Citizen CH-671F User manual

- Eng 1 -
REF CH-671F
INSTRUCTION MANUAL
FOR
DIGITAL BLOOD PRESSURE MONITOR
English
Español
Português
Deutsch
0801

GENERAL REMARKS
- Eng 2 -
General remarks on blood pressure and blood pressure
measurement
1. If the cuff is to be deflated quickly, depress “POWER” switch.
2. The attached cuff is suited for a wrist circumstance of 13.5 cm to 19.5
cm.
3. When attaching the cuff, the body of a blood pressure monitor should be
placed on the inside of your wrist.
4. Self measurement is not therapy! In no case may you change the
dosage of medication prescribed by your physician.
5. In preparation for blood pressure measurement, you should urinate and
then remain relatively still for 10 to 15 minutes prior to measurement.
6. Exercising, eating, drinking, smoking, etc., prior to measurement may
affect the results.
7. Blood pressure varies constantly throughout the day. Measurement
should be made regularly at the same time each day.
8. DO NOT be too impressed by the results of one measurement. Keep a
record of blood pressure variations. Many reading tell a story.
9. Emotional stress may tend to cause blood pressure to rise.
For proper measure of blood pressure
1. Take a deep breath five or six times and then relax before measuring
your blood pressure. If you are tense when taking the measurement, you
will not get a valid reading.
2. Blood pressure will be elevated when you are in a worrisome or irritated
state, suffering from lack of sleep or constipation, or after exercise or a
meal.
3. Wrap the cuff around your wrist snugly. (See page 14)
4. DO NOT measure blood pressure after bathing or drinking.
5. When you feel like relieving yourself, you should do so before measuring
your blood pressure.
6. Measure your blood pressure where the room temperature is about
20°C. DO NOT measure blood pressure when it is too cold (below 10°C)
or too hot (above 40°C) in the room.

7. DO NOT try to measure blood pressure immediately after drinking
coffee or tea or smoking.
8. Measure blood pressure with a relaxed and quiet posture. Keep
the center of the cuff at the level of your heart, and DO NOT move
your arm or talk.
9. DO NOT measure blood pressure after the cuff has been on your
wrist for a few minute, as you arm will have built up higher blood
pressure, and you will not get valid reading.
10. Next figure shows the classification of blood pressure according
to WHO-standard.
Measure your blood pressure at the same time on a daily basis.
* The blood pressure changes at all times. This means that data
gathered over a long period has great significance instead of data
on just one measurement. It is therefore necessary to measure
your blood pressure on a daily basis. Ideally, you should measure
your blood pressure daily at the same time.
- Eng 3 -
English
GENERAL REMARKS
Definition and Classification of Blood Pressure Levels
Remarks:
The graph is not exact,
but may be used as a
guide in understanding
non-invasive blood
pressure measurements.
The device intended for
use in adult population.

- Eng 4 -
PRECAUTION FOR USE AND MAINTENANCE
Precaution for use
1. If you suffer from heart disease, high blood pressure or other
circulatory disease, please consult your doctor first.
2. If you feel abnormal pressure of the cuff during use or any other
irregularity, reduce the pressure by immediately switching off the
power or remove the batteries and consult the sales outlet where
purchased.
3. If you think the measured value is abnormal or if measuring makes
you feel unwell, discontinue use and consult your doctor.
4. Measurement of blood pressure may not be possible for someone
with a weak pulse or arrhythmia.
5. If blood pressure is measured repeatedly, congestion, swelling, etc.
may occur in some people.
6. If blood pressure is measured repeatedly, an accurate result will not
be achieved. An interval of about 10 minutes should be allowed.
7. Consult your physician before use if you suffer a severe disorder of
blood circulation in the arms. Failure to do so may cause health
hazards.
8. Measurement may not be possible for someone with an insufficient
blood flow in the area to be measured or frequent irregular
heartbeats. Consult your physician for judgment.
9. DO NOT wrap the wrist cuff around an injured wrist.
10. DO NOT wrap the wrist cuff to the wrist where a drip (intravenous
infusion) or blood transfusion under medical treatment. Failure to do
so may cause an injury or a serious accident.
11. DO NOT use in the vicinity of flammable gases such as anesthetic
gases because of the risk of ignition and explosion.
12. DO NOT use in enriched oxygen environments such as a hospital’s
hyperbaric chamber or oxygen tent because of the risk of ignition
and fire.
13. DO NOT use a mobile phone near the unit. Doing so may result in
malfunction.
14. The power of this blood pressure monitor may be shut off by electro-
static discharge from the human body. This is only a temporary
phenomenon. You can measure the blood mesaure the blood
correctly after pressing the POWER switch once again.

