Clarke Vantage 13 User manual

Operator’s Manual
Libro de Instrucciones
Manuel d’utilisation
READ THIS BOOK
LEA ESTE MANUAL
LISEZ CE MANUEL
EN
ES
FR
English (1 - 18)
Español (19 - 36)
Français (37 - 54)
13
Vantage
Form No. 9097888000 - 05/2009

ENGLISH
Operator’s Manual - Vantage 13 1
TABLE OF CONTENTS
INTRODUCTION.............................................................................................................................................................. 2
MANUAL PURPOSE AND CONTENTS .......................................................................................................................................... 2
TARGET........................................................................................................................................................................................... 2
HOW TO KEEP THIS MANUAL....................................................................................................................................................... 2
IDENTIFICATION DATA................................................................................................................................................................... 2
OTHER REFERENCE MANUALS................................................................................................................................................... 2
SPARE PARTS AND MAINTENANCE............................................................................................................................................. 2
CHANGES AND IMPROVEMENTS ................................................................................................................................................ 2
OPERATION CAPABILITIES........................................................................................................................................................... 3
CONVENTIONS .............................................................................................................................................................................. 3
UNPACKING/DELIVERY ................................................................................................................................................. 3
SAFETY ........................................................................................................................................................................... 3
SYMBOLS ....................................................................................................................................................................................... 3
GENERAL INSTRUCTIONS............................................................................................................................................................ 3
120 VAC GROUNDING INSTRUCTIONS ....................................................................................................................................... 6
MACHINE DESCRIPTION ............................................................................................................................................... 7
MACHINE STRUCTURE ................................................................................................................................................................. 7
ACCESSORIES/OPTIONS.............................................................................................................................................................. 8
TECHNICAL DATA........................................................................................................................................................................... 8
WIRING DIAGRAM.......................................................................................................................................................................... 9
USE ................................................................................................................................................................................ 10
BEFORE MACHINE START-UP .................................................................................................................................................... 10
MACHINE START AND STOP....................................................................................................................................................... 12
MACHINE OPERATION (SCRUBBING/DRYING)......................................................................................................................... 12
MACHINE TRANSPORT/PARKING .............................................................................................................................................. 13
TANK EMPTYING.......................................................................................................................................................................... 13
AFTER USING THE MACHINE..................................................................................................................................................... 14
MACHINE LONG INACTIVITY ...................................................................................................................................................... 14
FIRST PERIOD OF USE ............................................................................................................................................................... 14
MAINTENANCE............................................................................................................................................................. 15
SCHEDULED MAINTENANCE TABLE ......................................................................................................................................... 15
SQUEEGEE CLEANING, CHECK AND REPLACEMENT ............................................................................................................ 16
BRUSH CLEANING....................................................................................................................................................................... 16
VACUUM GRID, DETERGENT TANK AND RECOVERY TANK CLEANING................................................................................ 17
SOLUTION HOSE FILTER CLEANING......................................................................................................................................... 17
SCRAPPING .................................................................................................................................................................. 18
PART LIST ..................................................................................................................................................................... 55

