Cleco 55NLTVC Series Installation and operating instructions

1
Operation & Service Manual
823013 2/01
55NLTVC Series Solenoid
Controlled Nutrunners
Vision (Lights)
Solenoid Controlled:
V
Vision (Lights) PositiveVP
LeverL
Options:
Handle:
Transducer:
55
Nutrunner:
55
Series:
NTXXC -L X
Built-in SocketS
Gear Train Designation:
(Specify Size)
Threaded SpindleT
Output Drive:
Angle Terminations:
2
34 67 10
X X X-
3/8"
1/2"4
3
V
T
PHDB T Hold & Drive
VHD V Hold & Drive
M
RRetractable Spindle
NORTH AMERICA EUROPE
P.O. Box 1410
Lexington, SC 29071 Postfach 30 D-73461 Westhausen

2
CAUTION!
Personal hearing protection is
recommended when operating
or working near this tool.
For your safety and the safety of others, read and under-
stand the safety recommendations and operating instruc-
tions before operating a nutrunner.
Always wear protective equipment:
For additional information on eye protection and face
protection, refer to Federal OSHA Regulations, 29 Code
ofFederalRegulations,Section1910.133.,EyeandFace
Protection, and American National Standards Institute,
ANSIZ87.1,OccupationalandEducationalEye andFace
Protection. Z87.1 is available from the American National
Standards Institute, Inc., 11 West 42nd Street, New York,
NY 10036.
Hearing protection is recommended in high noise areas
85 dBA or greater. The operation of other tools and
equipmentinthearea,reflectivesurfaces,processnoises
and resonant structures can substantially contribute to,
and increase the noise level in the area. Excessive air
pressureabove90PSIGandwornmotorcomponentscan
also increase sound level emitted by tool. Proper hearing
conservation measures, including annual audiograms
andtrainingintheuseandfitofhearingprotectiondevices
may be necessary. For additional information on hearing
protection,refertoFederal Regulations,Section1910.95,
Occupational Noise Exposure, and American National
Standards Institute, ANSI S12.6, Hearing Protectors.
Cleco nutrunners are designed to operate on 90 psig (6.2
bar)maximumairpressure.Ifthetoolisproperlysizedand
applied,higherairpressureisunnecessary. Excessiveair
pressure increases the loads and stresses on the tool
parts, sockets, and fasteners and may result in breakage.
Installation of a filter-regulator-lubricator in the air supply
line ahead of the tool is recommended.
Before the tool is connected to the air supply, check the
throttleforproperoperation(i.e.,throttlemovesfreelyand
returns to closed position). Being careful not to endanger
adjacent personnel, clear the air hose of accumulated
dustandmoisture.Beforeconnectingatooltotheairhose
orremovingatoolfromserviceorchangingsockets,make
sure the air line is shut off and drained of air. This will
Safety Recommendations
prevent the tool from operating if the throttle is accidently
engaged.
When using right angle nutrunners, be sure the throttle is
positionedrelativetotheangleheadsothatthethrottlewill
not become wedged against an adjacent object in the
"ON"position due to torquereaction. The angle headmay
be repositioned with respect to the lever to accommodate
proper location for task. If tool is to be reversed, locate
throttle lever in a neutral position that will prevent entrap-
ment. Refer to operating instructions for additional infor-
mation.
It is essential for safe operation that any operator of a
nutrunner use good balance, sure footing, and proper
posture in anticipation of a torque reaction.
Toolswithclutchescanstallratherthanshut-offifadjusted
over maximum power output of tool, or if there is a drop in
air pressure. Operator must then resist stall torque until
throttle is released.
Tool balance arms are available to absorb the torque
reaction of the tool while balancing the weight of the tool
for improved ergonomic applications.
Some individuals may be susceptible to disorders of the
hands and arms when performing tasks consisting of
highly repetitive motions and/or exposure to extended
vibration. Cumulative trauma disorders such as carpal
tunnel syndrome and tendonitis may be caused or aggra-
vated by repetitious, forceful exertions of the hands and
arms. Vibration may contribute to a condition called
Raynaud'sSyndrome.These disorders develop gradually
over periods of weeks, months, and years. It is presently
unknown to what extent exposure to vibrations or repeti-
tive motions may contribute to the disorders. Hereditary
factors, vasculatory or circulatory problems, exposure to
WARNING!
Impact resistant eye protection
must be worn while operating
or working near this tool.
CAUTION!
Spindle Rotation Torque Reaction
Repetitive work motions and/or vibration
may cause injury to hands and arms.
Use minimum hand grip force consistent
with proper control and safe operation.
Keep body and hands warm and dry.
Avoid anything that inhibits blood circulation.
Avoid continuous vibration exposure.
Keep wrists straight.
WARNING
!
Avoid repeated bending of wrists and hands.

