Clarion VT1010E Manual

+
Owner’s manual & Installation manual
Manuel de l'utilisateur et manuel d’installation
Benutzerhandbuch & Installationsanleitung
Manuale utente e guida di installazion
Manual de instalación y manual del propietario
Руководство пользователя иРуководство по монтажу
VT1010E
VT1510E
10” /15.4” OVERHEAD MONITOR SYSTEM WITH
DVD PLAYER & USB2.0 /SD /MMC PORTS
MONITEUR SUSPENDU DE 10” /15.4” AVEC
LECTEUR DE DVD ET PORTS USB2.0 /SD /MMC
10” /15.4”-DECKENMONITORSYSTEM MIT
DVD-PLAYER & USB2.0-/SD-/MMC-PORTS
SISTEMA MONITOR RIBALTABILE DA 10” /15.4” CON
LETTORE DVD E PORTE USB2.0 /SD /MMC
MONITOR DE TECHO DE 10"/15" CON
REPRODUCTOR DE DVD Y PUERTOS USB2.0/SD/MMC
10” /15.4” ПОТОЛОЧНЫЙ МОНИТОР C DVD ПЛЕЕРОМ И
ПОРТАМИ USB2.0 /SD /MMC

VT1010E/VT1510E 1
Thank you for purchasing this Clarion product.
Please read this owner’s manual in its entirety before operating this equipment.
After reading this manual, keep it handy, such as in your glove compartment.
Save your sales receipt. The warranty at the end of this manual and your sales receipt
are essential for warranty service.

Contents
2 VT1010E/VT1510E
Contents
1. FEATURES .....................................................................................................................3
OVERHEAD MONITOR & IMAGE FEATURES ....................................................................................... 3
DVD VIDEO FEATURES .......................................................................................................................... 4
2. PRECAUTIONS...............................................................................................................5
OPERATING............................................................................................................................................. 5
GENERAL................................................................................................................................................. 5
MAINTENANCE........................................................................................................................................ 5
INSTALLATION......................................................................................................................................... 6
3. CONTROLS.....................................................................................................................7
MONITOR CLOSED ................................................................................................................................. 7
MONITOR OPEN...................................................................................................................................... 8
SIDE PROFILE VIEW ............................................................................................................................... 9
REMOTE CONTROL .............................................................................................................................. 10
4. OPERATIONS ...............................................................................................................12
OPENING THE MONITOR ..................................................................................................................... 12
CLOSING THE MONITOR...................................................................................................................... 12
HANDLING DISCS ................................................................................................................................. 13
TURNING THE PLAYER ON.................................................................................................................. 13
TURNING THE PLAYER OFF................................................................................................................ 13
CHANGING THE IMAGE ASPECT RATIO ............................................................................................ 13
PLAYING A DISC (DVD OR CD)............................................................................................................ 13
USING HEADPHONES .......................................................................................................................... 14
PLAYING DVDs ...................................................................................................................................... 16
PLAYING AUDIO CDs ............................................................................................................................ 18
PLAYING MP3s ...................................................................................................................................... 18
USING THE USB STORAGE AND SD/MMC CARD.............................................................................. 19
CARE AND MAINTENANCE .................................................................................................................. 20
CHANGE THE BATTERY IN THE REMOTE CONTROL....................................................................... 20
5. INSTALLATION AND WIRING ......................................................................................22
WHAT IS INCLUDED IN THE BOX ........................................................................................................ 22
BEFORE YOU BEGIN ............................................................................................................................ 22
MOUNTING AND WIRING PRECAUTIONS .......................................................................................... 23
INSTALLATION PROCEDURE .............................................................................................................. 23
WIRING DIAGRAM................................................................................................................................. 26
6. SETTING PREFERENCES ...........................................................................................27
ACCESSING THE ON-SCREEN DISPLAY MENUS.............................................................................. 27
GENERAL SETUP PAGE....................................................................................................................... 27
SPEAKER SETUP PAGE....................................................................................................................... 27
PREFERENCE PAGE ............................................................................................................................ 27
7. TROUBLESHOOTING ..................................................................................................29
8. SPECIFICATIONS.........................................................................................................31
9. GLOSSARY...................................................................................................................32

