Cleantecs LR-180-GTR User manual

LR-180-GTR
Splash guard
enLR-180-GTR Splash guard
Operating instructions
YM 2019
LR-180-GTR
BA 0305235 R00 2022-12
Translation of operating instructions for
the LR-180-GTR splash guard

2BA 0305235 R00 2022-12
Basics 5
Safety information 6
Explanatory information 7
Overview of the components and scope of delivery of the
LR-180-GTR slat cleaner splash guard 8
How does the LR-180-GTR splash guard work? 10
Components and their function 11
Intended use 13
Improper and prohibited use 13
Requirements of the system user 13
Space requirements 13
Weight 13
Documentary evidence 14
Safety principles 15
For your safety 16
Working safely 18
Working safely 19
Safe fitting, removal and maintenance 19
Fitting + removal 20
Preparation for fitting 21
Unpacking and inspecting new products 21
Check before fitting 21
Fitting the splash guard 22
Setting the LR-180-GTR down 22
Removing the handle from the LR-180-GTR 22
Contents

3
BA 0305235 R00 2022-12
Fitting the splash guard 23
Fitting the handle on the LR-180-GTR 24
Removing the splash guard 25
Maintenance 26
Changing the brush strip 27
Pulling off the brush strip 27
Maintenance + storage 28
Cleaning and storing the LR-180-GTR splash guard 29
How do I clean the LR-180-GTR splash guard? 29
How do I maintain the bristles? 29
Preserving the splash guard 29
Storing the splash guard 29
Disposal 30
What happens to the waste? 31
Packaging 31
Splash guard plate 31
Brush 31
Contents

4BA 0305235 R00 2022-12
It is IMPORTANT that you read these operating
instructions CAREFULLY BEFORE USE and
RETAIN THEM FOR FUTURE REFERENCE.
Visit our homepage at regular intervals to check for a
more recent version of the operating instructions.
The operating instructions are for...
the LR-180-GTR splash guard, year of manufacture
2019. The revision level of the operating instructions is
R00.

5
BA 0305235 R00 2022-12
Basics
Components and functions of the
LR-180-GTR splash guard
Here you will find information about the components of
the system and the tool for maintenance.

6BA 0305235 R00 2022-12
Explanation of notices
Basics
Note: …
Failure to comply will result in death or serious
injury.
Failure to comply may result in death or serious
injury.
Failure to comply may lead to injuries.
Failure to comply may lead to material damage and
impair the function of the product.
Additional information about product operation.
Safety information
The information is for your safety. The information can be found in the general safe-
ty section and is always accompanied by an action that requires specific attention.
DANGER
Danger to life in severe weather conditions
A Never work during a storm.
This prevents the risk of being struck by lightning.
Risk of injury from falling
A Use a fall-arrest system.
This will protect you from injuries from falling off the roof.
WARNING
Illness and hypothermia caused by bad weather
A In bad weather, wear suitable protective clothing.
This will protect you from illness caused by hypothermia.
CAUTION
Risk of damage due to frost
A Prevent the machine from freezing up. Otherwise this could
cause damage to the components.
This will protect the machine from frost damage.
NOTICE

7
BA 0305235 R00 2022-12
Basics
The title of the image indicates the
text to which the figure belongs.
The detailed view highlights areas that
are important.
The numbers on the figures refer to
the steps in the explanatory text. They
always start again from [1] on each
double page.
The red arrows always indicate a move-
ment.
Image title
[1]
Explanatory information
You will find this information in the illustration area with a grey background. It helps
you to find the right diagram for the heading in the text, understand the details bet-
ter, follow steps, understand movements and identify the position.

8BA 0305235 R00 2022-12
Overview of the components and scope of delivery of the
LR-180-GTR slat cleaner splash guard
Basics

9
BA 0305235 R00 2022-12
Basics
1Splash guard, complete
2Brush

10 BA 0305235 R00 2022-12
Basics
How does the LR-180-GTR
splash guard work?
The LR-180-GTR slat cleaner splash
guard consists of a splash guard plate
and two brushes.
The splash guard plate forms the basis
of the splash guard. It is fitted on the
slat cleaner and holds the brushes.
The brushes catch the water that is
thrown out by the rotating brush rollers
of the LR-180-GTR. This keeps the
operator and the immediate working
environment dry.

11
BA 0305235 R00 2022-12
Components and their function
Splash guard plate: The base of the
LR-180-GTR splash guard and thus the
connection between the LR-180-GTR
and the brushes.
Brush: The brush catches the water
splashed out by the rotation of the
brush rollers of the LR-180-GTR.
Splash guard plate
Brush
Basics

12 BA 0305235 R00 2022-12
Basics
Intended use
Here you will find the following information:
For what purposes can the LR-180-GTR splash guard
be used? Where can the LR-180-GTR splash guard
be used? Who is allowed to use the LR-180-GTR
splash guard?