3
Safety Recommendations
Extension Neutral Flexion Radial Deviation Neutral Ulnar Deviation
Avoid Avoid Avoid OK Avoid OK
cold and dampness, diet, smoking and work practices are
thought to contribute to the conditions.
Any tool operator should be aware of the following warning
signs and symptoms so that a problem can be addressed
before it becomes a debilitating injury. Any user suffering
prolonged symptoms of tingling, numbness, blanching of
fingers, clumsiness or weakened grip, nocturnal pain in the
hand, or any other disorder of the shoulders, arms, wrists,
orfingersisadvisedtoconsultaphysician.Ifitisdetermined
that the symptoms are job related or aggravated by move-
ments and postures dictated by the job design, it may be
necessary for the employer to take steps to prevent further
occurrences. These steps might include, but are not limited
to, repositioning the workpiece or redesigning the worksta-
tion,reassigningworkerstootherjobs,rotatingjobs,chang-
ing work pace, and/or changing the type of tool used so as
tominimizestress on the operator. Some tasks may require
more than one type of tool to obtain the optimum operator/
tool/task relationship.
The following suggestions will help reduce or moderate the
effects of repetitive work motions and/or extended vibration
exposure:
• Use a minimum hand grip force consistent with proper
control and safe operation
• Keep body and hands warm and dry (cold weather is
reported to be a major factor contributing to Raynaud's
Syndrome)
• Avoid anything that inhibits blood circulation
—Smoking Tobacco (another contributing
factor)
—Cold Temperatures
—Certain Drugs
• Tasks should be performed in such a manner that the
wrists are maintained in a neutral position, which is not
flexed, hyperextended, or turned side to side.
• Stressful postures should be avoided — select a tool
appropriate for the job and work location
• Avoid highly repetitive movements of hands and wrists,
and continuous vibration exposure (after each period of
operation, exercise to increase blood circulation)
• Keep tool well maintained and replace worn parts
Work gloves with vibration reducing liners and wrist sup-
ports are available from some manufacturers of industrial
work gloves. Tool wraps and grips are also available from
anumberofdifferentmanufacturers.Thesegloves,wraps,
and wrist supports are designed to reduce and moderate
the effects of extended vibration exposure and repetitive
wrist trauma. Since they vary widely in design, material,
thickness, vibration reduction, and wrist support qualities,
it is recommended that the glove, tool wrap, or wrist
support manufacturer be consulted for items designed for
yourspecificapplication.WARNING! Proper fitof gloves
is important. Improperly fitted gloves may restrict
blood flow to the fingers and can substantially reduce
grip strength.
For more information on the safe use of portable air tools,
see the latest edition of ANSI B186.1, Safety Code for
Portable Air Tools, available from the American National
Standards Institute, Inc. 11 West 42nd Street, New York,
NY 10036.
This information is a compilation of general safety prac-
ticesobtained from various sources availableatthedateof
production. However, our company does not represent
that every acceptable safety practice is offered herein, or
that abnormal or unusual circumstances may not warrant
or require additional procedures. Your work may require
additional specific safety procedures. Follow these proce-
dures as required by your company.
Warning Labels
The warning labels found on these tools are an essential
part of this product. Labels should not be removed. Labels
shouldbecheckedperiodicallyforlegibility.Replacewarn-
ing labels when missing or when the information can no
longerberead.Replacementlabelscanbeorderedasany
spare part.
203289
OVER
CAUTION!
Personal hearing protection is recommended when operating or working near this tool.
WARNING!
Impact resistant eye protection must be worn while operating or working near this tool.
Read Operating Instructions carefully. Follow the Safety Recommendations for your safety and the safety of others. Hearing protection is recommended in high noise areas (above 85 dBA). Close proximity of other tools, reflective surfaces, process noises, and resonant structures can substantially contribute to the sound level experienced by the user.
WARNING
!
Repetitive work motions and/or vibration can cause injury to hands and arms. Use minimum hand grip force consistent with proper control and safe operation. Keep body and hands warm and dry. Avoid anything that inhibits blood circulation. Avoid continuous vibration exposure. Keep wrists straight.
Avoid repeated bending of wrists and hands.
Do not remove this tag until the operator of this tool has read these safety precautions.
203185
203185-4
READ
OPERATING
INSTRUCTIONS

