Pro-OX 5700-E Iron Filter Installaon
& Start-Up Guide
Thank you for purchasing a Clean Water System! With proper installaon and a lile
roune maintenance your system will be providing iron free water for many years.
Please review this start‐up guide enrely before beginning to install your system, and
follow the steps outlined for best results.
PRO-OX MEDIA CONTAINS DUST.
USE PAPER MASK AND VENTILATE AREA TO AVOID BREATHING DUST DURING
INSTALLATION
Quesons?
Call us toll‐free: 1‐888‐600‐5426 or 1‐831‐462‐8500
Email us: [e-mail]
See more informaon on our website: www.cleanwaterstore.com/resources
Clean Water Made Easy
hp://www.cleanwaterstore.com

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 2 www.cleanwaterstore.com
Rev 090514
Table of Contents
Packing List...................................................................................................................................................3
Pre-Installaon.............................................................................................................................................4
Best Pracces for Piping & Drain Installaon ..............................................................................................4
How Your Iron Filter Works .........................................................................................................................5
Assembly and Installaon Instrucons........................................................................................................8
Programming .................................................................................................................................10
Troubleshoong the Pro-OX 5700-E Iron Filter.........................................................................................12
What To Do If Your Filter Tank Does Not Sit Level On the Floor ...................................................12

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 3 www.cleanwaterstore.com
Rev 090514
Packing List
0.75 Cubic Foot Size System
Quanty (1): CWS 5700-E control valve w/ bypass assembly and pipe connector kit (1” or 3/4”)
Quanty (1): 8” x 44” standard lter tank with distributor tube
Blue media funnel for adding Pro-OX media
12 lbs. lter gravel
0.75 cubic foot of Pro-OX media
1.0 Cubic Foot Size System
Quanty (1): CWS 5700-E control valve w/ bypass assembly and pipe connector kit (1” or 3/4”)
Quanty (1): 10” x 44” (or 9” x 48”) standard lter tank with distributor tube
Blue media funnel for adding Pro-OX media
16 lbs. lter gravel
1.0 cubic foot of Pro-OX media
Carbon Filter 1.5 cubic foot size
Quanty (1): CWS 5700-E control valve w/ bypass assembly and pipe connector kit (1” or 3/4”)
Quanty (1): 10” x 54” standard lter tank with distributor tube
Blue media funnel for adding Pro-OX media
16 lbs. Filter gravel
1.5 cubic foot of Pro-OX media

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 4 www.cleanwaterstore.com
Rev 090514
Pre-Installaon
1. Review your packing list and make sure you have received all the parts before beginning installaon.
2. If you are going to turn o the water to your house and you have an electric water heater, shut o the
power to the water heater before beginning installaon in case the water heater is accidentally
drained.
3. Pick a suitable locaon for your lter system on a dry, level spot where it won’t be exposed to freezing
temperatures. A minimum of 20 PSI is required; maximum pressure is 90 PSI.
4. Get all of your plumbing parts together before beginning installaon. Installaon typically takes 3 to 5
hours, though the Pro-OX 5700-E iron lter must also be allowed to run through a complete backwash
and rinse cycle aer installaon.
5. Your water may be discolored or full of sediment and rust for a day or two aer installing and running
your system, parcularly if you have older or corroded piping.
Best Pracces for Piping & Drain Installaon
1. See typical installaon on page 5 (Fig. 2). The iron lter is installed aer the pressure tank.
2. Make sure to connect to the IN pipe to the CWS 5700-E inlet and the OUT pipe to the outlet (See Fig.
3). If you face the control valve from the front, the water will enter on the right and exit on the le.
From the back, the water enters on the le. The inlet and outlet are aached to the bypass valve,
which is marked with arrows as well.
3. Make sure there is a working gate or ball valve before the iron lter and also one aer as shown in Fig.
2. The pressure gauges are oponal and perhaps not necessary but a hose bib (a faucet to which you
can aach a garden hose) is strongly recommended aer the iron lter and before the second ball
valve. This makes it easy to rinse your new iron lter on start-up and gives you a place to test the wa‐
ter before it enters your household plumbing.
4. If you will be using copper piping, do not sweat the copper pipe directly on to the CWS 5700-E control
valve, and avoid heang the valve’s plasc with your torch.
5. If you have copper pipe before the iron lter and it is too dicult to replace, you may sll experience
some copper staining of xtures and have a copper residual in your water, because the copper pipe
will sll have acidic water owing through it. We recommend PEX or PVC pipe up to the iron lter and
then copper aer it, if you will use copper piping.
6. You do not need unions to install your CWS 5700-E control valve. It has quick-release couplings that
make it easy to put the lter on bypass and remove it from your piping.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 5 www.cleanwaterstore.com
Rev 090514
7. The drain line tubing (not supplied) is connected to a drain from the drain outlet using exible 1/2” ID
tubing. Note that the drain can run up above the CWS 5700-E control valve and into a drain—it does
not have to drain down, as the lter backwashes under line pressure from your well pump. Most
plumbing codes require an air-gap connecon, so that if your sewer or sepc tank backs up, it cannot
cross connect with the drain tubing.
How Your Iron Filter Works
See Fig. 1 below. Water enters your iron lter through the top of the tank and ows down through the
media and up the distributor tube. Downow type lters remove sediment and can be backwashed to
clean and reclassify the media inside, prevenng channeling. During backwash the ow of water is re‐
versed: water ows down the distributor tube and up through the media, liing, expanding, and cleaning
it.
Fig. 1—Iron lter cutaway diagram

