Cleco 55 Series Installation and operating instructions

Operation & Service Manual
823028
12/02/2013
55 Series
Pistol Grip Reaction Bar Nutrunner
55 X N X XX - x - x
Series
55
Rotation
- = Non Reversible
R = Reversible
Tool Type
N = Nutrunner
Clutch Designation
- = Stall Type
A = Clecomatic Clutch
Handle Type
P = Trigger (Stall)
PT = Trigger (Clecomatic)
Gearing Designation
2
3
4
6
Output Drive
3 = 3/8" Square Drive
4 = 1/2" Square Drive
For additional product information visit our website at http://www.apextoolgroup.com

2
For your safety and the safety of others, read and understand the
safety recommendations and operating instructions before operat-
ing a nutrunner.
Always wear protective equipment:
For additional information on eye protection and face protection,
refer to Federal OSHA Regulations, 29 Code of Federal Regula-
tions, Section 1910.133., Eye and Face Protection, and American
NationalStandardsInstitute,ANSIZ87.1,OccupationalandEduca-
tional Eye and Face Protection. Z87.1 is available from the Ameri-
can National Standards Institute, Inc., 11 West 42nd Street, New
York, NY 10036.
Hearing protection is recommended in high noise areas 85 dBA or
greater. The operation of other tools and equipment in the area,
reflective surfaces, process noises and resonant structures can
substantially contribute to, and increase the noise level in the area.
Excessiveairpressure90PSIGorwornmotorcomponentscanalso
increase sound level emitted by tool. For additional information on
hearing protection, refer to Federal Regulations, Section 1910.95,
Occupational Noise Exposure, and American National Standards
Institute, ANSI S12.6, Hearing Protectors.
Cleco nutrunners are designed to operate on 90 psig (6.2 bar)
maximum air pressure. If the tool is properly sized and applied,
higher air pressure is unnecessary. Excessive air pressure in-
creases the loads and stresses on the tool parts, sockets, and
fasteners and may result in breakage. Installation of a filter-regula-
tor-lubricator in the air supply line ahead of the tool is recom-
mended.
Before the tool is connected to the air supply, check the throttle for
proper operation (i.e., throttle moves freely and returns to closed
position). Clear the air hose of accumulated dust and moisture. Be
careful not to endanger adjacent personnel. Before removing a tool
from service or changing sockets, make sure the air line is shut off
and drained of air. This will prevent the tool from operating if the
throttle is accidently engaged.
Itis essentialfor safeoperation thatany operatorof anutrunner use
good balance, sure footing, and proper posture in anticipation of a
torque reaction. Insure that the operator's hand will not be wedged
or pinched between the work and the tool when operating.
Reaction bar nutrunners are equipped with a torque reaction bar.
These bars can be braced against the work or other suitable points
toabsorband relievethe operator ofthe torquereactiontransmitted
Safety Recommendations
WARNING!
Impact resistant eye protection
must be worn while operating
or working near this tool.
CAUTION!
Personal hearing protection is
recommended when operating
or working near this tool.
by the tool. Tool balance arms are also available to absorb the
torque reaction of the tool while balancing the weight of the tool for
improved ergonomic applications.
If the tool is to be reversed, locate torque reaction bar in a position
that will resist torque reaction and prevent entrapment. See Direc-
tions on next page.
Tools with clutches can stall rather than shut-off if adjusted over
maximum power output of tool, or if there is a drop in air pressure.
Reaction bar must be properly positioned to resist torque. Operator
must release throttle to stop tool if this occurs. Do not use without
properly positioned reaction bar.
Reversible tools can have torque reactions in either direction. The
reaction bar must be properly positioned to resist the torque reac-
tion.
Some individuals may be susceptible to disorders of the hands and
arms when performing tasks consisting of highly repetitive motions
and/or exposure to extended vibration. Cumulative trauma disor-
ders such as carpal tunnel syndrome and tendonitis can be caused
or aggravated by repetitious, forceful exertions of the hands and
arms. Vibration may contribute to a condition called Raynaud's
Syndrome. These disorders develop gradually over periods of
weeks, months, and years. It is presently unknown to what extent
exposure to vibrations or repetitive motions may contribute to the
disorders. Hereditary factors, vasculatory or circulatory problems,
exposure to cold and dampness, diet, smoking and work practices
are thought to contribute to the conditions.