4
OPERATING INSTRUCTIONS
LUBRICATION
An automatic in-line filter-lubricator-regulator is recom-
mended as it increases tool life and keeps the tool in
sustainedoperation. The in-line lubricator should beregu-
larlychecked andfilled withagood gradeof 10Wmachine
oil.Proper adjustmentof thein-line lubricator isperformed
by placing a sheet of paper next to the exhaust ports and
holdingthethrottleopenforapproximately30seconds.The
lubricatorisproperlysetwhenaverylightstainofoilcollects
onthepaper.Excessiveamountsofoilshould beavoided.
Application of the tool should govern how frequently it is
greased. It is recommended that the idler gears and right
angle gears receive a generous amount of NLGI 2-EP
grease through the grease fittings after 40 hours of opera-
tion.
STORAGE
In the event that it becomes necessary to store the tool for
an extended period of time, it should receive a generous
amountoflubricationatthattimeandagainwhenreturned
to service. The tool should be stored in a clean and dry
environment. This inhibits corrosion of the precision inter-
nal components and bearings.
FORYOURSAFETYANDTHESAFETYOFOTHERS,READANDUNDERSTANDTHESAFETY
RECOMMENDATIONS ON PAGES 2 & 3 BEFORE OPERATING A NUTRUNNER.
TORQUE ADJUSTMENT
The55NLTVCnutrunnerisdesignedtodevelopmaximum
rated torque at 90 psig. The torque setting is achieved by
entering a number within the tool's torque range into the
torquecontrolmonitor.Seecatalogfortorquerangeoftool.
The torque setting entered into the torque control monitor
must not exceed maximum torque range of tool or the
automatic shut-off device will not function and the tool will
operateasastalltool.Operatorshouldbepreparedtoresist
torque reaction until throttle is released.
THROTTLE POSITION
The throttle lever may be repositioned to accommodate
proper location for task and to avoid entrapment. Reposi-
tioningoftheangleheadisdonebylooseninghousinglock
nutNo.867521,andliftingtheangleheaduntilthesplineon
the angle head clears the gear case and can be rotated to
thepositiondesired.Lower the angle head back into place
and tighten housing lock nut.
AIR SUPPLY
For maximum performance, use a 1/2" I.D. air hose no
longer than 8' in length. If additional length is required, a
5/8" or larger hose should be connected to the 1/2" hose.
Being careful to avoid endangering adjacent personnel or
yourself, theairhoseshouldbeclearedofaccumulateddirt
andmoisture,thenone(1) teaspoonfulof10Wmachineoil
should be poured into the tool's air inlet before connecting
the hose to the tool.

5
SERVICE INSTRUCTIONS
DISASSEMBLY — GENERAL
Disconnecttoolfromairsupply.Clamptherightanglehead
in a vise and loosen (left hand threads) the motor housing.
Hold the tool in a vertical position with the right angle head
up.Unscrew (left hand threads) and remove the head, and
transducerhousingfromthemotorhousing.Disconnectthe
wireconnector, No. 202183, at the transducerandremove
the transducer and gear train from the motor housing. Slip
the complete motor unit out the front of the housing.
Clamp the angle head in the vise and unscrew (left hand
threads) the right angle housing lock nut, No. 867521, to
remove the transducer housing.
"M" Right Angle Head
Usingasuitablespannerwrench,unscrew(lefthandthreads)
the bearing cap, No. 864396. Remove the square drive
spindle, No. 867643, ball bearing, No. 842517, and driven
gearbyclampingthesquaredriveinthevise.Drivetheright
angle housing, No. 867506, away from the square drive
using a soft-faced mallet. The ball bearing can now be
removed by pressing the square drive end of the spindle
throughthebearingI.D.Press thesmallerendofthespindle
through the gear to remove the driven gear. Screw a 1/40
NCboltintothepiniongear.Clamptheheadoftheboltinthe
viseand usea soft-faced malletto drivethehousing offthe
gear.Ifthismethodfails,itwillbenecessarytouseasuitable
puller.
"P" Right Angle Head
Using a suitable wrench, unscrew (left hand threads) the
bearingcap,No.203250.Removethesquaredrivespindle,
No.203249, ball bearing,No.842517 and drivengear, No.
203251,by clamping the squaredrivein the vise. Drivethe
right angle housing, No. 203247, away from the square
driveusingasoft-facedmallet.Removethespindleretainer
nut, No. 203248, with a wrench. The ball bearing can now
beremovedbypressingthesquaredriveendofthespindle
through the gear to remove the driven gear. Screw a 1/40
NC bolt into the pinion gear. Clamp the head of the bolt in
thevise anduse a soft-facedmallet todrivethe housingoff
the gear. If this method fails, it will be necessary to use a
suitable puller.
"T" Right Angle Head
Loosen the bearing cap lock screw, No. 867997, and
unscrew (left hand threads) the bearing cap, No. 867509.
Removethesquaredrivespindle,No.867510,ballbearing,
No. 867547, and driven gear by clamping the square drive
in the vise. Drive the right angle housing away from the
squaredriveusingasoft-mallet.Pressthesquaredriveend
of the spindle through the bearing I.D. to remove the ball
bearing. The driven gear may be removed by pressing the
smaller end of the spindle through the gear. Remove the
greaseplug,No.867546,and,usingasuitabledriver,drive
the pinion gear out of the right angle housing.
Gear Train 2, 3, 4, 6, & 10
Important: Do not bend, strike, push or pull in any way that
willcausestrainintheplasticcoatedareaofthetransducer.
Remove the gear train from the front of the ring gear.
Removetheretainerringandballbearing.Driverollpin,No.
812164,infarenoughtocleartheringgearandslipthering
gear off the transducer.
Gear Train
Important: Do not bend, strike, push or pull on the plastic
coatedareaofthetransducer.Driverollpin,No.812164,in
farenoughtocleartheringgear.Removetheringgearand
align the idler gears with the pockets machined in the ring
gear.Slipthe spiderassembly outthe rearoftheringgear.
Removetheretainerringandball bearinganddrivetheroll
pin into the bearing bore.
Motor Unit
Clamp the cylinder lightly in a vise with the gear end of the
rotor up. Note: Rotor pinion, No. 867524, used on the and
models should be removed at this time. Drive the rotor out
of the front rotor bearing, No. 619377. Be careful not to
damage the rotor. The front bearing plate, No. 867536,
cylinder, and rotor blades, No. 203219, can now be re-
moved from the rotor. Clamp the rotor in the vise with the
rearbearingplateup.Afterunscrewingthebearinglocknut,
No. 865352, the rotor can be driven out of the rear rotor
bearing.
Motor Housing
Clamp the flats of the motor housing in the vise and use a
strap wrench to unscrew the handle, No. 202182. Discon-
nectthewirebundlefromthecableconnector,No.202183.
Remove solenoid retainer, No. 203369, with wrench and
remove solenoid, No. 203363. Remove retainer ring, No.
203053andrearlightring,No.203263.UnplugP.C.Board,
and remove from rear of tool. Remove set screw, No.
813315 and remove front light ring, No. 203262. Remove
exhaustdeflector,No.203261,exhaustscreen,No.202177,
and muffler, No. 202012, from the rear of the housing.
Remove throttle valve cap, No. 864531, valve cap, No.
203380 and shut-off valve cap, No. 203550 with screw-
driver to check seals and "O"-rings.