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 6 www.cleanwaterstore.com
Rev 090514
Fig. 2—Typical Pro-OX 5700-E iron lter piping installaon with ball valve and hose bib aer lter

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 7 www.cleanwaterstore.com
Rev 090514
Fig 3—CWS 5700-E valve from the rear showing the inlet (le) and outlet (right) end-connector ngs (1”
or 1-1/4” NPT in Noryl plasc). Brass end-connectors are also available for connecng to copper tubing.
Fig 4—CWS 5700-E Bypass Assembly

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 8 www.cleanwaterstore.com
Rev 090514
Assembly and Installaon Instrucons
1. By hand, unscrew the enre CWS 5700-E control valve from top of tank if it was shipped screwed on.
Place distributor tube in tank if not already inside. Make sure the tube is capped, or wrap the top of
the tube with electrical or duct tape. This will prevent gravel and Pro-OX media from entering the dis‐
tributor tube when you add them to your tank.
2. Add the lter gravel that came with your system. You want the gravel to cover the boom distributor
screen before adding the Pro-OX media. Note: Be sure not to let any parts of the bag or other foreign
materials enter the tank when you are adding media.
3. Next add Pro-OX media. The tank should be about 2/3 full of media.
4. Remove cap or tape from distributor tube, being careful not to pull up on the tube.
5. Fill tank with water. Add 2 cups of household bleach into the tank. This bleach will acvate and sani‐
ze the Pro-OX media.
6. Add a small amount of silicone grease or vegetable cooking oil to the tank threads and screw on con‐
trol valve carefully.
7. Note regarding Teon tape and pipe sealants: It is okay to use Teon tape and pipe sealant on the
water pipe connector threads, where you aach your pipes or plumbing to the CWS 5700-E control
valve. DO NOT USE any Teon tapes or pipe joint compound on the tank itself or on the threads where
the CWS 5700-E threads into the tanks. Also note that when installing the CWS 5700-E backwash con‐
trol-mer valve on to the top of the lter tank, do not over-ghten. Tighten by hand; there is no need
for a pipe wrench or other wrench.
9. See how the bypass assembly is connected. Note the pipe connectors in Fig. 5, while the other end is
what gets aached to the control valve. Your CWS 5700-E valve is usually shipped in the bypass posi‐
on.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 9 www.cleanwaterstore.com
Rev 090514
Fig. 5—CWS 5700-E Service and Bypass Knob Posions
10. Lubricate the bypass valve O-rings with some vegetable oil or silicone grease and connect the bypass
assembly to the control valve by sliding the bypass valve rmly into its body.
11. Next, lubricate the end-connectors with some silicone grease or vegetable cooking oil and insert them
into the bypass valve.
12. Make sure both knobs are in the bypass posion.
13. Now install your water pipes to the bypass valve’s end connectors. Make sure the inlet is installed to
the IN pipe connector and the outlet to the OUT connector.
14. Connect some exible tubing from the drain connecon on the CWS 5700-E control valve to a suitable
drain such as a sepc tank or drain to a sewer. It is ok to run the drain line up and over the lter up to
4 feet above the tank. If the drain will be more than 20 feet, use larger diameter tubing such as 3/4” or
1”. Note that is desirable to be able to run the drain line into a bucket in order to test the backwash
ow rate in the future. This is why hard piping the drain line is discouraged. However, you may use
hard PVC piping for the drain line if you are able to remove it and aach exible tubing should you ever
desire for tesng purposes. Make sure the drain line tubing is rmly clamped to the barbed ng with
a hose clamp to prevent leaks.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 10
www.cleanwaterstore.com
Rev 090514
Oponal Side Tank Installaon
Fig. 6: Oponal Side Tank Installaon
15. Insert 3/8” diameter tubing into the chlorine side tank connecon. Screw the nut with the sleeve and
Ferrell aached to prevent leaking.
16. Remove the rubber band and felt polypro pad from the tank and discard. Add 2 cups of non-perfumed
household bleach to the tank, followed by 2 gallons of water. Note that the tank may not be used with
solid chlorine pellets or powder, just liquid bleach.
17. Plug your CWS 5700-E control valve into an outlet. Aer being plugged in, the screen may display
“WAITING PLEASE” while it nds the service posion. By default, the control valve will be set to work
like a water soener, which is obviously not correct for this applicaon, so you’ll need to program the
