Configuring 1G Traffic on 8-port 10 Gigabit
Ethernet Interface Module
The 8-port 10 Gigabit Ethernet Interface Module (8X10GE) has eight ports and is supported on the Cisco
ASR 900 RSP3 module. Prior to Cisco IOS XE Everest 16.5.1, 1G traffic support was provided only with the
devices placed in the access layer. Effective Cisco IOS XE Everest 16.5.1, 1G traffic support is also provided
with the devices in the distribution layer and that support both 1G and 10G traffic. Thus, all the eight ports
can now work in 1G mode as well as 10G mode.
The configuration of 1G Traffic on 8X10GE IM provides cost-effective solution during migration from 1G
mode to 10G mode as a single device can support both the modes. The feature is supported on Cisco ASR
900 RSP3 module.
By default, the 8X10GE IM comes up in the 10G mode after reboot.
Note
•Restrictions for 1G Mode Support on 8-port 10 Gigabit Ethernet Interface Module, on page 1
•Configuring 1G Mode, on page 2
•Configuring 10G Mode from 1G Mode, on page 3
•Associated Commands, on page 4
Restrictions for 1G Mode Support on 8-port 10 Gigabit Ethernet
Interface Module
• SFP+ is not supported on 1G mode, but the physical link with SFP+ in 1G mode comes up.
•Support of 1G mode on a port and 10G mode on another port in the same interface module is not supported.
• Precision Time Protocol (PTP) is not supported.
• Sync-E is not supported.
• Port channel bundling on 1G mode is not supported.
•Although 1G mode is supported on the interface module, the interface is displayed as "Te0/X/Y" depending
on the port numbers for both 1G and 10G modes.
Configuring 1G Traffic on 8-port 10 Gigabit Ethernet Interface Module
1

• 10G mode support on 8x10GE interface module does not change with dual-rate support.
Configuring 1G Mode
Defaulting the Interface Module:
enable
hw-module subslot 0/4 default
end
Changing the Mode:
enable
configure terminal
hw-module subslot 0/4 ether-mode 1G
end
Configuring the Ports:
enable
configure terminal
interface te0/4/0
ip address 63.0.0.1 255.0.0.0
end
Verifying 1G Mode Configuration
The transport mode is LAN (1GB/s). The speed and bandwidth are 1000 Mbps and 1000000 Kbit/sec,
respectively.
To verify the configuration, use show interface command in privileged EXEC mode:
Router#show interface tengigabitethernet0/4/0
TenGigabitEthernet0/4/0 is up, line protocol is up
Hardware is A900-IMA8Z, address is c8f9.f98d.2024 (bia c8f9.f98d.2024)
Internet address is 50.0.0.1/8
MTU 1500 bytes, te0/4/0, DLY 10 usec,
reliability 255/255, txload 1/255, rxload 1/255
Encapsulation ARPA, loopback not set
Keepalive set (10 sec)
Full Duplex, 1000Mbps, link type is auto, media type is SX
output flow-control is off, input flow-control is off
Transport mode LAN (1Gb/s)
ARP type: ARPA, ARP Timeout 04:00:00
Last input 00:08:24, output 00:08:24, output hang never
Last clearing of "show interface" counters 00:07:59
Input queue: 0/375/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
…..
To verify the slots configured in 1G mode, use the show running-config | i ether-mode command in privileged
EXEC mode:
Router#show running-config | i ether-mode
hw-module subslot 0/3 ether-mode 1g
hw-module subslot 0/4 ether-mode 1g
hw-module subslot 0/11 ether-mode 1g
Configuring 1G Traffic on 8-port 10 Gigabit Ethernet Interface Module
2
Configuring 1G Traffic on 8-port 10 Gigabit Ethernet Interface Module
Configuring 1G Mode