6
REASSEMBLY — GENERAL
The tool is reassembled in the reverse order of disassem-
bly. Clean all parts thoroughly in kerosene and inspect for
damageor wear. Check all bearingsfor wear which can be
detected by excessive end play and/or roughness which
wouldindicateabrinelledcondition.Therotorbladesshould
be replaced at every repair cycle if they measure less then
1/4"(6.4mm)ateitherend.Allgearteeth,bearings,andpins
shouldreceiveacloseinspectionandbereplacedifneces-
sary.
NOTE: During reassembly of the complete tool, it is impor-
tant that the motor be free. After the tool is completely
assembled,therightanglesquaredrivespindleshouldturn
freelyusingasmallhandwrench.Ifthespindledoesnotturn
freely,themotor shouldbe checkedfor properspacing.Do
notrunthetooluntilthespindleturnsfreely.Failuretodothis
could result in damage to motor components.
Motor Unit
Install the rear rotor bearing into the rear bearing plate.
Makesuretheouterbearingraceisfirmlyseatedinbearing
plate. Clamp the rotor lightly in the vise with the threaded
end up and slip the rear bearing plate assembly onto the
rotor shaft far enough for the bearing lock nut to start.
Tighten the lock nut until there is approximately .0015"
clearance between the rotor and bearing plate. The outer
bearing race should be firmly seated and the rotor held
forward when checking this clearance.
Pack both rotor bearings with a good grade of No. 2 Moly
grease after assembly of the motor unit.
Gear Train
Wheninstallingthespiderassemblytheidlergearsmustbe
alignedwith thepockets machinedinthe ringgear. Lineup
thehole in the ring gear with the hole in the transducer and
install the pin, No. 812164.
Transducer Wiring Connection
NOTE: Do not bend, strike, push or pull the transducer on
theplasticcoatedareaofthetransducer.Connectthecable
connector, No. 202183, to the transducer and wrap the
wiringaroundthetransduceruntilthecableconnectorisone
(1)wrappasttheconnectionandthenthreadtheconnector
thrutheholeinthetransducer.Installthetransduceronthe
motor housing, feeding the connector thru the hole in the
housing. Line up the tangs on the transducer with the
grooves in the housing being careful not to pinch the
connector.
Right Angle Head
During reassembly of the gear train and angle head, all of
the various gears and bearings should receive a generous
amount of NLGI 2-EP grease. The pinion needle bearing
shouldbeslippedontothepiniongearandthenpressedinto
the right angle housing until the rear of the bearing is flush
or slightly below the step in the housing.
NOTE: During reassembly of the "T" right angle head, the
bearing cap, No. 867509, should be torqued to 100-110 ft.
lbs.Also,thebearingcaplockscrew,No.867997,shouldbe
torqued to 10 in. lbs. minimum.
Pour a few drops of 10W machine oil into the air inlet after
complete assembly to ensure immediate lubrication of all
motor parts when air is applied.
SAFETY CHECK
Afterrepairor replacementof parts,tools equippedwithan
automaticshut-offdeviceshouldbetestedtoverifythatitis
functioning properly. The torque setting entered into the
torque control monitor must not exceed maximum torque
range or tool will stall and not shut-off.
SERVICE INSTRUCTIONS
Must be replaced if
7/32" (5.6mm) or less
at either end.
SOFT
JAWED
VISE
.0015"
Clearance

