Cisco IE 3010 User manual

17
Cisco Systems, Inc. www.cisco.com
Switch Installation
Read the topics and perform the procedures in this order:
Warnings, page 17
Installation Guidelines, page 18
Verifying Switch Operation, page 18
Installing the Switch, page 19
Installing and Removing SFP Modules, page 35
Inserting and Removing the SFP Module Patch Cable, page 40
Replacing the SD Flash Memory Card, page 41
Connecting Devices to the Ethernet Ports, page 44
Where to Go Next, page 46
Warnings
These warnings are translated into several languages in the Regulatory Compliance and Safety Information for the Cisco
IE 3010 Switch document that ships on the documentation CD.
These warning statements apply to all the switches:
Warning: Before working on equipment that is connected to power lines, remove jewelry (including rings,
necklaces, and watches). Metal objects will heat up when connected to power and ground and can cause serious
burns or weld the metal object to the terminals. Statement 43
Warning: Read the installation instructions before you connect the system to its power source. Statement 1004
Warning: This unit is intended for installation in restricted access areas. A restricted access area can be accessed
only through the use of a special tool, lock and key, or other means of security. Statement 1017
Warning: This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an
electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning: This unit might have more than one power supply connection. All connections must be removed to
de-energize the unit. Statement 1028
Warning: Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning: Ultimate disposal of this product should be handled according to all national laws and regulations.
Statement 1040

18
Switch Installation
Installation Guidelines
Warning: For connections outside the building where the equipment is installed, the following ports must be
connected through an approved network termination unit with integral circuit protection.
10/100/1000 Ethernet Statement 1044
Warning: To prevent the system from overheating, do not operate it in an area that exceeds the maximum
recommended ambient temperature of:
140°F (60°C) Statement 1047
Warning: Installation of the equipment must comply with local and national electrical codes. Statement 1074
Note: For U.S. installations, refer to national electrical code ANSI/NFPA 70.
Warning: To prevent airflow restriction, allow clearance around the ventilation openings to be at least:
1.75 in. (4.4 cm). Statement 1076
Warning: Avoid using or servicing any equipment that has outdoor connections during an electrical storm. There
may be a risk of electric shock from lightning. Statement 1088
Installation Guidelines
Before installing the switch, verify that these guidelines are met:
Cabling is away from sources of electrical noise, such as radios, power lines, and fluorescent lighting fixtures. Make
sure that the cabling is away from other devices that might damage the cables.
Operating environment is within the ranges listed in
Relative humidity around the switch does not exceed 95 percent (noncondensing).
Altitude at the installation site is not higher than 10,000 feet.
For 10/100 and 10/100/1000 fixed ports, cable lengths from the switch to connected devices are not more than 328
feet (100 meters).
For cable lengths for small form-factor pluggable (SFP)-module connections, see the SFP Module Cables, page 74
and the module documentation.
Airflow around the switch and through the vents is unrestricted. To prevent overheating, the switch must meet the
minimum clearance of 1.75 inches (4.4 cm) at the top and bottom.
Note: If the switch is installed in a closed or multirack assembly, the temperature around it might be greater than
normal room temperature.
Verifying Switch Operation
Before installing the switch in a rack or on a wall, you should power the switch and verify that the switch passes the
power-on self-test (POST).
To wire the switch to the power source, see Power Supply Installation, page 47
When the switch begins POST, the SYS LED blinks green, and the other LEDs stay green. When the switch passes POST,
the SYS LED turns green. The other LEDs turn off and return to their operating status. If the switch fails POST, the SYS
LED is amber.
Note: Contact Cisco Systems immediately if your switch fails POST.
After a successful POST, disconnect the power from the switch. For more information, see Power Supply Installation,
page 47 See the Installing the Switch, page 19 to install the switch in a rack or on a wall.

