iSHAN YET-A1 User manual

1 - 21
Centralized Lubrication Systems
YET-A1 / YET-A2
Micro-computer controlled
lubricator
YET -A1P2 / YET-A2P2
Micro-computer controlled
lubricator withpressure detector
Operation Instructions
Congratulations on buying an iSHAN centralized lubrication system. For proper,
problem-free use, you must read through these instructions carefully and follow them
exactly.

2 - 21
Table of Contents
1 Use / Range of application...............................................................................3
2 Commencement of operation ...........................................................................4
2-1Safety measures.......................................................................................4
2-1.1 Before installing............................................................................4
2-1.2 Before filling oil............................................................................4
2-1.3 Safety measures for the control panel ...........................................4
2-1.4 When failures occur ......................................................................4
2-2Parts of lubricator....................................................................................5
2-3Marking Label.........................................................................................6
2-4Installation...............................................................................................7
2-4.1 Mounting of lubricator..................................................................7
2-4.2 Filling Oil......................................................................................7
2-4.3 Connection of oil pipe...................................................................8
2-4.4 Installation of power and alarm.....................................................8
3 Instructions for use.........................................................................................10
3-1Control panel.........................................................................................10
3-2Numerical intermittent time and lubricating time display.....................11
3-3Set the intermittent / lubrication time....................................................11
3-4Reset......................................................................................................12
3-5Setting of the operational module .........................................................12
3-5.1 Explanation of the indicators and acoustic sound .......................12
3-5.2 Soft key functioning table ...........................................................13
3-6Refilling oil...........................................................................................14
4 Maintenance...................................................................................................15
5 Trouble shooting ............................................................................................16
6 Guarantee.......................................................................................................17
7 Technical data ................................................................................................18
7-1Specification..........................................................................................18
7-2Electrical Drawing ................................................................................18
7-3Fluid Power Diagram............................................................................20
8 Attension........................................................................................................20

3 - 21
1 Use / Range of application
iSHAN centralized lubricating systems are designed to lubricate ball bearings, flat
bearings, flat slideways, circular slideways, linear guides, cams, gears, chains, etc..
iSHAN centralized lubricating systems are suitable for the lubrication of various
machines, such as lathes, mills, presses, planner, grinder, etc. It is possible to control
different lubricating points at different machines at the same time.
The permissible oil viscosity of YET-A lubricators range from 30 cSt to 250 cSt.
The YET-A lubricators are designed to lubricate intermittent. Its’ control unit may be
used as timer for time-dependent control or as counter for load-dependent control. The
interval times may be optionally adjusted from one to 999 minute for time-dependent
control, or from one to 999 pulses for load-dependent control. The lubrication time is time
dependent control, and ranges from one to 999 seconds. There are two control modes when
actuation: the lubricating actuation mode - to pump oil as soon as power on , or the
recording actuation mode - to continue the state recorded before last power off.
The maximum discharge rate of YET-A1 pump is 200 ml/min, and 100 ml/min for
YET-A2 model. The max discharge pressure are 7 bar for YET-A1 model, and 15 bar for
YET-A2 model. In order to protect the auxiliary equipments, there consists a pressure
release valve to control the pipe pressure remains a constant value during lubrication times.
For safety measurements, the oil level switch could send an acoustic alarm through
buzzer and stop pumping oil. Also, the pressure switch is optional for customer, it can detect
whether the oil pipe system leaks. To get further safety measurement, it is possible to
connect the lubricator to other controller, computer properly to enhance the alarm system.