ENGLISH
2 Operator’s Manual - Vantage 13
INTRODUCTION
NOTE
The numbers in brackets refer to the components shown in Machine Description chapter.
Thank you for choosing a Clarke scrubber-dryer.
Clarke scrubber-dryer Vantage 13 is an efficient and superior quality machine for floor cleaning.
The machine is equipped with two turning brushes for a cleaning width of 330 mm.
Front and rear squeegees clean out the floor, while a vacuum system collects the dirty water, all in one wipe.
MANUAL PURPOSE AND CONTENTS
The purpose of this Manual is to provide the operator with all necessary information to use the machine properly in a safe and
autonomous way. It contains information about technical data, safety, operation, storage, maintenance, spare parts and disposal.
Before performing any procedure on the machine, the operators and qualified technicians must read this Manual carefully. Contact
Clarke in case of doubts concerning the interpretation of the instructions and for any further information.
TARGET
This Manual is intended for operators and technicians qualified to perform the machine maintenance.
The operators must not perform procedures reserved for qualified technicians. Clarke will not be answerable for damages coming
from the non-observance of this prohibition.
HOW TO KEEP THIS MANUAL
The Operator’s Manual must be kept near the machine, inside an adequate case, away from liquids and other substances that can
cause damage to it.
IDENTIFICATION DATA
The machine serial number and model are shown on the plate (1).
The machine production year is indicated by the first two figures of the machine serial number.
This information is useful when requiring machine spare parts. Use the following table to write down the machine identification data.
MACHINE model ...............................................................................
MACHINE serial number ...................................................................
OTHER REFERENCE MANUALS
Spare Parts List (supplied with the machine)–
Service Manual (that can be consulted at any Clarke Service Center)–
SPARE PARTS AND MAINTENANCE
All necessary operating, maintenance and repair procedures must be performed by qualified personnel or by Clarke Service
Centers. Only original spare parts and accessories must be used.
Call Clarke for service or to order spare parts and accessories, specifying the machine model and serial number.
CHANGES AND IMPROVEMENTS
Clarke constantly improves its products and reserves the right to make changes and improvements at its discretion without being
obliged to apply such benefits to the machines that were previously sold.
Any change and/or addition of accessory must be approved and performed by Clarke.

ENGLISH
Operator’s Manual - Vantage 13 3
OPERATION CAPABILITIES
These scrubber-dryers are used to clean (scrubbing and drying) smooth and solid floors, in civil or industrial environment, under
safe operation conditions by a qualified operator.
The scrubber-dryers cannot be used for moquette and carpet cleaning.
CONVENTIONS
Forward and backward, front and rear, left and right references are intended with the operator in driving position with the hands on
the handlebar (2).
UNPACKING/DELIVERY
To unpack the machine carefully follow the instructions on the packing.
When the machine is delivered, check that the packing and the machine were not damaged during transportation. In case of visible
damages, keep the packing and have it checked by the carrier that delivered it. Call the carrier immediately to fill in a damage claim.
Please check that the following items have been supplied with the machine:
Scrubber-dryer Operator’s Manual–
Scrubber-dryer Spare Parts List–
SAFETY
The following symbols indicate potentially dangerous situations. Always read this information carefully and take all necessary
precautions to safeguard people and property.
The operator’s cooperation is essential in order to prevent injury. No accident prevention program is effective without the total
cooperation of the person responsible for the machine operation. Most of the accidents that may occur in a factory, while working
or moving around, are caused by failure to comply with the simplest rules for exercising prudence. A careful and prudent operator is
the best guarantee against accidents and is essential for successful completion of any prevention program.
SYMBOLS
DANGER!
It indicates a dangerous situation with risk of death for the operator.
WARNING!
It indicates a potential risk of injury for people.
CAUTION!
It indicates a caution or a remark related to important or useful functions.
Pay particular attention to the paragraphs marked by this symbol.
NOTE
It indicates a remark related to important or useful functions.
CONSULTATION
It indicates the necessity to refer to the Operator’s Manual before performing any procedure.
GENERAL INSTRUCTIONS
Specific warnings and cautions to inform about potential damages to people and machine are shown below.
DANGER!
Before performing any maintenance, repair, cleaning or replacement procedure disconnect the plug from the–
electrical mains.
This machine must be used by properly trained operators only. Children or disabled people cannot use this–
machine.
Do not wear jewelry when working near electrical components.–
Do not work under the lifted machine without supporting it with safety stands.–
Do not operate the machine near toxic, dangerous, flammable and/or explosive powders, liquids or vapors:–
This machine is not suitable for picking up hazardous materials.

