Cisco ASR 1002-F Installation guide

Cisco ASR 1002-F Router Overview and
Installation
This chapter describes the Cisco ASR 1002-F (Fixed) Router and provides procedures for installing the Cisco
ASR 1002-F Router on an equipment shelf or tabletop or in an equipment rack, and describes how to connect
interface and power cables.
This chapter contains the following sections:
•Cisco ASR 1002-F Router Description, on page 1
•Cisco ASR 1002-F Router Components, on page 4
•Installation Methods, on page 10
•General Rack Installation Guidelines, on page 11
•Guidelines for an Equipment Shelf or Tabletop Installation, on page 12
•Equipment Shelf or Tabletop Installation, on page 13
•Rack-Mounting the Cisco ASR 1002-F Router, on page 15
•Attaching the Chassis Rack-Mount Brackets, on page 16
•Installing the Cisco ASR 1002-F Router in a Rack, on page 19
•Attaching the Cable-Management Bracket, on page 23
•Attaching a Chassis Ground Connection, on page 24
•Connecting the Shared Port Adapter Cables, on page 27
•Connecting the Console and Auxiliary Port Cables, on page 27
•Connecting a Cable to the Management Ethernet Port, on page 28
•Connecting Power to the Cisco ASR 1002-F Router, on page 29
•Connecting a Terminal to the Cisco Integrated RP Console Port and Auxiliary Port, on page 36
•Connecting Cables, on page 37
Cisco ASR 1002-F Router Description
The Cisco ASR 1002-F Router is one of the Cisco ASR 1000 Series Aggregation Services Routers. The Cisco
ASR 1002-F Router supports all the general-purpose routing and security features of the Cisco ASR 1002
Router, and uses the same internal control and data-plane architecture as Cisco ASR 1002 Router.
The Cisco ASR 1002-F Router supports:
• The same features and components as the Cisco ASR 1002 Router
Cisco ASR 1002-F Router Overview and Installation
1

• An integrated 4xGE SPA interface
• Fixed 2.5 GB of system bandwidth and 4 GB DRAM
•A built-in 4x1GE SPA providing four small form-factor pluggable (SFP-based) GE connections, designated
as SPA bay 0
.
For information about the SFP transceiver modules that are compatible with Cisco ASR 1002 Built-in Gigabit
Ethernet Ports (4x1GE), refer to the “Modular Optics Compatibility” section in Cisco ASR 1000 Series
Aggregation Services Routers SIP and SPA Hardware Installation Guide .
Only Cisco software release four code supports the Cisco ASR 1002-F Router. Do not use earlier versions of
Cisco software.
Note
This section contains the following topics:
Front View
Figure 1: Cisco ASR 1002-F Router—Front View, on page 2 shows the front of the Cisco ASR 1002-F
Router with the Cisco ASR 1002-ESP-F, Cisco ASR 1000 route processor, and a SPA-4XOC12-POS installed.
Figure 1: Cisco ASR 1002-F Router—Front View
Cisco ASR 1002-SIP10-F with a SPA installed3Integrated Cisco ASR 1002-ESP-F1
——Integrated Cisco RP2
Rear View
The following image shows the rear of the Cisco ASR 1002-F Router with AC power supplies installed.
Cisco ASR 1002-F Router Overview and Installation
2
Cisco ASR 1002-F Router Overview and Installation
Front View

Figure 2: Cisco ASR 1002-F Router With AC Power Supplies—Rear View
Fan5Chassis ESD socket1
Captive installation screw6AC power supply slot 0 label2
AC power supply slot 1 label7AC power supply On (|)/Off (O) switch3
AC power inlet8AC power supply LEDs4
On the side of the Cisco ASR 1002-F Router there is an eUSB panel door and the grounding lug as shown in
the “Cisco ASR 1002-F Router Chassis Ground Lug Location and eUSB Side Panel Door” figure in the
Attaching a Chassis Ground Connection section. This panel door must not be opened. There is a Do Not
Tamper label on the panel door. Do not remove the label. If there is a problem with the eUSB flash card, then
the chassis should be returned.
Note
The follwing image shows the rear of the Cisco ASR 1002-F Router with DC power supplies installed.
Figure 3: Cisco ASR 1002-F Router With DC Power Supplies—Rear View
Captive installation screw6Chassis ESD socket1
DC power supply slot 1 label7DC power supply slot 0 label2
Ground lead8DC power supply Standby/On (|) switch3
Cisco ASR 1002-F Router Overview and Installation
3
Cisco ASR 1002-F Router Overview and Installation
Rear View

