Clean Water Systems 7500-REV2.5 User manual

7500-REV2.5 Tannin Filter Installation Guide
Thank you for purchasing a Clean Water System!
Please review this start‐up guide entirely before beginning
to install your system, and follow the steps outlined for
best results.
Minimum pressure of 30 PSI recommended.
Maximum pressure recommended 80 PSI.
For indoor installation only.
Protect from sunlight, rain, and freezing.
Questions?
Call us toll‐free: 1‐888‐600‐5426 or 1‐831‐462‐8500
Email us: [e-mail]
See more information on our website: www.cleanwaterstore.com/resources
Clean Water Made Easy
www.cleanwaterstore.com

Table of Contents
Packing Lists .................................................................................................................................................. 3
Pre‐Installation.............................................................................................................................................. 4
Best Practices for Piping & Drain Installation: .............................................................................................. 4
How the Bypass Valve Works........................................................................................................................ 5
Installation of Your System in Copper or Metal Piping Systems:.................................................................. 5
How Your Tannin Filter Works: ..................................................................................................................... 6
Diagram of Typical Installation Well Water .................................................................................................. 6
Tannin Tank Assembly and Installation Instructions: ................................................................................... 7
Programming Your Valve and Setting Time and Days for Backwash............................................................ 9
Set Time of Day ........................................................................................................................................... 10
Set Date....................................................................................................................................................... 10
Set Service Days .......................................................................................................................................... 11
Set Regen Time ........................................................................................................................................... 11
Start the First Regeneration Before Using.................................................................................................. 11
Advanced Programming Mode ................................................................................................................... 12
7500‐REV2.5 Water Conditioners Limited Warranty.................................................................................. 13

7500-REV2.5 Tannin Filter Installation & Startup Guide
3www.cleanwaterstore.com rev082922
Packing Lists
All systems include:
7500‐REV2.5 control valve, brine tank, small tube of silicone grease, bypass valve, 1” pipe
connectors, power supply, funnel for adding tannin resin, top screen, start‐up guide, and items
included in one of the following options:
Find Your Size System to See What is Included:
What to Do if Your Tank is Not Level Out of the Box:
Your black filter tank base is not glued to the bottom of your tank. Occasionally tank bases will become
crooked during shipment. If you find that that your tank does not sit level on the floor, you can easily
adjust it by holding the empty tank and knocking it on a concrete or solid floor once or twice to level it.
Tannin Filter 32K 1.0 cubic foot size
9” x 48” filter tank with distributor tube
12 lbs. filter gravel
1 cubic foot of Tannin Resin
Tannin Filter 48K 1.5 cubic foot size
10” x 54” filter tank with distributor tube
16 lbs. Filter gravel
1.5 cubic foot of Tannin Resin
Tannin Filter 64K 2.0 cubic foot size
12” x 52” filter tank with distributor tube
20 lbs. filter gravel
2.0 cubic foot of Tannin Resin
Tannin Filter 80K 2.5 cubic foot size
13” x 54” filter tank with distributor tube
35 lbs. filter gravel
2.5 cubic foot of Tannin Resin
Tannin Filter 96K 3.0 cubic foot size
14” x 65” filter tank with distributor tube
40 lbs. filter gravel
3.0 cubic foot of Tannin Resin

7500-REV2.5 Tannin Filter Installation & Startup Guide
4www.cleanwaterstore.com rev082922
Pre-Installation
1. Review your packing list and make sure you have received all the parts before installation.
2. If you are going to be turning off the water to the house and you have an electric water heater,
shut off the power to the water heater before beginning installation in case water heater is
accidentally drained.
3. Pick a suitable location for your filter system on a dry level spot where it won’t be exposed to
freezing temperatures. A minimum of 20 PSI is required. Maximum pressure is 90 PSI.
4. Get all of your plumbing parts together before beginning installation, and make sure you have
received all of your packages before beginning or scheduling an installation. Installation typically
takes 3 to 5 hours. However, after installation the Tannin Filter must be allowed to run through a
complete regeneration (backwash and rinse cycle) which can 2 hours to the time.
5. After the system is installed and running, your water may be discolored particularly if you have
older or corroded piping. This typically clears up over a day or two.
Best Practices for Piping & Drain Installation:
1. Make sure to connect the Inlet from your water source and outlet, following arrows on control
valve. Connect the External Flow Control fitting onto the Drain line.
2. Make sure there is a working gate or ball valve before the system and also one after as well as a
bypass valve.
3. A hose bib (which is a faucet to which you can attach a garden hose) is strongly recommended
after the Tannin Filter and before the second ball valve. This makes it easy to
rinse your new Tannin Filter on start‐up and gives you a place to test the
water.
4. If you will be using copper piping, do not sweat the copper pipe directly on to
the 7500‐REV2.5 control valve.
5. To connect drain line to drain, use an air‐gap connection, so that if your sewer or septic tank
backs up, it cannot cross connect with the drain tubing.
6. The pipe connectors are 1’ male pipe thread but you can add a reducer to reduce to ¾” pipe
with common pipe fittings if needed.
7. Make sure bypass valves are closed (system is in bypass) when you first start installing and keep on
bypass until you are ready to start it up with the first backwash.