ENGLISH
4 Operator’s Manual - Vantage 13
WARNING!
Before using the machine, close all doors and/or covers.–
The machine power supply cable is grounded and the relevant plug is grounded too. In case of machine–
malfunction or breakdown, grounding connection reduces the risk of electric shock.
The power supply cable plug must be connected to an appropriate outlet, which is grounded according to–
law in force.
Improper connection can cause electric shock. Consult a qualified technician to make sure that the outlet is–
properly grounded.
Do not modify the plug of the machine. If the power supply cable plug cannot be connected to the outlet,–
have new grounded outlet installed by a qualified technician, according to the law in force (local code).
Before connecting the power supply cable to the electrical mains, check that frequency and voltage, shown–
on the machine serial number plate (1), match the electrical mains voltage.
Do not unplug the machine by pulling the supply cable. To unplug, grasp the plug, not the cable.–
Do not handle the plug or the machine with wet hands.–
Turn off all controls before unplugging.–
Regularly check the power supply cable for damages, cracks and wear. If necessary, replace it.–
If the power supply cable is damaged, it must be replaced by Clarke Service Center.–
Do not pull or carry the machine by the supply cable; never use the power supply cable as a handle. Do not–
close a door on the supply cable, or pull the supply cable around sharp edges or corners. Do not run the
machine on the supply cable.
The brushes must not come into contact with the power supply cable.–
Keep the supply cable away from heated surfaces.–
To reduce the risk of fire, electric shock, or injury, do not leave the machine unattended when it is plugged–
in. Unplug the machine from the electrical mains when not in use and before servicing.
Always protect the machine against the sun, rain and bad weather, both under operation and inactivity–
condition. Store the machine indoors, in a dry place: This machine must be used in dry conditions, it must
not be used or kept outdoors in wet conditions.
Do not allow to be used as a toy. Close attention is necessary when used near children.–
Use only as shown in this Manual. Use only Clarke’s recommended accessories.–
Take all necessary precautions to prevent hair, jewelry and loose clothes from being caught by the machine–
moving parts.
Do not use the machine on incline.–
Do not use the machine in particularly dusty areas.–
While using this machine, take care not to cause harm to people or damage to objects.–
Do not bump into furniture, shelves or scaffoldings, especially where there is a risk of falling objects.–
Do not put any can containing fluids on the machine.–
The machine working temperature must be between 0°C and +40°C.–
The machine storage temperature must be between 0°C and +40°C.–
The humidity must be between 30% and 95%.–

ENGLISH
Operator’s Manual - Vantage 13 5
WARNING!
When using floor cleaning detergents, follow the instructions on the labels of the detergent bottles.–
To handle floor cleaning detergents, wear suitable gloves and protections.–
Do not use the machine as a means of transport.–
Do not allow the brush to operate while the machine is stationary to avoid damaging the floor.–
In case of fire, use a powder fire extinguisher, not a water one.–
Do not tamper with the machine safety guards and follow the routine maintenance instructions scrupulously.–
Do not allow any object to enter into the openings. Do not use the machine if the openings are clogged.–
Always keep the openings free from dust, hairs and any other foreign material which could reduce the air
flow.
Do not remove or modify the plates affixed to the machine.–
This machine cannot be used on roads or public streets.–
Pay attention during the machine transfers when temperature is below freezing point. The water in the–
recovery tank or in the hoses could freeze and seriously damage the machine.
Use only brushes supplied with the machine and those specified in the Operator’s Manual. Using other–
brooms could reduce safety.
In case of machine malfunctions, ensure that these are not caused by a lack of maintenance. Otherwise,–
request assistance from the authorized personnel or from an authorized Service Center.
If the machine–
does not work properly•
is damaged•
has water or foam leaks•
has been left outdoors exposed to bad weather conditions•
is wet or has been dropped into water•
turn it off immediately and contact Clarke Service Center or a qualified technician.
If parts must be replaced, require ORIGINAL spare parts from an authorized Dealer or Retailer.–
To ensure machine proper and safe operation, the scheduled maintenance shown in the relevant chapter of–
this Manual must be performed by the authorized personnel or by an authorized Service Center.
Carefully read all the instructions before performing any maintenance/repair procedure.–
Do not wash the machine with direct or pressurized water jets, or with corrosive substances.–
The machine must be disposed of properly, because of the presence of toxic-harmful materials (electronic–
parts, etc.), which are subject to standards that require disposal in special centers (see Scrapping chapter).

