PH500T pH Meter Operation Quick Guide
PH500T pH Meter Operation
Quick Guide
1. Specification
Parameters: pH, mV, Temperature
pH level: 0.001pH
pH range: (-2.000～20.000)pH
mV range: (-2000.00～2000.00)mV
Temperature range: (-10.0～135.0)℃
/(14.0 ～275.0) ℉
2. Screen Icons
2.1. Annotation
No.
Explanation
1
User ID
2
Measurement parameters
3
Reading states
4
Measurement information
5
Method management
6
Tips information
7
System time
8
Calibration information
No.
Explanation
9
Sample ID
10
Soft function buttons
2.2. Symbol
Symbol
Explanation
Reading status, display the
measurement status of reading, stable,
locked each indicates that the
processing, stable, and reading
completed.
PTS
The percentage slope of the pH
electrode calibration data
ATC
Auto Temperature compensation
MTC
Manual temperature compensation
ORP
Redox potential value, in mV
Offset
Offset potential, in mV
Measurement method management,
display the current method information
Standard solution for pH electrode
calibration
User ID
Sample ID
3. pH Operation Quick Guide
3.1. Preparation
1. Install the components of the
instrument and connect the pH and
temperature electrode.
2. Prepare standard buffer solutions
such as pH4.01, pH7.00, pH10.01
standard solutions.
3. Remove the protective cap at the
lower end of the pH electrode, pull
down the rubber cover at the upper
end of the electrode. Expose the top
hole, rinse the electrode with distilled
water, and dry with filter paper.
4. Press the power key to turn on the
instrument.
5. Select measurement method:
●The default measurement method of
the instrument is "No.001 direct reading
measurement method", pH measurement
parameter, continuous reading mode, if
adopting the default method for
measurement, this step can be omitted.
●Press to enter the measurement
method management. You can select the
method in the method list or create new
methods as required.
6. The main measurement parameter
settings of the instrument:

PH500T pH Meter Operation Quick Guide
●Reading mode: supports continuous,
timing and auto reading mode.
The default is continuous reading mode,
you can choose according to your
requirements, press the "Enter" key to
complete the setting.
3.2. Calibration
1. Setting.
1) Set the parameters (e.g. pH).
2) Select NIST standard solution
group, and check pH 4.01, pH
7.00 and pH 10.01 three
standard solutions.
3) Set the Auto Mode recognition.
2. After pressing the "Calibrate"-"pH
Verification" key, the instrument
enters the interface for selecting
calibration type. Select “Calibration”
to enter the pH electrode calibration
interface.
3. Put the cleaned electrode into pH
4.01 standard solution. Wait for the
instrument to display “Auto Mode
Matched”, or the instrument reading
is stable, press "Start" to calibrate
1-point, after the completion of the
instrument, display calibration
results.
4. If multi-point calibration is required,
please replace the pH7.01 and
pH10.01 standard buffer solutions.
After cleaning the electrode, put the
electrode into the standard solution.
After the instrument recognizes it
successfully, the instrument reads
stably, press the "Next Point" to
complete the calibration.
5. During the calibration process, press
the “Enter” key to terminate the
calibration, and the instrument will
automatically display the window
prompts whether to save the
calibration results. After selecting,
directly enter the start interface.
interface. If the checked standard
solution group is 6, automatically end
the calibration after six points of
calibration.
3.3. Measurement
1. Setting.
1) Set the parameters (e.g. pH).
2) Set the reading mode (e.g.
continuous reading,
auto-reading, or timed format).
2. Press " Measure" to enter the
measurement interface, after the
reading is stabilized (the data
stability mark is full), then measure.
3. Press the "Save" to save the
measurement results. Press the
"Output" to print the measurement
result when connect to the printer.
Note: For accurate measurement, please
calibrate and measure at the same
temperature.