Positive lead9DC power supply LEDs4
Negative lead10Fan5
Internal fans draw cooling air into the chassis and across internal components to maintain an acceptable
operating temperature. The fans are located at the rear of the chassis. A two-hole ground connector lug is
located on the side of the chassis. Two power supplies, either two AC power supplies or two DC power
supplies, are accessed from the rear of the router.
Use only AC power supplies or DC power supplies in the Cisco ASR 1002-F Router. Do not mix power supply
types.
Caution
Cisco ASR 1002-F Router Slot Numbering
The Cisco ASR 1002-F Router contains:
• One Cisco integrated RP— R0
• One integrated Cisco ASR1000-ESP-F forwarding processor— F0
• One integrated ASR1002-SIP10-F—slot 0
• 4-Gigabit Ethernet built-in interface—slot 0/0
• SPA-5x1GE-V2—slot 0/1
The following figure shows the slot numbering for the Cisco ASR 1002-F Router.
Figure 4: Cisco ASR 1002-F Router Slot Numbering
Slot 23Slot 01
——Slot 12
Cisco ASR 1002-F Router Components
The Cisco ASR 1002-F Router system is derived from the architecture of the Cisco ASR 1002 Router. The
main components of the Cisco ASR 1002-F Router are:
• Cisco integrated RP
• Cisco integrated ASR 1002-ESP-F
• Cisco ASR 1002-SIP10-F
• AC or DC power supplies
Cisco ASR 1002-F Router Overview and Installation
4
Cisco ASR 1002-F Router Overview and Installation
Cisco ASR 1002-F Router Slot Numbering

Cisco Integrated RP and Cisco ASR 1002-ESP-F Description
The Cisco ASR 1002-F Router supports the following integrated components:
• Cisco integrated RP—The Cisco ASR 1000 Series integrated Route Processor (RP) for the Cisco ASR
1002-F Router is the central control processor and runs the network operating system. The Cisco integrated
RP supports management interfaces such as the Management Ethernet port and console and auxiliary
serial ports. It has LED status indicators, an RJ-45 plug for a BITS timing reference, and one USB port
that can be used with smart cards for secure key distribution or for image or configuration file updates.
• Cisco ASR 1002-ESP-F services processor (does not support online insertion and removal)—The Cisco
embedded services processor is based on the Cisco QuantumFlow Processor for next-generation forwarding
and queuing. It performs all baseline packet routing operations, including MAC classification, Layer 2
and Layer 3 forwarding, quality of service (QoS) classification, policing and shaping, security access
control lists (ACLs), VPNs, load balancing, and NetFlow. The Cisco ASR 1002-ESP-F can only be used
in the Cisco ASR 1002-F Router and has forwarding performance of 2.5 Gbps and does not support
online insertion or removal.
The following image shows the Cisco ASR 1002-F Router faceplate labels for the Cisco integrated RP and
Cisco ASR 1002-ESP-F.
Figure 5: Cisco Integrated RP and Cisco ASR 1002-ESP-F LEDs on Cisco ASR 1002-F Router
Cisco ASR 1002-ESP-F LEDs: PWR, STAT, ACTV,
STBY
2Cisco RP LEDs: PWR, STAT, MIN, MAJ, CRIT1
The following image shows the Cisco ASR 1002-F Router faceplate labels for the Cisco integrated RP.
Cisco ASR 1002-F Router Overview and Installation
5
Cisco ASR 1002-F Router Overview and Installation
Cisco Integrated RP and Cisco ASR 1002-ESP-F Description

Figure 6: Cisco Integrated RP Faceplate Labels
CON6Gigabit Ethernet ports 0, 1, 2, 31
LINK7BITS2
CARRIER8MGMT3
BOOT9AUX4
Cisco integrated RP STAT LED10Cisco integrated ASR 1002-SIP10-F LEDs: PWR, STAT5
The following image shows the labels for the Cisco ASR 1002-SIP10-F SPA interface processor (SIP). The
ASR 1002-F router has only one half-height removable SPA.
Figure 7: Cisco ASR 1002-SIP10-F SPA Interface Processor
Port
2
4Cisco ASR 1002-SIP10-F1
Port
1
5SPA STATUS LED2
Port
0
6Port 33
The Cisco ASR 1002-F Router SPA has three types of LEDs: two LEDs for each port on the SPA and one
STATUS LED, as shown in the following image.
Figure 8: Cisco ASR 1002-F Router SPA Faceplate
Cisco ASR 1002-F Router Overview and Installation
6
Cisco ASR 1002-F Router Overview and Installation
Cisco Integrated RP and Cisco ASR 1002-ESP-F Description