ENGLISH
6 Operator’s Manual - Vantage 13
120 VAC GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electric
current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment-grounding conductor and
grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all
local codes and ordinances.
WARNING!
The machine must be used with an extension power cord as follows:
minimum length 15 feet–
type S, or ST, or SO, or STO, or STW–
minimum rate 300V 140/167°F (60/75°C)–
DANGER!
Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with–
a qualified electrician or service person if you are in doubt as to whether the outlet is properly grounded. Do
not modify the plug provided with the appliance. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician.
This appliance is for use on a nominal 120 V circuit, and has a grounding plug that looks like the plug (B, Fig.–
1). A temporary adapter (B and C) may be used to connect this plug to a 2-pole receptacle (B), if a properly
grounded outlet is not available. The temporary adapter should be used only until a properly grounded outlet
(A) can be installed by a qualified electrician. The green-colored rigid ear, tab, or the like extending from the
adapter must be connected to a permanent ground such as a properly grounded outlet box cover. Whenever
the adapter is used, it must be held in place by a metal screw. Grounding adapters are not approved for use
in Canada.
Replace the plug if the grounding pin is damaged or broken.–
The Green (or Green/Yellow) wire in the cord is the grounding wire. When replacing a plug, this wire must be–
attached to the grounding pin only.
Extension cords connected to this machine should be 12 gauge, three-wire cords with three-prong plugs and–
outlets. DO NOT use extension cords more than 50 ft (15 m) long.
A B C
Figure 1
S310183A

ENGLISH
Operator’s Manual - Vantage 13 7
MACHINE DESCRIPTION
MACHINE STRUCTURE
Serial number plate/technical data/conformity certification1.
Handlebar2.
Handlebar tilting adjustment lock/unlock lever3.
Control panel4.
Program selection knob5.
Program: brushes - vacuum system - solution flow5a.
activation
Program: brushes - solution flow activation5b.
Program: vacuum system activation5c.
Program: fitted carpet cleaning and floor wiping (optional)5d.
Main switch6.
Power supply cable holder7.
Wheels on fixed axle8.
Brush/squeegee-holder deck9.
Power supply cable10.
Solution hose quick coupling (to the pump)11.
Front squeegee12.
Rear squeegee13.
Solution tank14.
Transparent cover with vacuum grid15.
Recovery tank16.
Solution hose17.
Solution tank filler plug18.
Recovery tank drain plug19.
Vacuum system motor vacuum hose20.
Squeegee vacuum hose21.
One-way valve22.
Solution hose quick coupling (to the brushes)23.
Parking lever (if equipped)24.
Disengaged parking lever24a.
Engaged parking lever24b.
Solution filter25.
Tank lifting handle26.
Squeegee fasteners27.
Solution tank quick coupling28.
1
55a
5c5d
5b 6
3
16
15
2
7
20
21
26
28
18
14
8
27
13
9
24
12
24a 24b
4
98
23
11
25
15
19
17
22
10
P100311

ENGLISH
8 Operator’s Manual - Vantage 13
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specific use:
Brushes of different materials–
Fitted carpet cleaning and floor wiping–
For further information concerning the above-mentioned optional accessories, contact an authorized Retailer.
TECHNICAL DATA
General Vantage 13
115 Volts
Min/max machine length at the handlebar 28.1 / 44.1 in (715/1.120 mm)
Machine width with squeegee 15.1 in (385 mm)
Machine - brush deck width 15.1 in (385 mm)
Maximum machine height with adjustable handlebar 39.7 in (1.010 mm)
Total machine weight 52.9 lbs (24 Kg)
Gross Vehicle Weight (GVW) 70.5 lbs (32 Kg)
Cleaning width 12.9 in (330 mm)
Central wheel diameter 7 in (180 mm)
Brush diameter 6.5 in (165 mm)
Brush number No. 2 brushes/pads
Squeegee system Fixed on deck
Straight squeegee width 15 in (385 mm)
Squeegee blades type Front - Rear: PU 65 SH
Wheel pressure on the ground 101 psi (0,7 N/mm2)
Brush pressure on the floor with empty/full solution tank 19.8 / 33 lbs (9/15 Kg)
Performance Vantage 13
115 Volts
Vacuum 1.45 psi (0,10 Bar)
Solution flow 0.13 gal/min (0,4 L/min)
Theoretic/real productivity 1184/ 597 ft2/h (990/500 m2/h)
Solution autonomy ~ 18 min
Brush speed 200 rpm
Sound pressure level at workstation (ISO 11201, ISO 4871) (LpA) 72.5 dB(A) ± 3dB(A)
Machine sound pressure level (ISO 3744, ISO 4871) (LwA) 86 dB(A)
Vacuum system motor power 0.74 hp (550 W)
Brush motor power 0.13 hp (100 W)
Gradeability 2%
Solution tank capacity 2.1 gal (8,0 liters)
Recovery tank capacity 2.4 gal (9,0 liters)
Vibration level at the operator’s arms (ISO 5349-1) < 98.42 in/s2(< 2,5 m/s2)
Power supply cable length 590 in (15 m)

