |
| LWPP = 0 LWLT = 0 LWPS = 0 |
| LWR1 = 0 LWR2 = 0 |
| SVCDOM = |
| BCHAN = 1 && 30 |
| |
+---------------------------------------------------------------------------+

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 12 of 41
AMOUNT OF B-CHANNELS IN THIS DISPLAY-OUTPUT: 30
AMO-TDCSU-111 DIGITAL TRUNKS
DISPLAY COMPLETED;
<DISPLAY-LWPAR:DEV=INDEP,TYPE=DIUS2,BLNO=0;
DISPLAY-LWPAR:DEV=INDEP,TYPE=DIUS2,BLNO=0;
H500: AMO LWPAR STARTED
+-----------------------------------------------------------------------+
| LOADWARE PARAMETERS CIRCUIT TYPE: DIUS2 SOURCE:DB BLOCK: 1 |
+-----------------------------------------------------------------------+
| LNTYPE = COPPER VERSION = S2 QUAL = ON |
| MASTER = Y DCHAN1 = 16 DCHAN2 = 0 |
| PATTERN = D5H QUAL1 = 10 SEC. QUAL2 = 10 MIN. |
| SMD = Y PERMACT = Y FCBAB = DFH |
| CDG = N FIXEDTEI = 0 CNTRNR = 255 |
| TEIVERIF = N CRC4REP = N |
| DEV = INDEP |
| INFO = |
+-----------------------------------------------------------------------+
AMO-LWPAR-111 LOADWARE PARAMETERS FOR NETWORKING MODULES
DISPLAY COMPLETED;
For Slave Side Configuration
<DISPLAY-TDCSU:PEN1=1-2-49-0;
DISPLAY-TDCSU:PEN1=1-2-49-0;
H500: AMO TDCSU STARTED
+------------------------ DIGITAL TRUNK (FORMAT=L) -------------------------+
| DEV = S2CONN PEN = 1-02-049-0 TGRP = 20 |
|---------------------------------------------------------------------------|
| PROTVAR = PSS1V2 INS = N SRCHMODE = ASC |
| COTNO = 21 COPNO = 21 DPLN = 0 |
| ITR = 1 COS = 10 LCOSV = 1 |
| LCOSD = 1 CCT = HICOM S2 DESTNO = 1 |
| SEGMENT = 1 DEDSCC = DEDSVC = NONE |
| FACILITY = DITIDX = SRTIDX = |
| TRTBL = GDTR SIDANI = N ATNTYP = TIE |
| CBMATTR = NONE NWMUXTIM = 10 TCHARG = N |
| SUPPRESS = 0 DGTPR = CHIMAP = N |
| ISDNIP = ISDNNP = |
| PNPL2P = PNPL1P = PNPAC = |
| TRACOUNT = 31 SATCOUNT = MANY NNO = 1 -1 -300 |
| ALARMNO = 0 FIDX = 1 CARRIER = 1 |
| ZONE = EMPTY COTX = 21 FWDX = 5 |
| DOMTYPE = DOMAINNO = TPROFNO = |
| INIGHT = CCHDL = |
| UUSCCX = 16 UUSCCY = 8 FNIDX = 1 |
| CLASSMRK = EC & G711 & G729OPT SRCGRP = |
| TCCID = |
|---------------------------------------------------------------------------|
| BCNEG = N BCGR = 1 LWPAR = 0 |
| LWPP = 0 LWLT = 0 LWPS = 0 |
| LWR1 = 0 LWR2 = 0 |
| SVCDOM = |
| BCHAN = 1 && 30 |
| |
+---------------------------------------------------------------------------+
AMOUNT OF B-CHANNELS IN THIS DISPLAY-OUTPUT: 30
AMO-TDCSU-111 DIGITAL TRUNKS
DISPLAY COMPLETED;
<DISPLAY-LWPAR:DEV=INDEP,TYPE=DIUS2,BLNO=0;
DISPLAY-LWPAR:DEV=INDEP,TYPE=DIUS2,BLNO=0;
H500: AMO LWPAR STARTED

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 13 of 41
+-----------------------------------------------------------------------+
| LOADWARE PARAMETERS CIRCUIT TYPE: DIUS2 SOURCE:DB BLOCK: 0 |
+-----------------------------------------------------------------------+
| LNTYPE = COPPER VERSION = S2 QUAL = ON |
| MASTER = N DCHAN1 = 16 DCHAN2 = 0 |
| PATTERN = D5H QUAL1 = 10 SEC. QUAL2 = 10 MIN. |
| SMD = N PERMACT = Y FCBAB = DFH |
| CDG = N FIXEDTEI = 0 CNTRNR = 255 |
| TEIVERIF = N CRC4REP = N |
| DEV = INDEP |
| INFO = |
+-----------------------------------------------------------------------+
AMO-LWPAR-111 LOADWARE PARAMETERS FOR NETWORKING MODULES
DISPLAY COMPLETED;
Reference Clock Configuration, REFTA
For Master-side configuration
<DISPLAY-REFTA:TYPE=CIRCUIT,PEN=1-2-49-0;
DISPLAY-REFTA:TYPE=CIRCUIT,PEN=1-2-49-0;
H500: AMO REFTA STARTED
+-------------------------------------------------------------------------+
| R E F E R E N C E C L O C K C I R C U I T S |