Anytooloperatorshouldbeawareofthefollowingwarningsignsand
symptoms so that a problem can be addressed before it becomes
a debilitating injury. Any user suffering prolonged symptoms of
tingling, numbness, blanching of fingers, clumsiness or weakened
grip, nocturnal pain in the hand, or any other disorder of the
shoulders, arms, wrists, or fingers is advised to consult a physician.
If it is determined that the symptoms are job related or aggravated
by movements and postures dictated by the job design, it may be
necessary for the employer to take steps to prevent further occur-
rences.Thesesteps mightinclude, butare not limitedto, reposition-
ing the workpiece or redesigning the workstation, reassigning
workers to other jobs, rotating jobs, changing work pace, and/or
changing the type of tool used so as to minimize stress on the
operator. Some tasks may require more than one type of tool to
obtain the optimum operator/tool/task relationship.
CAUTION!
Repetitive work motions and/or vibration
may cause injury to hands and arms.
Use minimum hand grip force consistent
with proper control and safe operation.
Keep body and hands warm and dry.
Avoid anything that inhibits blood circulation.
Avoid continuous vibration exposure.
Keep wrists straight.
WARNING
!
Avoid repeated bending of wrists and hands.

3
Safety Recommendations
OVERLOADED REACTION BARS
MAYBENDORBREAK!USETHIS
GUIDE FOR PROPER APPLICA-
TION OF THE CLECO REACTION
BAR.
The reaction bar is secured to the tool and braced
against the work in the opposite direction of spindle
rotation. This will transfer the torque reaction from the
tool to the work.
The following suggestions will help reduce or moderate the effects
of repetitive work motions and/or extended vibration exposure:
• Use a minimum hand grip force consistent with proper
control and safe operation
• Keep body and hands warm and dry (cold weather is
reported to be a major factor contributing to Raynaud's
Syndrome)
• Avoid anything that inhibits blood circulation
—Smoking Tobacco (another contributing factor)
—Cold Temperatures
—Certain Drugs
• Tasks should be performed in such a manner that the
wrists are maintained in a neutral position, which is
not flexed, hyperextended, or turned side to side.
• Stressful postures should be avoided — select a tool
appropriate for the job and work location
• Avoid highly repetitive movements of hands and
wrists, and continuous vibration exposure (after each
period of operation, exercise to increase blood circu-
lation)
• Keep tool well maintained and replace worn parts
For more information on the safe use of portable air tools, see the
latest edition of ANSI B186.1, Safety Code for Portable Air Tools,
available from the American National Standards Institute, Inc. 11
West 42nd Street, New York, NY 10036.
This information is a compilation of general safety practices ob-
tained from various sources available at the date of production.
However, our company does not represent that every acceptable
safety practice is offered herein, or that abnormal or unusual
circumstances may not warrant or require additional procedures.
Yourworkmayrequireadditionalspecificsafetyprocedures.Follow
these procedures as required by your company.
Warning Labels
Thewarning labels found onthese tools are anessential part of this
product. Labels should not be removed. Labels should be checked
periodically for legibility. Replace warning labels when missing or
when the information can no longer be read. Replacement labels
can be ordered as any spare part.
203185-4
READ
OPERATING
INSTRUCTIONS
203185
OVER
CAUTION!
Personal hearing protection is recommended when operating or working near this tool.
WARNING!
Impact resistant eye protection must be worn while operating or working near this tool.
Read Operating Instructions carefully. Follow the Safety Recommendations for your safety and the safety of others. Hearing protection is recommended in high noise areas (above 85 dBA). Close proximity of other tools, reflective surfaces, process noises, and resonant structures can substantially contribute to the sound level experienced by the user.
WARNING
!
Repetitive work motions and/or vibration can cause injury to hands and arms. Use minimum hand grip force consistent with proper control and safe operation. Keep body and hands warm and dry. Avoid anything that inhibits blood circulation. Avoid continuous vibration exposure. Keep wrists straight.
Avoid repeated bending of wrists and hands.
Do not remove this tag until the operator of this tool has read these safety precautions.
