Clarus BE! MOBILE User manual

BE! MOBILE
Installation Instructions
PLEASE READ ALL INSTRUCTIONS
BEFORE INSTALLATION
PLEASE READ ALL INSTRUCTIONS

The packaging of one be! Mobile unit consists of:
• One (1) 67.375” x 40” center panel with glass
• Four (4) legs with caster attached (Fig. A)
• Twelve (12) threaded standos (Fig. B)
• Two (2) allen keys (Fig. C)
• Twenty four (24) M8 flat head socket cap screws (Fig. D)
INCLUDED HARDWARE
Fig. A Leg with caster, QTY: 4
Fig. D M8 flat head socket cap screw, QTY: 24
Fig. B Threaded stando, QTY: 12
Fig. C Allen Key, QTY: 2

Fig. E
Fig. F
Place the leg on any flat surface, (leg must always be oriented so
it looks like an ‘L’ when seen from the top).
Align three (3) M8 flat head socket screws with the left three (3)
counter-sunk holes on the leg and then, by hand, attach three (3)
threaded standos from the other side of the foot (Fig. E).
Standos should always be on the left side of the leg (Fig. F).
Repeat for remaining legs.
STEP 1
Always put standos on left row of holes.
Right row of holes should be left empty.

Fig. G
Fig. H
Place the center panel with glass on a flat surface. Make sure
the holes are away from the flat surface to give more room to
assemble the legs (Fig. G).
Align the legs from both sides of the glass (Fig. H).
Best completed with two (2) people.
STEP 2
STEP 3

Fig. I
Fig. J
Hold the glass and legs together and begin to screw the six (6)
screws into the empty holes of the feet by hand. Tighten with
provided allen keys. Best completed with two (2) people.
Repeat Step 4 for remaining legs (Fig. J).
STEP 4
STEP 5

Your be! Mobile is now assembled and ready!
Let the collaboration begin!
STEP 6
© 2020 Clarus. All rights reserved.clarus.com | +1.888.813.7414