4 - 21
2 Commencement of operation
2-1 Safety measures
2-1.1 Before installing
! Before installing, refer to instructions for the correct connection of the power.
! Make sure the correct electrical specification before installation.
! iSHAN centralized lubrication systems shall not used for purposes other than the
lubrication of machines with oil.
2-1.2 Before filling oil
! Use only oil with a viscousity of 30 to 250 cSt. Caution ! Lubricator might start to burn
if using oil with a viscousity higher than 250 cSt.
! Fill in only with new oil. Please never fill in with used oil.
! Never fill in with chemical substances or water.
! Remove any particles and dirt sticking in the oiltank immediately in order to maintain
propper lubrication.
! When filling with oil in the tank, please watch out that no oil is spilled onto the
display and controlpanel.
2-1.3 Safety measures for the control panel
! In order to avoid disorders of the control panel, never let it have contact with water or
oil.
2-1.4 When failures occur
! In order to avoid disorders of the control panel, never let it have contact with water or
oil.
! Only the iSHAN-customer service workshops are authorized to repair lubricators and
the spare parts must be the originals.

5 - 21
2-2 Parts of lubricator
1. Screw of cover of control box. 9. Oil level switch
2. Control Box 10. Oiltank (3L)
3. Control panel 11. Thimble nut
4. Cable gland 12. Pressure Relief Valve
5. Inlet filter 13. Oil pump
6. Oiltank cap 14. Outlet filter
7. Pressure gauge 15. Suspension hole
8. Upper lid
1
4
6
15
8
5
9
10
3
2
7
11
12
13
Fig. 1

6 - 21
2-3 Marking Label
Name Plate (YET-A1) Name Plate (YET-A2) Electric Shock
Right front side of control box Right front side of control box Outside the control box
Oil level Connection Operation
HIGH
LOW
Left front
side of
oiltank
Inside the control box Left lateral side of the oil tank
YET-A1/YET-A2 操作說明（Operation instruction）
一、 操作方式（Operating）：
1. ▲▼：潤滑/間歇時間設定鍵（潤滑時間：1~999 秒、間歇時
間：1~999 分）。當按住設定鍵約 2秒後即可調整時間設定值，
鬆手約 2秒後，注油機開始此一新設定之時間運作。
2. ▲：數字遞增； ▼：數字遞減。
3. 潤滑、間歇兩指示燈同時閃爍表示在設定模式。
4.
RES
：復歸鍵。按住此鍵約 2秒可重新開始潤滑計時。
1. ▲▼：Lubrication/intermittent time setting keys.( Lubrication time
range from 1~999 seconds, intermittent time range from 1~999
minutes）. Push down the soft key for 2 seconds then adjust the
setting time. After releasing for 2 seconds, the lubricator will operate
as new set.
2. ▲：Soft key for time increase progressively.
▼：Soft key for time decrease progressively.
3. Both of the lubrication and intermittent indicators will blink under
setting mode.
4.
RES
：Soft key for restart lubricating cycle. (Push down the soft key
for 2 seconds to restart lubricating cycle.）
二、 注意事項（Notes）：
1. 本機適用油品之粘度約 30 ~250 cSt.。
2. 限用新油並請定期清理油箱底部及濾網
3. 如對本注油機有任何疑難問題，請立即與本公司聯絡。
1. Permissible oil viscosity range from 30 to 250 cSt.
2. Use new oil and clean the oil filter and the oiltank periodically.
3. If you meet any question about this lubricator, please inform with
us at once.
接地
電源
POWER
異常出力
NC COM NO

7 - 21
2-4 Installation
2-4.1 Mounting of lubricator
Mount the lubricator on the machine by
fastening it with two screws cat the
suspension holed(Fig. 2) to the hole on the
machine for fastening the screws must have a
distance of 188~206 mm.eThe lubricator
should be mounted in the height of 0.6~1.7 m
above the ground level.
2-4.2 Filling Oil
Remove the oiltank cap and fill with
clean and non-used oil into the tank until the
oil level reaches the above line at “HIGH”
(Fig. 3). The oiltank has an capacity of 3
liters. When having filled in the oil to the
proper level, lock the oiltank cap. Please note
that use only oil with a viscosity of 30 to 250
cSt.
Caution ! Lubricator might start to burn if using
oil with a viscousity higher than 250 cSt.

