Cisco DPC3848 User manual

OL-30544-01
CiscoModel DPC3848, DPC3848V,
and DPC3848VMDOCSIS 3.0 24x8
WirelessResidentialGateway
User Guide

PleaseRead
Important
Read this entire guide. If this guide provides installation or operation instructions,
give particular attention to all safety statements included in this guide.

Notices
TrademarkAcknowledgments
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its
affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this
URL: www.cisco.com/go/trademarks. DOCSIS is a registered trademark of Cable
Television Laboratories, Inc. The Wi-Fi Protected Setup mark is a mark of the Wi-Fi
Alliance.
Other third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between
Cisco and any other company. (1110R)
Publication Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that may
appear in this publication. We reserve the right to change this publication at any
time without notice. This document is not to be construed as conferring by
implication, estoppel, or otherwise any license or right under any copyright or
patent, whether or not the use of any information in this document employs an
invention claimed in any existing or later issued patent.
Disclaimer
The maximum performance for wireless is derived from IEEE Standard 802.11
specifications. Actual performance can vary, including lower wireless network
capacity, data throughput rate, range and coverage. Performance depends on many
factors, conditions and variables, including distance from the access point, volume of
network traffic, building materials and construction, operating system used, mix of
wireless products used, interference and other adverse conditions.
Software and Firmware Use
The software described in this document is protected by copyright law and
furnished to you under a license agreement. You may only use or copy this software
in accordance with the terms of your license agreement.
The firmware in this equipment is protected by copyright law. You may only use the
firmware in the equipment in which it is provided. Any reproduction or distribution
of this firmware, or any portion of it, without our express written consent is
prohibited.

Copyright
© 2014 Cisco Systems, Inc. All rights reserved.
Information in this publication is subject to change without notice. No part of this
publication may be reproduced or transmitted in any form, by photocopy,
microfilm, xerography, or any other means, or incorporated into any information
retrieval system, electronic or mechanical, for any purpose, without the express
permission of Cisco Systems, Inc.

NoticetoInstallers
The servicing instructions in this notice are for use by qualified service personnel only. To reduce the
risk of electric shock, do not perform any servicing other than that contained in the operating
instructions, unless you are qualified to do so.
Notice àl’attention desinstallateurs deréseaux câblés
Les instructions relatives aux interventions d’entretien, fournies dans la présente notice, s’adressent
exclusivement au personnel technique qualifié. Pour réduire les risques de chocs électriques, n’effectuer
aucune intervention autre que celles décrites dans le mode d'emploi et les instructions relatives au
fonctionnement, à moins que vous ne soyez qualifié pour ce faire.

MitteilungfürCATV-Techniker
Die in dieser Mitteilung aufgeführten Wartungsanweisungen sind ausschließlich für qualifiziertes
Fachpersonal bestimmt. Um die Gefahr eines elektrischen Schlags zu reduzieren, sollten Sie keine
Wartungsarbeiten durchführen, die nicht ausdrücklich in der Bedienungsanleitung aufgeführt sind,
außer Sie sind zur Durchführung solcher Arbeiten qualifiziert.
Avisoa losinstaladores desistemas CATV
Las instrucciones de reparación contenidas en el presente aviso son para uso exclusivo por parte de
personal de mantenimiento cualificado. Con el fin de reducir el riesgo de descarga eléctrica, no realice
ninguna otra operación de reparación distinta a las contenidas en las instrucciones de funcionamiento, a
menos que posea la cualificación necesaria para hacerlo.
20080814_Installer820_Intl