+--------------+---------+----------+---+------+------+------+-----+------+
| PEN | MODULE | DEVICE |PRI|ERROR |BLOCK |SUPP. |READY|SRCGRP|
| | | | | | | |BUT | |
| | | | | | | |ASYN.| |
+--------------+---------+----------+---+------+------+------+-----+------+
| 1- 2- 49- 0 | DIU-N2 | S2CONN | 1| 0| N | | N | 1|
+--------------+---------+----------+---+------+------+------+-----+------+
AMO-REFTA-111 REFERENCE CLOCK TABLE
DISPLAY COMPLETED;
For Slave-side configuration
<DISPLAY-REFTA:TYPE=CIRCUIT,PEN=1-2-49-0;
DISPLAY-REFTA:TYPE=CIRCUIT,PEN=1-2-49-0;
H500: AMO REFTA STARTED
+-------------------------------------------------------------------------+
| R E F E R E N C E C L O C K C I R C U I T S |
+--------------+---------+----------+---+------+------+------+-----+------+
| PEN | MODULE | DEVICE |PRI|ERROR |BLOCK |SUPP. |READY|SRCGRP|
| | | | | | | |BUT | |
| | | | | | | |ASYN.| |
+--------------+---------+----------+---+------+------+------+-----+------+
| 1- 2- 49- 0 | DIU-N2 | S2CONN | 0| 0| N | | N | 1|
+--------------+---------+----------+---+------+------+------+-----+------+
AMO-REFTA-111 REFERENCE CLOCK TABLE
DISPLAY COMPLETED;
Trunk Least Cost Routing Configuration
<DISPLAY-LDAT:TYPE=LCR;
DISPLAY-LDAT:TYPE=LCR;
H500: AMO LDAT STARTED
+--------------------------------------------------------------------------+
| LROUTE = 806 LDPLN NAME = OPEN NUMBER SERVICE = ALL |
| TYPE = LCR DNNO OF ROUTE = 99 |
| SERVICE INFO = |
+-------+-----+-----+-----+------+----------+------------+----------+------+
| | | | | | SCHEDULE | CARRIER | | |
| LRTEL | LVAL| TGRP| ODR| LAUTH| ABCDEFGH | ZONE | LATTR | LDSRT|
+-------+-----+-----+-----+------+----------+------------+----------+------+

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 14 of 41
| 1 | 1| 20| 15| 1 | ******** | 1 EMPTY | NONE | |
| | DNNO = 99 |
+--------------------------------------------------------------------------+

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 15 of 41
RICHT
<DISPLAY-RICHT:MODE=LRTE;
DISPLAY-RICHT:MODE=LRTE;
H500: AMO RICHT STARTED
+-----------------------------------------------------------------+
| LRTE = 806 NAME = OPEN NUMBER (NEUTRAL) LSVC = ALL |
| DNNO = 99 PDNNO = 0 DESTNO = 99 |
| ROUTOPT = YES REROUT = YES PLB = NO FWDBL = NO |
| DTMFCNV = WITHOUT DTMFDSP = WITHOUT DTMFTEXT = |
| DTMFPULS = BUGS = LIN ROUTATT = NO MAINGRP = 32 |
| EMCYRTT = NO CONFTONE = NO RERINGRP = NO RTENO = 32 |
| INFO = |
| NOPRCFWD = NO |
+-----------------------------------------------------------------+
| TGRP = 20 LDAT PRI PSSV1 (NEUTRAL) SUBGROUP = 3 |
+-----------------------------------------------------------------+
AMO-RICHT-111 TRUNK ROUTING
DISPLAY COMPLETED;
Out-going Dialing Rule, LODR
<dis-lodr
ODR = ;
DIS-LODR:;
H500: AMO LODR STARTED
+--------+----------------------------------------------+
| ODR POSITION CMD PARAMETER |
+--------+----------------------------------------------+
| 15 | 1 ECHO 2 |
| | 2 END |
+--------+----------------------------------------------+
AMO-LODR -111 ADMINISTRATION OF LCR OUTDIAL RULES
DISPLAY COMPLETED;
Digital Station Configuration
<DISPLAY-SBCSU:STNO=5004;
DISPLAY-SBCSU:STNO=5004;
H500: AMO SBCSU STARTED
---------------------------- USER DATA ---------------------------------------
STNO =5004 OPT =OPTI COS1 =2 DPLN =1
MAINO =5004 CONN =DIR COS2 =2 ITR =1
PEN = 1- 3- 31- 4 LCOSV1 =6 COSX =0
INS =Y ASYNCT =500 LCOSV2 =6
PERMACT = LCOSD1 =6
SSTNO =N EXTBUS = LCOSD2 =6 CBKBMAX =5
TRACE =N RCBKB =N
ALARMNO =0 DFSVCANA= SPDI =0 RCBKNA =N
HMUSIC =0 FLASH = SPDC1 = CBKNAMB =Y
PMIDX =1 SPDC2 =
COMGRP =0