8 - 21
2-4.3 Connection of oil pipe
Connect the oilpipe now (Fig. 4). The
elbow joint efor the oilpipe is located at the
right side of the lubricator. Remove the
thimble nut cand carefully take out the
thimb dinside the elbow joint and connect
the oilpipe ftogether with the nut and the
thimble. Then insert the oilpipe set into the
elbow joint.
To avoid leakage of oil during the operation, the thimble should be completely slipped
over so that at least 1mm of the pipe sticks out when inserting into the elbow joint. And the
oilpipe set should be fastened on the elbow joint firmly by fastening the thimble nut at the
joint.
2-4.4 Installation of power and alarm
Note !! Install a fuse between the power supply and the lubricator !! (See 7-1)
Connect the cable for power and alarm. Remove the upper cover of the control box in
which have the connection points for the power and alarm by loosening the screws for
casting (Fig. 5). There is a cable gland for fastening the cable on the left lateral side of the
control box. Remove this gland through turning (Fig. 6) and slip it over the cable in such a
direction, so that you can fasten the gland later. Next, push the cable through the opening
into the casing (Fig. 7).

9 - 21
Connect the cable at the connection points for power and alarm now (Fig. 8). First,
open the screw for the point of the earthing c.Next, connect the ground cable and fix it by
fastening the screws. Connect the cables for plus and minus accordingly at "POWER" d.
According to this connection the lubricator will send out an acoustic and an optic signal
when the oil level reaches a critical minimum. Also, the lubricator will stop working.
Secondly, for further measurements in order to react on an alarm it is possible to
connect one cable at "COM" fand another cable whether at "NO"gor "NC"e. If it is
optional. For proper connection, the lubricator will stop the power supply of the machine
to be lubricated, or the lubricator can also be connected with a computer or other appliance
which will allow the user to react according to his wishes. For COM-NO
connection(normal open), the circular loop will be open when the amount of oil is
enough. For COM-NC connection, the lubricator will begin to pump while the oil is
insufficient. The electricity specification for NC-COM-NO connection is max. 6 A @
250 V AC, or 10A @ 110V AC, or 6A @30 VDC.

10 - 21
Close the cover after having connected all cables.
For protecting the cable not to be pulled out of the box
and disconnected from the ports, fasten the gland again
(Fig. 9). The lubricator can be connected with the
power supply now. When connected properly, you will
hear a “beep”-sound first which is send out by the
alarm. Also, the lubrication indicator (Fig. 10, L1)
starts to shine orange light. Then the lubricator starts
with the mode of lubricating When actuation.
3 Instructions for use
3-1 Control panel
D1 Display for lubricating time setting S1 Lubricating time set key “increase”
D2 Display for intermittent time setting S2 Lubricating time set key “decrease”
L1 Lubrication indicator , orange S3 Intermittent time set key “increase”
L2 Intermittent indicator , green S4 Intermittent time set key “decrease”
L3 Alarm indicator , red S5 Reset key
D1
D2
S5
L1
S1
S2
S4
S3
Fig. 10