203289
Extension Neutral Flexion Radial Deviation Neutral Ulnar Deviation
Avoid Avoid Avoid OK Avoid OK
Standard Length Spindle X = 2 1/2" Minimum
Y = 2 1/2" Maximum
Torque Capacity = 125 Ft. Lbs. Maximum
3" Longer Than
Standard Spindle X = 4" Minimum
Y = 5 1/2" Maximum
Torque Capacity = 80 Ft. Lbs. Maximum
These capacities apply to Cleco Reaction Bars code
numbers: 869769, 869770, 202007, 202008,
202009.
Substitute bars without proper
metallurgymaynotbeadequate.
Use Cleco reaction bars.
Due to the multitude and variety of tooling applications
involving reaction bar nutrunners,the "User's" Methods
Engineering, Standard Tooling Engineering, and/or Safety
Engineering Departments , etc. , must consider any
hazards associated with each specific application of this
product and provide adequate operator protection,
reaction points and strengths, and operator training in the
safe use of this product.
WARNING
!
WARNING
!

4
OPERATING INSTRUCTIONS
SERVICE INSTRUCTIONS
exhaust ports and holding the throttle open approximately 30
seconds. The lubricator is properly set when a light stain of oil
collects on the paper. Excessive amounts of oil should be
avoided.
Applicationofthetoolshouldgovernhowfrequentlyitisgreased.
It is recommended that the idler gears receive a generous
amountofNLGI2-EPgreasethroughthegreasefittingsafter40
hours of operation.
STORAGE
In the event that it becomes necessary to store the tool for an
extended period of time (overnight, weekend, etc.), it should
receivea generousamountof lubricationatthattimeandagain
when returned to service. The tool should be stored in a clean
and dry environment.
DISASSEMBLY — GENERAL
Stall Tools
To disassemble the tool, clamp the motor housing lightly in a
soft-jawed vise with the tool in a vertical position. Using a
suitablewrench,loosenandremovethegearcase.Usingasoft-
faced mallet, tap the front of the motor housing to remove the
motor unit.
Automatic Shut-Off Tools
To disassemble the tool, clamp the flats of the clutch housing in
a soft-jawed vise and loosen the gear case. Clamp motor
housing in the vise and using a suitable wrench, loosen the
clutchhousingfromthemotorhousing.Tapthefrontofthemotor
housing with a soft-faced mallet to remove the motor unit.
SUB-ASSEMBLY DISASSEMBLY
Gear Train
Thecompletegeartrainmaybeslippedoutoftherearofthegear
case.By drivingthe idlergear pinsout ofthe rearof thespiders,
the idler gears can be removed from the spider pockets.
Clecomatic Clutch
Remove the adjustment cover by sliding it off the back of the
clutchhousing.Be carefulnot tolosethe steelball, No. 844077,
thatwilldropoutatthistime.Usingtheslotsprovidedontherear
faceofthe adjustingnut, No.867678,unscrew itfrom the clutch
housing. The torque spring bearing, No. 867683; spring plate,
No. 867669; and torque spring, No. 869626, will come out
through the rear of the clutch housing. With a soft mallet, tap on
the gear end of the clutch to remove it from the clutch housing.
By removing the retainer ring, No. 847022; the drive shaft
washer,No.867666;tripsleevespring,No.202056;tripsleeve,
No. 867670; and two (2) steel balls, No. 842161, can be
removed from the drive shaft. Remove the clutch cam bearing,
No. 619377, with a suitable puller. Using a sharp instrument,
remove the spiral ring, No. 865436. This will allow the clutch
cam, No. 867676; three (3) steel balls, No. 842161; trip plunger
spring,No.867671;andtripplunger,No.867668,toberemoved
through the front of the drive shaft. To remove the six (6) steel
balls,No.844265,slidetheballretainer,No.867673,offoverthe
rear of the drive shaft.
CAUTION !
55 STALL-TYPE NUTRUNNERS
The 55 stall-type nutrunner is designed to develop maximum
ratedtorqueat90psig.Torqueoutputiscontrolledbyapressure
regulator in the air supply line. Adjust the regulator until the
desired torque is reached.
55 CLECOMATIC NUTRUNNERS
The 55 Clecomatic nutrunner is designed to operate on 90 psig
maximum air pressure but does not depend on controlled air
pressuretomaintainaccuratetorque.Accuratetorqueisachieved
by setting the Clecomatic clutch to the desired torque on the
application. The tool will shut off automatically at this torque.
