CITC FogMax 100090 User manual

FOGMAXTM
Operating Instructions
P/N 100090 (120 VAC w/DMX)
P/N 100095 (230 VAC w/DMX)

1
Thank you for purchasing this FOGMAXTM
As you will notice from the table of contents, the manual for your
new product is quite extensive.
To guarantee perfect and successful work with this machine, please
take some time to read the manual carefully.
And finally, we believe you will enjoy years of great smoke effects if
you care for and maintain your FOGMAXTM.
CITC
1420 80th St. SW #D
Everett, WA 98203
(888) 786-CITC
www.citcfx.com

2
Contents
1. Set of Equipment Supplied 3
2. Accessories and Parts 3
3. Description 4
4. Safety Instructions 4
5. Operating the FogMaxTM 5
5.1 Selecting the Location
5.2 Electrical Power Requirements
5.3 Hooking things up
5.4 Operating the machine
5.5 DMX Control
5.6 Rest Period
5.7 Shut Down
5.8 Troubleshooting
5.9 Notes on DMX Control
6. Service and Maintenance 7
7. Technical Data 7
8. Limited Warranty Conditions 8

3
1. Set of Equipment Supplied
FogMaxTM w/DMX (w/5-pin XLR connectors)
Remote Cycle-Timer Controller w/5-pin XLR connector
Bracket for hanging
Instruction booklet
2. Accessories and Parts
CITC SmartFog™ Fluid
(available in gallons (3.8 liter) and 5-gallon (19 liter) cubitainer)
P/N 150460 60 Minute Longest-Lasting SmartFog™ Fluid
P/N 150450 45 Minute Long-Lasting SmartFog™ Fluid
P/N 150410 25 Minute Regular SmartFog™ Fluid
P/N 150411 15 Minute “Fog-It” SmartFog™ Fluid
P/N 150490 3 Minute Low-Ground SmartFog™ Fluid
P/N 150491 1 Minute Quick SmartFog™ Fluid
C-Clamp w/Safety Cable (P/N 250110)
C-Clamp w/eyebolt & hanging harness for 5 gallon (19 liter)
Cubitainer (P/N 250076)
Please check whether all the products you ordered are supplied.

4
3. Description of the FogMaxTM
The FogMaxTM w/DMX is CITC’s industry-proven fogging system. No other
comparable machine delivers a thicker, whiter output of 30,000 cfm (850m3/minute) of
digitally controlled fog. Extremely reliable, the FogMaxTM can produce longer on high
than the stiffest competition. Accurate temp control makes shut down history. It now
has a quieter pump with a 1500 watt heating head, a 1-channel DMX on board, remote
control cycle-timer and hanging bracket. The FogMax™ is your best bet for
professional fog. Uses water-based CITC SmartFog™ fluid in 15 Minute, 1 Minute, 3
Minute, 25 Minute, 45 Minute or 60 Minute. The extra dry fog leaves no mess, no
residue and can be fully controlled with DMX.
The following sequence produces fog:
1. The fog generator is preheated for 5 – 10 minutes.
2. The pump is controlled from 0 – 100% output by the Remote Cycle-Timer
Controller or by DMX.
3. At 12 o’clock output, the unit will produce fog continuously without delay
4. At 100% output (3 o’clock on Volume Control), the unit will produce a heavy fog
for 30 minutes or more without delays. After a short rest period the FogMax™
is again warmed up and ready to produce fog.
4. Safety instructions
WARNING: Read and understand all labels and operating
instructions before attempting installation.
oNever open the machine without disconnecting power lead first!
Risk of electrical shock- This device is supplied with a grounding conductor. To
reduce risk of electrical shock, connect only to properly grounded, grounding type
receptacles. Never remove the third prong from the plug.
oThis machine requires a 120VAC/20A circuit for operation (or a 230VAC/10A circuit for
the 230VAC machine). The FogMaxTM draws approximately 15 amps at 120 VAC (8
amps at 230VAC). During FogMaxTM operation this circuit should be dedicated to the
FogMaxTM. If you have any doubts about the capacity or grounding of your existing
circuits, consult a qualified electrician.
oBe sure area around fogger is dry before applying electrical power.
oMake sure that your unit is pointed in a direction that leaves a 10ft (3m) open area out
in front. Place the front of the machine away from direct contact with electrical
instruments and people. Close output is very hot and wet.
oNever operate the pump without fluid passing through the tube. Operating the pump
without fluid can cause damage that is not covered under warranty.
oFluid is very slippery when spilled. Care in keeping any drips or spills cleaned up is
necessary.
oDo not store FogMaxTM in freezing conditions.