11 - 21
3-2 Numerical intermittent time and lubricating time display
Setting for the intermittent/lubricating time could be done by pressing the soft key
button “▲“ or ” ▼ ” (Fig. 10, S1 ~ S4) for 1 to 2 seconds and then the setting could be
read from the display (Fig. 10, D1 and D2). If no soft key is pressed, the lubricator will be
actuated as the previous setting after 5 seconds.
During the intermittent period, D1 indicates the lubricating time setting and D2
indicates the remaining time of intermittent time setting. Reversibly, During the lubricating
period, D1 indicates the remaining time of lubricating time setting and D2 indicates the
intermittent time setting. The display will show the setting by pressing the soft key “▲“ or
” ▼ ” for 2 seconds in any period. If no soft key is pressed, the lubricator will be actuated
as the previous setting after 5 seconds.
3-3 Set the intermittent / lubrication time
The lubricator will turn to the setting mode by press either intermittent/lubricating soft
key “▲“ or ” ▼ ” for 1 to 2 seconds and the displays will indicate the previous setting. In
this time both of the intermittent and lubricating indicator (L1 and L2) start blinking. The
numerical display will be increased 1 by one press of “▲“ (S1 / S3) and it will be increased
fast by press down the key. The numerical display will be decreased 1 by one press of ” ▼”
(S2 / S4) and it will be decreased fast by press down the key. The time unit could be set as
minute or second and the numerical display is from 1 to 999. The lubricator will save the
new settings automatically if no button has been pressed for 5 seconds. Then the lubricator
turns into the operational model. In this time the indicators blink no more but the shine of
the indicators indicates the state of intermittent or lubricating accordingly.

12 - 21
3-4 Reset
As press this key (Fig. 10, S5) for one to two seconds at any period, the lubricator will
restart the lubrication cycle again according to the present setting of intermittent and
lubricating time. Whether the lubricator is set as the “Lubricating when actuation mode” or
“Recording when actuation mode”( see 3.5.2 ), when the machine needs to be lubricated,
press the “RES “ key for 2 seconds will forces the lubricator to pump oil at once, i.e. the
lubricator could be manually operated by pressing the “ RES “ key.
3-5 Setting of the operational module
Attention: Only the iSHAN-customer service workshops are authorized to change the
original function settings of the lubricator. The users may proceed the basic
lubrication/intermitent time setup only.
3-5.1 Explanation of the indicators and acoustic sound
Signal
Mode
Lubrication
L1
(Orange)
Intermittent
L2
(Green)
Alarm
L3
(Red)
Buzzer
Operational
Mode
Lubricating State
Intermittent
State
Min. / Sec.
Counting
Setting Mode
Alarm
Mode
Lack of Oil
Insufficient pipe pressure
Detecting the pipe pressure

13 - 21
L1 Lubrication Indicator L2 Intermittent Indicator L3 Alarm lamp
Lamp Shines Lamp Blinks
Continuous Beep Discrete Beep
REMARK！The internal buzzer makes acoustic sound under the following condition：
1. Makes one beep when re-start the lubricator (including Power-On, pressing RES
key, and the time setting has been done).
2. Make two beeps when change the functional setting (including change time unit:
min ↔sec, for intermittent/labricating time setting ; Universal time ↔Times
Counting control mode; Lubricating When Actutation ↔Record during
Actuating Mode).
3-5.2 Soft key functioning table
One can change the basic operation model by pressing the hot keys on the front
control panel. When you press the combination of soft keys , just press down the keys in
the indicated order and release them at the same time after the last key has been
pressed. If the buzzer makes two beeps, the functional setting has been changed
successifully. You may check the operation model by the state of indicators listed in
the table of previous section.(3-5.1)
：First key ( it need to be pressed down for 2 sec. during the Basic Mode).
：Second key. ：Third key.
S1 S2 S3 S4 S5
Basic Setting
Mode
Lub. Time+ 1
Lub. Time- 1
Int. Time+ 1
Int. Time- 1
Restart /
Saving Setting

14 - 21
Actuating
Mode
Lubricating /
Recording
When Actuation
Time Unit
Setting
Mode
Lubricat-ing
Minute/ Second
Intermittent:
Minute/ Second
Intermittent:
counting time /
times mode
Initial mode
Example：
1. Change between the lubricating and the recording modes when actuation.
Lubricating when actuation :The lubricator starts pumping oil as soon as power-On
.Recording when actuation：The lubricator continues the setting of the last condition
before Power-Off as soon as it is Power-On.
2. The initial setting mode are : Lubrication time in minute, Intermittent time in
second, and lubricating when actuation. Once you are confused with the setting
mode, you can press the “S5” , “ S1” and the “S3” keys in order to return to
the initial mode.
3. Attention, to finish pressing the combined keys between two seconds and in
order. Else, it’ll not work.
Anytime you press down “ S5 ” key first﹐and then press down “ S3 “ key, can
change the operation models between lubricating and recording model. After the
buzzer beeped twice will start to operate with the new mode.
3-6 Refilling oil
Always keep the oil level between HIGH and LOW. If the oil level falls below LOW,
the lubricator will stop working and will send out an acoustic alarm. For refilling in new oil,
remove the oiltank cap (Fig. 3) and fill in new clean oil.
Attention ! Never use used oil