To verify the bandwidth and port speed, use the show platform hardware pp active interface all in privileged
EXEC mode:
Router#show platform hardware pp active interface all
Interface manager platform keys
-------------------------------------------------
Name: TenGigabitEthernet0/4/7, Asic: 0, hwidx: 9
lpn: 0, ppn: 9, gid: 9, mac: c8f9.f98d.202b
InLportId: 0, ELportId: 0, dpidx: 31, l3ID: 25
port_flags: 0, port_speed: 1000 Mbps, efp_count: 0, destIndex: 9, intType: 1
etherchnl: 0, efp: 0, bdi: 0, l2PhyIf: 0, l3PhyIf: 1, l3TDM: 0, loopBack: 0
tunnel: 0, tunneltp: 0, icmp_flags: 0, icmp6_flags: 0
bandwidth: 1000000, fcid: 0, cid: 0, mpls_tbid: 0, protocols: 4
v4_netsmask: 8, v4_tableid: 8, v6_tableid: 65535, vrf_tbid_dstrm: , snmp_index: 0
bd_id: 0, encap: 1, ip_mtu: 1500, l2_max_tu: 1500, l2_min_tu: 0
vrfid: 8, enctype: 0, admin_state: 1, admin_state_oir: 0
Name: TenGigabitEthernet0/4/6, Asic: 0, hwidx: 10
lpn: 0, ppn: 10, gid: 10, mac: c8f9.f98d.202a
InLportId: 0, ELportId: 0, dpidx: 30, l3ID: 24
port_flags: 0, port_speed: 1000 Mbps, efp_count: 0, destIndex: 10, intType: 1
etherchnl: 0, efp: 0, bdi: 0, l2PhyIf: 0, l3PhyIf: 1, l3TDM: 0, loopBack: 0
tunnel: 0, tunneltp: 0, icmp_flags: 0, icmp6_flags: 0
bandwidth: 1000000, fcid: 0, cid: 0, mpls_tbid: 0, protocols: 4
v4_netsmask: 8, v4_tableid: 6, v6_tableid: 65535, vrf_tbid_dstrm: , snmp_index: 0
bd_id: 0, encap: 1, ip_mtu: 1500, l2_max_tu: 1500, l2_min_tu: 0
vrfid: 6, enctype: 0, admin_state: 1, admin_state_oir: 0
Configuring 10G Mode from 1G Mode
Deafulting the Interface Module:
enable
hw-module subslot 0/4 default
end
Changing the Mode:
enable
configure terminal
hw-module subslot 0/4 ether-mode 10G
end
The default is 10G mode.
Note
Configuring the Ports:
enable
configure terminal
interface te0/4/0
ip address 63.0.0.1 255.0.0.0
end
Verifying 10G Mode Configuration
To verify the configuration, use show interface command in privileged EXEC mode:
Configuring 1G Traffic on 8-port 10 Gigabit Ethernet Interface Module
3
Configuring 1G Traffic on 8-port 10 Gigabit Ethernet Interface Module
Configuring 10G Mode from 1G Mode

Router#show interface tengigabitethernet0/4/0
TenGigabitEthernet0/4/0 is up, line protocol is up
Hardware is A900-IMA8Z, address is c8f9.f98d.2024 (bia c8f9.f98d.2024)
Internet address is 50.0.0.1/8
MTU 1500 bytes, BW 10000000 Kbit/sec, DLY 10 usec,
reliability 255/255, txload 1/255, rxload 1/255
Encapsulation ARPA, loopback not set
Keepalive set (10 sec)
Full Duplex, 10000Mbps, link type is auto, media type is SX
output flow-control is off, input flow-control is off
Transport mode LAN
ARP type: ARPA, ARP Timeout 04:00:00
Last input 00:08:24, output 00:08:24, output hang never
Last clearing of "show interface" counters 00:07:59
Input queue: 0/375/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
…..
For 10G mode, the hw-module subslot 0/x ether-mode 10G command is not displayed when you use show
running-config command.
Note
To verify the bandwidth and port speed, use the show platform hardware pp active interface all in privileged
EXEC mode:
Router#show platform hardware pp active interface all
Interface manager platform keys
-------------------------------------------------
Name: TenGigabitEthernet0/4/7, Asic: 0, hwidx: 9
lpn: 0, ppn: 9, gid: 9, mac: c8f9.f98d.202b
InLportId: 0, ELportId: 0, dpidx: 31, l3ID: 25
port_flags: 0, port_speed: 10000 Mbps, efp_count: 0, destIndex: 9, intType: 1
etherchnl: 0, efp: 0, bdi: 0, l2PhyIf: 0, l3PhyIf: 1, l3TDM: 0, loopBack: 0
tunnel: 0, tunneltp: 0, icmp_flags: 0, icmp6_flags: 0
bandwidth: 10000000, fcid: 0, cid: 0, mpls_tbid: 0, protocols: 4
v4_netsmask: 8, v4_tableid: 8, v6_tableid: 65535, vrf_tbid_dstrm: , snmp_index: 0
bd_id: 0, encap: 1, ip_mtu: 1500, l2_max_tu: 1500, l2_min_tu: 0
vrfid: 8, enctype: 0, admin_state: 1, admin_state_oir: 0
Name: TenGigabitEthernet0/4/6, Asic: 0, hwidx: 10
lpn: 0, ppn: 10, gid: 10, mac: c8f9.f98d.202a
InLportId: 0, ELportId: 0, dpidx: 30, l3ID: 24
port_flags: 0, port_speed: 10000 Mbps, efp_count: 0, destIndex: 10, intType: 1
etherchnl: 0, efp: 0, bdi: 0, l2PhyIf: 0, l3PhyIf: 1, l3TDM: 0, loopBack: 0
tunnel: 0, tunneltp: 0, icmp_flags: 0, icmp6_flags: 0
bandwidth: 10000000, fcid: 0, cid: 0, mpls_tbid: 0, protocols: 4
v4_netsmask: 8, v4_tableid: 6, v6_tableid: 65535, vrf_tbid_dstrm: , snmp_index: 0
bd_id: 0, encap: 1, ip_mtu: 1500, l2_max_tu: 1500, l2_min_tu: 0
vrfid: 6, enctype: 0, admin_state: 1, admin_state_oir: 0
Associated Commands
The following commands are used to configure 8-port 10 Gigabit Ethernet Interface Module (8X10GE):