1. FEATURES
VT1010E/VT1510E 3
1. FEATURES
Warning!
The Clarion VT1010E / VT1510E overhead monitor players are
designed strictly for rear-seat entertainment. Viewing the monitor
while operating a motor vehicle can result in serious injury and/or
property damage.
Clarion is not responsible for any injury and/or property damage as
a result of the improper use or viewing of the monitor.
The Clarion VT1010E/VT1510E overhead monitor players are engineered with advanced
technological designs and components to combine flexibility with reliability, and
expandability for the best picture quality and ease-of-use.
Flexibility
Designed primarily for rear seat entertainment, the audio from a VT1010E/VT1510E can be
enjoyed privately through wireless headphones and/or incorporated into any head unit.
Reliability
High-grade electronic components and heightened electronic connections provide years of
service in extremely harsh, mobile environments.
Expandability
The player’s built-in audio/video (A/V) connectors allow you to add multiple A/V sources.
OVERHEAD MONITOR & IMAGE FEATURES
Flip-down thin film transistor (TFT) active matrix display with screen width that
depends on the model:
VT1010E: 10.2”
VT1510E: 15.4”
High Resolution LCD with 16:9 aspect ratio:
VT1010E: 800 x 480 pixels
VT1510E: 1280 x 800 pixels
NTSC, AUTO and PAL support
Wide viewing angle
Manual display angle adjustment: vertically adjustable up and down with a maximum
angle of 150 degrees
Adjustable color, contrast brightness, and hue (PAL) or tint (NTSC)
On-screen display (OSD) of configuration options
USB2.0 (full speed) Support
Memory Card Reader for SD/MMC formats
Roof Mounted Application
Automotive Start-up Protection
2 Audio/Video Inputs
1 Audio/Video Output
Built-in White LED Dome Light
Built-in IR Transmitter for IR Wireless Headphones

1. FEATURES
4 VT1010E/VT1510E
Wireless IR Remote Control
Slot-in DVD Player with Multi-format Support
Capability to read: DVD /DVD±R /DVD±RW /CD-DA /CD-RW/MP3 /WMA /VCD
/SVCD/DivX
Note:
Multi-session CDs and 320kbps WMA files cannot be played on this player.
3.5 mm Audio/Video Input
DVD VIDEO FEATURES
DVD drive that supports the following formats:
DVDs (12cm)
Video CDs (12cm)
Audio CDs (12cm)
MP3 CDs (12cm)
DivX CDs / DVDs
Playback of CDs with two recorded sessions (one audio and one data).
Multi-sound ( ): DVD audio that supports up to eight languages per film.
Multi-angle function ( ): for DVDs that provide multiple views of the same scene.
Subtitles ( ): support up to 32 languages.
The playback of MP3 music files stored on a CD-R/CD-RW disc.
Region number assigned based on the sales area; region number is indicated on the
box as follows:
ALL
12
3
2
DivX Certified®to play DivX®video, including premium content.
ABOUT DIVX VIDEO: DivX®is a digital video format created by DivX, Inc. This is an
official DivX Certified®device that plays DivX video. Visit divx.com for more information
and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified®device must be registered in
order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your registration.
DivX®, DivX Certified®and associated logos are trademarks of DivX, Inc. and are used
under license.