SECR =N DIGNODIS=N DSSTNA =N
STD =55 CALLOG =NONE DSSTNB =Y TEXTSEL =ENGLISH
REP =0 OPTICOM =N OPTIUSB : VPI =
IDCR =N OPTICA =1 OPTIS0A :0 VCI =
OPTIDA =1 OPTISPA :0 PATTERN =
OPTIABA :0
DCFWBUSY=N HEADSET =N APICLASS=
DNIDSP =N HSKEY =NORMAL ACFAPPL =
DTMFBLK =N IPPASSW =
DTMFCTRD=Y BASICSVC=

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 16 of 41
DVCFIG =OPTISET TSI =1 SPROT = SOPTIDX =
DPROT = DOPTIDX =
FPROT = FOPTIDX =
------------------- ACTIVATION IDENTIFIERS FOR FEATURES ----------------------
FWDS :N HTOS :N DND :N
FWDD :N HTOD :N VCP :Y TWLOGIN :N
FWDF :N HTOF :N CWT :N
------------------- FEATURES AND GROUP MEMBERSHIPS ---------------------------
PUGR : ESSTN :
KEYSYS :N NOPTNO :
HUNT CD :N
------------------- SUBSCRIBER ATTRIBUTES (AMO SDAT) -------------------------
NONE
------------------------------------------------------------------------------
AMO-SBCSU-111 STATION AND S0-BUS CONFIGURATION OF SWITCHING UNIT
DISPLAY COMPLETED;
<

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 17 of 41
Configuring the Siemens Hicom 330E
DPLN
<dis-wabe;
TYPE = gen;
DIS-WABE:GEN;
H500: AMO WABE STARTED
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 001 - 010 |* ..... ..... ..... ..... ..| NETRTE | |
| 1000 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 25 |
| | | |DNNO 0- 0- 25 |
| 11 |. ..... ..... ..... ....* ..| MBKY | |
| 111 |. .**** ***** **... ..... ..| TIE | |
| 222 |. .**** ***** **... ..... ..| OWNNODE | |
| 3000 - 3010 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 33 |
| | | |DNNO 0- 0-333 |
| 3011 - 3020 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 43 |
| | | |DNNO 0- 0-444 |
| 3021 - 3030 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 53 |
| | | |DNNO 0- 0-445 |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 3031 - 3040 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 63 |
| | | |DNNO 0- 0-446 |
| 3041 - 3050 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 73 |
| | | |DNNO 0- 0-447 |
| 3051 - 3060 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 83 |
| | | |DNNO 0- 0-448 |
| 32 |. .**** ***** **... ..... ..| TIE | |
| 34 - 36 |. .**** ***** **... ..... ..| TIE | |
| 39 |. .**** ***** **... ..... ..| TIE | |
| 4000 - 4050 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 111 |
| | | |DNNO 0- 0-111 |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 4051 - 4599 |. .**** ***** **... ..... ..| STN | R |
| | | |DESTNO 0 |

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 18 of 41
| | | |DNNO 0- 0-222*|
| 4700 - 4999 |. .**** ***** **... ..... ..| STN | R |
| | | |DESTNO 0 |
| | | |DNNO 0- 0-222*|
| 5000 - 5009 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 55 |
| | | |DNNO 0- 0- 55 |
| 5010 |. .**** *.*** **... ..... ..| ATNDIND | R |
| 5011 - 5020 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 55 |
| | | |DNNO 0- 0- 55 |
| 5021 - 5050 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 111 |
| | | |DNNO 0- 0-111 |
| 5051 |. .**** *.*** **... ..... ..| ATNDIND | |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 5500 - 5501 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 56 |
| | | |DNNO 0- 0-560 |
| 555 |. .**** ***** **... ..... ..| TIE | |
| 560 |. .**** ***** **... ..... ..| TIE | |
| 6000 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 33 |
| | | |DNNO 0- 0-333 |
| 7000 - 7002 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 56 |
| | | |DNNO 0- 0-560 |
| 79 |. .**** ***** **... ..... ..| TIE | |
| 8000 - 8019 |. .**** ***** **... ..... ..| STN | |
