Clarke CAT194 Installation and operation manual

OPERATING & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC0619 - ISS 1
AIRLINE LUBRICATOR
MODEL NO: CAT194
PART NO: 3120511

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Airline Lubricator.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
Your lubricator has been designed to give long and trouble free service. If,
however, having followed the instructions in this booklet carefully, you
encounter problems, take the unit to your local CLARKE dealer.
SPECIFICATIONS
GENERAL SAFETY RULES
WORK ENVIRONMENT
1. Keep the work area clean and tidy.
2. Dress appropriately - do not wear loose clothing or jewellery. Tie long hair
out of the way.
3. Keep children and visitors away - do not let children handle the air tools.
4. Do not operate air tools where there are flammable liquids or gases.
CAT194
Dimensions (D x W x H) 36 x 42 x 140 mm
Air Inlet /Outlet Size 1/4”BSP (female)
Max Flow 14 CFM
Max Inlet Pressure 150 psi
Max working Temperature 125 deg F
CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN
PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
USE OF AIRLINE EQUIPMENT
1. Stay alert and use common sense - do not operate an air tool when you
are tired or under the influence of alcohol, drugs or medication.
2. Do not overreach - Keep proper footing and balance at all times.
3. Never use oxygen, CO2, combustible gases or any type of bottled gas as a
source of power for air tools.
4. Do not exceed the maximum pressure for the airline component stated in
the specification.
5. Check airline hoses for leaks or worn condition before use and ensure that
all connections are secure.
6. Keep the air supply hose away from heat, oil and sharp edges.
7. Avoid damaging the component for example by applying excessive force
of any kind.
8. Always maintain the air tool with care. Keep it clean for the best and safest
performance.
COMPRESSED AIRLINE REQUIREMENTS
Use only clean, dry, regulated compressed air as a power source.
Air compressors must comply with the appropriate European Community
Safety Directives.
A build-up of moisture in the air compressor will accelerate wear and corrosion
in the air tool. Ensure any moisture is drained from the compressor daily and
the airline filter is kept clean.
If an unusually long air hose is required, (over 8 metres), the line pressure or the
hose inside diameter may need to be increased.
The air hose must be rated at least 150% of the maximum operating pressure of
the air tool.
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF
COMPRESSORS AND COMPRESSED AIR SUPPLY.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
.
A typical air line layout is shown above. If an automatic in-line filter/regulator is
used it will keep the tool in good condition. The lubricator should be adjusted
to approx 2 drops per minute and SAE 10 oil should be used.
Never exceed the maximum operating pressure for the air tool. Ensure that air
pressure does not exceed that stated in the specification for the tool when
running. Higher pressures and contaminated air will shorten the life of the air
tool due to faster wear and is a possible safety hazard.
INSTALLATION
1. Ensure the compressor is turned off. Before using the airline, drain water
from the air reservoir at the compressor.
• The lubricator should be installed with reasonable accessibility for
service whenever possible.
2. Keep pipe or tubing lengths to a minimum with the inside clean and free of
dirt. Pipe joint compound should be used sparingly and applied only to the
male pipe — never into the female port.
3. Avoid using PTFE tape to seal pipe joints — pieces have a tendency to
break off and lodge inside the unit, possibly causing malfunction. Also a
new pipe or hose should be installed between the lubricator and the
equipment being protected.
4. Install the lubricator so that air flows as marked by the arrow on the
lubricator body.
5. Installation should be downstream of the filter and regulator but upstream
of the device it is to lubricate (valve, cylinders, tool, etc.).
6. A filter installed upstream of the lubricator is recommended.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
7. Install the lubricator vertically with the bowl drain mechanism at the
bottom. Any free moisture will thus drain into the area at the bottom of the
bowl.
8. Fit the mounting bracket to a suitable support, situated in line with the
compressed air supply.
• Ensure sufficient free space above the lubricator for future access.
9. Fit the lubricator to the mounting bracket from below and secure with the
retaining ring.
• Note the arrow mark on the regulator body, indicating the direction
of air flow.
10. Remove the blanking plugs from the connection ports and connect to the
supply and delivery hoses.
11. Your lubricator is now ready for use.
FILLING AND ADJUSTMENT
1. Ensure that the pressure to the air inlet of the lubricator from air line does
not exceed the maximum pressure specified in the instructions.
2. Shut off inlet air pressure and reduce the inlet and outlet lines to zero.
Remove the bowl and fill with oil. Use good quality, light, misting type of oil
for air-powered tool/motor.
3. Fill the oil to the maximum fill line on the bowl. DO NOT OVERFILL.
4. Re-install the bowl and turn fully clockwise into the body before
pressurizing. Tighten hand-tight.
5. Turn on the air line system to obtain the required pressure to the lubricator.
6. Adjust the lubricator drip rate only when there is a constant rate of air flow
through the lubricator. Monitor the drip rate through the sight feed dome.
7. Determine the average rate of air flow through the lubricator. Turn the
slotted rotator in the sight feed dome to obtain the recommended drops
per minute. See Drip Rate Chart. Turn the rotator anti-clockwise to increase
the drip rate or clockwise to decrease the drip rate.
8. Monitor the device being lubricated for a few days following the above
drip rate adjustment and see how well the device works, then determine
whether the drip rate at the lubricator should be adjusted for higher or
lower level.
9. NEVER apply lubricated compressed air to run a spray gun, since paint
mixed with oil will spoil the finish of workpiece being sprayed.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
DRIP RATE CHART
MAINTENANCE
DISASSEMBLY
1. The lubricator can be disassembled without removal from air line.
2. Shut off the inlet pressure. Reduce pressure in inlet and outlet lines to zero.
3. Remove the bowl by turning anti-clockwise.
4. Do not remove the drain valve unless replacement is necessary. Remove
and replace only if the drain malfunctions. Remove and replace cartridge
assembly only if lubricator malfunctions.
CLEANING
1. Clean the plastic bowl with warm water only. Clean other parts with warm
water and soap.
2. Rinse and dry all parts. Blow out internal passages in the body with clean,
dry, compressed air.
3. Inspect all parts. Replace any found to be damaged. Replace the plastic
bowl with a metal bowl if plastic bowl shows signs of cracking or cloudiness.
ASSEMBLY
1. Assemble as shown on page 7 using the torque values listed in the table.
Lubricate all o-rings with o-ring grease.
Flow (CFM) Drops per minute Flow (CFM Drops per minute
0.5 4 6 16
15 719
28 821
310 923
412 1025
514
Torque Settings
Part Inch Pounds (Nm)
Drain 1.5 to 2.5 (0.17 to 0.28)
Bowl 5 to 10 (0.56 to 1.13)
Dome 20 to 25 (2.3 to 2.8)

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST & DIAGRAM
ACCESSORIES
A wide range of accessories is available including filter/regulators, lubricators,
high-pressure hoses (5 to 50 metres) etc. Contact your CLARKE dealer for
further information or CLARKE International Service Department.
No Description No Description
1 Polycarbonate bowl assembly 3 Universal wall bracket & ring
2 Mounting ring 4 Oil adjusting dome assembly
