Clarion NX807E User manual

DVD MULTIMEDIA STATION WITH BUILT-IN NAVIGATION &
7 ’’ TOUCH PANEL CONTROL
Owner’s Manual
NX807E

1
NX807E
English
English Owner’s Manual English Owner’s Manual
CAUTIONS:
!CAUTION
ADVARSEL.
OBS!
VAROITUS
This appliance contains a laser system
and is classified as a “CLASS 1 LASER
PRODUCT”. To use this model properly, read
this Owner’s Manual carefully and keep this
manual for your future reference. In case of
any trouble with this player, please contact
your nearest “AUTHORIZED service station”.
To prevent direct exposure to the laser beam,
do not try to open the enclosure.
Apparaten innehåller laserkompo-
nenten som
avger laserstrålning överstigande
gränsen för laserklass 1.
Suojakoteloa si saa avata.
Laite sisältää
laserdiodin, joka lähettää
näkymätöntä
silmille vaarallista lasersäteilyä.
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED IN THE
OWNER’S MANUAL MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
Denne mærking er anbragt udvendigt på
apparatet og indikerer, at apparatet arbejder
med laserstråler af klasse 1, hvilket betyder,at
der anvendes laserstråler af svageste klasse,
og at man ikke på apparatets yderside kan
blive udsat for utilladelig kraftig
stråling.
APPARATET BØR KUN ÅBNES AF
FAGFOLK MED SÆRLIGT KENDSKAB TIL
APPARATER MED LASERSTRÅLER!
Indvendigt i apparatet er anbragt den her
gengivne advarselsmækning, som advarer
imod at foretage sådanne indgreb i apparatet,
at man kan komme til at udsaætte sig for
laserstråling.

2NX807E
English
English Owner’s Manual English Owner’s Manual
Contents
1. FEATURES...........................................................................................................4
Expanding Systems ..............................................................................................4
2. PRECAUTIONS....................................................................................................5
3. CAUTIONS ON HANDLING.................................................................................8
Operation Panel ....................................................................................................8
USB Port...............................................................................................................8
Cleaning................................................................................................................8
Handling Discs......................................................................................................9
4. OPERATION PANEL..........................................................................................11
Functions of Buttons...........................................................................................11
5. REMOTE CONTROL..........................................................................................12
Remote Control Functions..................................................................................13
6. MAIN MENU.......................................................................................................15
7. DVD VIDEO PLAYER OPERATIONS ...............................................................16
Discs ...................................................................................................................16
Change DVD System Settings............................................................................17
Watching to a Disc..............................................................................................17
Showing DVD Player Mode Screen ....................................................................18
Operate the DVD Player Menu............................................................................18
Showing Video Files Player Mode Screen..........................................................19
Operate the Video Files Player Menu .................................................................20
Playable Video Disc Formats..............................................................................21
8. CD PLAYER OPERATIONS ..............................................................................22
Listening to a Disc/Ejecting a Disc .....................................................................22
Showing CD Player Mode Screen ......................................................................22
Operate the CD Player Menu..............................................................................22
Listening to Compressed Audio .........................................................................23
Tag Display Function ..........................................................................................23
Playback MP3/WMA/AAC menu ........................................................................24
9. USB AUDIO OPERATIONS ..............................................................................25
Notes on Using USB Memories..........................................................................25
Select USB Audio Mode.....................................................................................25
Playing Audio Files in USB Memory ...................................................................26
10. USB VIDEO OPERATIONS..............................................................................27
Notes on Using USB Memory Device.................................................................27
Select USB Video Mode .....................................................................................27
Playing Video Files in USB Memory ...................................................................27
Playable Video Format........................................................................................27
11. iPod®OPERATIONS .......................................................................................29
Notes on Using iPod/iPhone®............................................................................29
iPod Audio Menu Operations..............................................................................29
iPod Audio ID3 Mode Screen .............................................................................29
iPod Audio Playlist Mode Screen .......................................................................30
iPod Audio List Mode Screen .............................................................................30
iPod Audio Bluetooth®Mode.............................................................................30
12. Bluetooth AUDIO PLAYER OPERATIONS.....................................................31
Selecting the Bluetooth Audio Mode..................................................................31
Bluetooth Audio Player Settings.........................................................................31
Registering Your Bluetooth Audio Player (Pairing) .............................................31
Selecting the Bluetooth Audio Player .................................................................32
Controlling the Bluetooth Audio Player...............................................................32
13. Bluetooth TELEPHONE OPERATIONS ............................................................33
Select the BT Phone Mode.................................................................................33
Bluetooth Telephone Settings ............................................................................33
Registering Your Phone (Pairing)........................................................................34