| | | |DESTNO 0 |
| | | |DNNO 0- 0-222*|
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| 8020 |. .**** ***** **... ..... ..| STN | R |
| | | |DESTNO 0 |
| | | |DNNO 0- 0-222*|
| 854 |. .**** ***** **... ..... ..| NETW | R |
| | | |DESTNO 2 |
| | | |DNNO 0- 0- 0 |
| 9 |. .**** ***** **... ..... ..| TIE | |
| *66 |. ....* ..... ..... ..... ..| SIGNON | |
| *91 |. ....* ....* ..... ..... ..| MBOFF | |
| #66 |. ....* ..... ..... ..... ..| SIGNOFF | |
| #91 |. ....* ....* ..... ..... ..| MBON | |
| ##22 |. ..... ..... ..... ....* ..| DAKY | |
| ##24 |. ..... ..... ..... ....* ..| DSSKY | |
| ##25 |. ..... ..... ..... ....* ..| FWDKY | |
| ##26 |. ..... ..... ..... ....* ..| HTKY | |
| ##27 |. ..... ..... ..... ....* ..| KNOVRKY | |
| ##28 |. ..... ..... ..... ....* ..| MBKY | |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 19 of 41
------------------------------------------------------------------------------
| ##29 |. ..... ..... ..... ....* ..| MSGRKY | |
| ##35 |. ..... ..... ..... ....* ..| TIMEKY | |
| ##36 |. ..... ..... ..... ....* ..| VCKY | |
| ##37 |. ..... ..... ..... ....* ..| VCRKY | |
| ##38 |. ..... ..... ..... ....* ..| CCKY | |
| ##39 |. ..... ..... ..... ....* ..| CONFKY | |
| ##41 |. ..... ..... ..... ....* ..| NAMEKY | |
| ##42 |. ..... ..... ..... ....* ..| PARKKY | |
| ##43 |. ..... ..... ..... ....* ..| REMKY | |
| ##44 |. ..... ..... ..... ....* ..| STKY | |
| ##45 |. ..... ..... ..... ....* ..| CBKKY | |
| ##46 |. ..... ..... ..... ....* ..| CONSKY | |
| ##47 |. ..... ..... ..... ....* ..| DNDKY | |
| ##48 |. ..... ..... ..... ....* ..| EXHOLDKY | |
| ##49 |. ..... ..... ..... ....* ..| HOLDKY | |
| ##50 |. ..... ..... ..... ....* ..| IUSEKY | |
| ##51 |. ..... ..... ..... ....* ..| LNRKY | |
------------------------------------------------------------------------------
| DIGIT INTERPRETATION VALID FOR ALL DIAL PLANS |
------------------------------------------------------------------------------
| | CALL PROGRESS STATE | DIGIT | RESERVED/CONVERT |
| CODE | 1 11111 11112 22| ANALYSIS | DNI/ADD-INFO |
| |0 12345 67890 12345 67890 12| RESULT | *=OWN NODE |
------------------------------------------------------------------------------
| ##52 |. ..... ..... ..... ....* ..| PRIVKY | |
| ##53 |. ..... ..... ..... ....* ..| RLSKY | |
| ##54 |. ..... ..... ..... ....* ..| SNRKY | |
| ##55 |. ..... ..... ..... ....* ..| TRNSKY | |
| ##56 |. ..... ..... ..... ....* ..| RCTOFFKY | |
| ##57 |. ..... ..... ..... ....* ..| TOGGLEKY | |
------------------------------------------------------------------------------
AMO-WABE -111 DIALLING PLANS, FEATURE ACCESS CODES
DISPLAY COMPLETED;
Overlap Sending Dial Plan
<DISPLAY-LDPLN:TYPE=LDP,LDPNO=35;
DISPLAY-LDPLN:TYPE=LDP,LDPNO=35;
H500: AMO LDPLN STARTED
+--------------+------------------------------------------+
| | |
| LDPNO : 35 | LDP : 79-X |
| | SPC : 22 |
+--------------+------+------+------++------+------+------+
| | DPLN | LRTE | LAUTH|| DPLN | LRTE | LAUTH|
| +------+------+------++------+------+------+
| | 0 | 79 | 1 || 8 | 79 | 1 |
| | 1 | 79 | 1 || 9 | 79 | 1 |
| | 2 | 79 | 1 || 10 | 79 | 1 |
| | 3 | 79 | 1 || 11 | 79 | 1 |
| | 4 | 79 | 1 || 12 | 79 | 1 |
| | 5 | 79 | 1 || 13 | 79 | 1 |
| | 6 | 79 | 1 || 14 | 79 | 1 |
| | 7 | 79 | 1 || 15 | 79 | 1 |
+--------------+------+------+------++------+------+------+
AMO-LDPLN-111 ADMINISTRATION LCR DIALPLAN
DISPLAY COMPLETED;
Enbloc Sending Dial Plan
<DISPLAY-LDPLN:TYPE=LDP,LDPNO=35;
DISPLAY-LDPLN:TYPE=LDP,LDPNO=35;

© 2007 Cisco Systems, Inc. All right reserved.