SPA
STATUS
3C/A (Carrier/Alarm)1
——A/L (Active/Loopback)2
The following table describes the Cisco ASR 1002-F Router SPA LEDs.
Table 1: Cisco ASR 1002-F Router SPA LEDs
MeaningStateColorLED
Label
SONET alarm controller is shut down.OffOffC/A
Port is enabled by software and there is a valid SONET alarm signal without any
alarms.
OnGreen
Port is enabled by software and there is at least one alarm.OnAmber
Interface is shut down.OffOffA/L
Port is enabled by software and loopback is off.OnGreen
Port is enabled by software and loopback is on.OnAmber
SPA power is off.OffOffSTATUS
SPA is ready and operational.OnGreen
SPA power is on and good and the SPA is being configured.OnAmber
Cisco Integrated ASR 1002-SIP10-F and SPA for Cisco ASR 1002-F Router
Description
The Cisco ASR 1002-SIP10-F in the Cisco ASR 1002-F Router is integrated into the chassis and you cannot
insert or remove it. The Cisco integrated ASR 1002-SIP10-F provides the physical and electrical termination
for one half-height SPA.
The Cisco integrated ASR 1002-SIP10-F interface supports all Cisco SPA interface processor functions and
services. However, the Cisco integrated ASR 1002-SIP10-F differs in the following areas:
• Functions as the base board for the Cisco integrated RP
• Is not a field-replaceable unit (FRU) and does not support online insertion and removal (OIR)
Power Supplies in the Cisco ASR 1002-F Router
The Cisco ASR 1002-F Router power supply consists of either an AC or DC input in a closed frame power
supply with two DC voltage outputs: 12 V and 3.3 V. The AC power supply operates between 85 VAC to
264 VAC and the DC power supply operates between –40.5 VDC to –72 VDC.
Cisco ASR 1002-F Router Overview and Installation
7
Cisco ASR 1002-F Router Overview and Installation
Cisco Integrated ASR 1002-SIP10-F and SPA for Cisco ASR 1002-F Router Description

The power supplies are installed into the rear of the chassis and are hot pluggable. The Cisco ASR 1002-F
Router supports up to 588 W of input power from an infrastructure standpoint, but the initial power supply
development limit is up to 470 W of output power (AC and DC input).
AC Power Supply for the Cisco ASR 1002-F Router
The AC power supply input inlet is an IEC connector with an AC switch and the current rating on the connector
and switch is 10 A. The AC power supply is secured into the chassis with two captive installation screws
mounted on the faceplate.
The following table describes the LEDs on the Cisco ASR 1002-F Router.
Table 2: Cisco ASR 1002-F Router AC Power Supply LEDs
DescriptionColorLEDLED Label
The AC input voltage is greater than 85V.GreenPower supply activityINPUT OK
If the LED is not illuminated, then either the input voltage is less than 70V, or the
power supply is turned off.
If the AC input voltage is between 70V and 85V, the INPUT OK LED can be on,
off, or flashing.
None
All fans are operational.Green
Power supply fan
activity
A bi-color LED
indicates fan status.
FAN OK
A fan failure is detected.Red
If the INPUT OK LED is illuminated, this LED is red if the DC output voltages are
below the minimum limit or above the maximum limit.
If the INPUT OK LED is not illuminated, this LED might be off or red.
Red
Power supply activityOUTPUT
FAIL
If the INPUT OK LED is illuminated, this LED is off if the DC output voltages are
within the normal operating range.
If the INPUT OK LED is not illuminated, this LED might be off or red.
Off
DC Power Supply for the Cisco ASR 1002-F Router
The DC power supply input connector is a Euro-style type of terminal block. It is compliant with safety
agencies’ guidelines and electrical requirements of the supply. The DC power supply operates within
specification from –40.5 VDC to –72 VDC continuously once the power supply DC input turn-on threshold
of –43.5 V has been reached.
The DC power supply input connector accepts three wires: one positive polarity, one negative polarity, and
one ground. There are provisions on the front panel to use a wire tie for strain relief of the DC input wiring.
The DC power supply is secured into the system chassis with two installation captive screws mounted on the
faceplate.
The following image shows the DC power supply for the Cisco ASR 1002-F Router.
Cisco ASR 1002-F Router Overview and Installation
8
Cisco ASR 1002-F Router Overview and Installation
AC Power Supply for the Cisco ASR 1002-F Router