OL-30544-01 iii
Contents
IMPORTANT SAFETYINSTRUCTIONS v
United States FCC Compliance viii
About This Guide x
Introducingthe DOCSIS 3.0 Wireless ResidentialGateway 1
Introduction .........................................................................................................................2
What's In th e Carto n? ..........................................................................................................3
Fro nt Panel Description ......................................................................................................4
Back Panel Desc ription .......................................................................................................6
Top Panel Desc ription.........................................................................................................8
Installingthe DOCSIS 3.0 Wireless ResidentialGateway 9
Installation P reparatio ns ...................................................................................................10
Install the Wireless Res idential Gateway ........................................................................15
MoCA Installation Guid elines ..........................................................................................18
OperationofFront Panel Indicators 21
Initial Power On, Calibratio n, and Registration (AC Power applied) ...........................22
Normal Op erations (AC Power Applied) .......................................................................23
Special Co nditions .............................................................................................................24
Troubleshootingthe DOCSIS 3.0 Wireless Residential Gateway 25
Fre que ntly Ask ed Questio ns ............................................................................................26
Common Troubles hooting Issues ....................................................................................31
Tips for Improved Performa nce .......................................................................................32
CustomerInformation 33

IMPORTANT SAFETY INSTRUCTIONS
OL-30544-01 v
IMPORTANT SAFETY INSTRUCTIONS
1)
Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4)
Follow all instructions.
5)
Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10)
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12)
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use ca ution when
moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged inany way, such as a power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Power SourceWarning
A label on this product indicates the correct power source for this product. Operate this product only
from an electrical outlet with the voltage and frequency indicated on the product label. If you are
uncertain of the type of power supply to your home or business, consult your service provider or your
local power company.
The AC inlet on the unit must remain accessibleand operable at all times.
Groundthe Product
WARNING: Avoid e lectr ic shock a nd fir e hazard! I f this product conne cts to coax ial
cable wiring, be sure the cable system is grounded (earthed). Grounding provides
some protection against voltage surges and built-up static charges.

IMPORTANT SAFETY INSTRUCTIONS
vi OL-30544-01
Protect theProductfromLightning
In addition to disconnecting the AC power from the wall outlet, disconnect the signal inputs.
Verify the PowerSource fromtheOn/Off Power Light
When the on/off power light is not illuminated, the apparatus may still be connected to the power
source. The light may go out when the apparatus is turned off, regardless of whether it is still plugged
into an AC power source.
Eliminate AC Power/MainsOverloads
WARNING: Avoid ele ctr ic shock a nd fire hazard! Do not overloa d AC power/mains,
outlets, ext
ension cords, or integral convenience receptacles. For products that require
battery power or other power sources to operate them, refer to the operating
instr uctions for those products.
Provide Ventilation andSelect aLocation
Remove all packaging material before applying power to the product.
Do not place this apparatus on a bed, sofa, rug, or similar surface.
Do not place this apparatus on an unstable surface.
Do not install this apparatus in an enclosure, such as a bookcase or rack, unless the installation
provides proper ventilation.
Do not place entertainment devices (such as VCRs or DVDs), lamps, books, vases with liquids, or
other objects on top of this product.
Do not block ventilation openings.
OperatingEnvironment
This product is designed for operation indoors with a temperature range from 32° to 104° F (0° to 40°C).
Each product should have adequate spacing on all sides so that the cooling air vents on the chassis are
not blocked.
Protect fromExposure toMoistureandForeignObjects
WARNING: Avoid ele ctric shock and fire haza r d! Do not ex p ose this product to
dripping or splashing liquids, rain, or moisture. Objects filled with liquids, such as
vases, should not be placed on this apparatus.
WARNING: Avoid ele ctr ic shock and fir e ha z a r d! Unplug this product b e f ore cle a ning.
Do not use a liquid cleaner or an aerosol cleaner. Do not use a magnetic/static cleaning
device (dust remover) to clean this product.
WARNING: Avoid ele ctr ic shock and fir e ha z a r d! Ne ve r p ush ob jects thr ough the
openings in this product. Foreign objects can cause electrical shorts that can result in
electric shock or fire.

