Citizen Eco-Drive User manual

1
English
ank you for your purchase of this Citizen watch.
Before using the watch, read this instruction manual carefully to ensure
correct use.
Aer reading the manual, store it in a safe place for future reference.
Visit the Citizen website (http://www.citizenwatch-global.com/) to view
visual guides for operation of your watch. Some models may be equipped
with external features (calculation scale, tachymeter, etc.). Visual guides for
operation of such external features can also be found on the website.
To check the movement number
A case number—4 alphanumeric characters and
6 or more alphanumeric characters—is engraved
on the case back. (Figure on the right) The first
4 characters of the case number represent the
movement number of the watch. In the example on
the right," " is the movement number.
Engraving position example
The engraving position may differ
depending on watch model.

2
is manual contains instructions that should be strictly followed at all times
not only for optimal use, but to prevent any injuries to yourself, other persons
or property. We encourage you to read the entire booklet (especially, pages 40 to
51) and understand the meaning of the following symbols:
■ Safety advisories are categorized and depicted in this manual as follows:
DANGER Highly likely to cause death or serious injury
WARNING Can cause serious injury or death
CAUTION Can or will cause minor or moderate injury or
damage
Safety precautions (IMPORTANT)

3
English
■ Important instructions are categorized and depicted in this manual as follows:
Warning (caution) symbol followed by instructions that should
be followed or precautions that should be observed.
Warning (caution) symbol followed by prohibited matters.
Safety precautions (IMPORTANT)

4
Before using this watch
Aer unpacking, the following must be done before using the watch:
■Checking the power reserve ⇨Page 17
Check the charge level of the watch.
This watch has a rechargeable cell which is charged by
exposing the dial to light.
Expose the dial to light regularly to charge the watch.
For details of charging, see pages 13 to 17.

5
English
■Protective Stickers
Be sure to remove any protective stickers that may be on your watch (case
back, band, clasp, etc.). Otherwise, perspiration or moisture may enter the gaps
between the protective stickers and the parts, which may result in a skin rash
and/or corrosion of the metal parts.
■Band adjustment
We do not recommend attempting to adjust the watch band yourself. If not
adjusted correctly, the band may become detached leading to an injury or loss
of your watch. (Some retailers may supply a band adjustment tool with your
purchase).
For band adjustment, we recommend you consult the retailer where the watch
was purchased or your nearest Authorized Citizen Service Center. Some repair
shops may charge a nominal fee for adjustment if the watch was not purchased
directly from them.
Before using this watch

6
■How to use a specially designed crown/push button
Some models are equipped with a specially designed crown and/or push button
to prevent accidental operation.
Screw down crown and screw down push button
Unlock the crown prior to operate your watch.
Unlock Lock
Screw
down
crown
Rotate the crown
counterclockwise
until it releases from
the case.
Push the crown in to the
case. With gentle pressure
towards the case, rotate
the crown clockwise to
secure it to the case. Be
sure to tighten firmly.
Screw
down push
button
Rotate the
locking screw
counterclockwise, and
loosen until it stops
Rotate the locking screw
clockwise, and tighten
firmly.
Before using this watch

7
English
Recessed buttons
Press the button with a narrow-tipped object
such as a wooden toothpick.
Before using this watch

8
Table of contents
Features………………………………………………………… 10
Component identification …………………………………… 12
Charging your watch ………………………………………… 13
Crown position and operation ……………………………… 18
Adjusting the time …………………………………………… 19
Adjusting the calendar ……………………………………… 21
Month and leap year indications …………………………… 24
Adjusting the time difference ……………………………… 28

9
English
Checking the current reference position ………………… 30
Timekeeping accuracy ……………………………………… 34
Troubleshooting ……………………………………………… 36
Eco-Drive (solar powered) watch handling precautions … 40
Water resistance ……………………………………………… 44
Precautionary items and usage limitations ……………… 46
Specifications ………………………………………………… 52
Table of contents

10
is watch includes the following features:
Eco-drive
No need for periodical changing of rechargeable cells. e watch is charged by
light.
12 o'clock midnight sharp calendar update function
e calendar updates as the clock strikes midnight (0:00:00).
Annual time accuracy: ±10 seconds
is high-precision watch realized an annual time dierence of about ±10
seconds max.
Time difference correction function
When you travel overseas, you can easily adjust your watch to the local time
without having to stop the watch.
Features

11
English
Perpetual calendar
No need for date correction at the end of each month. e leap year is also
updated automatically.
Antimagnetic performance
e functionality of the watch will be maintained even when the watch is
brought as close as up to 5 cm of the devices that emit magnetic elds in daily
life.
Shock detection function
is function prevents the second, minute, and hour hands from becoming
misaligned should the watch be subjected to shock.
Automatic hand position adjustment function
e hand positions are checked at regular intervals. Any misalignment
detected will be corrected immediately to keep accurate time.
Features