7
TRANSDUCER SPECIFICATIONS
MAXIMUM TORQUE CAPACITY See full scale values below
OUTPUT VOLTAGE (Vo) 2 Millivolts per volt at maximum torque capacity
BRIDGE RESISTANCE (Rbr) 700 ohm (nominal) can be used with 350 and 700 ohm strain gage equipment*
TRANSDUCER CABLE Cannon No. PTO1A0P (mates with Cannon No. PTO1A0S or equivalent)
CALIBRATION INSTRUCTIONS
ANGLE HEAD SIZE FULL SCALE VALUE (FS)
FT. LBS. Nm
M 95.7 129.8
P 99.3 134.6
T 118.5 160.7
In order to calculate the calibration value for the system in % full scale, the following formula may be used:
% FS = Rbr 1 1
------------------ X ----- X -----
2(Rcal) + Rbr Vo 2
Where Rcal = Calibration Resistor Value in ohms of the torque monitor used.
The following is an example of a 55 series right angle tool, a "P" head and a torque monitor with a 110,000 ohm calibration
resistor.
The values are: FS = 99.3 ft. lbs.
Rbr = 700ohm
Vo = .002
Rcal = 110,000ohm
700ohm 1 1
% FS = --------------------------- X ------ X ----- = 79.3%
2(110,000ohm) + 700ohm .002 2
Calibration Value = 99.3 (.793) = 78.7 ft. lbs.
*Calculated calibration value should be doubled if a torque monitor designed for use with a 350ohm bridge resistance
transducer is used.
AA
BB
CC
DD
BLACK
GREEN
RED
WHITE
TOOL RECEPTACLE
CABLE CONNECTORS
R
WIRING DIAGRAM
EE
FF
(+) SIGNAL
(-) SIGNAL
SHIELD
(+) EXCITATION
(-) EXCITATION
Ro/2Rm/2
R
R
R
tC
t
C
Ro/2Rm/2
Rcal
R= Gage Resistance
Rm= Modulus Resistor
Ro= Output Scaling Resistor
Rm & Ro may be omitted
Rcal= Shunt Calibration Resistor

8
KK
LL
(+) SOLENOID
(-) SOLENOID
TOOL RECEPTACLE CABLE CONNECTORS
BLACK
RED
SOLENOID SPECIFICATIONS
6V DC-8V DC CONTINUOUS VOLTAGE
24V DC-36V DC FOR 15 msec MAX.
14.95ohm RESISTANCE
SOLENOID RETAINER
PLUNGER PIN
HAT
.015/.020
1. Solenoid plunger pin to hat dimension should be .015/.020 as shown. A new plunger pin should be
spaced as shown; however, a previously used plunger pin must be pressed to this dimension.
2. Assemble the solenoid components as shown. Solenoid retainer must be torqued to 10 to 12 ft. lbs.
using 242 Loctite. Note: Overtightening may damage solenoid body. Undertightening may result in
air leakage that may affect operation.
3. Connect tool to air supply. Air supply operating pressure should be between 40 and 90 PSI.
ADJUSTMENT SCREW

9
6. While keeping throttle lever fully depressed and using the 5/64" hex
wrench, turn adjustment screw counterclockwise until motor stops. At this
point rotate the screw an additional 1/2 turn counterclockwise.
7. Connect tool electronics. Tool should now shut off automatically at programed
torque limits.
SOLENOID RETAINER
PLUNGER PIN
HAT
ADJUSTMENT SCREW
5/64 HEX WRENCH
SOLENOID SEAT VALVE PLUNGER
SOLENOID RETAINER
PLUNGER PIN
HAT
4. Using a 5/64" hex wrench, turn adjustment screw clockwise until plunger pin is pressed through
hat and valve plunger is fully seated in solenoid seat.
5. Depress throttle and check tool for rated speed at 90PSI. If tool does not perform according
to specifications, valve plunger may not be fully depressed. Continue to turn
adjustment screw clockwise. Note: Do not exceed 76 in. lbs. torque.
ADJUSTMENT SCREW
5/64 HEX WRENCH
SOLENOID SEAT VALVE PLUNGER