Figure 9: DC Power Supply for the Cisco ASR 1002-F Router
Captive installation screw6Chassis ESD socket1
DC power supply slot 1 label7DC power supply slot 0 label2
Ground lead8DC power supply Standby/On (|) switch3
Positive lead9DC power supply LEDs4
Negative lead10Fan5
The following table defines the Cisco ASR 1002-F Router DC power supply LEDs on the Cisco ASR 1002-F
Router.
Table 3: Cisco ASR 1002-F Router DC Power Supply LEDs
DescriptionColorLEDLED Label
The DC power supply input voltage is greater than 43.5 VDC at turn-on and remains
green down to 39 VDC.
GreenPower supply
activity
INPUT OK
The power supply turns off due to low input voltage (falls below 39VDC) and indicates
that there is still a hazard present (voltage on the terminal block). The LED remains
amber and is active to around 20 V +/-5 V.
Amber
The input is below 15VOff
All fans are operational.Green
Power supply fan
status activity
FAN OK
A fan failure is detected.Red
The DC output is out of the specified range. When you turn the power supply on, the
red LED illuminates for two to three seconds to test LED operation before going off.
Red
Power supply
activity
OUTPUT
FAIL
The DC output voltage are within the normal operating range.Off
The table shows the DC power supply output voltage alarm range.
Cisco ASR 1002-F Router Overview and Installation
9
Cisco ASR 1002-F Router Overview and Installation
DC Power Supply for the Cisco ASR 1002-F Router

Table 4: DC Power Supply Output Voltage Alarm Threshold Ranges
MaximumMinimumOutput
12.8–13.8V10.0–11.2V12V
None2.6–3.0 V3.3V
Power Cords Supported by the Cisco ASR 1002-F Router
The following table lists the power cords that are supported by the Cisco ASR 1002-F Router.
Table 5: Power Cords Supported by the Cisco ASR 1002-F Router
DescriptionPower Cord Item Number
Power Cord, 110 V, Right AngleCAB-AC-RA
Plug, Power Cord, Australian, 10 A, Right AngleCAB-ACA-RA
Power Cord, Brazil, Right Angle, 10 ACAB-ACB10A-RA
Power Cord, Brazil, Right Angle, 16 ACAB-ACB16A-RA
Power Cord China, Right AngleCAB-ACC-RA
Power Cord Europe, Right AngleCAB-ACE-RA
Power Cord, Italian, Right AngleCAB-ACI-RA
Power Cord Argentina, Right AngleCAB-ACR-RA
Power Cord, Switzerland, Right AngleCAB-ACS-RA
Power Cord UK, Right AngleCAB-ACU-RA
Power Cord India, Right AngleCAB-IND-RA
Power Cord-Japan, Right AngleCAB-JPN-RA
Installation Methods
The Cisco ASR 1002-F Router is designed for a standalone, two-rail 19-inch rack-mount (front rail only), or
four-rail 19-inch rack-mount (front and rear rail).
Although rack-mounting is the preferred method of installation for the Cisco ASR 1002-F Router, you can
mount the chassis on an equipment shelf or tabletop.
The Cisco ASR 1002-F Router usually ships fully loaded. However, you can remove components, such as
the power supplies, from the chassis to make the chassis lighter for your rack installation.
Note
Cisco ASR 1002-F Router Overview and Installation
10
Cisco ASR 1002-F Router Overview and Installation
Power Cords Supported by the Cisco ASR 1002-F Router