IMPORTANT SAFETY INSTRUCTIONS
OL-30544-01 vii
Service Warnings
WARNING: Avoid ele ctric shock! Do not open the cove r of this product. Op e ning or
removing the cover may expose you to dangerous voltages. If you open the cover, your
warranty will be void. This product contains no user-serviceable parts.
Check ProductSafety
Upon completion of any service or repairs to this product, the service technician must perform safety
checks to determine that this product is in proper operating condition.
Protect theProductWhenMovingIt
Always disconnect the power source when moving the apparatus or connecting or disconnecting
cables.

United States FCC Compliance
viii OL-30544-01
UnitedStatesFCC Compliance
This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against such interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy. If not installed and used in accordance with the
instructions, it may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment OFF and ON, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the service provider or an experienced radio/television technician for help.
Any changes or modifications not expressly approved by Cisco Systems, Inc., could void the
user's authority to operate the equipment.
The information shown in the FCC Declaration of Conformity paragraph below is a
requirement of the FCC and is intended to supply you with information regarding the FCC
approval of this device. The phone numbers listed are for FCC-related questions only and not
intended for questions regarding the connection or operation for this device. Please contact your
service provider for any questions you may have regarding the operation or installation of this device.
Declarationof Conformity
This device complies with Part 15 of FCC
Rules. Operation is subject to the following
two conditions: 1) the device may not cause
harmful interference, and 2) the device must
accept any interference received, including
interference that may cause undesired
operation.
DOCSIS 3.0 Wireless Residential Gateway
Model(s): DPC3848 DPC3848V
DPC3848VM
Manufactured by:Cisco Systems, Inc.
170 West Tasman Drive
San Jose, California 95134 USA
CanadaEMIRegulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme NMB-003 du Canada.

United States FCC Compliance
OL-30544-01 ix
2.4 Gand 5G Wi-Fi
The equipment operates in the 2400-to-2483.5 MHz, the 5150-to-5350 MHz, and the 5470-to-
5725 MHz frequency range.
RF Exposure Statements
Note: This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter. This equipment should be installed and operated with a minimum
distance of 7.9 inches (20 cm) between the radiator and your body. For products available in
the USA/Canada market, only channels 1-11 can be operated. The selection of other channels
is not possible.
US
This system has been evaluated for RF exposure for humans in reference to ANSI C 95.1
(American National Standards Institute) limits. The evaluation was based in accordance with
FCC OET Bulletin 65C rev 01.01 in compliance with Part 2.1091 and Part 15.27. The minimum
separation distance from the antenna to general bystander is 7.9 inches (20 cm) to maintain
compliance.
Canada
This system has been evaluated for RF exposure for humans in reference to Canada Health
Code 6 (2009) limits. The evaluation was based on evaluation per RSS-102 Rev 4. The
minimum separation distance from the antenna to general bystander is 7.9 inches (20 cm) to
maintain compliance.

About This Guide
x OL-30544-01
AboutThisGuide
Introduction
Welcome. This guide provides instructions and recommendations for placing,
installing, configuring, operating, maintaining, and troubleshooting the DPC3848,
DPC3848V, and DPC3848VM DOCSIS 3.0 Wireless Residential Gateways.
Purpose
This guide covers the following product models:
DPC3848 DOCSIS 3.0 Wireless Residential Gateway
DPC3848V DOCSIS 3.0 Wireless Residential Gateway
DPC3848VM DOCSIS 3.0 Wireless Residential Gateway
All features described in this guide are standard to these models of residential
gateways unless otherwise noted. For the purpose of this guide, whenever a feature
or option applies to only a specific model, the model number is specified. If a model
number is not specified, then the feature or option applies to all of the models.
Audience
This guide is written for the home subscriber.
Document Version
This is the first formal release of this document.

