Clearlight Designs Halo User manual
by
Installation Guide
Illuminated Mirror
Halo
Clearlight Designs®
Clearlight Designs Pty Ltd
Superior Quality Lighted Mirror - Made in Australia
www.clearlightdesigns.com.au
T 02 9905 9570 M 0417 621 127
3/12 Ethel Ave Brookvale, NSW 2100 Australia
Electrical installation
A light switch to operate the mirror should be installed on the wall
or other convenient location, by a licensed electrician.
If a demister is tted to the mirror you will need two cables through
the wall. The Demister and LEDs can be operated by the same switch
or separate switches.
Smaller mirrors (less than about one square metre) with the
low-prole the drivers can be adhered to the back of the mirror
glass. Adhesive tape is supplied on the back of each driver. in this
case the cable through the wall would carry 240 volts
OR place the driver remotely and install as per Larger Mirrors below
Larger mirrors - The Drivers for both the LEDs and Demister are
best place remotely - i.e. in ceiling or vanity cupboard. This is
because of the diculty in safely removing the large heavy mirrors
to swap out the driver if it fails. In this case the cable through the
wall would carry 24v DC or 12v DC.
Installation Instructions
STEP 1 -
Fitting the mounting structure to the wall:
The mounting structure is to be installed using appropriate wall plugs or expanding wall anchors.
If the mounting structure lines up with a wall stud even better, just drill another hole/s in the White MDF and screw through into the wall
stud.
Do not drill through the split battens as this may result in bending them out of alignment when screwed to the wall.
Large mirrors (around 2 square metres) will have additional holes in the mounting structure for extra load bearing screws.
As a guide, the mirrors weigh approximately 20kg per square metre.
Start by plotting the planned position of the mirror on the wall:
• Mark the top centre and top corners of where the mirror will be on the wall.
• Mark out the position of the hole for the first mounting screw (#1) - 120mm down from the top centre point.
• Drill the first hole in the wall at that position
• Fit wall plug or expanding wall anchor. Then screw the mounting structure to the wall through screw hole #1.
• Adjust to level by pivoting on the screw.
• When level, using the mounting structure as a template, mark out or drill pilot holes into the wall through the holes in the
Clearlight Designs Pty Ltd
Superior Quality Lighted Mirror - Made in Australia
www.clearlightdesigns.com.au
T 02 9905 9570 M 0417 621 127
3/12 Ethel Ave Brookvale, NSW 2100 Australia
Failure to follow installationinstructions could result in
serious injury, or damage toproperty.
Failure to follow installationinstructions will void warranty.
Please readthese instructions carefully before installation to make
sure you have all you need, and to understand what you will be
doing during all phases of the handling, installation, removal,
operation and maintenance of this product. Failure to comply with
these precautions violates safetystandards of design, manufacture
and intended use of the product.
ClearlightDesignsassumes no liabilityforcustomer’s failure to
comply with these requirements.
Installation must only be carried out by a licensed electricianor
builder according to local authority regulations.
Allelectrical works must onlybe undertaken after disconnection of
pole isolation of the electrical supply.
Do not remove protective lm or plastic corners until mirror is installed Move mirrors SLOWLY. Plan what you are doing.
Handling Tips
• Always place the mirror on a soft surface e.g. carpet or folded towels.
The edge of the mirror will almost certainly chip if placed on a stone or tiles or hard surface.
• Mirrors are heavy and fragile. Always lift the larger mirrors with two people to share the load.
Before tting the mounting structure to the wall or wiring for power connection:
You will need to know the location of:
• the wall studs • water pipes • electrical cables
Consult your plans and have a licensed electrician install electrical requirements for your mirror in accordance with this installation guide.
split batten
split batten
split batten
split batten
Back view of Mirror Glass
Front view of Mounting Structure
These may appear slightly dierent
depending on size of mirror.
120mm to rst screw
top left corner of mirror top right corner of mirror
C
X
X
low voltage Power leads
from remote driver/s
through hole in wall
Holes for
mounting screws
Low coltage DC
Power lead
attached to LEDs
#1
Corner protectors
DO NOT remove until installation is nished
You need at least two people for this next procedure.
• If there is no vanity cupboard in front of the mounting structure use a table or similar. Make sure you have folded towels or
similar padding in place to rest the mirror on. Lift the mirror into a vertical position in front of the mounting structure allowing
enough room at one side to reach in and join the cables.