system to work as an iron lter. There are a few sengs that must be changed before the system can
be put into service for this purpose.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 11
www.cleanwaterstore.com
Rev 090514
Normal Operaon Programming:
Time Mode: Home screen will display days and
hours le unl the unit regenerates.
Meter Mode: Meter mode tracks the number of gallons used instead of regenerang on a
specic me. In this mode immediate regenera‐
on will occur once the unit hits its target calcu‐
lated number of gallons based on hardness
sengs.
Timed Meter Mode: Timed Meter Mode tracks the number gallons used, like the Meter
Mode, but waits unl its set me to regenerate
instead of immediately. A buer period is fac‐
tored in to prevent you from running out of
so water. The water droplet to the right of
Current Time signies the unit tracking water
ow.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 12
www.cleanwaterstore.com
Rev 090514
Meter & Timed Meter Menus:
The following menus will allow you to change the current me, unit hardness, and calendar
day override sengs within the Meter and Timed Meter Modes.
Current Time sengs: Press the gear to
begin menus. Current me and period of
the day will be ashing.
Aer pressing the Regen buon, only
the hour poron will be ashing.
Use the up and down arrows to adjust
the me. Press the gear again to switch
to the minute poron. Note, once the
mer passes a 12 hour period it will au‐
tomacally change A.M. to P.M.
Unit Hardness sengs: Hard-25 will be
ashing.
Pressing the Regen buon will allow
changes to hardness to be made. The unit
has a range of 1-99 grains per gallon.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 13
www.cleanwaterstore.com
Rev 090514
Meter and Time Meter Menus connued..
Calendar Day Override seng: Allows user
to set a me to regenerate by if the unit
hasn’t met its set meter amount within
that me period.
Pressing the Regen buon allows you to
change the days. Default seng is 0 days,
but can range from 0-99 days.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 14
www.cleanwaterstore.com
Rev 090514
Time Menus
The following menus will let you change the Current Time and the Regeneraon Day for
Time Mode only.
Current Time sengs: Press gear to begin
menus. Current me and period of the
day will be ashing.
Aer pressing the Regen buon, only the
hour poron will be ashing.
Use the up and down arrows to adjust
the me. Press the gear again to switch
to the minute poron. Note, once the
mer passes a 12 hour period it will auto‐
macally change A.M. to P.M.
Pressing the gear again brings you to
the Regeneraon day seng.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 15
www.cleanwaterstore.com
Rev 090514
Time Menus Connued..
Using the up and down arrows, you
can set the number of days you wish
to have between regeneraons. The
unit has a range of 1-99 days. Default
seng is 7 days.
Advanced Menus
Within the Advance Menus the Regeneraon Mode, Regeneraon Cycle Period Lengths,
and Unit Capacity are adjustable.
To enter, press both the Gear
and Regen buon at the same
me. All mode types will be
ashing.
Press the Regen buon again to
select the mode type you wish
to be in. Use the up and down
arrow to scroll through the
modes.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 16
www.cleanwaterstore.com
Rev 090514
Advanced Menus Connued..
Aer selecng the mode, the me of day
the unit is set to regenerate will appear.
Pressing the Regen buon will allow the
me to be changed. Use the up and down
arrows to adjust the hours and A.M. and
P.M. sengs.
Pressing the gear again will bring you to
phase 1, Backwash. BW will be present
and P1-10 will be ashing.
Total minutes spent in backwash will be
ashing. The unit can be programmed for
0-99 minutes. Generally, the recommend‐
ed seng is for 10 minutes.
Next menu displays brine draw sengs. BD
will be present and P2-60 will be ashing.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 17
www.cleanwaterstore.com
Rev 090514
Advanced Menus Connued..
Total minutes the unit draws brine will be
ashing. Unit can be set anywhere from 0-99
minutes. If you don’t have the oponal side
tank, set to 0
This menu displays Rapid Rinse sengs.
RR will be present and P3-12 will be
ashing. If you don’t have the oponal
side tank, set to 0
Total minutes the unit rinses will be
ashing. Unit can be set anywhere from
0-99 minutes. Generally, the recom‐
mended seng is for 6 minutes.
This menu displays Brine Rell sengs.
BF will be present and P4-10 will be
ashing.
Total minutes the unit lls the brine tank
for will be ashing. Unit can be set any‐
where form 0-99 minutes. If you don’t
have the oponal side tank, set to 0