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work
on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard
practices for preventing accidents. Use the statement number provided at the end of each warning to locate
its translation in the translated safety warnings that accompanied this device. Statement 1071
Warning
Before you install, operate, or service the system, read the Regulatory Compliance and Safety Information
for Cisco ASR 1000 Series Aggregation Services Routers publication. This document provides important
safety information you should know before working with the system. Statement 200
Warning
General Rack Installation Guidelines
When planning your rack installation, consider the following guidelines:
•The Cisco ASR 1002-F Router requires a minimum of 3.5 inches or 8.9 cm of vertical rack space. Measure
the proposed rack location before mounting the chassis in the rack.
•Before using a particular rack, check for obstructions (such as a power strip) that could impair rack-mount
installation. If a power strip does impair a rack-mount installation, remove the power strip before installing
the chassis, and then replace it after the chassis is installed.
• Allow sufficient clearance around the rack for maintenance. If the rack is mobile, you can push it back
near a wall or cabinet for normal operation and pull it out for maintenance (installing or moving cards,
connecting cables, or replacing or upgrading components). Otherwise, allow 19 inches/48.3 cm) of
clearance to remove field-replaceable units.
• Maintain a minimum clearance of 3 inches/7.62 cm on the front and back sides of the chassis for the
cooling air inlet and exhaust ports, respectively. Avoid placing the chassis in an overly congested rack
or directly next to another equipment rack; otherwise, the heated exhaust air from other equipment can
enter the inlet air vents and cause an overtemperature condition inside the router.
To prevent chassis overheating, never install a Cisco ASR 1002-F Router in an enclosed room that is not
properly ventilated or air-conditioned.
Caution
• Always install heavier equipment in the lower half of a rack to maintain a low center of gravity to prevent
the rack from falling over
.
• Install and use the cable-management brackets included with the Cisco ASR 1002-F Router to keep
cables organized and out of the way of the cards and processors. Ensure that cables from other equipment
already installed in the rack do not impair access to the cards or require you to disconnect cables
unnecessarily to perform equipment maintenance or upgrades
.
• Install rack stabilizers (if available) before you mount the chassis
.
Cisco ASR 1002-F Router Overview and Installation
11
Cisco ASR 1002-F Router Overview and Installation
General Rack Installation Guidelines

• Provide an adequate chassis ground (earth) connection for your router chassis.
In addition to the preceding guidelines, review the precautions for avoiding excessive temperature conditions
in the “Site Environmental Requirements” section on page 5-9 .
The following table provides the Cisco ASR 1002-F Router dimensions and weight information.
Table 6: Cisco ASR 1002-F Router Dimensions and Weight
DimensionsCisco ASR 1002-F
22.50 in. (57.15 cm)(including card handles, cable-management brackets, power supply
handles
Depth
3.47 in. (8.813 cm)—2RU rack-mount per EIA RS-310 standardHeight
17.25 in. (43.815 cm)—19-inch rack-mountWidth
40 lb (18.143 k)—fully configuredWeight
Guidelines for an Equipment Shelf or Tabletop Installation
The chassis should already be in the area where you will install it. If you have not determined where to install
your chassis, see the “Cisco ASR 1000 Series Routers Component Overview” section on page 2-1 for
information about site considerations.
If you are not rack-mounting your Cisco ASR 1000 series chassis, place it on a sturdy equipment shelf or
tabletop.
When installing the Cisco ASR 1002-F Router on an equipment shelf or tabletop, ensure that the surface is
clean and that you have considered the following:
• The Cisco ASR 1002-F Router requires at least 3 inches (7.62 cm) of clearance at the inlet and exhaust
vents (the front and rear sides of the chassis).
• The Cisco ASR 1002-F Router should be installed off the floor. Dust that accumulates on the floor is
drawn into the interior of the router by the cooling fans. Excessive dust inside the router can cause
overtemperature conditions and component failures
.
• There must be approximately 19 inches (48.3 cm) of clearance at the front and rear of the chassis to
install and replace FRUs, or to access network cables and equipment.
• The Cisco ASR 1002-F Router needs adequate ventilation. Do not install it in an enclosed cabinet where
ventilation is inadequate.
• Have the cable-management bracket available if you plan to install it on the front of the chassis.
• An adequate chassis ground (earth) connection exists for your router chassis
(see the Attaching a Chassis Ground Connection, on page 24).
• Always follow proper lifting practices as outlined in the next section, when handling the chassis.
Cisco ASR 1002-F Router Overview and Installation
12
Cisco ASR 1002-F Router Overview and Installation
Guidelines for an Equipment Shelf or Tabletop Installation