7500-REV2.5 Tannin Filter Installation & Startup Guide
5www.cleanwaterstore.com rev082922
How the Bypass Valve Works
Turn knob so the valve is bypassed
when installing.
When you go to start up system
turn the bypass SLOWLY to let
water in and put in service.
Installation of Your System in Copper or Metal Piping Systems:
If your new filter system is to be installed in a metal (conductive) plumbing system, i.e., copper, or
galvanized steel pipe, the plastic components of the system will interrupt the electrical continuity of the
plumbing system.
As a result, any stray currents from improperly grounded appliances downstream or potential galvanic
activity in the plumbing system can no longer ground through the contiguous metal plumbing.
Some homes may have been built in accordance with building codes, which encouraged the grounding
of electrical appliances through the plumbing system.
Consequently, the installation of a bypass consisting of the same material as the existing plumbing, or a
grounded "jumper wire" bridging the equipment and reestablishing the contiguous conductive nature of
the plumbing system must be installed prior to your systems use.
This is simple and easy step to take if you are installing your water treatment system into copper piping.
A simple ground jumper wire with a pipe clamp can be purchased at any Home Center, or hardware
store etc. for a few dollars.

7500-REV2.5 Tannin Filter Installation & Startup Guide
6www.cleanwaterstore.com rev082922
How Your Tannin Filter Works:
In the Tannin Filter, water enters the top of the tank
and flows down through the media and up the
distributor tube. Hardness minerals are attracted to
the resin beads.
During backwash, the water flow is reversed and
water flows down the distributor tube and up
through the media, expanding the Tannin resin, and
removing sediment.
After the backwash stage, salt brine is automatically
drawn in from the brine tank which then slowly
rinses through the Tannin Resin for 1 hour, allowing
hardness minerals (calcium, magnesium) to be
swapped out with sodium ions in a process known as ion‐exchange.
This entire automatic process, called ‘regeneration’ takes about 90 minutes.
The 7500‐REV2.5 Control Valve tracks the amount of water that is used and will backwash
based on gallons OR every 7 days, whichever comes first.
Diagram of Typical Installation Well Water
If water is high in hardness (over 5 grains per gallon) a water softener is recommended.

7500-REV2.5 Tannin Filter Installation & Startup Guide
7www.cleanwaterstore.com rev082922
Tannin Tank Assembly and Installation Instructions:
1. Wrap the top of distributor tube with electrical or duct tape so that no
gravel or Tannin resin will go down the distributor tube when adding
the media.
2. Add the filter gravel that came with your order. You want the gravel to cover the bottom
distributor screen before adding the Tannin resin.
3. Next add Tannin resin. The tank should be about 2/3rds full of media, do not fill more than 2/3rds,
even if there is some media left over.
4. Remove cap or tape from top of distributor tube. Be careful not to pull up distributor tube when
removing cap or tape.
5. Fill tank completely with water.
6. Add a small amount of silicone grease to the inner O‐ring, where the distribution tube goes.
7. Next, install the top screen by inserting upwards
and rotating to lock in place. (This is a funnel‐
shaped plastic screen that locks into the bottom
side of control valve.
8. Lubricate the main tank O‐ring with silicone
grease and screw on the 7500‐REV2.5 control valve carefully. Do not use pipe‐joint compound,
vegetable oil, Teflon tape, or Vaseline or other greases to lubricate tank threads.
9. Connect bypass assembly with 1” pipe connectors to control valve install black clips and make sure
valve is in bypass
10. Install inlet and outlet piping and hook
up drain line tubing to drain.
11. Insert meter cable into meter cable
port on bypass
12. If you are in earthquake zone, strap
your backwash filter tank to wall with
metal strapping.

