Clarke CVACASH500 Installation and operation manual

OPERATING & MAINTENANCE
INSTRUCTIONS
GC0614
ELECTRIC ASH CAN
Model: CVACASH500
Part No: 6471132

2
INTRODUCTION
Thank you for purchasing this electrically powered Ash Can which is designed
for fast, easy removal of ash from stoves and fireplaces.
Before attempting to operate this product, it is essential that you read this
manual thoroughly and carefully follow all instructions given. In doing so you
will ensure the safety of yourself and that of others around you, and you can
also look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for its intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
ENVIRONMENTAL RECYCLING POLICY
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.
PARTS & SERVICE
This product has been designed to give long and trouble free service. If,
however, having followed the instructions in this booklet carefully, you
encounter problems, refer to your local Clarke dealer.

3
GENERAL SAFETY PRECAUTIONS
WORK AREA
1. Avoid operating in the presence of flammable liquids or gases. The motor
may produce sparks during operation. Do not use in enclosed areas
where flammable, explosive or toxic vapours are given off.
PERSONAL SAFETY
1. Always stay alert, watch what you are doing and use common sense
when operating the ash can. Do not use the ash can while you are tired or
under the influence of medication, drugs or alcohol. Lack of attention can
result in personal injury.
2. Always store the ash can out of reach of children.
005HSACAVCledoM
thgieW)ytpme(gk3.3
)thgieHxaiD(snoisnemiDmm004x003
yticapaCmurD)gnikrowL61(sertiL22
muucavxaMaPk11
elcyCytuD)suounitnoc(1S
gnitaResuFA5
ylppuSrewoPhp1zH05@V032
gnitaRrewoProtoMW005
gnitaRPI02
leveLrewoPdnuoSAwLBd49
leveLer
usserPdnuoSApLBd08
leveLrewoPdnuoSdeetnarauGAwLBd28
)K(rotcaFytniatrecnU3
SPECIFICATION
Please note that the details and specifications contained herein, are correct at the
time of going to print. However, Clarke International reserve the right to change
specifications at any time without prior notice.

4
3. Never over-reach. Keep your proper footing and balance at all times to
enable better control of the ash can in unexpected situations.
GENERAL PRODUCT USE AND CARE
WARNING: DO NOT USE THIS ASH CAN TO COLLECT HOT ASHES, COALS
OR WOOD EMBERS. ALWAYS ALLOW THE RESIDUE FROM STOVES AND
FIREPLACES TO COOL FULLY BEFORE COLLECTING WITH THIS ASH CAN.
1. Prior to use, all users should become familiar with this instruction booklet.
2. Always maintain the ash can with care and keep it clean for best/safest
performance.
3. Never use this product if any part is damaged. Have it inspected and
repaired by your Clarke dealer. Do not use if the electric cable, plug, or
the product itself, is in poor condition.
4. Never abuse the power cable. Never pull on the cable when removing
the plug from the socket or lift the ashcan by the power cable. Take care
not to close doors on the cable, or allow it to become snagged under
furniture/objects with sharp edges. Keep away from heat or oil.
5. Only use extension leads that are of an appropriate power rating and
suitable for the work environment. Extension leads must have an earth
connection. Inspect the extension lead regularly and replace if damaged.
6. Always take care when a long hose is required in the work area as it
presents a trip hazard. Tidy the hose away when the job is finished.
7. Never pick up flammable or readily combustible material such, or use in
the presence of explosive liquids or vapours.
8. Never pick up burning cigarettes or other smoking substances.
9. Never abuse the ash can by standing on it.
10. Always transport the ash can using the handle.
11. Only use the metal suction hose provided with this ash can. A normal
plastic vacuum cleaner hose is not suitable and may be damaged.