10
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
TRANDUCER
INDICATOR
LIGHTS
WHITE
BLACK
GREEN
RED
A + EXCITATION
BLACK
GREEN
RED
SHIELD
CAMBION
CONNECTORS
CAMBION
CONNECTORS
19 PIN CONNECTOR
WHITE B - EXCITATION
C + SIGNAL
D - SIGNAL
E SHIELD
F
G
H
J
K + SOLENOID
N
P
S YELLOW LED SIGNAL
T COMMON
U GREEN LED SIGNAL
V RED LED SIGNAL
RED
RED
SOLENOID
CAMBION
CONNECTORS
BLACK
BLACK
ARMOR CABLE
55 & 75 SOLENOID CONTROL TOOL WIRING DIAGRAM
S S
T T
U U
V V
WHITE
WHITE
WHITE
WHITE YELLOW LED
COMMON
GREEN LED
RED LED
TOOL RECEPTACLE CABLE CONNECTORS
(-)
(-)
(-)
+24V COMMON
R
R
R
203350 POSITIVE
COMMON PC BOARD
INDICATOR LIGHT WIRING DIAGRAMS
S S
T T
U U
V V
WHITE
WHITE
WHITE
WHITE YELLOW LED
COMMON
GREEN LED
RED LED
TOOL RECEPTACLE CABLE CONNECTORS
+24V
+24V
+24V
COMMON (-)
R
R
R
203259 NEGATIVE
COMMON PC BOARD
L - SOLENOID
M
R

11
867522
867521867520842517
863360
382633
867506 867519
882629
864076 842517 847710
864396
867641
843589
867643
867642 847219
842980 202569 869051
3/8 - 24 Thd.
DRILL SPINDLE
FLUSH SOCKET SPINDLE
SIZE SPINDLE CONVERSION
PART NO. KIT* PART NO.
10mm 202566 201102
11mm 202725 201214
13mm 202567 201103
14mm ------------ ------------
15mm 202568 201104
*Conversion kit contains all parts
needed to convert a "M" right angle
head to flush socket operation.
"M" RIGHT ANGLE HEAD
NAME OF PART
Spline Protector
Ball Bearing
Grease Fitting
Lock Pin Spring
"O"-Ring 1/2" x 5/8"
Pinion Bearing (upper)
Driven Gear
Bearing Cap
Housing (incl. 843589)
Pinion Gear
Housing Make-Up Plate
Housing Lock Nut
Housing Clamp Ring
Lock Pin Spring Cap
Socket Lock Pin
3/8" Sq. Dr. Spindle (incl.
847219, 867641, 867642)
3/84 Thd. Drill Spindle
Spindle Needle Bearing
•Denotes parts not included in subassem-
blies listed below. The "M" right angle
gears can be purchased as a set using
Part No. 861481. The "M" right angle head
can be purchased as a subassembly using
Part Numbers:
3/8" Sq. Dr. Spindle—Part No. 861495
3/84 Thd. Spindle—Part No. 861659
PART NO.
382633
842517
843589
847219
847710
863360
864076
864396
867506
867519
867520*
867521*
867522*
867641
867642
867643
869051
882629
QTY.
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1

12
867522
867521867520842517
203247 203252 203253
864105
867546
382633
203248 203251 842517 847272 203250
203439 3/8" SQ. DR.
203249 1/2" SQ. DR.
844013
844016 3/8" SQ. DR.
844011 1/2" SQ. DR.
844017 3/8" SQ. DR.
844014 1/2" SQ. DR.
847445 203772
842980
FLUSH SOCKET SPINDLE
SIZE SPINDLE CONVERSION
PART NO. KIT* PART NO.
10mm 203766 201512
11mm 203767 201513
13mm 203768 201514
14mm 203769 201515
15mm 203770 201516
16mm 203962 201569
17mm 203771 201517
9/16" 203807 201528
*Conversion kit contains all
parts needed to convert a
"P" right angle head to flush
socket operation.
203247
203248
203249
203250
203251
203252
203253
203439
382633
842517
844011
844013
844014
844016
844017
847272
864105
867520
867521
867522
867546
Angle Head
Spindle Retainer Nut
1/2" Sq. Dr. Spindle
Spindle Cap
Driven Gear (14T)
Pinion Gear (9T)
Pinion Gear Needle Bearing
3/8" Sq. Dr. Spindle
Spline Protector
Ball Bearing
Socket Lock Pin
Spring Retainer
Lock Pin Spring
Socket Lock Pin
Lock Pin Spring
"O"-Ring 5/8" x 3/4"
Needle Cap Bearing
Housing Make-Up Plate*
Housing Lock Nut*
Housing Clamp Ring*
Grease Plug
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
PART NO. NAME OF PART QTY.
PARTS LIST —"P" Right Angle Head
* Denotes parts not included in subassemblies
listed below.
The "P" right angle gears can be purchased as a
set using Part No. 201376.
The "P" right angle head 1/2" sq. dr. can be
purchased as a subassembly using Part No.
201373.
The "P" right angle head 3/8" sq. dr. can be
purchased as a subassembly using Part No.
201464.
"P" RIGHT ANGLE HEAD