Equipment Shelf or Tabletop Installation
To mount your Cisco ASR 1002-F Router on an equipment shelf or tabletop, follow these steps:
SUMMARY STEPS
1. Remove any debris and dust from the tabletop or platform, as well as the surrounding area.
2. Lift the chassis into position on the equipment shelf or tabletop. image shows how to lift the chassis.
3. Attach the front rack-mount brackets. Locate the threaded holes in the front sides of the chassis (first holes
beyond the vent holes) and use the package of black screws that shipped with the chassis.
4. Align the front rack-mount bracket to one side of the chassis.
5. Insert and tighten the screws on one side.
6. Repeat Step 4 through Step 5 on the other side of the chassis. Use all the screws to secure the rack-mount
brackets to the chassis.
7. Gather the two cable-management brackets and screws that shipped with your chassis. The following
image shows cable-management brackets attached on the front of the Cisco ASR 1002-F Router.
8. Screw the cable-management brackets to each side of the rack-mount brackets already attached to the
chassis. Use two screws for each cable-management bracket.
9. Check that all the screws are securely tightened.
DETAILED STEPS
Step 1 Remove any debris and dust from the tabletop or platform, as well as the surrounding area.
Step 2 Lift the chassis into position on the equipment shelf or tabletop. image shows how to lift the chassis.
At least two people are required to lift the chassis onto a tabletop or platform. To prevent injury, keep your
back straight and lift with your legs, not your back. Statement 164
Warning
Figure 10: Lifting the Chassis
Cisco ASR 1002-F Router Overview and Installation
13
Cisco ASR 1002-F Router Overview and Installation
Equipment Shelf or Tabletop Installation

The chassis in the above image does not represent the Cisco ASR 1002-F Router. This is only an example of
how to lift a Cisco chassis.
Note
Step 3 Attach the front rack-mount brackets. Locate the threaded holes in the front sides of the chassis (first holes beyond the
vent holes) and use the package of black screws that shipped with the chassis.
Step 4 Align the front rack-mount bracket to one side of the chassis.
Step 5 Insert and tighten the screws on one side.
Step 6 Repeat Step 4 through Step 5 on the other side of the chassis. Use all the screws to secure the rack-mount brackets to the
chassis.
The chassis rack-mount brackets must be installed first so that you can attach the cable-management brackets
to the chassis rack-mount brackets after the chassis is installed in the rack.
Note
Step 7 Gather the two cable-management brackets and screws that shipped with your chassis. The following image shows
cable-management brackets attached on the front of the Cisco ASR 1002-F Router.
Make certain that the cable-management bracket “U” feature device has the open end pointing upwards when
you attach it to the chassis
Note
Figure 11: Attaching the Cable-Management Brackets to the Cisco ASR 1002-F Router
Chassis front rack-mount bracket3Cable-management bracket top screw hole and bottom screw hole1
——Cable-management bracket “U” feature2
Step 8 Screw the cable-management brackets to each side of the rack-mount brackets already attached to the chassis. Use two
screws for each cable-management bracket.
Step 9 Check that all the screws are securely tightened.
What to do next
Go to the Attaching a Chassis Ground Connection, on page 24 to continue the installation.
Cisco ASR 1002-F Router Overview and Installation
14
Cisco ASR 1002-F Router Overview and Installation
Equipment Shelf or Tabletop Installation

Rack-Mounting the Cisco ASR 1002-F Router
The Cisco ASR 1002-F Router can be installed in an existing rack with equipment or in an empty rack with
no equipment. The chassis can be mounted in two equipment rack types:
• Two-post rack, 19-inch or 23-inch equipment rack. Inner clearance (the width between the inner sides
of the two posts or rails) must be at least 19 inches (48.26 cm). The height of the chassis is 3.47 inches
(8.8 cm). Airflow through the chassis is from front to back
.
If you are using a two-post rack, secure the rack to the floor surface to prevent tipping and avoid bodily injury.
Note
• Four-post, 19-inch equipment rack. Inner clearance (the width between the inner sides of the two posts
or rails) must be at least 19 inches (48.26 cm). The height of the chassis is 3.47 inches/8.8 cm). Airflow
through the chassis is from front to back.
The Cisco ASR 1002-F Router can be installed with both front or rear rack-mount brackets.
Verifying Rack Dimensions
Before you install the chassis, measure the space between the vertical mounting flanges (rails) on your
equipment rack to verify that the rack conforms to the measurements shown in the following image.
SUMMARY STEPS
1. Mark and measure the distance between two holes on the left and right mounting rails. The distance should
measure 18.31 inches ± 0.06 inches (46.5 cm ± 0.15 cm).
2. Measure the space between the inner edges of the left front and right front mounting flanges on the
equipment rack. The space must be at least 17.7 inches (45 cm) to accommodate the chassis, which is
17.25 inches (43.8 cm) wide and fits between the mounting posts on the rack.
DETAILED STEPS
Step 1 Mark and measure the distance between two holes on the left and right mounting rails. The distance should measure 18.31
inches ± 0.06 inches (46.5 cm ± 0.15 cm).
Measure for pairs of holes near the bottom, middle, and top of the equipment rack to ensure that the rack posts
are parallel.
Note
Step 2 Measure the space between the inner edges of the left front and right front mounting flanges on the equipment rack. The
space must be at least 17.7 inches (45 cm) to accommodate the chassis, which is 17.25 inches (43.8 cm) wide and fits
between the mounting posts on the rack.
Cisco ASR 1002-F Router Overview and Installation
15
Cisco ASR 1002-F Router Overview and Installation
Rack-Mounting the Cisco ASR 1002-F Router