5
ELECTRICAL CONNECTIONS
WARNING! Read these electrical safety instructions thoroughly
before connecting the product to the mains supply.
Before switching the product on, make sure that the voltage of your
electricity supply is the same as that indicated on the rating plate. This
product is designed to operate on 230Vac 50Hz. Do not connect it to any
other power source.
This product may be fitted with a non-rewireable plug. If it is necessary to
change the fuse in the plug, the fuse cover must be refitted. If the fuse cover
becomes lost or damaged, the plug must not be used until a suitable
replacement is obtained.
If the plug has to be changed because it is not suitable for your socket, or
due to damage, it should be cut off and a replacement fitted, following the
wiring instructions shown below. The old plug must be disposed of safely, as
insertion into a mains socket could cause an electrical hazard.
WARNING! The wires in the power cable of this product are
coloured in accordance with the following code:
Blue = Neutral Brown = Live
If the colours of the wires in the power cable of this product do not
correspond with the terminal markings of your plug, proceed as follows.
• The wire which is coloured Blue must be connected to the terminal which
is marked N or coloured Black.
• The wire which is coloured Brown must be connected to the terminal
which is marked L or coloured Red.
Plug must be BS1363/A approved.
Always fit a 5 Amp fuse.
Neutral Live
(Blue) (Brown)
Ensure that the outer sheath of the cable is firmly held by the clamp
We strongly recommend that this product is connected to the mains supply
via a Residual Current Device (RCD).
If in doubt, consult a qualified electrician. DO NOT attempt repairs yourself.
This symbol indicates that this is a Class II product and does not require
an earth connection.

6
COMPONENTS
oN noitpircseD oN noitpircseD
1knaT5revoCknaT
2pilCgniruceS6retliFegnopS
3ebuTnoitcuS7retliFegdirtraC
4esoHnoitcuS8retsinnaChseM
1
2
3
4
56
8
7

7
PREPARATION FOR USE
WARNING: Before using the ash can, make sure that you have read
and understood the safety instructions.
UNPACKING & ASSEMBLY
1. With the ash can removed from the packaging, undo the securing clips
(2) securing the tank cover (5) and remove the components from within
the tank. Check for shortages and that no damage was suffered in transit.
2. Check that the sponge filter (6) is
correctly in position on the motor
housing.
3. Place the cartridge filter (7) over
the motor housing.
4 The cartridge filter is secured to
the tank cover by a protective
mesh cannister. Secure this in
place by engaging the three
retaining tabs shown in figure 2
into the fixing on the tank cover
and twisting the cannister
clockwise.
Note: The motor will not run without
the filter correctly in position.
4. Fit the tank cover to the tank,
securing in place with three clips.
5. Insert the suction tube (3) into one
end of the suction hose (4) as
shown in fig 3.
• Note that the two ends of the
suction hose are different. The
end with the collar and swivel fits
into the tank.
6. Insert the other end of the suction
hose into the inlet connection in
the tank.
7. Before plugging into the power
supply, the ash can should be
positioned on a firm, level
surface. Do not cover the ash
can and always position it with good all-round air ventilation. The ash can
must remain upright.
4
3
Fig 3
Cannister
Cartridge Filter
Sponge Filter
Fig 1
Fig 2
Tab

