Clarke CWL6B Installation and operation manual

O
OPERATING & MAINTENANCE
INSTRUCTIONS
0302
20” WOODLATHE
20” WOODLATHE
Model No. CWL6B
Part No. 6501650

O
Lathe Specifications ................................................................................................... 3
General Safety Instructions ........................................................................................ 4
Wood Lathe Safety Instructions ................................................................................. 5
Electrical Connections and Motor Specifications ................................................... 6
Unpacking And Checking Contents ........................................................................ 7
Spindle Speeds and Belt Tensioning ......................................................................... 8
Preparation for use (Spindle/Faceplate/Outboard Turning & Indexing) ............. 9
Using Woodworking Chisels and Basic Techniques .............................................. 12
Making Standard Cuts ............................................................................................. 17
Spindle Turnings ........................................................................................................ 20
Face Plate And Chuck Turnings .............................................................................. 22
Fancy Face Plate Turnings ....................................................................................... 23
Turning Plastics .......................................................................................................... 26
Sanding, Buffing And Polishing ............................................................................... 27
Maintenance ............................................................................................................. 28
Lubrication ................................................................................................................. 28
Optional Accessories ............................................................................................... 29
Spares And Servicing Contacts .............................................................................. 29
Parts List ......................................................................................................................30
Parts Diagram ............................................................................................................ 31
CONTENTS Page
231
PARTS DIAGRAM

O3
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the
date of purchase. Please keep your receipt as it will be required as proof of purchase. This guarantee
is invalid if the product is found to have been abused or tampered with in any way, or not used for the
purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be returned to us without
prior permission. This guarantee does not effect your statutory rights.
Thank you for purchasing this CLARKE 20” Wood lathe, designed for DIY use only.
Before assembling this machine, please read this manual thoroughly and follow all instructions
carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can
look forward to the wood lathe giving you long and satisfactory service.
WARNING:
THIS MACHINE MUST NOT BE MODIFIED, OR USED FOR ANY PURPOSE
OTHER THAN THAT FOR WHICH IT IS DESIGNED.
SPECIFICATIONS
Motor .............................................................................................. 230V 50Hz 1Ph
Power Rating ................................ 370W (1/2 HP)
Switch Type ................................... No Volt Release
Turning Capacity (Between Centres) ....................... 20 in (508mm)
(Over Bed) .................................... 9 1/2in Dia (242mm)
Spindle Speeds 1. .................................................... 850RPM
2. .................................................... 1250RPM
3. .................................................... 1750RPM
4. .................................................... 2510RPM
Headstock Thread ........................................................................ 3/4” x 16TPI (UNF)
Tailstock Spindle ............................................................................ Fixed Rotating Centre
Tailstock Spindle Advance ........................................................... 2” (50mm) max. via hand wheel
Overall Dimensions (LxWxH) ......................................................... 950x220x280mm
Weight ............................................................................................ 24kg
No. Description Part No.
1 Bearing Block SD6001
2 Face Plate SD6002
3 Tool Rest SD6003
4 Tool Rest Holder SD6004
5 Slide Block SD6005
6 Locking Block SD6006
7 Spindle Pulley SD6007
8 Motor Pulley SD6008
9 Hand Wheel SD6009
10 Head Stock Spindle SD6010
11 Driving Centre SD6011
12 Name Plate (Not Shown) SD6012
14 Tool Rest Shaft SD6014
15 Tailstock Spindle SD6015
16 Locknut SD6016
17 Locknut SD6017
18 Headstock Cover - 1 SD6018
19 Motor Cover SD6019
20 Pulley Cover SD6020
21 Headstock Cover - 2 SD6021
22 Headstock Cover - 3 SD6022
23 Mounting Foot SD6023
24 Bed Rail SD6024
25 Tailstock SD6025
26 Belt Tension Lever SD6026
27 Bolt SD6027
28 Bolt SD6028
29 Bolt SD6029
30 Bolt SD6030
31 Machine Screw SD60231
32 Bolt SD6032
33 Lock Knob SD6033
34 Socket Head Screw SD6034
35 Washer SD6035
36 Washer SD6036
37 Washer SD6037
38 Bearing SD6038
39 Bearing SD6039
40 Switch SD6040
41 Belt Tensioning Lever SD6041
42 Hinge SD6042
43 Belt SD6043
45 Bolt SD6045
46 Motor SD6046
47 Washer SD6047
48 Bolt
49 Power Cable with Plug
30
PARTS LIST
No. Description Part No.

O
GENERAL SAFETY RULES FOR OPERATING MACHINERY
1. KNOW YOUR MACHINE.
Read the manual carefully. Learn the
machines applications and limitations, as
well as the specific potential hazards
peculiar to it.
2. KEEP GUARDS IN PLACE
and in working order.
3. EARTH ALL MACHINES.
If the machine is equipped with three-pin
plug, it should be plugged into a three-pin
electrical socket. Never remove the earth
pin.
4. REMOVE ADJUSTING KEYS AND WRENCHES.
5. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite
accidents.
6. DON’T USE IN DANGEROUS ENVIRONMENT.
Don’t use machinery in damp or wet
locations, or expose them to rain. Keep
work area well lit.
7. KEEP CHILDREN AND VISITORS AWAY.
All children and visitors should be kept a
safe distance from work area.
8. MAKE WORKSHOP CHILDPROOF
Use padlocks, master switches or remove
starter keys etc.
9. DON’T FORCE THE MACHINE.
It will do the job better and safer, at the rate
for which it was designed.
10. USE RIGHT TOOL.
Don’t force a tool or attachment to do a
job for which it was not designed.
11. WEAR PROPER APPAREL.
Loose clothing, gloves, neckties, rings,
bracelets, or other jewellery may get
caught in moving parts. Nonslip footwear is
recommended. Long hair should be
contained.
12. USE SAFETY GLASSES.
Also use face or dust mask if cutting
operation is dusty. Everyday eyeglasses
only have impact resistant lenses, they are
NOT safety glasses.
13. USE EAR DEFENDERS.
14. DON’T OVERREACH.
Keep proper footing and balance at all
times.
15. MAINTAIN TOOLS IN TOP CONDITION.
Keep tools sharp and clean for best and
safest performance. Follow instructions for
lubricating and changing accessories.
16. ALWAYS DISCONNECT THE MACHINE
before servicing or changing accessories.
17. AVOID ACCIDENTAL STARTING.
Ensure the machine is switched OFF before
plugging in.
18. CHECK FOR DAMAGE.
If part of the machine (eg. A cover or
guard), is damaged, it should be carefully
inspected to ensure that it can perform its’
intended function correctly. If in doubt, the
part should be renewed. Damage to
moving parts or major components should
be Inspected by a qualified technician
before operating the machine. Contact
your local dealer for advice.
19. DO NOT STAND ON THE MACHINE.
Serious injury could occur if the machine is
tipped over. Do not store materials above
or near the machine such that it is
necessary to stand on the machine to get
to them.
20. NEVER operate a machine when under the
influence of alcohol, drugs or medication.
WARNING
As with all machinery, there are certain hazards involved with their operation and use. Exercising
respect and caution will considerably lessen the risk of personal injury. However, if normal safety
precautions are overlooked, or ignored, personal injury to the operator may result.
4
OPTIONAL ACCESSORIES
A full range of optional accessories (detailed below) are available from your local dealer.
Accessory Part No
Cup Turning Chuck 6500641
Screw Chuck 6500642
4 Jaw Independent Lathe Chuck 6500645
6" Face Plat (Right Hand) 6500646
8 Piece Chisel Set 6500649