5
5.Operating the FOGMAXTM
5.1 Selecting the Location
Secure a good location for the machine to rest solidly on the floor or suspended so
that the output of the machine will not be restricted. Make sure that your unit is pointed
in a direction that leaves an open area out in front and can travel 10ft (3m) without
restriction. Place the front of the machine away from direct contact with electrical
instruments and people. Close output is very hot and wet. Always allow plenty of air
circulation to allow the fog to expand, separate and enlarge.
5.2 Electrical Power Requirements
This machine requires a separate 120VAC/20Amp (or 230VAC/10Amp) circuit for
operation. The FogMaxTM draws approximately 15 amps at 120 VAC and 8 amps at
230VAC. During FogMaxTM operation this circuit should be dedicated to the FogMaxTM.
If you have any doubts about the capacity or grounding of your existing circuits,
consult a qualified electrician.
5.3 Hooking things up
Plug the 5-pin XLR of the Remote Control to the inlet marked “Remote Control”. Fill
the bottle with CITC’s SmartFog Fluid. Place the filter end of the tube inside the
bottom of the bottle and tighten cap. Be sure the vent hole in the cap is not blocked.
5.4 Operating the machine with the remote
1. Turn on the power switch on the fogger. Verify that the red light in the switch and the
red “power” LED on the remote both illuminate. Wait approximately 7-10 minutes for
the green "ready” light, located on the remote control, to come on.
2. Using the "vary output" button, you may adjust the output volume with the volume
control. Using the “timer” button, you may adjust the "on" and "off" knobs for timing the
fog and the “output” knob. The amount of fog can be adjusted by using the volume
"output" knob. NOTE: Do not depress "vary output" when using timer. When using the
“blast” button, you will not have timer or volume output control. The "blast" button
provides maximum smoke as long as you hold the button down.
5.5 DMX Control
With DMX control, you will be able to adjust the fog levels on/off, from 0 – 100%. DMX
will override all remote control functions. Once your fogger is warm and the green
“ready” light is on, you may control the fog output from the control booth. (See section
5.9)

6
5.6 Rest Period
Continuous operation of this machine can be accomplished when volume is set at the
3 o’clock position. If dial is set for full output or blast, the fogger may cool enough to
require a 3 minute rest period for reheating before continuing to fog.
5.7 Shut down
When finished with the machine, clean the tube and pump by operating the unit while
running a pint of 5% vinegar/distilled water mix through the pump and then rinse with a
pint of distilled water. When finished, water should remain in the line for storage. Do
not drain or empty the tube of water.
5.8 Troubleshooting
If the pump does not draw fluid into the fogging unit, be sure the unit is warm and
ready to operate. Then check to see that the tubing is in the fluid, not above the fluid.
Check electrical power to the machine. Check to hear any sound coming from the
pump side (nearest the top). A slight vibrating sound should be heard if the pump is
pumping fluid. Allow fluid to flow through the line to get the pump primed. Note: do
not run the pump without fluid passing through the tube. This can cause
damage to the pump and is not covered under warranty.
5.9 Notes on DMX operation
Each DMX’d unit will occupy a unique DMX address on the DMX chain. By adjusting
the dip switches on the side of the machine near the DMX cable plug-ins, the user may
assign one address to the machine, giving you on/off and volume control with one
DMX channel (there is no timer on this DMX).
Step 1). Attach the DMX cable (5-pin XLR) to the upper “in” female connector located
on the back of the fogger.
Step 2). The DMX address is configured by adding the dip switch numbers together to
total the number required. For example, DipSwitch 1 + 6 = 33. Your DMX channel
would be 33.
Dip Switch 1 2 3 4 5 6 7 8 9
Channel # 1 2 4 8 16 32 64 128 256
When you move the slide control or digital control;
0 – 5% = Off
6– 80% = Volume Control
80 – 100% = Maximum Blast Output
“Input” and “Output” designations on the DMX plugs are arbitrary (i.e., you can use
the input plug for output and vice-versa). It is not necessary to attempt converting your
DMX line’s connector to female/male to match the appropriate socket on the plug. As
long as it is looped in/out, it will work.