Figure 12: Verifying Equipment Rack Dimensions
Attaching the Chassis Rack-Mount Brackets
This section explains how to attach the front and rear rack-mount brackets to the chassis. Before installing
the chassis in the rack, you must install the rack-mount brackets on each side of the chassis.
The parts and tools required for installing the rack-mount brackets and cable-management brackets are listed
in the “Tools and Equipment” section on page 5-23 .
The cable-management brackets are attached to the chassis after you install the chassis rack-mount brackets
on the chassis and mount the chassis in the rack.
Note
Chassis Front Rack-Mount Brackets
Determine where in the rack you want the chassis to be mounted. If you are mounting more than one chassis
in the rack, then start from the bottom up or the center of the rack.
To install the front rack-mount brackets on the Cisco ASR 1002-F Router, perform the following steps:
SUMMARY STEPS
1. Locate the threaded holes on the side of the chassis. Make certain that you hold the front rack-mount
bracket with the ear and holes facing outward and towards the front of the chassis.
2. Position the front rack-mount bracket top hole with the chassis first top hole behind the side vent holes.
3. Insert and tighten the black screws on one side.
4. Repeat Step 1 through Step 3 on the other side of the chassis. Use the black screws to secure the rack-mount
brackets to the chassis.
5. Install the chassis in a rack. To install the Cisco ASR 1002-F Router in a rack, go to the Installing the
Cisco ASR 1002-F Router in a Rack.
Cisco ASR 1002-F Router Overview and Installation
16
Cisco ASR 1002-F Router Overview and Installation
Attaching the Chassis Rack-Mount Brackets

DETAILED STEPS
Step 1 Locate the threaded holes on the side of the chassis. Make certain that you hold the front rack-mount bracket with the
ear and holes facing outward and towards the front of the chassis.
The following image shows where to attach the front rack-mount brackets to the Cisco ASR 1002-F Router. Depending
on the bracket holes you use, the chassis may protrude in the rack.
Figure 13: Attaching the Front Rack-Mount Brackets to the Cisco ASR 1002-F Router
Front rack-mount bracket
screws
3Front rack-mount bracket ear
and holes
1
——Front rack-mount bracket2
Step 2 Position the front rack-mount bracket top hole with the chassis first top hole behind the side vent holes.
Step 3 Insert and tighten the black screws on one side.
Step 4 Repeat Step 1 through Step 3 on the other side of the chassis. Use the black screws to secure the rack-mount brackets to
the chassis.
Step 5 Install the chassis in a rack. To install the Cisco ASR 1002-F Router in a rack, go to the Installing the Cisco ASR 1002-F
Router in a Rack.
What to do next
This completes the steps for attaching the front rack-mount brackets to the Cisco ASR 1002-F Router.
Chassis Rear Rack-Mount Brackets
If you are rack-mounting the chassis using the rear rack-mount brackets, then this type of installation provides
for the chassis being recessed in the rack.
To install the rear rack-mount brackets on the Cisco ASR 1002-F Router, perform the following steps:
Cisco ASR 1002-F Router Overview and Installation
17
Cisco ASR 1002-F Router Overview and Installation
Chassis Rear Rack-Mount Brackets