ENGLISH
Operator’s Manual - Vantage 13 9
WIRING DIAGRAM
Key
C1 Brush motor condenser
C2 Filtering condenser
D1 Pump diode
ES1 Relay
M1 Brush motor
M2 Vacuum system motor
P Water pump
PL Plug
SW1 Main switch
SW2 Program selection knob
Color code
BK Black
BU Blue
BN Brown
GN Green
GY Gray
OG Orange
PK Pink
RD Red
VT Violet
WH White
YE Yellow
115 V
P100312

ENGLISH
10 Operator’s Manual - Vantage 13
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
DANGER–
WARNING–
CAUTION–
CONSULTATION–
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates.
Do not cover these plates for any reason and immediately replace them if damaged.
BEFORE START-UP
1
2
9
3
9
12
18
14
P100308
Brush installation
NOTE
The machine is supplied with two brushes (A, Fig. 2) installed. According to the type of floor to be cleaned, the brushes
can be replaced.
Lift the machine by prying the handlebar (2).1.
Install the brushes (A, Fig. 2) in the 2 hubs of the deck (9).2.
Lower the machine by using the handlebar (2).3.
A
A
Figure 2
P100313

ENGLISH
Operator’s Manual - Vantage 13 11
Brush application guide (suggestions only)
Types of brushes available Prolite Prolene
General cleaning:
Concrete
Terrazzo floor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Solution tank filling
Use the filler plug (18) to fill the tank (14) with a solution suitable for the work to be performed.4.
Do not fill the solution tank completely, leave few inches from the edge.
Always follow the dilution instructions on the label of the chemical product used to prepare the solution.
The solution temperature must not exceed +40°C.
CAUTION!
Use only low-foam and non-flammable detergents, intended for automatic scrubber applications.
Adjustments
Adjust the handlebar (2) with the knobs (3) to reach a comfortable position.5.

ENGLISH
12 Operator’s Manual - Vantage 13
MACHINE START AND STOP
1
55a
5c5d
5b 6
3
16
15
2
7
26
18
14
24
24a 24b
4
11
25
19
15 17
28
10
P100309
Starting the machine
Prepare the machine as shown in the previous paragraph.1.
Turn the parking lever (24, if equipped) to position (24a).2.
Drive the machine to the working place by pushing it with the hands on the handlebar (2).3.
Connect the power supply cable (10) to the electrical mains.4.
WARNING!
Before connecting the power supply cable to the electrical mains, check that frequency and voltage, shown on
the machine serial number plate (1), match the electrical mains voltage.
Turn the knob (5) to the suitable program.5.
brushes - vacuum system - solution flow activation(5a)
brushes - solution flow activation(5b)
vacuum system activation(5c)
fitted carpet cleaning and floor wiping (optional)(5d)
Turn on the machine by pressing the switch (6) and start cleaning the floor.6.
Stopping the machine
Turn off the machine by pressing the switch (6).7.
Disconnect the power supply cable (10) from the electrical mains.8.
Lift the brush by turning the transport/parking device (24, if equipped) to position (24b).9.
MACHINE OPERATION (SCRUBBING/DRYING)
Start the machine as shown in the previous paragraph.1.
While keeping both hands on the handlebar (2), move the machine and start scrubbing/drying the floor.2.
CAUTION!
To avoid damaging the floor surface, do not use the brushes without the solution and, when the machine is not
operating, stop the brush by pressing the program (5c or 5d), or by pressing the switch (6).
CAUTION!
Before lifting the brush, turn it off by pressing the switch (6).