13
867522
867521867520842517
867507 867511 867548
882661
867546
867512 867547 867509
844013
382633
844014
844011
867510
867997
867787
1/2 - 20 Thd.
DRILL SPINDLE
Name of Part
Spline Protector
Ball Bearing
Socket Lock Pin
Spring Retainer
Lock Pin Spring
"T" Right Angle Head
Bearing Cap (incl. 867997)
l/2" Sq. Dr. Spindle (incl.
844011, 844013, 844014-l)
"T" Pinion Gear
Driven Gear
Housing Make-Up Plate
Housing Lock Nut
Housing Clamp Ring
Grease Plug
Spindle Ball Bearing
Pinion Needle Bearing
Bearing Cap Set Screw
Spindle Needle Bearing
"T" RIGHT ANGLE HEAD
* Denotes parts not included in subassemblies listed below.
The 'T' right angle gears can be purchased as a set using
Part No. 861478.
The "T" right angle head can be purchased as a subassembly using
Part No. 861496.
Part No.
382633
842517
844011
844013
844014
867507
867509
867510
867511
867512
867520*
867521*
867522*
867546
867547
867548
867997
882661
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
PARTS LIST—"T" Right Angle Head

14
1-5/16"
3/8" DIA.
3/4" NPT
1-1/4"
202319
202320
842554 (QTY. 2)
C
L
C
L
PARTS LIST
REACTION BAR BRACKET ASSEMBLY
PART NO. NAME OF PART QTY.
202319 Reaction Bracket 1
202320 Reaction Bar Clamp 1
842554 5/168 x 1/4" Bracket Bolt 2
The complete reaction bar bracket can be purchased as
Subassembly using Part No. 201012.
The reaction bracket, No. 202319,
must fully engage the spline on the
right angle head. Position the bracket forward on the small
diameter of the head and move it rearward to engage the
spline. Securely tighten the reaction bar and bolts to
prevent coming loose from vibration.
CAUTION !
REACTION BAR BRACKET ASSEMBLY
"T" HEAD —RETRACTABLE SPINDLE
PART NO. NAME OF PART QTY.
202537 1/2" SQUARE DRIVE EXTENSION SPINDLE
(INCLUDES 844011, 844013, 844014, & PIN) 1
202538 RETRACTABLE SPINDLE 1
202539 RETAINER CLIP 1
202540 SPRING 1
844011 SOCKET RETAINER 1
844013 SOCKET SPRING RETAINER 1
844014 SOCKET RETAINER SPRING 1
COMPLETE "T" HEAD WITH RETRACTABLE SPINDLE CAN BE ORDERED
USING PART NUMBER —201134
COMPLETE RETRACTABLE SPINDLE CAN BE ORDERED USING PART NUMBER —201674
PARTS LIST —RETRACTABLE SPINDLE

15
844774
202154
832125
Part No. Model
203104 -2
203105 -3
203104 -4
203105 -6
Part No. Model
203106 -2
203107 -3
203106 -4
203107 -6 204809
Part No. Model
861525 -2
861485 -3
861484 -4
861486 -6
Part No. Model
867526 -2
867526 -3
867523 -4
867523 -6
Part No. Model
NONE -2
NONE -3
867524 -4
867524 -6
867505
867535
867527
-2, -3, -4, & -6 Gear Trains
-7 Gear Train
861487 844774
832125 867526
-10 Gear Train
869629
847566
869634
202605
812164
202156
847566
869634
202605
812164
202158
847566
869634
202605
812164
202155
202157
Part No. Model
844774 -2
844774 -3
844774 -4
844774 -6
45 & 55
RIGHT ANGLE HEAD
TRANSDUCERIZED
GEAR TRAINS
PART NO.
202154
202155
202156
202157
202158
202605
203104
203105
203106
203107
204809
812164
832125
844774
847566
861484
861485
861486
861487
861525
867505
867523
867524
867526
867527
867535
869629
869634
Model
2
3
4
6
Model
7
10
QUANTITY
MODELS -3
1
-
-
-
-
1
-
1
-
3
3
1
3
9
1
-
1
-
-
-
-
-
-
3
-
-
1
1
-4
1
-
-
-
-
1
1
-
3
-
3
1
3
9
1
1
-
-
-
-
-
3
1
-
-
-
1
1
-6
1
-
-
-
-
1
-
1
-
3
3
1
3
9
1
-
-
1
-
-
-
3
1
-
-
-
1
1
-2
1
-
-
-
-
1
1
-
3
-
3
1
3
9
1
-
-
-
-
1
-
-
-
3
-
-
1
1
-10
-
-
-
1
1
1
-
-
-
-
-
1
3
3
1
-
-
-
1
-
-
-
-
3
-
-
-
1
-7
-
1
1
-
-
1
-
-
-
-
-
1
-
-
1
-
-
-
-
-
3
-
-
-
3
1
-
1
NAME OF PART
Transducer Housing
Transducer Housing
Ring Gear 38T
Transducer Housing
Ring Gear 50T
Transducer
2nd Red. Spider
2nd Red. Spider
2nd Red. Gear 18T (incl. 844774)
2nd Red. Gear 15T (incl. 844774)
2nd Gear Pin
Ring Gear Pin
Gear Pin
2nd Red. Gear Bearing
Transducer Bearing
Spider 13T (incl. Pin)
Spider 19T (incl. Pin)
Spider 19T (incl. Pin)
Spider -(incl. 832125)
Spider 13T (incl. Pin)
Idler Gear Pin
1st Red. Gear 17T (incl. 844774)
Rotor Pinion 16T
Idler Gear 21T (incl. 844774)
Idler Gear 11T & 22T
Spider
Ring Gear 50T
Retainer Ring
2nd Red. Spider (Incl. Spider, Gears and Pins)
201307
201308
201309
201308
1st Red. Spider (Incl. Spider, Gears and Pins)
861488
------------
Gear Train (Incl. 1st & 2nd Red. Spider, Gears and Pins)
201350
201351
201352
201353
Gear Train (Incl. 1st & 2nd Red. Spider, Gears and Pins)
------------
------------