15 - 21
4 Maintenance
iSHAN centralized lubrication system are easy to maintain. For maintenance,
please clean periodically the oiltank. The oiltank also has to be cleaned if there are any
impurity found at the bottom of the oiltank or the filter in the oil suction set. For cleaning
the oiltank dismount the lubricator and loosen the four screws on each corner. Now, the
oiltank can be separated from the rest of the lubricator. After having clean the tank please
fasten the two short screws at the front corners and the two longer screws at the front corner.
For proper, problem-free operation, please obey the following rules exactly:
1. Use clean, new oil and with permissible viscosity.
2. To protect the electrical stability, once you have turn off the power, please wait for at least 20
seconds to restart the lubricator.
3. The elbow joints of YET-A1 and YET-A2 are special parts, never change them by yourself.
4. The YET-A2 lubricator is reacted by pressure release model. Generally, it should be
compacted with piston distributers to control the mount of oil discharged per cycle
precisionly. In order to work properly, the elbow joint of the lubricator can not be non-
return model. It must be simple direct joint, and please don’t change it by yourself.

16 - 21
5 Trouble shooting
Note！！Turn off the power before check, repair, or maintain.
Note！！Please do not repair or disassemble the lubricator for the faults not listed below.
You should consult and inform the iSHAN workshop at once.
Fault Cause Rectification
Lamps are not shining
Electricity cut-out Check leads and plugs
Lamps fault. Change new lamps.
Wrong voltage used Use proper power supply.
Fault at the IC-control New IC-control nessecary
Lamps are shining but
no discharge of oil
Oillevel switch does not work Change oillevel switch
Oil insufficient. Add oil to the proper level.
Pumpmotor does not run Change pumpmotor
Pump is working but
no discharge
Air in the pump hosing
Wait for about 1 minute. If no
discharge of oil, please relax the
thimble nut on the elbow joint to
remove the air inside the pipe.
Fasten the thimble nut.after the
oil flowes out.
Disassemble piping. Switch
power on and check if oil could
be discharged. If not, the gear
pump might be blocked.
Clean the pump. If it does
not work, change pump
Disassemble piping. Switch
power on and check if oil could
be discharged. If does, the
lubricator is ok and the oilpipe
might be choked or crashed.
Find the crashed section and
change new pipe.
If you have installed the
pressure switch, check the
pressure of the oil pipe. If the
pressure had been built up, your
pressure switch or limit switch
might be fault. Else, the pipe or
the pump-motor shoult be fault.
If pressure hadn’t been built up,
see above. Else, if the pressure
had been built up correctly,
please consult the iSHAN
workshop to change a new
pressure switch.

17 - 21
Fault Cause Rectification
Oil discharged
insufficiently Filter is blocked Clean the oil suction set .
Wrong viscousity of the oil Use suitable oil
The motor doesn’t run.
Wrong voltage used Check the electricity specification and your power
supply to be compatable.
Pump contacts with
humidity or water. Clean the pump. If it does not work, change pump
Gear pump faults. Use only new oil.
While lubricating time,
oil leaks at the connec-
tion of pipe adaptor and
oilpipe
Wrong installation
Thimble should be completely
slipped over so that at least 1
mm of the pipe sticks out
when inserting into the
oiladaptor ( See 2.4.3 )
6 Guarantee
The machine is guaranteed for a period of 12 months. Furthermore claims under
guarantee can only be accepted if the machine has not been tamper with and are send to the
iSHAN service workshop in a complete, unopened condition. Never send spare-parts to our
service workshop without consultation. Shipments which have to be paid by the receiver
can only be accepted when our service workshop agrees in advance.
The guarantee covers exclusively material and manufacturing faults. Damage which
occurs because of misuse or not following the instructions are excluded from guarantee.