- Eng 5 -
English
PRECAUTION FOR USE AND MAINTENANCE
15. If you use a cardiac pacemaker, consult your doctor before use.
16. Be sure to use this unit only for measuring blood pressure. DO
NOT use it for any other purpose.
17. DO NOT use this unit on an infant.
Recaution for maintenance
1. DO NOT store the blood pressure monitor where it will be
exposed to direct sunlight, high temperature (over 60°C), low
temperature (below -20°C), high relative humidity (over 95%) or
in a dusty place.
2. DO NOT drop or expose the blood pressure monitor to under
force or vibration.
3. Remove the battery/batteries when not in use for a long period.
4. DO NOT disassemble the apparatus.
5. DO NOT bend the cuff or air hose unnecessarily.
6. NEVER wipe the blood pressure monitor with thinner or benzene,
as they may damage it.
7. When the monitor is very dirty, wipe it clean with a cloth
moistened with sterilizing alcohol or a neutral detergent, and then
wipe it with a dry cloth. DO NOT use thinner or benzene.
Nature and frequency of maintenance:
This product is designed for use over an extended period of time;
however, it is generally recommended that it be inspected every two
years to ensure proper function and performance.
Protect the nature environment:
Please help protect natural environment by respecting natural and/or
local recycling regulations when disposing of the batteries and the
products at the end of their useful lives.

- Eng 6 -
WEEE MARK
If you want to dispose this product, do not mix with general
household waste. There is a separate collection systems for
used electronics products in accordance with legislation under
the WEEE Directive (Directive 2002/96/EC) and is effective
only within European Union.
Reference European standard:
The blood pressure measuring device corresponds to regulation EN60601-1-2.
Name :
Address : FLAT A-B, 4TH FLOOR, HUNG MOU INDUSTRIAL
BUILDING, 62 HUNG TO ROAD, KWUN TONG, KOWLOON,
HONG KONG
( : Manufacturer)
European Representative:
Name : WvW elektronische Geräte Vertrieb GmbH
Address : Fintelmannstraße 20/Eingang, Martin-Heydert-Straße,
D-14109 Berlin, Germany
PRECAUTION FOR USE AND MAINTENANCE
Warning
The device has been tested and homologated in accordance with
EN60601-1-2 for EMC. This does not guarantee in any way that the
device will not be affected by electromagnetic interference. Avoid
using the device in high electromagnetic environment.

- Eng 7 -
English
IDENTIFICATION OF PARTS
The product has been developed through the concept of
Universal Design to ensure safe and easy use for a wide range
of users. The product, which is designed laying importance on
Universal Design, adopts a product shape and color that
conveys an image of “warmth” and “gentleness” and has
functions that cope with human body, which are “easy to
understand”, “safety in use” and “easy to use”.
UNIVERSAL DESIGN
MODE switch
SET switch
MEMORY switch
POWER switch
MONTHLY AVERAGE switch
Battery box
Wrist cuff Time/Date display section
Systolic blood
pressure display section
Diastolic blood
pressure display section
Pulse display section
AVG
AVG

- Eng 8 -
HOW TO LOAD BATTERIES
Push
Push
Remove the battery box from the unit. Install two “AAA” alkaline
batteries, observing the proper battery polarity (“+/–”).
1
While pinching the stopper
tabs, pull the battery box in the
direction of the arrow to
remove from the unit.
2
Insert the batteries into the
battery box, ensuring a correct
match with positive + and –
negative terminals.
* The battery goes in negative – side first.
3
Re-attach the battery box to the
unit with the battery’s visible
side facing up.
* Make sure not to depress the switch when
you re-attach the battery box into the main
unit.
* Install the battery box properly. Improper
installation may prevent proper display
when the is pressed.
* After replacing the batteries, be sure to set the
clock.
( See page 10
“HOW TO SET THE CLOCK”.)
* The data in memory is kept after the batteries are replaced.

- Eng 9 -
English
• Replace the batteries with two new “AAA” alkaline batteries when appears
on the display, or when nothing appears on the display when the POWER
switch is pressed.
• Be sure to replace both batteries with new ones.
• Use the commercial alkaline dry cells. Do not use rechargeable batteries.
• Batteries included are for demonstration purposes only. Battery life may be
shorter than specified.
• Dispose of used batteries properly in accordance with local regulations.
Replacing the batteries
HOW TO UNLOAD BATTERIES
HOW TO UNLOAD BATTERIES
1
Pull the battery box to remove from
the unit.
( See page 8 “HOW TO LOAD BATTERIES”.)
2
Push up each battery by lifting up its
positive + end side with your
fingertip.
* Use caution when removing batteries that are held
in place by the springs in the battery box. Failure
to do so may cause injury to your fingernail.
3
Re-attach the battery box to the unit.
( See page 8 “HOW TO LOAD BATTERIES”.)

- Eng 10 -
HOW TO SET THE CLOCK
The device is equipped with a built-in clock allowing you to record
your pressure readings with time and date information. Set the
clock properly to keep a precise record of the time and date of your
measurement results. The clock-setting procedure goes in the
following order: Year/Month/Date and then Hour/Minute.
The clock has been factory preset to 12:00AM on January 1, 2004.
After batteries have been replaced, the clock will indicate the time
and date of the most recent measurement data in memory.
1
After making sure that the power is
turned off, press and hold for
more than a second.
The last figure of the Year (A.D.) will appear on the
pulse display section and Month/Date will appear
on the Time/Date display section.
The “ ” Year blinks and then will be corrected.
2
Set the “Year”.
Press to set the current year.
* The “ ”Year can be set between 04(2004)and
33(2033).
Press .
This will finalize the “ ”Year setting. The digits
representing the “ ”Month On the date display
section will flash.
Example: Set the clock to 08:05 PM on May 1, 2004.