• Have someone hold the mirror vertically in place while you take the low voltage DC cable (protruding from the wall) from the LED
driver and connect it to the cable, (from the LEDs on the mirror), using insulated cable joiners.
• The same procedure applies to low voltage DC cable for demister/s if fitted to mirror.
• Make sure the wires will not interfere with the split battens when the mirror is lifted into position. Excess cables can be taped
out of the way on the mounting structure or,l preferably, inserted into the wall cavity.
Clearlight Designs Pty Ltd
Superior Quality Lighted Mirror - Made in Australia
www.clearlightdesigns.com.au
T 02 9905 9570 M 0417 621 127
3/12 Ethel Ave Brookvale, NSW 2100 Australia
L
o
w
v
o
l
t
a
g
e
D
C
t
o
D
e
m
i
s
t
e
r
/
s
STEP 2 -
Connecting the mirror lights to power
split batten
split batten
Front view of Mounting Structure
These may appear slightly dierent
depending on size
120mm to rst screw
top left corner of mirror top right corner of mirror
C
X
X
Holes for
mounting screws
#1
Connect 240volt from wall
into LED driver
If Demister is tted
Connect 240volt from wall
into Demister Driver
split batten
split batten
Back view of Mirror Glass
FOR INTERNAL DRIVER
FOR REMOTELY SITUATED DRIVER
Corner protectors
DO NOT remove until installation is nished
LED driver
DEMISTER driver
240v Power
to driver
Care and Cleaning
On the edge of every the mirror there is a thin line of silver that is exposed to the air. Silver will tarnish eventually and the tarnish may
spread under the paint. The mirrors we use employ the latest and best paint technology to prevent this. In order to protect your mirror even
more we apply an edge sealer. Cleaning the edge of the mirror with commercial cleaners is
unnecessary and may eventually damage that edge seal. To clean the mirror edge all you need is a quick wipe down with a soft cloth
dampened with distilled water.
DO NOT USE CLEANERS ON THE EDGE OR BACK OF THE MIRROR. Even air born chemicals e.g. toilet flush chemicals, may tarnish your mirror,
When cleaning a mirror simply wipe the glass surface with a few drops of methylated spirits or Isopropyl Alcohol on a clean slightly damp
cotton cloth. We have found the Isopropyl Alcohol is the best for cleaning mirrors.
Do not use cleaners containing Ammonia, or bleach, this will void warranty
Some paper towels may leave a smear.
Clearlight Designs Pty Ltd
Superior Quality Lighted Mirror - Made in Australia
www.clearlightdesigns.com.au
T 02 9905 9570 M 0417 621 127
3/12 Ethel Ave Brookvale, NSW 2100 Australia
Low voltage DC Driver
Internal side-view of how the Split battens install works...
... and what can go wrong
Mirror Wall
123
Split
Battens
Trouble shooting
If the lights in the mirror malfunction it is most probably the driver. The driver in question can beswapped out with another
driver to resolve the issue or you can contactClearlight Designs byphone or email.
If there is any other problem with the mirror,or with the LEDs that can not be resolved by swapping out the driver/s contact
Clearlight Designs by email - info@clearlightdesigns.com.au or mobile - 0417 621 127,or through the website
www.clearlightdesigns.com.au
Uninstalling the mirror is simply a reversal of the installation proceedure outlined earlier.
It is possible your mirror may end up
100mm higher than you planned
STEP 3 - Hanging the mirror on the split battens
• NOTE : First note the position on the wall where the top centre of the mirror needs to be. When the mirror is level and
lifted 20mm to 25mmm above the top centre mark on the wall the split battens on the mirror will be high enough to engage
the coresponding split battens on the mounting structure. Do not lift it higher than this. Randomly moving the mirror around on the wall
trying to feel out the split battens will cause damage to the mirror from the split battens.
With the bigger mirrors you will need 2 people two people to lift the mirror.
• When in this position, the mirror can be pressed at on the wall and allowed to slide down into position to engage the split battens.
NOTE It is possible to engage only the top or bottom batten, so at this point do not release the mirror until you are sure both split
battens are engaged and the mirror is sitting at against the wall. If you need to adjust the mirror sideways just lift slightly so
the split battens release their grip and the mirror will be easier to slide.
When you are happy with the position push rmly down on the mirror so the split batten grip into position.
Remove protective plastic corners and remove the plastic lm from the front of the mirror, starting at the top and slowly peel down.
35
280 - 320mm
17mm