7
6. Service and Maintenance
Care of your FogMaxTM will give you years of service. Note: cleaning
your unit is going to pay off in constant good performance.
1. Dry all areas on the exterior of the machine once it is cool. Clean with a soft cloth to
remove any fog fluid from inside the fluid compartment or outside area.
2. Do not store with fog fluid inside. When finished with the machine, clean the tube and
pump by operating the unit while running a pint of 5% vinegar/distilled water mix
through the pump and then rinse with a pint of distilled water. When finished, water
should remain in the line for storage.
3. Do not transport or ship with fog fluid inside the machine.
7. Technical Data
FogMax™ Technical Data P/N 100090/100095
Type of Fog
Thick, white, dry, low-ground fog
Size
22” x 9” x 11”
(56cm x 23cm x 28cm)
Weight
26 lbs (12 kg)
Shipping Box Size
26” x 13” x 16”
(66 cm x 33 cm x 41 cm)
Shipping Weight
33 lbs (15 kg)
DMX
Built in 1-channel DMX
CITC SmartFog™ Fluid
(water-based)
P/N 150460 60 Minute Longest-Lasting
P/N 150450 45 Minute Long-Lasting
P/N 150410 25 Minute Regular
P/N 150490 3 Minute Low-Ground
P/N 150491 1 Minute Quick
Warm Up Time
10-12 minutes
Continuous Fog
Runs continuously without shutdown
Heating unit
1500 watts
Remote Timer Included:
0-100% output control for continuous fog
0-100% fog output control when using
cycle-timer
100% output on manual momentary
“BLAST” button
Cycle-timer = 1-11 seconds. "on",
0.2 - 5 minutes. "off"
Electrical Supply
120 VAC, 15 A, 60 Hz
or 230 VAC, 8 A, 50 Hz
Breaker
120VAC: 15A ; 230VAC: 7A
Limited Warranty
One Year
Rev: 03/15/2018

8
8. One Year Limited Warranty
Model: ________________ Purchased on (date): ________________
Serial number: ________________ Purchased from: ________________
Congratulations!
You can now look forward to many years of reliable operation and outstanding
performance. Thank you for making CITC your personal choice in special effects
equipment. Please take a moment to fill out the top of this warranty, and then keep it –
with the receipt – in a safe place.
If you would like to receive information about specials, sales, and new products, please
log on to www.citcfx.com and click on the “Contact Us” link.
We appreciate your business, and wish to provide you with a quality product that will
serve you for many years to come. Once again, thank you for choosing CITC, and enjoy
your new entertainment product!
LIMITED WARRANTY CONDITIONS
This limited warranty guarantees to the original purchaser that this product shall be free of
defects in material and workmanship, under normal use, for a period of one year from the
date of purchase shown on the sales receipt. This warranty covers parts and labor
providing the product is returned to CITC in the original shipping carton and packaging.
The warranty for electrical is a (90) NINETY DAY limited warranty.
Damage resulting from shipping, accidents, misuse, negligence, unauthorized repairs or
modification is not covered by this warranty. Using any fluid other than what is
recommended for this machine will void warranty. No liability is accepted for injury or for
loss, damage or expense resulting from any interruption whatsoever in the operation of
the product or from any consequential loss arising there from. No liability is accepted for
normal wear and tear.
We wish to satisfy YOU, our customer, and have implemented many measures to prevent
problems and assure customer satisfaction. However, should you need a missing part or
have a functional problem with your product, please call:
(888) 786-CITC, from 7:30 am – 4:00 pm (Pacific Time), Monday – Friday, except for
holidays. Our customer service department will respond to your problems immediately.
Subject to the following conditions, CITC will repair any defect or fault in the unit if it is
caused by a proven factory defect within one year of delivery to the end user.
Insignificant deviations of the regular product quality does not guarantee replacement
rights, nor do faults or defects caused by water, by generally abnormal environment
conditions or Force Majeure:
1. Faulty parts or equipment will be repaired or replaced (manufacturer’s choice) with
correct parts. Faulty units must be shipped to CITC at customer’s expense. Call for
an RMA# - AN RMA# MUST COME WITH THE UNIT. Payment arrangements for

9
repair must be made before receiving your RMA#, in case the unit is not covered
under this limited warranty.
2. Repairs/replacements will only be made with the approval of the customer.
3. Exposure to outside elements voids Warranty. Unit cannot be used outdoors or in
wet weather without complete protection against the elements. Even then, high
salty or humid conditions will cause instant corrosion of connectors and will void
Warranty.
4. The customer loses all rights for limited warranty services if any repairs or
adjustments are done to the units by unauthorized persons, and/or if spare parts
are used, which are not approved by CITC. The right of limited warranty service is
also lost if a fluid other than appropriate CITC fluid has been used or if units are
sent in without first emptying the equipment of fluid.
5. Freight costs to and from CITC, when under the limited warranty services, are the
responsibility of the customer. Customer must place appropriate insurance on
return of product. However, if product is returned due to factory defect within the
first year, CITC will cover the cost of returning the repaired unit to the customer.
6. Limited warranty services do not cause an extension of the limited warranty period
or the start of a new limited warranty period. The warranty of replaced parts ends
with the limited warranty period of the whole unit.
7. Further claims, especially for damages, losses etc. outside the unit are excluded.
Send unit to: CITC
RMA # XXXXXXX
1420 80th St. SW #D
Everett, WA 98203
Tel: (888) 786-CITC or [phone]
Fax: [phone]
Website: www.citcfx.com
E-mail: [e-mail]
Find us on Facebook!
www.facebook.com/CITCFX
March 16, 2018