13
BA 0305235 R00 2022-12
Intended use
The splash guard is intended for use on
the LR-180-GTR only.
Using the splash guard, especially the
brush, for any other purpose is not
permitted.
Improper and prohibited use
The LR-180-GTR splash guard must not
be modified.
Requirements of the system user
The LR-180-GTR splash guard is for
commercial use.
User: The user must have been given
adequate and appropriate instruction
from the plant operator about the rele-
vant tasks and possible dangers in the
event of improper behaviour. Tasks that
go beyond the scope of the product’s
normal operation may only be carried
out by the user if they are specified in
these instructions and the plant opera-
tor has expressly entrusted the user to
complete them.
Specialist staff: Due to their profession-
al training, expertise, experience and
knowledge of the relevant standards
and regulations, specialist staff are able
to carry out the work assigned to them
and to recognise possible dangers and
avoid hazards themselves.
The following groups of people are not
allowed to operate the LR-180-GTR
splash guard:
�Persons with restricted
physical, sensory or
mental capacity
�Children and young people under
the age of 18
�People who have not received
instruction
Space requirements
�Space required for fitting:
L 1,000 mm x W 1,000 mm
Weight
�Weight of the splash guard: 0.25 kg
Basics

14 BA 0305235 R00 2022-12
Basics
Documentary evidence
/Volumes/DATEN BUSS/30 TECHNISCHE DOKUMENTATION/20 Technische Dokumentation CE -
Cleantecs/1_KONFORMITÄTSERKLÄRUNG/Nachweisdokumentation nach EN ISO 12100/Spritzschutz LR-180-GTR-nw_2022-07-06.docx
Seite 1 von 22 28.02.23
Projekt: Spritzschutz LR-180-GTR
Produkt: 0200918
Hersteller:
Verantw.: Anton Jäger
Cleantecs GmbH
Grundweg 10
89250 Senden
Tel: [phone]
Fax: [phone]
Nachweisdokumentation nach
EN ISO 12100
für
Spritzschutz LR-180-GTR

15
BA 0305235 R00 2022-12
Safety principles
General safety
instructions
Important instructions for safe use of the
system and for ensuring safe cleaning.

16 BA 0305235 R00 2022-12
Safety principles
For your safety
Important instructions for safe use of the system. These instructions enable you to
protect yourself and others from dangerous situations and injuries.
Risk of injury during installation
A Wear gloves during installation.
This will protect your skin from abrasions and pinching.
CAUTION
Risk of injury due to slippery surface
A Check the surface for any situations that may facilitate slipping.
This will protect you from falling and injuring yourself.
CAUTION
CAUTION
Risk of injury from inadvertent start-up
A Always disconnect the sunblind cleaner from the pressure
washer before performing maintenance work.
This prevents harm to persons or property caused by inadvertent
start-up of the system.
WARNING
Report malfunction
A Report malfunctions to your supervisor immediately.
This will prevent injuries or damage.
Risk of injury during disassembly
AWear gloves during disassembly.
This will protect your skin from abrasions and pinching.
CAUTION

17
BA 0305235 R00 2022-12
CAUTION
Illness from lowering of body temperature
A Be sure to wear water-repellent clothing.
This protects you against illness caused by lowering of the body
temperature.
Illness and hypothermia caused by bad weather
A In bad weather, wear suitable protective clothing.
This will protect you from illness caused by hypothermia.
CAUTION
Risk of injury from flying dirt and parts
A Wear safety goggles when working.
This will protect you from injuries caused by ying dirt and loose
parts.
CAUTION
Risk of injury from overloading/strain
A Take regular breaks.
This will prevent injuries caused by physical and mental overload
and fatigue.
CAUTION
Safety principles

18 BA 0305235 R00 2022-12
Safe operation
Here you will find information about: choosing a safe
cleaning location, sources of danger in the working
area, sources of danger when working.
Working safely

19
BA 0305235 R00 2022-12
Working safely
Working safely with the LR-180-GTR
splash guard is described here.
Safe fitting, removal and mainte-
nance
�Always find a level location for fitting
or maintaining the LR-180-GTR splash
guard.
�Switch off the high-pressure clean-
er when working on the LR-180-GTR
splash guard.
�Disconnect the LR-180-GTR from the
high-pressure hose.
Working safely
Risk of injury due to falling
ACheck your working area for
unevenness and obstacles.
This will protect you from injuries
resulting from a fall.
CAUTION
Risk of injury from inadvertent start-up
AAlways disconnect the sunblind cleaner
from the pressure washer before
performing maintenance work.
This prevents harm to persons or property
caused by inadvertent start-up of the
system.
VORSICHT

20 BA 0305235 R00 2022-12
Fitting + removal
Fitting and removal of the LR-
180-GTR splash guard
Here you will find information about preparing the
LR-180-GTR splash guard for work.