Releasing the throttle will allow the tool to reset for the next
cycle.
If the clutch is adjusted over the maximum
power output of the tool, the clutch will not
functionandthe toolwilloperatelike astall-typetool. Also,ifthe
tool is being operated at its upper torque limits, a drop in air
pressure could cause the clutch not to function due to a loss of
motor power and the tool will function like a stall-type tool. If the
tool stalls the operator must release throttle to stop tool.
Reaction bar must be properly positioned against adequate
stop. Do not use without reaction bar.
CLECOMATIC CLUTCH ADJUSTMENT
Depress the pin, No. 864711, and rotate the adjustment cover,
No.867677,180°soitlinesupwiththeadjustmentslot.Withthe
angle head end of the tool facing outward, away from the
operator, use a 1/8" diameter pin to rotate the adjustment nut,
No.867678,clockwisetoincreasethetorqueandcounterclock-
wise to decrease the torque.
Note: The steel ball, No. 844077, is a positive lock for the
adjustment nut and must be in place in a locking slot before the
adjustingcoverisrotatedtothelockedpositionaftereachclutch
adjustment is completed.
METERING VALVE
The metering nut No. 203203, can be adjusted with a hex
wrench clockwise to lower the RPM of the tool or counterclock-
wise to raise the RPM of the tool.
AIR SUPPLY
For maximum performance, use a 3/8" I.D. air hose no longer
than 8' in length. If additional length is required, a 1/2" or larger
hose should be connected to the 3/8" hose.
The air hose should be cleared of accumulated dirt and mois-
ture,thenone(1)teaspoonof10Wmachineoilshouldbepoured
into the tool's air inlet before connecting the hose to the tool.
LUBRICATION
An automatic in-line filter-lubricator is recommended as it in-
creases tool life and keeps the tool in sustained operation. The
in-line lubricator should be regularly checked and filled with a
goodgradeof10Wmachineoil.Properadjustmentofthein-line
lubricator is performed by placing a sheet of paper next to the

5
Motor Unit
Clampthecylinderlightlyin thevisewiththegear endoftherotor
up.Note: Therotor pinion, No.867524, usedon the and models
should be removed at this time. Drive the rotor out of the front
rotor bearing, No. 619377. Be careful not to damage the rotor.
The front bearing plate, No. 867536, cylinder, and rotor blades,
No.869569,cannowberemovedfromtherotor.Clampthebody
of the rotor in the vise with the rear bearing plate up. After
unscrewing the bearing lock nut, No. 865352, the rotor can be
driven out of the rear rotor bearing.
Motor Housing
Unscrewingthethrottlevalvecap,No.864531,willallowremoval
of the throttle valve for inspection of the throttle valve seal, No.
847366. Drive out the throttle lever pin, No. 847808, for removal
of the throttle lever, No. 847505. The exhaust deflector, No.
869736, and muffler, No. 869735, can be slipped off the rear of
the housing after the rear "O"-ring, No. 864737, is removed. On
the automatic shut-off tools, the valve block, No. 867682, and
shut-off valve, No. 867667, can be removed from the front of the
housing.
REASSEMBLY
The tool is reassembled in the reverse order of disassembly.
Cleanallpartsthoroughly inkeroseneandinspect fordamageor
wear. Check all bearings for wear which can be detected by
excessive end play and/or roughness which would indicate a
brinelledcondition. The rotor bladesshould be replaced atevery
repair cycle or if they measure less than 7/32" (5.6mm) at either
end.
All gear teeth, bearings, and pins should receive a close inspec-
tion and be replaced if necessary.
Motor
Toassemble the motor,install the rearrotor bearing intothe rear
bearing plate. Make sure the outer bearing race is firmly seated
in the bearing plate. Clamp the rotor body lightly in the vise with
thethreadedendupandsliptherearbearingplateassemblyonto
therotorshaftfarenoughforthebearing lock nuttostart.Tighten
the lock nut until there is .0015" clearance between the rotor and
bearingplate.Theouterbearingraceshouldbefirmlyseatedand
the rotor bumped forward when checking this clearance. Pack
both rotor bearings with a good grade of No. 2 Moly grease after
assembly of the motor unit.
