Citizen CMP-30 series User manual

MOBILE THERMAL PRINTER
MODEL CMP-30 series
Technical Manual
Rev. 1.00

- 2 -
TABLE OF CONTENTS
1. General Specifications
1.1 Printing Specifications
1.2 Character Specifications
1.3 Paper Specification
1.4 Printable Area
1.5 Internal Buffer
1.6 Electrical Characteristics
1.7 EMI and Safety Standards Applied
1.8 Reliability
1.9 Environmental Conditions
2. Configuration
2.1 RS-232 serial interface
2.1.1 Specifications
2.1.2 Switching between on-line and off-line
2.1.3 Interface connector terminal assignments and signal functions
2.1.4 Serial interface connection example
2.2 USB Interface
2.3 Bluetooth Interface
2.4 WiFi Interface
2.5 Interface Connector
3. Connectors
3.1 MSR
3.2 IC-CARD
4. Control Command Summary

- 3 -
1. General Specifications
1.1 Printing Specifications
1) Printing method: Thermal line printing
2) Dot density: 203dpi
3) Printing direction: Unidirectional with friction feed
4) Printing width: 72mm(2.83"), 576 dot positions (203dpi)
5) Characters per line(ESC Emulation): Font A: 48
Font B: 64
6) Printing speed: 80mm/second maximum
☞NOTE: Speeds are switched depending on the applied voltage to the printer and head
temperature conditions automatically.
☞NOTE: There may be variations in printing after switching the mode of the printing
speed. To prevent this for logo printing with ESC* command, using a
downloaded bit image is recommended. Change in printing speed does not
occur during downloaded bit image printing.
7) Line spacing (default): 1/6 inch (4.23mm)
Programmable by control command.

- 4 -
1.2 Character Specifications
1) Number of characters: Alphanumeric characters: 95
Extended graphics 128 × 18 pages
(including one space page)
International characters: 14
① English
② Hangul
③ Chinese (GB2312,Big5)
④ Kanji
2) Character structure (ESC Emulation)
Font A: 12 ⅹ24
Font B: 9 ⅹ17
Hangul, Chinese: 24 ⅹ24
Font A is selected as the default
3) Character size:
EPSON Emulation
1)Dot density 0.125ⅹ0.125mm/dot (203*203dpi)
[dpi: dots per 25.4mm{1"}]
2)Printing direction Unidirectional With friction feed
3)Paper width
80mm(3.14")
4)Maximumprintable area
72mm(576dots)
5)Character / line (ESC Emulation)
Font A (12ⅹ24) 48
Font B (9ⅹ17) 64
Kanji Font (24ⅹ24) 24
4) Character structure (CPCL Emulation)
Fixed-Width Fonts
Font # / Font Size 0 1 2 3 4 5 6 7
0 8 16 8 16 32 16 32
1 (see separate table)
2 20 20
4 (see separate table)
5 (see separate table)
6 28
7 12 12

- 5 -
Font Height
Font # / Font
Size
0 1 2 3 4 5 6 7
0 9 9 18 18 18 36 36
1 48
2 12 24
4 47 94 45 90 180 270 360 450
5 24 48 46 92
6 27
7 24 48
1.3 Paper Specification
1) Paper type: Specified thermal paper
2) Form: Paper roll
3) Paper width: 80 ±0.5mm
4) Paper roll size: Roll diameter : Maximum 56mm
☞NOTE: Paper must not be pasted to the paper roll spool.

- 6 -
1.4 Printable Area
1.5 Internal Buffer
1) Receive buffer: 4Kbyte
1.6 Electrical Characteristics
1) Supply voltage: +7.4VDC , 2200mAH Li-ion Battery
1.7 EMI and Safety Standards Applied
1) UL: Safety – EN 60950-1:2001+A11:2003
EMS – EN55022:98+A1:2000+A2:2003
– EN55024:98+A1:2001+A2:2003
– EN301 489-1 V1.6.1
– EN301 489-17 V1.2.1
RF – EN 300 328 V1.7.1(2006-10)
1.8 Reliability
1) MCBF: 50 million lines
(based on an average printing rate of 12.5% with paper thickness in the
range 65 ㎛to 75 ㎛).
1.9 Environmental Conditions
1) Temperature: Operating: 5°to 45°C
Storage: -20°to 60°C
(except for paper)
2) Humidity: Operating: 10 to 90%RH
Storage: 10 to 90%RH (except for paper)
80
72
4 4