SUMMARY STEPS
1. Locate the threaded ear holes on the rear side of the chassis. Make certain that you hold the rear rack-mount
bracket with the ear and holes facing outward and towards the rear of the chassis.
2. Position the rear rack-mount bracket top hole with the chassis top hole from the back.
3. Insert and tighten the screws on one side.
4. Repeat Step 1 through Step 3 on the other side of the chassis. Use the remaining screws to secure the rear
rack-mount brackets to the chassis.
DETAILED STEPS
Step 1 Locate the threaded ear holes on the rear side of the chassis. Make certain that you hold the rear rack-mount bracket with
the ear and holes facing outward and towards the rear of the chassis.
The following image shows where to attach the rear rack-mount brackets to the Cisco ASR 1002-F Router.
Figure 14: Attaching the Rear Rack-Mount Brackets to the Cisco ASR 1002-F Router
Rear rack-mount bracket screws3Rear rack-mount bracket ear and holes1
——Rear rack-mount bracket2
Step 2 Position the rear rack-mount bracket top hole with the chassis top hole from the back.
Step 3 Insert and tighten the screws on one side.
Step 4 Repeat Step 1 through Step 3 on the other side of the chassis. Use the remaining screws to secure the rear rack-mount
brackets to the chassis.
What to do next
This completes the steps for attaching the rear rack-mount brackets to the Cisco ASR 1002-F Router.
Before you mount the Cisco ASR 1002-F Router in a rack, make certain you understand which rack-mount
bracket ear holes to use when positioning the chassis in the rack. As a result of using the designated ear holes
on the rack-mount bracket, the cable-management bracket installation will be made easier.
Caution
Cisco ASR 1002-F Router Overview and Installation
18
Cisco ASR 1002-F Router Overview and Installation
Chassis Rear Rack-Mount Brackets

Installing the Cisco ASR 1002-F Router in a Rack
After installing the rack-mount brackets on the chassis, you mount the chassis by securing the rack-mount
brackets to two posts or mounting strips in the rack using the screws provided.
Because the rack-mount brackets support the weight of the entire chassis, be sure to use all the screws to fasten
the rack-mount brackets to the rack posts.
Note
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable.
Danger
The following guidelines are provided to ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the
heaviest component at the bottom of the rack
.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the
unit in the rack. Statement 1006
We recommend that you allow at least 1 or 2 inches (2.54 or 5.08 cm) of vertical clearance between the router
and any equipment directly above and below it.
To install the chassis in the rack, perform the following steps:
Step 1 On the chassis, ensure that all screws on the installed components are securely tightened.
Step 2 Make sure that your path to the rack is unobstructed. If the rack is on wheels, ensure that the brakes are engaged or that
the rack is otherwise stabilized. For chassis rack-mount installation types, see the “Two-Post Rack Installation” or the
“Four-Post Rack Installation.”
Step 3 (Optional) Install a shelf in the rack to support Cisco ASR 1002-F Router. If you use a shelf, this will help support the
chassis while you secure it to the rack.
Step 4 Lift the chassis into position between the rack posts.
Step 5 Align the mounting bracket ear holes with the rack post holes to attach the chassis to the rack.
If you are using a shelf, raise the chassis to the level of the shelf. Let the bottom of the chassis rest on the
brackets, but continue to support the chassis.
Note
Step 6 Position the chassis until the rack-mounting flanges are flush against the mounting rails on the rack.
Step 7 Hold the chassis in position against the mounting rails in the equipment rack and follow these steps:
a) Insert the bottom screw into the second bracket ear hole up from the bottom of the rack-mount ear and use a hand-held
screwdriver to tighten the screw to the rack rail.
b) Insert the top screw into the second bracket ear hole from the top of the rack-mount ear diagonally from the bottom
screw and tighten the screw to the rack rail.
Cisco ASR 1002-F Router Overview and Installation
19
Cisco ASR 1002-F Router Overview and Installation
Installing the Cisco ASR 1002-F Router in a Rack

c) Insert the four screws to secure the chassis to the rack equipment.
As a result of using the specified rack-mount bracket ear holes, the cable-management bracket can be easily
attached to the rack-mount bracket when the chassis is in the rack.
Tip
Step 8 Tighten all screws on each side to secure the chassis to the equipment rack.
What to do next
You can install your Cisco ASR 1002-F Router on a two-post or four-post rack. See the “Two-Post Rack
Installation” or the “Four-Post Rack Installation.”
Two-Post Rack Installation
The Cisco ASR 1002-F Router can be installed on a two-post rack, either a 19-inch or 23-inch rack.
Inner clearance (the width between the inner sides of the two posts or rails) must be at least 19 inches (48.26
cm). The height of the chassis is 3.47 inches (8.8 cm). Airflow through the chassis is from front to back.
Note
If you are using a two-post rack, secure the rack to the floor surface to prevent tipping and avoid bodily injury
and component damage.
Caution
Step 1 Position the chassis so the front is closest to you and lift it carefully into the rack. To prevent injury, avoid any sudden
twists or moves.
The folowing image shows the Cisco ASR 1002-F Router on a two-post rack.
Cisco ASR 1002-F Router Overview and Installation
20
Cisco ASR 1002-F Router Overview and Installation
Two-Post Rack Installation