Note:Duringreassemblyofthecompletetool,itisimportantthat
the motor be free. After the tool is completely assembled, the
square drive spindle should turn freely using a small hand
wrench. If the spindle does not turn freely, the motor should be
checked for proper spacing. Do not run the tool until the spindle
turns freely. Failure to do this could result in damage to motor
components.
Duringreassemblyof thegeartrain ,all ofthevarious gearsand
bearings should receive a generous amount of No. 2 Moly
grease.
Theclutchisassembledinthereverseorderofdisassembly.The
torque spring bearing, No. 867683, must be assembled so the
solidsideoftheballseparatorisfacingtowardthetorquespring.
During reassembly of the stall tools, the motor make-up plate,
No. 869059, should be installed with the opening toward the
grease fitting inside the motor housing. During reassembly on
theautomaticshut-off tools,thetip rodmustbe groundflush (+0
to-1/32)withthehexendoftherotor.Holdthemotorfirmlyinthe
housing at the time the trip rod is being sized to length.
Pour a few drops of 10W machine oil into the air inlet after
complete assembly to insure immediate lubrication of all motor
parts when air is applied.
SAFETY CHECK
After repair or replacement of parts, tools equipped with an
automaticshut-offdeviceshouldbe testedtoverifythat theyare
functioning properly.
Must be replaced if
7/32" (5.6mm) or less
at either end.
SOFT
JAWED
VISE
.0015"
Clearance

6
45 & 55 INLINE REACTION BAR NUTRUNNER GEAR TRAINS
844774
832125
Part No. Model
203336 -2
203337 -3
203336 -4
203337 -6
Part No. Model
203106 -2
203107 -3
203106 -4
203107 -6
204809
Part No. Model
861525 -2
861485 -3
861484 -4
861486 -6
Part No. Model
867526 -2
867526 -3
867523 -4
867523 -6
Part No. Model
NONE -2
NONE -3
867524 -4
867524 -6
844773
202502 202324
(Incl. in 202502)
865576
844778
869767
(Incl. in 202502)
869758 3/8" Sq. Dr.
869759 3/8" Sq. Dr. 3" Ext.
869756 1/2" Sq. Dr.
869757 1/2" Sq. Dr. 3" Ext.
844016 3/8"
844011 1/2"
844017 3/8"
844014 1/2"
844013 3/8"
844013 1/2"
869761
REACTION BAR
Material Complete Reaction Head Pin
Reaction Bar Bar Only Only
Aluminum 869769 202009 202007 884126
Steel 869770 202008 202007 884126
Part No. Model
844774 -2
844774 -3
844774 -4
844774 -6
PART NO.NAME OF PART
Reaction Bar Head
Reaction Bar (Steel)
Reaction Bar (Aluminum)
Spindle Bushing
Gear Case (incl. 869767 & 202324)
2 —2nd Red. Gear- 18T (incl. 844774)
3, 6 —2nd Red. Gear- 15T (incl. 203062)
2nd Red. Gear
2, 3, 4, 6 —1st Red. Gear Pin
Socket Retainer Pin
Retainer Plug
Spring
Socket Retainer Pin
Spring
Ball Bearing
Gear Bearing
Retainer Ring
4 —1st Red. Spider - 13T (incl. Pin)
3 —1st Red. Spider- 19T (incl. Pin)
QTY.
PARTS LIST —45 & 55 GEAR TRAINS
QTY.
1
1
1
1
1
3
3
3
3
1
1
1
1
1
1
9
1
1
1
NAME OF PART
PART NO.
202007
202008
202009
202324
202502
203106
203107
204809
832125
844011
844013
844014
844016
844017
844773
844774
844778
861484
861485
861486
861525
867523
867524
867526
869756
869757
869758
869759
869761
869767
869769
869770
884126
6 —1st Red. Spider- 19T (incl. Pin)
2 —1st Red. Spider- 13T (incl. Pin)
4, 6 —1st Red. Gear- 17T (incl. 844774)
4, 6 —Rotor Pinion - 16T
2, 3 —1st Red. Gear - 21T (incl. 844774)
1/2" Sq. Dr. Spindle (incl. Ret. Pin)
1/2" Sq. Dr. Spindle - 3" Ext. (ind. Ret. Pin)
3/8" Sq. Dr. Spindle (incl. Ret. Pin)
3/8" Sq. Dr. Spindle - 3" Ext.(incl. Ret. Pin)
Lock Nut
Grease Seal
Aluminum Reaction Bar (incl. 202007, 202008,
884126)
Steel Reaction Bar (incl. 202007, 202008,
884126)
Pin
1
1
3
1
3
1
1
1
1
1
1
1
1
1

7
55 REACTION BAR PISTOL CLECOMATIC CLUTCH
PART NO.