18 - 21
7 Technical data
7-1 Specification
Voltage & frequency range available 110VAC 50/60 Hz
220 VAC 50 / 60 Hz
Electrical specification for
“NC - COM - NO” Port 6A @ 250 VAC 10 A @ 120 VAC
6A @ 30 VDC
Rated power output ( W ) 80W for YET-A1 Model
100W for YET-A2 Model
Permissible operating viscosity ( cSt ) 30 cSt ~ 250 cSt
Discharge rate 100 (ml/min)
Max. discharge pressure 7 ±1 (bar) for YET-A1 Model
15±1 (bar) for YET-A2 Model
Interminent time (minute) 1 ~ 999
dia of elbow joint. ( mm ) ∮4 or ∮6
Dimension ( mm ) 227 (W) ×168 (D) ×300 (H)
Oiltank capacity 3 ( L)
Operating temperature 0~50 (℃)
Fuse at power supply 1.2A for YET-A1 model, 220V AC
1.4A for YET-A2 model, 220V AC
Operating range for pressure switch ( bar )10 ~ 12
7-2 Electrical Drawing
If you meet any electrical fault, we strongly suggest you to sent the lubricator back to
the iSHAN-customer service workshops. We will changing a new PC board with same
function or updated function instead of the old one in reasonable price. The following
diagram are only a basic reference of the controller which support you to understand the
fault by yourself.

19 - 21
P 1
D 3
D 2 C 1
R 1P
1
Z 1
R 8 R 9
R 1 1
C 1 0
C 1 1R
1 0
R 7
R 2
R 6
Q 2G
1
Q 3
D 4
R 4
C 3
P 7
Q 5
Q 1
D 1
R L 1
R L 2
P 3
P2-2
P2-3
P2-1
6
5
4
3
2
1
C 9
C 8 C 4 C 5 C 6
U 1
C 7
D 8
D 3
D 6
D 7
F 1
F T 1
C 2
R 3
P 2 D 5
Circular diagram for powe connection
R 9
U 4
R 1 4
R 1 5Q
1
Z 1
R 1 1
U 3U
2
C 2
U 1
X 1C
4
C 1
C 3
R 6
R 1 0
R 1R
3
R 4R
7
R 8R
2
R 5
A 2 A 2 A 2 A 1 A 1 A 1
ABE
P 2
1 2 9
81
2
9 8
D 4 D 7 D 6 D 1 D 2 D 3 D 5
S 4
S 5
油壓 S
1
S 2
S 3
油位
R 1 2
R 1 3
1
23
45
67
8
91
6
1 51
4
1 31
2
1 11
0
Circular diagram for control unit

20 - 21
7-3 Fluid Power Diagram
1 Oiltank
2 Inlet Filter
3 Gear Pump
4 Oil Level Switch
5 Pressure Gauge
6 progressive feeder
7 Non-return valve
8 Presure Switch
1 Oiltank
2 Inlet Filter
3 Gear Pump
4 Oil Level Switch
5 Pressure Gauge
6 Piston distributors
(Metering units)
7 Pressure Relief valve
8 Presure Switch
8 Attension
Technical and optical changes for improvements may be done without announcement.
All datum, informations and explanations of this operating instruction are without guarantee.
Therefor, no legal claims can be made as a result of this operating instruction.
Fig 11 Fluid power diagram of
YET-A1 type lubricator.
Fig 12 Fluid power diagram of
YET-A2 type lubricator.