OL-30544-01 1
Introduction
This chapter provides an overview of residential gateway features,
indicators, and connectors to help you become familiar with the
residential gateway and the benefits it offers. This chapter also lists the
accessories and equipment that are provided with the residential
gateway so that you can verify that you received all of these items.
1Chapter 1
Introducingthe DOCSIS 3.0
Wireless Residential Gateway
InThisChapter
Introduction ..........................................................................................2
What's In th e Carto n? ...........................................................................3
Front Panel Description .......................................................................4
Back Panel Desc ription ........................................................................6
Top Panel Desc ription..........................................................................8

Chapter 1 Introducing the DOCSIS3.0 Wireless Residential Gateway
2 OL-30544-01
Introduction
Your new Cisco®Model DPC3848, DPC3848V, or DPC3848VM DOCSIS 3.0 Wireless
Residential Gateway is a high-performance home gateway that combines a cable
modem, router, and wireless access point(s) in a single device, providing a cost-
effective networking solution for both the home and small office.
This guide provides procedures and recommendations for placing, installing,
configuring, operating, and troubleshooting your residential gateway. Refer to the
appropriate section in this guide for the specific information you need for your
situation. Contact your service provider for more information about subscribing to
these services.
Your new residential gateway offers the following outstanding benefits and features:
Compliant with DOCSIS 3.0, 2.0, and 1.x standards to deliver high-end
performance and reliability
High performance broadband Internet connectivity to energize your online
experience
(Optional) Multimedia over Coax Alliance (MoCA) networking over coaxial
cable in the home
Four 1000/100/10BASE-T Ethernet ports to provide wired connectivity
Dual-band concurrent 802.11n Wireless Access Point (WAP) with eight Service
Set Identifiers (SSIDs) compatible with 802.11b/g/n and optional 802.11ac
Wireless Protected Setup (WPS), including a pushbutton switch to activate WPS
for simplified and secure wireless setup
User configurable Parental Control blocks access to undesirable Internet sites
Advanced firewall technology deters hackers and protects the home network
from unauthorized access
Attractive compact design and versatile orientation to stand vertically on a desk
or shelf, or mount easily to a wall
Color-coded interface ports and corresponding cables simplify installation and
setup
DOCSIS-compliant LED labeling and behavior provides a user and technician
friendly method to check operational status and act as a troubleshooting tool
Allows automatic software upgrades by your service provider

What's In the Carton?
OL-30544-01 3
What'sIntheCarton?
When you receive your residential gateway, you should check the equipment and
accessories to verify that each item is in the carton and that each item is undamaged.
The carton contains the following items:
One DPC3848, DPC3848V, or
DPC3848VM DOCSIS 3.0 Wireless
Residential Gateway
One AC power cord (Image may vary
from product. Item varies based on the
region where the item is used.)
One Ethernet cable (May not be
provided with all products.)
If any of these items are missing or damaged, please contact your service provider
for assistance.
Note: You need an optional cable signal splitter and additional standard RF coaxial
cables if you want to connect a Digital Home Communications Terminal (DHCT), a
set-top converter, or a TV to the same cable connection as your residential gateway.

Chapter 1 Introducing the DOCSIS3.0 Wireless Residential Gateway
4 OL-30544-01
FrontPanelDescription
The front panel of your residential gateway provides LED status indicators that
indicate how well and at what state your residential gateway is operating. See
Operation of Front Panel Indicators (on page 21), for more information on front
panel LED status indicator functions.
1POWER—ON, power is applied to the residential gateway
2DS—ON, the residential gateway is receiving data from the cable network
3US—ON, the residential gateway is sending data to the cable network
4ONLINE—ON, the residential gateway is registered on the network and fully
operational
51-4—ON, a device is connected to the Ethernet port. Blinking indicates that data
is being transferred over the Ethernet connection
62.4G—ON, the wireless access point is operational. Blinking indicates that data is
being transferred over the wireless connection. OFF indicates that the wireless
access point is not enabled
75G—ON, the wireless access point is operational. Blinking indicates that data is
being transferred over the wireless connection. OFF indicates that the wireless
access point is not enabled