202056
202141
202142
202143
619377
842161
842162
844265
847022
865436
867666
867668
NAME OF PART
Trip Sleeve Spring
Clutch Housing
Bearing Retainer Plate
Adjustment Hole Cover
Clutch Cam Bearing
Steel Ball 3/16" Dia.
Steel Ball 1/4" Dia.
Steel Ball 1/8" Dia.
Washer Retainer Ring
Spiral Ring
Drive Shaft Washer
Trip Plunger
QTY.
1
1
1
1
1
5
1
6
1
1
1
1
PART NO.
867669
867670
867671
867673
867674
867676
867678
867683
869119
869626
NAME OF PART
Torque Spring Plate
Trip Sleeve
Trip Plunger Spring
Ball Retainer
Drive Shaft
Clutch Cam
Adjustment Nut
Torque Spring Bearing
Adjustment Ball Spring
Torque Spring
QTY.
1
1
1
1
1
1
1
1
1
1
The complete clutch with housing can be purchased as a subassembly using Part No. 861027.
PARTS LIST —CLECOMATIC CLUTCH
202141
202142
869119
842162 202143
619377 867676
842161
842161
867671 867668
867674
844265
865436
867673 867670 202056 867666
847022
869626 867669 867683 867678

8
55 REACTION BAR NUTRUNNER MOTOR
PART NO. NAME OF PART QTY.
202272 MOTOR SPACER (STALL) 1
203100 ROTOR-HEX (AUTOMATIC SHUT-OFF) 1
203101 CYLINDER (NON-REVERSIBLE) - INCL. 8863887 1
203102 ROTORT (NON-REVERSIBLE STALL) 1
203103 CYLINDER (REVERSIBLE) - INCL. 812164 1
619377 FRONT ROTOR BEARING 1
812165 REVERSIBLE CYLINDER PIN 1
843444 REAR ROTOR BEARING (NON-REVERSIBLE) 1
847096 REAR ROTOR BEARING (REVERSIBLE) 1
847603 ALIGNMENT PIN (REVERSIBLE) 1
863468 TRIP ROD (AUTOMATIC SHUT-OFF) 1
863887 NON-REVERSIBLE CYLINDER PIN 1
865352 ROTOR LOCK NUT 1
867536 FRONT BEARING PLATE 1
869569 ROTOR BLADE 5
869660 REAR BEARING PLATE (REVERSIBLE) 1
869572 REAR BEARING PLATE (NON-REVERSIBLE) 1
869573 ROTOR- 7T (REVERSIBLE STALL) 1
PARTS LIST —MOTOR
Non-Reversible Tools (Round Rotor)
203102 Stall Tools
203100 Automatic Shut-off Tools
Reversible Tools (Star Rotor)
869573 Stall Tools
203100 Automatic Shut-off Tools
812165 Rev.
863887 Non-Rev.
619377
869569
202272
Stall Tools
Only
843444 Non-Rev.
847096 Rev.
847603
Rev. Models Only
865352
869572 Non-Rev.
869660 Rev.
203101 Non-Rev.
203103 Rev.
867536
863468
Automatic Shut-off
Tools Only

9
55 REACTION BAR NON-REVERSIBLE NUTRUNNER HANDLE
PART NO.
202144
202831
203281
412775
619016
833471
847272
847275
863072
863468
867667
867682
869349
869350
869548
869712
869763
NAME OF PART
Valve Seat
Handle
Muffler
Exhaust Screen
Retainer Ring
Inlet
"O"-Ring
"O"-Ring
Throttle Valve Spring
Shut Off Valve Rod (Clecomatic Only)
Shut Off Valve (Clecomatic Only)
Valve Block
Sleeve
Throttle Valve
Air Inlet Screen
"O"-Ring
Trigger (incl. 869712)
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
The complete handle can be purchased as a subassembly using the following part number. Part No. 201208

10
55 REACTION BAR REVERSIBLE NUTRUNNER HANDLE
The complete handle can be purchased as a subassembly using the following part number. Clecomatic Models—
Part No. 861026 Stall Models—Part No. 861029
PART NO.