3
NX807E
English
English Owner’s Manual English Owner’s Manual
Select the Phone.................................................................................................34
Get the Phone Book Data...................................................................................34
Telephone Operations ........................................................................................34
14. TUNER OPERATIONS.....................................................................................36
15. DAB OPERATIONS..........................................................................................38
16. TV OPERATIONS.............................................................................................40
17. HDMI MODE ....................................................................................................41
Wire Connection of HDMI Mode.........................................................................41
Select HDMI Source ..........................................................................................42
18. Apple CarPlay™..............................................................................................42
To start Apple CarPlay........................................................................................42
To go to Apple CarPlay screen ..........................................................................43
To move to Apple CarPlay screen .....................................................................43
To return to original screen ................................................................................44
19. AUX .................................................................................................................45
20. CAMERA INPUT OPERATIONS .....................................................................45
21. REAR SOURCE OPERATIONS.......................................................................46
DVD Video in Rear ..............................................................................................46
DVD Video Rear Source Control Info Mode. ......................................................46
DVD Video Rear Source Control Direct Mode. ..................................................46
AUX Video in Rear...............................................................................................47
22. FULL DIGITAL SOUND SYSTEM....................................................................47
23. SETTING OPERATIONS..................................................................................48
General Setup Menu...........................................................................................48
Video Setup Menu ..............................................................................................49
Audio Setup Menu ..............................................................................................49
Navigation Setup Menu ......................................................................................49
Others Setup Menu.............................................................................................50
Set the Anti-Theft Code......................................................................................50
24. TROUBLESHOOTING .....................................................................................51
General................................................................................................................51
DVD Player..........................................................................................................51
USB Device.........................................................................................................52
Bluetooth ............................................................................................................52
TFT Screen..........................................................................................................53
25. ERROR DISPLAY.............................................................................................54
DVD/CD Player ...................................................................................................54
26. SPECIFICATIONS............................................................................................55
27. WIRE CONNECTION GUIDE...........................................................................57

4NX807E
English
English Owner’s Manual English Owner’s Manual
1. FEATURES
Expanding Systems
NOTE:
• The items listed outside of the frames are the commercial products generally sold.
• CCA-771,CCA-802:Sold separately.
Apple CarPlay™
Optical Digital Output
Latest Map Guarantee
iPod
®
Expanding Visual Features
Rear Monitor Rear Vision Camera
Expanding Audio Features
External Power
Amplier
External Sound
Processor
iPhone
®
USB
Memory
Bluetooth
Telephone
iPhone/Smartphone via HDMI
Connect via CCA-771,CCA-802