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 18
www.cleanwaterstore.com
Rev 090514
Advanced Menus Connued..
This last menu is to change the unit’s
capacity.
Unit has a range of 1-199 Capacity (for
Meter and Timed Meter Modes only).
Mulply capacity seng by 1000 to get
grains.
Example: A seng of 064 is equal to
64,000 grain capacity.
*Gallons = (Capacity/Hardness) x .75 (Timed Meter Mode only)
*Gallons = (Capacity/Hardness) (Meter Mode only)
Immediate Regeneraon
While in service posion, hold the Regen buon in for 5-6 second to iniate an immediate
regeneraon.
Pressing the Regen buon again will jump to the next cycle
phase. Holding the two arrow buons together will termi‐
nate Immediate Regeneraon and return the unit to service
posion.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 19
www.cleanwaterstore.com
Rev 090514
Restore Factory Sengs
Hold the Regen buon while plugging in the power supply to the unit. Aer the unit has
powered up release Regen buon.
Next press the Regen buon again to
select no next to reset.
Using the down arrow, scroll to yes.
Hing the Gear will begin reseng
the unit.
Power Outage Memory.
During a loss of power, all program sengs will be stored in permanent memory. The cur‐
rent valve posion, cycle step and me of day are all stored as well, but upon power up a
reset of the current me will be necessary.
If the unit were to lose power during a regeneraon stage, the valve will return back to its
prior posion when the outage occurred. The unit will take 4 -5 minutes to reset back to
that posion.

Pro-OX 5700-E Iron Filter Installaon & Startup Guide
Page 20
www.cleanwaterstore.com
Rev 090514
Troubleshoong the Pro-Ox 5700-E0 Iron Filter
Measure the backwash ow rate by pung the system into a backwash mode and pung the drain tube
into a 5 gallon bucket and ming the ow rate. A 0.75 cubic foot system should ow at 5 gallons in one
minute, so the 5 gallon bucket should ll in one minute. The 1.0 cubic foot system should ow at 7 GPM
during backwash.
In some cases, the CWS 5700-E valve has simply been programmed incorrectly. Double-check your
sengs against those described above or consult your system’s service manual for instrucons. In some
cases a nightly backwash is required for best results. Adjust backwash frequency to every 1 to 2 nights if
necessary.
What To Do If Your Filter Tank Does Not Sit Level On the Floor
Your black lter tank base is not glued to the boom of your tank. Occasionally tank bases will become
crooked during shipment. If you nd that that your tank does not sit level on the oor, you can easily ad‐
just it by holding the empty tank and rapping it on a concrete or solid oor once or twice in order to level
it.