19
Switch Installation
Installing the Switch
Installing the Switch
Rack-Mounting, page 19
Wall-Mounting, page 30
If the switch is wall-mounted in an enclosure, follow these minimum clearances:
Sides of switch (facing up and facing down): 3.75 in. (9.52 cm)
Port side 3.0 in. (7.62 cm)
Power supply side: 5.25 in. (13.33 cm)
Cover side (side not facing wall): 1.75 in. (4.44 cm)
Base side (facing wall): 0 in. (0 cm)
Rack-Mounting
To rack-mount the switch, select the rack size and follow the steps in these sections:
Attaching Brackets for 19-Inch Racks, page 19
Attaching Brackets for 19-Inch Racks for IP-30 Compliance (Optional), page 21
Attaching Brackets for 23-Inch Racks, page 27
Attaching Brackets for ETSI Racks, page 28
Rack-Mounting the Switch, page 28
.
Warning: For mounting railway-application equipment and for EN50155 standard compliance, the switch must be
installed only in a rack mid-mounting position. If you install the switch in a front rack-mounting (cable side or power
supply side) position or in a wall-mounting position, a mechanical failure can occur that results in the switch
becoming detached from the rack. Statement 403
Attaching Brackets for 19-Inch Racks
Figure 10 on page 20 and Figure 11 on page 21 show how to attach brackets to the switches.
Warning: To prevent bodily injury when mounting or servicing this unit in a rack, you must take special
precautions to ensure that the system remains stable. The following guidelines are provided to
ensure your safety:
This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
When mounting this unit in a partially filled rack, load the rack from the bottom to the top with
the heaviest component at the bottom of the rack.
If the rack is provided with stabilizing devices, install the stabilizers before mounting or
servicing the unit in the rack. Statement 1006

20
Switch Installation
Installing the Switch
Figure 10 Attaching Brackets for 19-Inch Racks
1Mid-mounting position 3Cable-side mounting position
2Phillips flat-head screws 4Power-supply-side mounting position
208366
2
1
2
2
3
4
Cisco IE 3010
Cisco IE 3010

21
Switch Installation
Installing the Switch
Figure 11 Attaching Brackets for 19-Inch Racks
Attaching Brackets for 19-Inch Racks for IP-30 Compliance (Optional)
Before installing the mounting brackets, you need to install the rubber plugs in the unused mounting holes. The rubber
plugs are not supplied with the switch. You can order a kit (part number IE-3010-IP30KIT) containing the rubber plugs.
You can order a kit (part number IE-3010-IP30KIT) that contains the rubber plugs.
Figure 12 on page 22 shows a close-up of the rubber plug. You can install the rubber plugs in the holes as shown in
Figure 13 on page 23 and Figure 14 on page 24.
1Phillips flat-head screws 3Power-supply-side mounting position
2Cable-side-mounting position
Cisco CGS 2520
207231
1
1
2
3

22
Switch Installation
Installing the Switch
Figure 12 Inserting the Rubber Plug
1. Identify your bracket mounting position. See Figure 15 on page 25 or Figure 16 on page 26.
2. Insert the rubber plugs in the appropriate holes on both sides of the switch. See Figure 13 on page 23 or Figure 14
on page 24.
3. Use a screwdriver or pen to completely push in the rubber plugs. See Figure 12 on page 22.
4. Install the brackets on both sides of the switch. See Figure 15 on page 25 or Figure 16 on page 26.
1Rubber plug 3Screwdriver
2Switch
255738
2
3
1

23
Switch Installation
Installing the Switch
Figure 13 Inserting the Rubber Plugs
1Rubber plug 3Cable-side mounting position
2Mid-mounting position 4Power-supply-side mounting position
255739
1
2
1
3
1
4

24
Switch Installation
Installing the Switch
Figure 14 Inserting the Rubber Plugs
1Rubber plug 3Power-supply-side mounting position
2Cable-side-mounting position
Cisc o CG S 2520
255740
1
2
1
3

25
Switch Installation
Installing the Switch
Figure 15 Attaching Brackets for 19-Inch Racks
1Mid-mounting position 3Cable-side mounting position
2Phillips flat-head screws 4Power-supply-side mounting position
255750
1
2
3
4
2
2

26
Switch Installation
Installing the Switch
Figure 16 Attaching Brackets for 19-Inch Racks
Note: For IP-30 compliance: If you use 23-inch brackets or ETSI brackets, you can insert the rubber plugs in the same
holes as shown in Figure 13 on page 23 or Figure 14 on page 24 before installing the brackets.
1Phillips flat-head screws 3Power-supply-side mounting position
2Cable-side-mounting position
Cisco CGS 2520
PSU2
2
255751
3
1
1