202139
202144
202145
202146
202148
202272
203281
412775
619016
619164
833471
847272
863072
863468
867667
869349
869350
869548
869655
869659
869712
869763
NAME OF PART
Handle
Valve Seat
Reversing Valve Knob
Reversing Knob Spacer
Knob Screw
Motor Make-up Plate
Muffler
Exhaust Screen
Retainer Ring
"O" Ring
Inlet Bushing
"O" Ring
Throttle Valve Spring
Shut Off Valve Rod (Clecomatic Only)
Shut Off Valve (Clecomatic Only)
Sleeve
Throttle Valve
Air Inlet Screen
Motor Spacer
ReversingValve
"O" Ring
Trigger (incl. 869712)
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

11
NOTES

823028/Printed in USA 12/2013/Copyright © Apex Tool Group, LLC
Apex Tool Group, LLC
1000 Lufkin Road
Apex, NC 27539
Phone: [phone]
Fax: [phone]
www.apextoolgroup.com
Sales & Service Centers
Note: All locations may not service all products. Please contact the nearest Sales & Service Center for
the appropriate facility to handle your service requirements.
Detroit, Michigan
Apex Tool Group
Sales & Service Center
2630 Superior Court
Auburn Hills, MI 48326
Tel: [phone]
Fax: [phone]
Houston, Texas
Apex Tool Group
Sales & Service Center
6550 West Sam Houston
Parkway North, Suite 200
Houston, TX 77041
Tel: [phone]
Fax: [phone]
Lexington, South Carolina
Apex Tool Group
670 Industrial Drive
Lexington, SC 29072
Tel: [phone]
Tel: [phone]
Fax: [phone]
Los Angeles, California
Apex Tool Group
Sales & Service Center
6881 Stanton Avenue
Unit B
Buena Park, CA 90621
Tel: [phone]
Fax: [phone]
Seattle, Washington
Apex Tool Group
Sales & Service Center
2865 152nd Avenue N.E
Redmond, WA 98052
Tel: [phone]
Fax: [phone]
York, Pennsylvania
Apex Tool Group
Sales & Service Center
3990 East Market Street
York, PA 17402
Tel: [phone]
Fax: [phone]
Brazil
Apex Tool Group
Sales & Service Center
Av. Liberdade, 4055
Zona Industrial - Iporanga
18087-170 Sorocaba
SP Brazil
Tel: [phone]
Fax: [phone]
Canada
Apex Tool Group
Sales & Service Center
7631 Bath Road
Mississauga
Ontario L4T 3T1
Canada
Tel: [phone]
Tel: [phone]
China
Apex Power Tool Trading
(Shanghai) Co., Ltd
Building A8, No. 38
Dongsheng Road
Pudong, Shanghai
China 201201
Tel: [phone]
Fax: [phone]
England
Apex Tool Group
GmbH & Co. OHG
C/O Spline Gauges
Piccadilly, Tamworth
Staffordshire B78 2ER
United Kingdom
Tel: [phone]
Fax: [phone]
France
Apex Tool Group S.N.C.
25 rue Maurice Chevalier
B.P. 28
77831 Ozoir-La-Ferrière
Cedex, France
Tel: [phone]
Fax: [phone]
Germany
Apex Tool Group
GmbH & Co. OHG
Industriestraße 1
73463 Westhausen
Germany
Tel: [phone]
Fax: [phone]
Hungary
Apex Tool Group
Hungaria Kft
Platànfa u.2
9027 Györ
Hungary
Tel: [phone]
Fax: [phone]
India
Apex Power Tools India
Private Limited
Gala No. 1, Plot No. 5
S. No. 234, 235 & 245
Indialand Global
Industrial Park
Taluka-Mulsi, Phase I
Hinjawadi, Pune 411057
Maharashtra, India
Tel: [phone]
Mexico
Apex Tool Group México
S. de R.L. de C.V.
Vialidad El Pueblito #103
Parque Industrial Querétaro
Querétaro, QRO 76220
Mexico
Tel: [phone]
Fax: [phone]