12
* The illustrations may diff er from the actual watch you have purchased.
* A solar cell is placed under the dial.
Date indicator
Hour hand
Minute hand
Charge
indicator
Second hand
Crown
Button
Component identification

13
English
is watch has a rechargeable cell which is charged by exposing the dial to light,
such as direct sunlight or uorescent lamps.
Aer taking o the watch, put it in a location where the dial is exposed to bright
light, such as by a window.
e watch can be charged eectively when the dial
is exposed to sunlight as shown in the gure.
For optimal performance, be sure to:
• Charge the watch by exposing it to direct sunlight for
five to six hours at least once a month.
• Avoid leaving the watch in a dark place for long periods
of time.
Charging your watch
• If the watch is obscured from light by long sleeves frequently, supplemental charging
may be needed to ensure continual operation.
• Do not charge the watch at high temperature (about 60°C/140°F or higher).

14
■When the watch reaches a low charge state
(insuffi cient charge warning function)
When the watch reaches a low charge state, the insucient charge warning
function kicks in, and the second hand begins to move in two-second
increments (two-second mode). Charge the watch by exposing its dial to light.
• Aer some time of charging, the second hand will begin to move in onesecond
increments (normal mode).
• If the watch is le in two-second mode for three days or longer, the watch will
run out of power and stop working.
• e time and date are indicated even during
two-second mode.
• Make sure that the watch is charged and
moving in one-second increments (normal
mode) before setting or adjusting the watch.
• While the insucient charge warning
function is active, the compensation
mechanism to ensure timekeeping accuracy
remains disabled. Promptly charge the watch.
Charging your watch

15
English
■Charging time by environment
Below are the approximate times required for charging when exposing the watch
dial to light continuously. Please use this table as a reference only.
Environment Illuminance
(lx)
Charging time (approx.)
To work for
one day
To start working
normally when the
cell is discharged
To become fully
charged when the
cell is discharged
Outdoors (sunny) 100,000 4 minutes 40 minutes 30 hours
Outdoors (cloudy) 10,000 12 minutes 1.5 hours 45 hours
20 cm (7-7/8 inches)
from a fluorescent
lamp (30W)
3,000 40 minutes 3.5 hours 150 hours
Interior lighting 500 4 hours 19 hours —
• When the battery is fully charged, the overcharge protection function stops the charging so that the
watch performance and rechargeable cell are not adversely aff ected by overcharge.
Your watch will run for approximately 7 months from a full charge or up to 1.5 years with the power
save feature engaged (based on a full charge).
After the second hand starts moving once every two seconds, it will last for approximately 3 days.
Charging your watch

16
■Power save feature
If you store the watch inside the case or other dark places where no light can
reach the dial of the watch for seven consecutive days or longer, the watch
will automatically stop at the 12 o'clock position to save battery power. In the
meantime, the time is kept internally, whereas the date and power reserve
indicators continue to work normally.
• e power save feature does not work while the crown is at Position 1or Position 2.
• e power save feature cannot be activated manually.
■To cancel the power save feature
Once the dial of the watch is exposed to light and the battery begins to charge,
power save mode will be cancelled, and the hands will move to point to the current
time. Do not pull the crown out while the power save mode is being cancelled and
the hour, minute, and second hands are moving to point to the current time.
Pulling the crown out causes the hands to stop moving at that moment,
preventing them from pointing correctly to the current time.
Charging your watch

17
English
Level 3 2 1 0
Power
reserve
level
Approximate
duration of
operation at
each level
Approx.
210 to 160 days
Approx.
160 to 100 days
Approx.
100 to 3 days Approx. 3 days
Power reserve
is sufficient for
all features and
functions. Optimal
performance is
achieved at this
level.
Power reserve is
sufficient for all
operations at this
level.
Power reserve is
getting low. The
watch should be
fully charged to
ensure optimal
performance.
Power reserve is
not sufficient for
normal operation.
The watch must
be fully charged.
The watch must be charged immediately.
■How to check the power reserve indicator
e hand position of the power reserve indicator shows the power reserve
amount, as illustrated below.
*With the charge level 0, the compensation mechanism to ensure timekeeping accuracy is
disabled. Charge the battery immediately.
Charging your watch

18
Pull the crown out to make necessary adjustments, as illustrated below.
: For adjusting time difference and calendar
: For adjusting time
0
2
1
0
1 2
* The screw down lock returns to position 0
when unlocked.
(default position): No adjustment can be performed
Crown position and operation