8
OPERATING INSTRUCTIONS
1. Switch on the ash can and use the suction tube to collect the ash.
2. When moving the ash can:
• Always use the handle.
• Do not lift it by (or place a strain on) the hose or cable.
• Always switch it off and disconnect it from the mains power supply.
CAUTION! MAKE SURE THAT FIREPLACES AND STOVES ARE COLD
BEFORE YOU ATTEMPT TO VACUUM THEM CLEAN.
• Take care not to collect material which appears to have cooled
down on the outside but which may still be hot on the inside. Hot
ash particles may ignite again in the air flow.
CAUTION! WAIT UNTIL THE ASH HAS COOLED DOWN COMPLETELY
BEFORE YOU BEGIN TO COLLECT IT.
• Any ash which has a temperature exceeding 40°C may damage
the ash can.
3. Do not attempt to quickly extinguish fires in fireplaces or stoves with water
in order to achieve cool ash. The construction material in the fireplace or
stove may not withstand any sudden variations in temperature and suffer
permanent damage.
4. Continuously check the tube and ash can for excess temperature during
use. If you notice a significant temperature rise, switch off immediately
and disconnect the ash can from the power supply. Let the ash can cool
down under supervision before emptying the vacuumed material.
CAUTION! EXCESSIVE TEMPERATURES CAN LEAD TO DAMAGE TO THE
SUCTION HOSE AND THE ASH CAN AND CAUSE A RISK OF FIRE.
5. Watch the visual indicator on the
top of the ash can.
• The red indicator will be visible
when the ash can is full and
needs emptying, or if there is a
blockage in the hose or filter.
6. Always empty the ash can after
use and clean it when required.
Never use solvents for cleaning
any part of the ash can.
Fig 3
Indicator

9
MAINTENANCE
1. Inspect the cartridge filter regularly and clean it when necessary. Remove
the lid and twist the mesh cartridge filter off the housing.
2. Dislodge as much imbedded debris as possible before washing the filter
with tap water before drying it completely.
3. Reposition it, ensuring it is in place by engaging the three retaining tabs
into the fixings on the tank cover and twisting the canister clockwise.
Important: cleaning should not use chemicals or compressed air.
4. Always ensure that the sponge filter covering the motor fan is in good
condition and not blocked. Lift it away and wash it in water if required
and allow it to dry completely before use.
5. Ensure the hose is kept in good condition.
• A damaged hose will seriously effect the efficiency of the ash can and
should be replaced.
6. Contact your CLARKE dealer for replacements.
CARE & STORAGE
1. When not in use, turn off using the switch on top of the ash can, then
remove the plug from the mains power supply.
2. When you have finished with the ash can, ensure the electric cable is
stowed away by winding it around the handle, and not left as a hazard for
others to trip over.
3. Do not change filters, or carry out any cleaning or servicing, without first
disconnecting the ash can from the power supply.
4. Keep the external surfaces clean. Avoid impact damage & do not allow
the ash can to come into contact with abrasive or corrosive materials.
5. Do not use solvents, thinners or alcohol to clean the ash can, as these
chemicals will damage the finish. With the ash can unplugged from the
power supply, use a dry cloth to wipe over the casing.
6. When not in use the ash can should be stored in a secure, dry place, out
of the reach of children. DO NOT leave it exposed to the elements and
avoid direct sunlight, direct heat, rain/moisture etc.
7. Only use parts and accessories recommended in this manual. The use of
unauthorised accessories or attachments is not permitted and may result
in personal injury or damage to the ash can.
8. Do not attempt to repair or modify the ash can. Do not attempt any
electrical repair yourself. Consult a qualified electrician or the Clarke
Service Department on 020 8988 7400.

10
oN rebmuNtraP noitpircseD
110005CAVCTHeldnaHgniyrraC
220005CAVCTHrevoCpoT
330005CAVCTHhctiwSffO/nO
440005CAVCTHpaCgnilaeS
550005C
AVCTHrotoM
660005CAVCTHgniRgnilaeSdiL
770005CAVCTHrotacidnIlluFnachsA
8TH80005CAVClaeSrebbuR
9TH90005CAVChctiwsorciM
retliF
01TH01005CAVCgniriWrennI
11TH11005CAVCgnisuoHrotoM
21TH21005CAVCylbmessArevoCpoT
31TH31005CAVCesoHnoitcuS
41TH410
05CAVCretliFegdirtraC
51TH51005CAVCgulP&elbaCrewoP
61TH61005CAVCebuTnoitcuS
71THA71005CAVCretsinaCretliF
81TH81005CAV
CwoblEgnitcennoC
91TH91005CAVCL22knaThsA
0202005CAVCTHretliFegnopS
COMPONENT PARTS LIST

11
DECLARATION OF CONFORMITY