- 7 -
2. Configuration
2.1 RS-232 serial interface
2.1.1 Specifications
Data transmission: Serial
Synchronization: Asynchronous
Handshaking: DTR/DSR or XON/XOFF control
Signal levels: MARK= -3 to –15V: Logic “1”
SPACE= +3 to +15V: Logic “0”
Baud rage: 4800, 9600, 19200, 38400,57600,115200 bps
Data word length: 7 or 8 bits
Parity Settings: None, even, odd
Stop bits: 1 or more
Connector (printer side): Female DSUB-25 pin connector
☞NOTE: The data word length, baud rate, and parity depend on the
Software-Tool settings.
2.1.2 Switching between on-line and off-line
The printer does not have an on-line/off-line switch.
The printer goes off-line:
•Between when the power is turned on (including reset using the interface)
•During the self-test.
•When the cover is open.
•During paper feeding using the paper feed button.
•During macro executing stand by status.
•When a temporary abnormality occurs in the power supply voltage.
•When an error has occurred.
2.1.3 Interface connector terminal assignments and signal functions
PIN SIGNAL I/O DESCRIPTION
1 RXD - Printer receive data line RS-232C level
2 TXD - Printer transmit data line RS-232C level
3 DTR Output Printer handshake to host line RS-232C level
4,5,6,7,8 GND - System Ground

- 8 -
2.1.4 Serial interface connection example
Host side Printer side
TXD ………………………………… RXD
DSR ………………………………… DTR
RXD ………………………………… TXD
FG ………………………………… FG
SG ………………………………… SG
DETAILS: ◦Set the handshaking so that the transmit data can be received.
◦Transmit data to the printer after turning on the power and initializing
the printer.
< Figure 2.1 Serial transmission bit frame >
< Figure 2.2 Line transmission with protocol >
ready busy ready busy
buffer full buffer emptied
"1"
"0"
"0"
"1"
RxD
DTR
B0 B1 B2 B3 B4 B5 B6 B7START PARITY
"1"
"0"
STOP
1Bit
7 or 8
Bi
t
N
one or
1 Bi
t
1 or 2
Bit

- 9 -
2.2 USB Interface
PIN SIGNAL I/O DESCRIPTION
1 +5V - +5V
2 DATA- - Printer transmit data line
3 DATA+ - Printer transmit data line
4 GND - System Ground
1) Specifications
Data transmission: USB 2.0
Connector: USB “B” type connector
2) USB interface connection example
Host side Printer side
VCC ………………………………… VCC
DATA+ ……………………………… DATA+
DATA- ……………………………… DATA-
GND ………………………………… GND
2.3 Bluetooth Interface (Option)
1) The printer can be connected to devices equipped Bluetooth communication capacity
(PDA, PC, etc…)
2) Use the Bluetooth connection function suppoeted by the device to connect to the printer
Classifications Description
Bluetooth Spec. Bluetooth V2.0 / Class2(10m)
Frequency 2.4GHz ISM BAND
Modulation method
FH method(Frequency hopping spectrum
diffusion method)
Hypothetical interference distance 10m
Transfer rate
The communication speed between Bluetooth and
the printer
is 115.2kbps.
Data bit / Parity bit / Stop bit 8 Data bit / Noparity / 1 Stop bit Fixed.
Transfer capacity Up to +4 dBm (class 2)
PIN code “0000” Fixed.
Profile Serial Port Profile (SPP)

- 10 -
2.4 Wifi Interface ( Factory Option )
Item Content
Standard 802.11b, 802.11g
Communication Speed(Max) 54M
Transmission Distance(Max)
100m(Indoors without obstructs))the
distance Depending on
the environment)
chanel 1-14
Wireless
Safety 64/128 WEP, WPA
Condition’s monitor
Special configure tools
Browser
Configuration management
Special configure tools
Browser
Firmware updating TFTP
Basic communication protocol ARP, RARP, IP, ICMP, TCP, UDP
The
interface
module
Printing communication mode Port 9100, LPR/LPD
State demand
The Software package
(include DLL and Routines), browser
Average communication speed >50kByte/s
2.5 Interface Connector
<Serial connector> <USB Connector>