5
NX807E
English
English Owner’s Manual English Owner’s Manual
2. PRECAUTIONS
WARNING
• For your safety, the driver should not watch any video sources and/or operate the controls while driving.
Please note that watching and operating any video sources while driving are prohibited by law in some
countries. Also, while driving, keep the volume to a level at which external sounds can be heard.
• Do not disassemble or modify this unit. It may cause an accident, re, or electric shock.
• Do not use this unit when a trouble exists, such as no screen content appears or no sound is
audible. It may cause an accident, re, or electric shock. For that case, consult your authorized
dealer or a nearest Clarion service center.
• In case of a problem, such as any material has been entered in the unit, the unit gets wet, or
smoke or strange smells come out of the unit, etc., stop using this unit immediately, and consult
your authorized dealer or a nearest Clarion service center.
Using it in that condition may cause an accident, re, or electric shock.
• Use a fuse with the same specication only when replacing the fuse.
Using a fuse with a different specication may causes a re.
• For the installation of this unit or a change in the installation, ask your authorized dealer or a
nearest Clarion service center for safety. Professional skills and experiences are required to do
so.
• This navigation system should not be used to replace your own judgment. No itinerary suggested
by this navigation system should ever override any highway regulations, your own judgment, or a
knowledge of safe driving practices. Do not follow the navigation system’s suggested itinerary if it
would cause you to perform a dangerous or illegal act, place you in a dangerous situation, or take
you into an area you consider unsafe.
• The advice provided by the navigation system is to be regarded as a suggestion only. There may
be times when the navigation system displays the vehicle’s location incorrectly, fails to suggest
the shortest route, or fails to direct you to your desired destination. In such instances, rely on your
own driving judgment, taking into account the driving conditions at the time.
• Do not use the navigation system to locate emergency services. The database does not contain
a complete listing of emergency services such as police stations, re halls, hospitals and walk-in
clinics. Please show discretion and ask for directions in such instances.
• As the driver, you alone are responsible for your driving safety.
• In order to avoid a trafc accident, do not operate the system while driving.
• In order to avoid a trafc accident, operate the system only when the vehicle is stopped at a safe
place and the parking brake is on.
• In order to avoid a trafc accident or trafc offense, remember that actual road conditions and
trafc regulations take precedence over the information contained on the navigation system.
• The software may contain inaccurate or incomplete information due to the passage of time,
changing circumstances, and the sources of information used. Please respect current trafc
conditions and regulations at all times while driving.
• Where actual road conditions and highway regulations differ from the information contained on
the navigation system, abide by the highway regulations.
• Keep the amount of time spent viewing the screen while driving to a strict minimum.
• The navigation system does not provide, nor represent in any way information on: trafc and
highway regulations; technical aspects of the vehicle including weight, height, width, load and
speed limits; road conditions including grade, percentage of incline and surface conditions;
obstacles such as the height and width of bridges and tunnels; and other current driving or road
conditions. Always rely on your own judgment when driving a car, taking into account current
driving conditions.

6NX807E
English
English Owner’s Manual English Owner’s Manual
• Changes or modications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
• Improper connection of speed pulse signal may result in serious damage or injury including
electrical shock, and interference with the operation of the vehicle’s anti-lock braking system,
automatic gearbox and speedometer indication.

7
NX807E
English
English Owner’s Manual English Owner’s Manual
NX807E
CNE-8288E-CL
1:1
机身大贴纸
技术说明：
1、大小65x75mm,红色外框线为刀模线。
2、材质，80g铜版纸,过哑胶。
3、内容印刷黑色:PANTONE Black C。
4、要求内容印刷正确、清晰，贴纸表面干净、整洁，不得有脏污、斑点、折痕；
切边务必整齐,不得歪斜。
D025034
7E 8
XXXXX
Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby
Laboratories.
NX807E
1.When the inside of the car is very cold and
the player is used soon after switching on the
heater, moisture may form on the disc (DVD/
CD) or the optical parts of the player and
proper playback may not be possible. If
moisture forms on the disc (DVD/CD), wipe it
o with a soft cloth. If moisture forms on the
optical parts of the player, do not use the
player for about one hour. The condensation
will disappear naturally allowing normal
operation.
2.Driving on extremely bumpy roads which
cause severe vibration may cause the sound
to skip.
3.This unit uses a precision mechanism. Even
in the event that trouble arises, never open
the case, disassemble the unit, or lubricate
the rotating parts.

