ClearSpan 500 Cold Frame Series User manual

1
Revision date: 08.08.14
©2014 ClearSpan™
All Rights Reserved. Reproduction
is prohibited without permission.
Series 500 Cold Frame
42' Wide
42' Wide Series 500 Cold Frame:
All Standard Lengths.

2Revision date: 08.08.14
Important Information
READ THIS DOCUMENT BEFORE YOU
BEGIN TO ASSEMBLY
Thank you for purchasing a Series 500 cold frame.
When properly assembled and maintained, this product
will provide years of reliable service. These instructions
include helpful hints and important information needed
to safely assemble and properly maintain the structure.
Please read these instructions before you begin.
If you have any questions during the assembly, please
contact customer service for assistance.
SAFETY PRECAUTIONS
• Wear eye protection.
• Wear head protection.
• Wear gloves when handling metal parts.
• Use a portable GFCI (Ground Fault Circuit Interrupter)
when working with power tools and cords.
• Do not climb on the frame during or after construction.
• Do not occupy the structure during high winds,
tornadoes, or hurricanes.
• Provide adequate ventilation if the structure is
enclosed.
• Do not store hazardous materials in the structure.
• Provide proper ingress and egress to prevent
entrapment.
LOCATION
Choosing the proper location is an important step before
you begin.
The following suggestions and precautions will help
determine whether your selected location is the best
location.
• Never erect the structure under power lines.
• Identify whether underground cables and pipes are
present before preparing the site, setting ground
posts (if equipped), or anchoring the structure.
• Location should be away from structures that could
cause snow to drift on or around the building.
• Do not position the structure where large loads
such as snow and ice, large tree branches, or other
overhead obstacles could fall.
• Always check local building codes before you begin
and follow codes as instructed.
SITE
After choosing a location, proper preparation of the site is
essential. Follow the information below.
• A level site is required. The site must be level to
properly and safely erect and anchor the structure.
• Drainage: Water draining off the structure and from
areas surrounding the site should drain away from
the site to prevent damage to the site, structure, and
contents of the structure.
WARNING: The individuals assembling this structure
are responsible for designing and furnishing all
temporary bracing, shoring and support needed
during assembly. For safety reasons, those who are
not familiar with recognized construction methods
and techniques must seek the help of a qualified
contractor.
SETTING THE GROUND POSTS
The frame assembly of this building requires the
setting of all ground post in concrete. Review the
layout diagrams for additional details.
Enlist the services of a professional and competent
contractor to prepare the site and set the ground posts.
Failing to secure ground posts in concrete as required
may result in damage to the building, building contents,
and surrounding property.

3
Revision date: 08.08.14
ASSEMBLY
Following the instructions as presented will help ensure
proper assembly. Failing to follow these steps may result
in an improperly assembled and anchored structure.
The steps outlining the basic frame assembly are as
follows:
1. Verify that all parts are included in the shipment.
Notify Customer Service for questions or concerns.
2. Read this guide and all additional documentation
included with the shipment before you begin.
3. Gather the tools, bracing, ladders, lifts, and
assistants needed to assemble the structure.
4. Check the weather before you install the roof cover
and any end panels (if equipped). Do not install
covers or panels on a windy or stormy day.
5. Re-evaluate the location and site based on the
information and precautions presented in the
documentation included with the shipment.
6. Prepare the site (if applicable) and set the ground
posts in concrete.
7. Assemble rafter components and rafter support kit
components (if equipped). Optional support kits
require an additional purchase.
8. Assemble main building frame (rafters, cabling,
purlins, etc).
9. Attach customer-supplied baseboards if used.
10. Install main cover if purchased.
11. Complete and return all warranty information as
instructed if present.
REQUIRED TOOLS
The following list identifies the main tools needed to
assemble the shelter. Additional tools and supports may
be needed depending on the structure, location, and
application.
• Tape measure or measuring device and marker to
mark locations on the pipes and rafters.
• Variable speed drills and impact drivers. (Cordless
with extra batteries works best.)
• Metal-cutting saws or tools to cut pipe and
aluminum.
• Wrenches and impact socket set, hammer, and
gloves.
• Adjustable pliers and self-locking pliers.
• Ladders, work platforms, and other machinery for
lifting designed to work safely at height of building.
• Safety equipment to protect head, eyes, hands and
feet.
UNPACK AND IDENTIFY PARTS
The following steps will ensure that you have all the
necessary parts before you begin to assemble the
shelter frame.
1. Unpack the contents of the shipment and place
where you can easily inventory the parts. Refer to
the Bill of Materials/Spec Sheets.
2. Verify that all parts listed on the Bill of Materials/
Spec Sheets are present. If anything is missing
or you have questions, consult the Pictorial Parts
Guide and all diagrams for clarification, or contact
Customer Service.
NOTE: Do not open plastic bags containing smaller
parts such as fasteners or washers at this time.
Simply verify quantity.
Important Information

4Revision date: 08.08.14
104189 Turnbuckle
Parts Identication
The following graphics will help identify the basic
parts of the frame. (Some parts are not shown.)
*107795
Box Bolt
*IMPORTANT: The installation of the blind
connection bolts cannot be reversed. Follow
the instructions when installing these fasteners.
103856
Band Clamp
FA4482B
Tek Screw
100441 Magnetic
Nut Setter
102546 Cross
Connector
QH1070
Pipe Strap
AS2167 Anchor
Shackle
AS1004
Clamp
AS1084
3/16" Cable Thimble
SHELTER CARE AND MAINTENANCE
Proper care and maintenance of the shelter is important.
Check the following items periodically to properly maintain
the shelter:
• Regularly check the cover (if purchased) to ensure
that it remains tight and in proper repair.
• Replace all damaged or broken components
immediately.
• Check connections and all fasteners to verify that they
remain tight and in good condition.
• Do not climb or stand on the building at anytime.
• Inspect the anchoring system to verify that all
components remain tight and in good condition.
• Remove debris and objects that accumulate on the
building. Use tools that will not damage the cover (if
equipped) when removing debris.
• Remove snow to prevent excess accumulation. Use
tools that will not damage the cover when removing
snow. Keep heated during non-growing season to
prevent snow and ice buildup.
• Check the contents of the shelter to verify that nothing
is touching the cover that could cause damage.
• If the shelter is dismantled and moved, inspect all
parts and connections before using.
• For replacement or missing parts, call 1-800-245-9881
for assistance.
FALB08B
1/2" Nut
105370B
1/2" x 4-1/2" Hex Bolt
108503
Bracket

5
Revision date: 08.08.14
Overview
Drawing may show a model of a different length. Refer to
Quick Start section located near the back of this guide for
on-center measurements and post layout.
OVERVIEW
This section describes assembling your building frame.
See illustration below to identify main parts.
1. Prepare site and set the ground posts in concrete.
2. Locate the required parts for each assembly
procedure.
3. Assemble the rafters and main frame.
Finished Grade
End Rafter
Interior Rafter
Ridge Purlin
Cable
Ground
Post
On-Center
Rafter Spacing
Side
Purlin
Ridge
Purlin
ClearSpan™
Series 500 Cold Frame