7500-REV2.5 Tannin Filter Installation & Startup Guide
8www.cleanwaterstore.com rev082922
13. Connect black 3/8” tubing to brine tank.
14. Hook up drain line tubing to drain. If needed heat up the tubing with warm water or a hair dryer to
make it easier to slip over the barbed fitting on the drain port.
15. Proceed to programming your 7500‐REV2.5 control valve timer and backwash frequency.
16. IMPORTANT: you must program the time and then start a regeneration backwash and rinse. The
tannin must run through one regeneration cycles. See following pages for instructions.

7500-REV2.5 Tannin Filter Installation & Startup Guide
9www.cleanwaterstore.com rev082922
Programming Your Valve and Setting Time and Days for Backwash
How to Start a Manual Backwash: Press the Back / Regen button
Pressing “Back Regen” at any time results in an immediate manual regeneration.
Pressing and holding for 3 seconds, when system is locked, results in a delayed regeneration at the
preselected time.
Extended Power Outage Indicator
If power outage exceeds 3 days, the time‐of‐day indicator “_” will flash 12:12. The current time of day
needs to be re‐set. All other set parameters remain stored in memory. The valve will resume to operate
from the point of the power outage.
Lockout Function
Keypad will lock after 5 minutes without use. To access the parameter changes, press and hold “Up” and
“Down” buttons simultaneously for 3 seconds to unlock.

7500-REV2.5 Tannin Filter Installation & Startup Guide
10 www.cleanwaterstore.com rev082922
Set Time of Day
1. If LOCK icon is lit, press, and hold both UP and
DOWN buttons for 3 seconds to unlock keypad.
2. Then press the MENU/CONFIRM button to enter
the main menu.
3. Press DOWN button to select “Set Time of Day”
4. Press the MENU/CONFIRM button again to change
time of day (Hour will flash)
5. Adjust hour by using DOWN or UP buttons.
6. Press the MENU/CONFIRM button again to change minutes (Minutes will flash)
7. Adjust minutes by using DOWN or UP buttons.
8. Press Back/Regen
Set Date
1. If LOCK icon is lit, press, and hold both UP and DOWN buttons for 3 seconds to unlock keypad.
2. Then press the MENU/CONFIRM button to enter the main menu.
3. Press DOWN button to select “Set Date”
4. Month: Press the MENU/CONFIRM button again to change time of day (Month will flash) and
adjust to current Month date by using DOWN or UP buttons.
5. Day: Press the MENU/CONFIRM button again to change Day date (Day date will flash) and
adjust to current day date by using DOWN or UP buttons.
6. Year: Press the MENU/CONFIRM button again to change Year date (Year date will flash) and
adjust to current Year by using DOWN or UP buttons.
7. Press BACK/REGEN button to save current date and go back to menu.
8. Continue to review and/or change the remaining settings (as follows)

7500-REV2.5 Tannin Filter Installation & Startup Guide
11 www.cleanwaterstore.com rev082922
Set Service Days Set for every 3 to 4 days. In some cases it may need to be set to every 1 to 2 days.
Set Regen Time The time tannin filter will backwash. Default is 2:00 AM
Set Backwash Time Length Set for 10 minutes. This is the first cycle.
Set B. S. R. Time “Brine Slow Rinse” time. Set for 60 minutes.
Set Fast Rinse Time Set for 8 minutes.
Set B. R. Time ”Brine Refill” –Pick your Tannin Filter size, enter minutes.
Review Regen. Times review number of times system has regenerated
Start the First Regeneration Before Using
1After programming, the system must be run through a regeneration.
2Start with both bypass valves in the Bypass Position.
3Press the BACK/REGEN button once to enter regneration.
4When the backwash icon is displayed, slowly open the bypass to a quarter position to make
the water flow into the tank and out the backwash drain line to drain.
5After 3 or 4 minutes open bypass valve completely.
6Allow to complete regeneration process, about 90 minutes.
Congratulations, you are done setting up your system!
B.R. Times
0.75 CF
8 MIN.
1.0 CF
10 MIN.
1.5 CF
11 MIN.
2.0 CF
9 MIN.
2.5 CF
11 MIN.
3.0 CF
7 MIN.