ENGLISH
Operator’s Manual - Vantage 13 13
MACHINE TRANSPORT/PARKING
To transport/park the machine, proceed as follows.
Turn off the machine by pressing the switch (6).1.
Disconnect the power supply cable (10) from the electrical mains and place it on the holder (7).2.
Push the machine with the handlebar (2) and keep the brush/squeegee-holder deck slightly lifted.3.
Lift the machine and turn the parking lever (24, if equipped) to position (24b).4.
TANK EMPTYING
WARNING!
To avoid spilling the water (for example during an abrupt machine maneuver), drain the recovery tank (16) at the
end of every cleaning cycle.
Use the transparent cover with vacuum grid (15) to check if the recovery tank (16) is full.
CAUTION!
If the recovery tank (16) is not emptied when full, the vacuum system ejects the excess of liquid through the air
outlets, thus dampening the floor.
When the recovery tank (16) is full, empty it as shown below.
Recovery tank and solution tank emptying
Turn off the machine by pressing the switch (6).1.
Disconnect the power supply cable (10) from the electrical mains and place it on the holder (7).2.
Drive the machine to the appointed disposal area.3.
Lift the brush/squeegee-holder deck and turn the parking lever to position (24b).4.
Carefully remove the quick coupling (28) from the solution tank.5.
Move the transparent cover (15) aside and lift the tanks with the handle (26).6.
Open the recovery tank drain plug (19) and empty the tank.7.
If necessary empty the solution tank (14) by opening the plug (18).8.
Then, rinse the tanks and the solution hose filter (25) with clean water.

ENGLISH
14 Operator’s Manual - Vantage 13
AFTER USING THE MACHINE
24b
7
10
14
16
24
P100310
After working, before leaving the machine:
Turn the parking lever (24, if equipped) to position (24b).1.
Disconnect the power supply cable (10) from the electrical mains and place it on the holder (7).2.
Empty the tanks (14 and 16) as shown in the previous paragraph.3.
Perform the daily maintenance procedures (see the Maintenance chapter).4.
Store the machine in a clean and dry place.5.
MACHINE LONG INACTIVITY
If the machine is not going to be used for more than 30 days, proceed as follows:
Perform the procedures shown in After Using the Machine paragraph.1.
Store the machine in a clean and dry place.2.
FIRST PERIOD OF USE
After the first 8 hours, check the machine fastening and connecting parts for proper tightening. Check the visible parts for integrity
and leakage.

ENGLISH
Operator’s Manual - Vantage 13 15
MAINTENANCE
The lifespan of the machine and its maximum operating safety are ensured by correct and regular maintenance.
The following chart provides the scheduled maintenance. The intervals shown may vary according to particular working conditions,
which are to be defined by the person in charge of the maintenance.
WARNING!
Maintenance operations must be carried out with the machine switched off and the power supply cable
disconnected from the electrical mains.
Moreover, carefully read all the instructions in the Safety paragraph.
All scheduled or extraordinary maintenance procedures must be performed by qualified personnel, or by an authorized Service
Center.
This Manual describes only the easiest and most common maintenance procedures.
NOTE
For other maintenance procedures shown in the Scheduled Maintenance Table, refer to the Service Manual that can be
consulted at any Service Center.
SCHEDULED MAINTENANCE TABLE
Procedure Daily, after using
the machine Weekly Every six months Yearly
Brush cleaning
Squeegee cleaning
Tank and vacuum screen cleaning
Squeegee blade check and replacement
Solution hose filter cleaning
Screw and nut tightening check (1)
Vacuum system motor carbon brush check and replacement (2)
And after the first 8 working hours.(1)
This maintenance procedure must be performed by Clarke authorized Service Center.(2)