8NX807E
English
English Owner’s Manual English Owner’s Manual
3. CAUTIONS ON HANDLING
Operation Panel
• The operation panel will operate properly in a
temperature range of 0˚ to 60˚ C.
• Do not allow any liquids on the set from
drinks, umbrellas etc. Doing so may damage
the internal circuitry.
• Do not disassemble or modify the set in any
way. Doing so may result in damage.
• Subjecting the operation panel to shocks
may result in breakage, deformation or other
damage.
• Do not let cigarettes burn the display.
• If a problem should occur, have the set
inspected at your store of purchase.
• The remote control unit may not work if the
remote control sensor is exposed to direct
sunlight.
• In extremely cold weather, the display
movement may slow down and the display
may darken, but this is not a malfunction.
The display will work normally when the
temperature increases.
• Small black and shiny spots inside the liquid
crystal panel are normal for LCD products.
For a longer service life, be sure to read the following cautions.
Cleaning
• Cleaningthecabinet
Use a soft, dry cloth and gently wipe off
the dirt. For tough dirt, apply some neutral
detergent diluted in water to a soft cloth, wipe
off the dirt gently, then wipe again with a dry
cloth.
Do not use benzene, thinner, car cleaner, etc.,
as these substances may damage the cabinet
or cause the paint to peel. Also, leaving rubber
or plastic products in contact with the cabinet
for long periods of time may cause stains.
• Cleaningtheliquidcrystalpanel
The liquid crystal panel tends to collect dust,
so wipe it off occasionally with a soft cloth.
The surface is easily scratched, so do not rub
it with hard objects.
USB Port
• The USB memory sticks must be recognized
as “USB mass storage class” to work
properly. Some models may not operate
correctly.
When the memorized data is lost or
damagedbyanychance,Clarionshallnot
beliableforanydamage.
When using an USB memory stick, we
recommend that you backup your data stored
on it before by using a personal computer etc.
• Data les may be broken when using USB
memory sticks in the following situation:
When disconnecting the USB memory stick or
turning the power off during writing or reading
data. When affected by static electricity or
electric noise. Connect/disconnect the USB
memory stick when it is not accessed.
• Connecting with the computer is not
supported.
• Connecting with the USB Hub is not
supported.

9
NX807E
English
English Owner’s Manual English Owner’s Manual
Handling Discs
Handling
• New discs may have some roughness
around the edges. If such discs are used,
the player may not work or the sound
may skip. Use a ball-point pen or the like
to remove any roughness from the edge
of the disc.
Ball-point pen
Roughness
Never stick labels on the surface of the
disc or mark the surface with a pencil or
pen.
• Never play a disc with any cellophane
tape or other glue on it or with peeling off
marks. If you try to play such a disc, you
may not be able to get it back out of the
DVD player or it may damage the DVD
player.
• Do not use discs that have large
scratches, are misshapen, cracked,
etc. Use of such discs may cause
misoperation or damage.
• To remove a disc from its storage case,
press down on the center of the case
and lift the disc out, holding it carefully
by the edges.
• Do not use commercially available disc
protection sheets or discs equipped with
stabilizers, etc. These may damage the
disc or cause breakdown of the internal
mechanism.
Storage
• Do not expose discs to direct sunlight or
any heat source.
• Do not expose discs to excess humidity
or dust.
• Do not expose discs to direct heat from
heaters.
Cleaning
• To remove ngermarks and dust, use
a soft cloth and wipe in a straight
line from the center of the disc to the
circumference.
• Do not use any solvents, such as
commercially available cleaners, anti-
static spray, or thinner to clean discs.
• After using special disc cleaner, let the
disc dry off well before playing it.
On Discs
• Never turn off the power and remove the
unit from the car with a disc loaded.
CAUTION
Foryoursafety,thedrivershouldnot
insertorejectadiscwhiledriving.