2. PRECAUTIONS
VT1010E/VT1510E 5
2. PRECAUTIONS
Failure to observe these precautions may damage your car, the monitor, or the video
source, and may void the warranty.
For questions or problems not covered in this manual, contact your local Clarion Dealer.
OPERATING
Do not operate this product in ways other than those described in this manual.
Failure to follow instructions may void the warranty.
Do not use the unit with the ignition off. This could drain the car’s battery.
If the internal temperature of the vehicle is extremely high (over 50 degrees Celsius),
let the unit cool down a bit before you use it.
If the temperature in the car is very low (below -5 degrees Celsius), starting the unit
right after you start the car with its heater running may cause moisture to form in the
unit. Do not power on the unit for an hour. Failure to do so may cause an electrical
short. Allow about one hour for the condensation to dissipate before using the unit.
In extremely cold temperatures the picture may appear dark and move slowly. The
display returns to normal when the temperature rises.
When operating the unit, ensure you are seated with your seat belt fastened, or parked
in a safe location. Otherwise, you may be injured if the driver brakes suddenly. In an
accident, injuries may be more severe if your seat belt is not fastened.
Before leaving the vehicle, eject the disc and store it separately away from direct
sunlight. Heat and humidity can damage discs causing them not to play.
GENERAL
Do not leave the monitor open when the unit is not in use. Direct sunlight can cause the
monitor to malfunction.
Do not hang onto or hang items from the overhead monitor.
Do not pour liquid into the unit or insert foreign objects into the DVD drive slot. Water,
humidity and foreign objects may damage internal circuitry.
If the unit becomes wet, turn off all power and consult your authorized Clarion Dealer
for service. Do not operate the unit until it has been inspected and repaired.
Do not drop the unit or hit the LCD panel. You may cause permanent damage.
If the LCD breaks, avoid touching the glass and fluid. If you do touch the fluid, clean it
off your body and/or clothes with plenty of water, then get medical attention.
MAINTENANCE
Do not clean the surface of the LCD with chemical solvents or corrosive detergents.
Permanent damage to the screen may result. Avoid using abrasive cleaners. Use a
soft, damp cloth to clean.
Do not disassemble or modify this unit. You may damage the monitor, void the
warranty, and suffer electric shock. Modification of this unit will void safety
certifications.

2. PRECAUTIONS
6 VT1010E/VT1510E
INSTALLATION
Installation of mobile audio and video components requires experience with a variety of
mechanical and electrical procedures. Although this manual provides general installation
and operation instructions, it does not depict the exact installation methods for your
particular vehicle.
If you do not have the required knowledge, experience, and/or tools to successfully
complete the installation, consult an authorized Clarion Dealer about professional
installation options.

3. CONTROLS
VT1010E/VT1510E 7
3. CONTROLS
MONITOR CLOSED
Looking up directly below at the player with the LCD panel closed.
Buttons functions (monitor is closed)
Power button Press to turn On or Off the player.
Menu button Open the operational menu. Press again to select each menu
item sequentially.
Source button Selects the video input source: DVD-IN, AV IN1 or AV IN2,
DVD/USB
NOTE: To switch to the USB mode, switch to DVD mode, then
insert the USB into the port. Press and hold this button for 2
seconds to switch to USB mode while in the DVD mode.
Decrease button Decrease volume during playback.
In the MENU mode, press to select menu item down.
Increase button Increase volume during playback.
A
UX In 3.5mm
Dome Ligh
t
Power button
Operational Menu button
Source button
Decrease button
Increase button
USB por
t
(VT1010E)
Dome Light switch
IR window
Dome Ligh
t
Eject button
Play / Pause button
Stop button
Next button
Previous button
Monitor Release button
SD/MMC port
s
(VT1010E)
SD/MMC port
s
(VT1510E)
U
SB por
t
(
VT1510E)

3. CONTROLS
8 VT1010E/VT1510E
In the MENU mode, press to select menu item up.
Previous button Skips to the previous chapter on a DVD or track on a CD.
During playback, press and hold to fast reverse playback
Next button Skips to the previous chapter on a DVD or track on a CD.
During playback, press and hold to fast forward playback
Stop button Press once to stop playback. To resume where the player left off,
press the play/pause button.
Press this button twice to stop playing fully. To start playing at
the beginning of the disc, press the play/pause button.
Play/Pause
button
Plays or pauses the disc.
Eject button Ejects the disc.
Monitor
Release button Release the LCD panel from the storage area.
Dome light switch Configures the dome light: ON, OFF or door activated. To
manually turn the light on or off, move this switch to the ON or
OFF positions.
In the car door activated position, the dome light turns on and off
when you open and close the car door.
NOTE:
The dome light switch works only when the green dome light
wire is connected to the door sensor and the polarity switch is
set correctly.
See the vehicle’s wiring manual for connection details.
MONITOR OPEN
Looking up directly below at the player with the LCD panel open.
Screw hole
Screw hole
Screw hole
Screw hole
Reset button
LCD Off switch