ENGLISH
16 Operator’s Manual - Vantage 13
SQUEEGEE CLEANING, CHECK AND REPLACEMENT
NOTE
The squeegees must be clean and its blades must be in good conditions in order to get a good drying.
CAUTION!
It is advisable to wear protective gloves when cleaning the squeegees and the brush deck because there may be
cutting debris.
Drive the machine on a level ground.1.
Make sure that the power supply cable (10) is disconnected from the electrical mains.2.
To reach for the brush/squeegee-holder deck, lift the machine by using the handlebar (2).3.
Remove the squeegees from the deck by pressing the fasteners (27).4.
Check the brush/squeegee-holder deck (9) and clean it, in particular, clean the compartments (A, Fig. 3) and the vacuum hole5.
(B).
Wash and clean the squeegee. In particular, clean the compartments (C) and the vacuum hole (D) from dirt and debris.6.
Check that the blade (E) and the blade (F) are integral and free from cuts and lacerations; if necessary replace them.7.
Install the squeegees.8.
A
C
E
F
D
A
B
B
E
Figure 3
P100314
BRUSH CLEANING
CAUTION!
It is advisable to wear protective gloves when cleaning the brushes because there may be cutting debris.
Remove the brushes from the machine, as shown in Use chapter.1.
Clean and wash the brushes with water and detergent.2.
Check the brush bristles for integrity and wear; if necessary, replace the brushes.3.

ENGLISH
Operator’s Manual - Vantage 13 17
VACUUM GRID, DETERGENT TANK AND RECOVERY TANK CLEANING
Drive the machine to the appointed disposal area.1.
Make sure that the power supply cable (10) is disconnected from the electrical mains.2.
Open the transparent cover (A, Fig. 4) and clean it carefully.3.
Clean the vacuum grid (B) with care. If necessary disconnect the hoses (20 and 21).
Check the transparent cover gasket (C) for integrity.4.
NOTE
The gasket (C) creates vacuum in the tank that is necessary for vacuuming the recovery water.
If necessary replace the gasket (C) by removing it from its housing (A).
Check that the seating surface (D) of the gasket (C) is integral and adequate for the gasket itself.5.
Drain and wash the recovery tank (16) and the detergent tank (14) as shown in Use chapter.6.
Install the tanks and the transparent cover with the vacuum grid.7.
A
B
D
C
Figure 4
P100315
SOLUTION HOSE FILTER CLEANING
Drive the machine on a level ground.1.
Make sure that the power supply cable (10) is disconnected from the electrical mains.2.
Remove the solution hose plug (A, Fig. 5), carefully remove the hose from the tank and clean the filter (B) with water.3.
If necessary, remove the filter and replace it with a new one.
Install the filter and the solution hose in the tank, then install the plug.4.
A
B
Figure 5
P100316

ENGLISH
18 Operator’s Manual - Vantage 13
TROUBLESHOOTING
Trouble Possible Cause Remedy
The motors do not turn on. The power supply cable is faulty or
disconnected from the electrical mains. Replace the cable or connect it.
Dirty water vacuuming is insufficient or there is
no vacuuming.
The vacuum grid is clogged. Clean.
The vacuum hose is disconnected from the
deck or it is damaged. Connect or replace.
The squeegees are dirty or the squeegee
blades are worn or damaged. Clean or replace the squeegees.
The gasket of the transparent cover is
damaged.
Check and/or clean the seating surface or
replace the gasket.
The vacuum system motor is faulty. Replace (*).
The solution flow is insufficient. The solution filter is dirty. Clean or replace.
The brushes do not turn. The driving belt is loosened or broken. Adjust or replace (*).
The brush motor is damaged. Replace (*).
The squeegee leaves marks on the floor.
There are debris under the squeegee
blades. Remove the debris.
The squeegee blades are worn, chipped or
torn. Replace the blades.
The floor is wet with dirty water. The recovery tank is full and the excess of
dirty water is ejected. Empty the tank.
This maintenance procedure must be performed by Clarke authorized Service Center.(*)
For further information refer to the Service Manual, available at any Clarke Service Center.
SCRAPPING
Have the machine scrapped by a qualified scrapper.
Before scrapping the machine, remove and separate the following materials, which must be disposed of properly according to the
Law in force (local guidelines):
Brooms–
Electrical and electronic components (*)–
Refer to the nearest Clarke Center especially when scrapping electrical and electronic components.(*)