Important notices, privacy statements, and trademarks of Cisco Systems, Inc. can be found on cisco.com
Page 20 of 41
H500: AMO LDPLN STARTED
+--------------+------------------------------------------+
| | |
| LDPNO : 35 | LDP : 79-XXXX |
| | SPC : 22 |
+--------------+------+------+------++------+------+------+
| | DPLN | LRTE | LAUTH|| DPLN | LRTE | LAUTH|
| +------+------+------++------+------+------+
| | 0 | 79 | 1 || 8 | 79 | 1 |
| | 1 | 79 | 1 || 9 | 79 | 1 |
| | 2 | 79 | 1 || 10 | 79 | 1 |
| | 3 | 79 | 1 || 11 | 79 | 1 |
| | 4 | 79 | 1 || 12 | 79 | 1 |
| | 5 | 79 | 1 || 13 | 79 | 1 |
| | 6 | 79 | 1 || 14 | 79 | 1 |
| | 7 | 79 | 1 || 15 | 79 | 1 |
+--------------+------+------+------++------+------+------+
AMO-LDPLN-111 ADMINISTRATION LCR DIALPLAN
BCSU
DISPLAY COMPLETED;
<DISPLAY-BCSU:TYPE=TBL,LTG=1,LTU=1,SLOT=79;
DISPLAY-BCSU:TYPE=TBL,LTG=1,LTU=1,SLOT=79;
H500: AMO BCSU STARTED
ADDRESS : LTG 1 LTU 1
-----+-----------+---------+---+---+-+------------+-----+--------+------------+
| ASSIGNED | MODULE |FCT|HWY| | INSERTED | | | MODULE |
PEN | MODULE | TYPE |ID |BDL| | MODULE |STATE| HW-INFO| STATUS |
-----+-----------+---------+---+---+-+------------+-----+--------+------------+
79 | Q2196-X DIU-N2 1 A | | Q2196-X | 1 | -06 - | READY |
AMO-BCSU -111 BOARD CONFIGURATION, SWITCHING UNIT
DISPLAY COMPLETED;
Class of Trunk, COT
<DISPLAY-COT:COTNO=5;
DISPLAY-COT:COTNO=5;
H500: AMO COT STARTED
COT: 5 INFO: 5:ECMA1 V2.0
DEVICE: INDEP SOURCE: DB
PARAMETER:
PRIORITY FOR AC WILL BE DETERMINED FROM MESSAGE PRI
RECALL IF USER HANGS UP IN CONSULTATION CALL RCL
TRUNK CALL TRANSFER XFER
TRUNK SIGNALING ANSWER ANS
CHANGEOVER FROM HOLD TO RING TONE CHRT
KNOCKING OVERRIDE POSSIBLE KNOR
CALL EXTEND FOR BUSY, RING OR CALL STATE CEBC
NETWORKWIDE AUTOMATIC CALLBACK ON BUSY CBBN
NETWORKWIDE AUTOMATIC CALLBACK ON FREE CBFN
DON'T RELEASE CALL TO BUSY HUNT GROUP BSHT
CONNECTION TO ROUTE OPTIMIZATION NODE ROPT
TSC-SIGNALING FOR NETWORKWIDE FEATURES (MANDATORY) TSCS
INCOMING CDR BY ZONE OR FROM LINE ICZL
AOC PER CALL (AUTOMATICAL OR ON REQUEST), MAND. CORNET-NQ AOCC
LINE WITH IMPLICIT NUMBERS LINO
NO TONE NTON
AMO-COT -111 CLASS OF TRUNK FOR CALL PROCESSING
DISPLAY COMPLETED;