7500-REV2.5 Tannin Filter Installation & Startup Guide
12 www.cleanwaterstore.com rev082922
Advanced Programming Mode
The Advanced Programming Mode allows you to set the Regen Cycle and Regen Mode.
Skip this for most applications as your tannin system has already been set to correct modes.
1. Plug the RevV4 in and immediately press in
sequence MENU/CONFIRM, then press
BACK/REGEN button, then press the
DOWN button to enter the Advanced
Programming Mode.
2. Press UP or DOWN buttons or to select the
menu item to be changed
3. Note: If valve locks while programming,
unplug power supply and repeat step
above.
4. Press MENU/CONFIRM to enter the main
menu and adjust settings as desired.
Screen View
Default Settings
Review Company Info
CWS 831‐462‐8500
Set Valve Model
62605
Set Language
English
Set Company Info
CWS 831‐462‐8500
Set Hour Mode
12 HR
Set Time of Day
Current time of day
Set Date
Current date
Set Program Type
Interlock
Set Regen Cycles
No. 1
Set Set Clear Data
Close
Set Regen Mode
A-06
Set Service Days
3
Set Regen Time
2:00 AM
Set Backwash Time
10 Minutes
Set B.S.R. Time
60 Minutes
Set Fast Rinse Time
10 Minutes
Set B.R. Time
Minutes
Signal Output Mode
b‐01
Set Service Alarm
Disabled
Review Regen Times
NA
Review Software Version
Ver. 5.0

7500-REV2.5 Tannin Filter Installation & Startup Guide
13 www.cleanwaterstore.com rev082922
7500-REV2.5 Water Conditioners Limited Warranty
We warrant this water filter when installed according to factory recommendations, to be free from defects in materials
and workmanship as follows:
‐‐‐‐‐‐‐‐‐‐Limited Warranty‐‐‐‐‐‐‐‐‐‐
This water conditioner unit is comprised of the finest industry components available. Each individual component used in the
assembly of our equipment is covered by the original equipment manufacturer’s warranty. All components, except those
specifically listed below, are warranted for a period of one (1) year from date of installation to the original purchaser to be free
of defects in materials and workmanship subject to the manufacturer’s conditions and/or the conditions shown below.
‐‐‐‐‐‐‐‐‐‐Mineral Tanks‐‐‐‐‐‐‐‐‐‐
The fiberglass, polyglass or composite mineral tanks used in the assembly of this unit are warranted to be free of defects in
materials and workmanship for a period of ten (10) years on 6” – 13” size tanks, and five (5) years on 14” and larger size tanks
used for tannin/filtration applications, subject to the manufacture’s conditions and/or the conditions shown below. Warranty
does not cover exposure to weather, freezing, fractures caused by external impact, or exposure to vacuum.
‐‐‐‐‐‐‐‐‐‐Control Valves‐‐‐‐‐‐‐‐‐‐
The CWS control valve is warranted to be free of defects in materials and workmanship for a period or five (5) years.
‐‐‐‐‐‐‐‐‐‐Conditions‐‐‐‐‐‐‐‐‐‐
1. This warranty only covers water conditioners installed for residential use. Water conditioners installed for
commercial or industrial applications are guaranteed for one (1) year from the date of installation.
2. Installation must be made in accordance with legal or local codes and manufacturer’s recommendations.
3. Failure must not result from exposure to weather, rodents, misuse, alteration, fire, lightning, power surges or neglect.
4. Water pressure must not exceed 100 PSI and water temperature must not exceed 100 degrees.
5. Subject to the above terms and conditions we will replace and/or repair, at our option, any parts of the water
conditioner found defective in materials and workmanship. Defective parts must be returned, freight pre‐paid
for repair or replacement.
6. This warranty does not cover labor, shipping charges, damages caused by delays of consequential damages or
other causes beyond our control. Warranty does not cover pipes, fixtures or appliances. Warranty extends to
the actual water conditioner components only.
7. This warranty is to the original purchaser and is not transferable to any subsequent owner(s).
8. No other guarantees or warranty, expressed or implied, is applicable to our product. No repair or replacement
made under the terms of the warranty shall extend this warranty.
9. Any product returned to Clean Water Store without a valid return authorization number will be
rejected. Any product found to be defective will, at the sole discretion of Clean Water Store be
repaired or replaced. Clean Water Store is not responsible for shipping cost to the repair facility.