16
55NLTVC MOTOR
PARTS LIST—MOTOR ASSEMBLY
PART NO. NAME OF PART QTY.
202396 MOTOR SPACER 1
203099 ROTOR (NLT) 1
203101 CYLINDER (INCL. 863887) 1
619377 FRONT ROTOR BEARING 1
843444 REAR ROTOR BEARING 1
863887 CYLINDER PIN 1
865352 ROTOR LOCK NUT 1
867536 FRONT BEARING PLATE 1
869569 ROTOR BLADE 5
869572 REAR BEARING PLATE 1
203374 DRIVE SHAFT 1
203374 202396
619377 867536 203101 869572
843444
865352
203099
869569
863887
55NLTVC MOTOR HOUSING AND HANDLE
203259 Neg. Common
203350 Pos. Common
203450
863241
203369
203363
203365
203368
203367
844265
864531
844309
832595
864375
202174
864530
865063
864195
812164
203053
617754
203549
203378
203379
203418
203550
203380
203377
863399
203553
202171
203263
203262
203261
202401
202183
202012
202182
203376
864533
813315
864030
864030
202724
847981
617754
847710
863454
812023
203366

17
PART NO.
2O2012
202171
202174
202182
202183
202401
202724
203053
203259
203261
203262
203263
203350
203363
203365
203366
203367
203368
203369
203376
203377
203378
203379
203380
203418
203549
203450
203550
203553
617754
812023
812164
813315
832595
844265
844309
847710
847981
863241
863399
863454
864030
864195
864375
864530
864531
864533
865063
PARTS LIST 55NLTVC MOTOR HOUSING AND HANDLE
NAME OF PART
Muffler
Shut-off Valve Seat
Throttle Valve*
Handle
Cable Connector
Motor Housing
Pipe Cable Protector
Retaining Ring
PC Board (Negative Common)**
Exhaust Deflector**
Light Ring (Front) (incl. 2, 864030)**
Light Ring (Rear)**
PC Board (Positive Common)**
Solenoid*
ValvePlunger*
Solenoid Valve Spring*
Solenoid Seat Gasket*
SolenoidSeat*
Solenoid Retainer (incl. 863241)*
Air Inlet
Valve Piston (incl. 866399)*
Shut-off Valve (incl. 203379)*
Valve Seal
Valve Cap* (incl. 847710)
Throttle Valve Spring*
Bushing*
Wire Bundle (19 pin) (29")
Shut-off Valve Cap* (incl. 863454)
Backhead (incl. 203549, 812164, 864530)*
"O"-Ring 2" x 2/8"**
Set Screw (3/16")**
Roll Pin*
Set Screw (1/8")**
Spring*
Ball 1/8" Dia.*
"O"-Ring 7/16" x 5/8"*
"O"-Ring 1/2" x 5/8"*
"O"-Ring 1/8" x 1/2"**
Adjustment Screw*
"O"-Ring 7/16" x 9/16"*
"O"-Ring 9/16" x 11/16"*
Dowel Pin
Roll Pin*
Seal*
Bushing*
Cap*
Screen
Throttle Lever*
The handle can be purchase as a subassembly using part no. 201405.
*Parts included in handle subassembly 201405.
The Light Kit can be purchased as a subassembly using part no. 201402 —
Positive Common, 201300 —Negative Common.
**Parts included in light kit subassembly 201402 and 201300.
QUANITY
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
3
1
1
1
2
1
1
1
1
1
1

18
PART NO.
203387
203389
203390
203391
203392
203393
203496
203497
203710
203950
203951
382633
512077
812023
812667
842274
842517
847219
867520
867521
867522
867546
867548
867641
867642
867997
869013
869025
867522
867521867520842517
203387 203391 8675480
203393
203390
812667
867546
203951
512077
869013 869025842274
867641
382633
847219
867642
203389 STD.
203496 OPT.
867997
203950 812023
203710
203392 STD.
203497 OPT.
DESCRIPTION
ANGLE HEAD
SQUARE DRIVE SPINDLE
BEARING SLEEVE
PINION
SPRING
NEEDLE BEARING
1" EXTENDED SPINDLE
SPRING
INTERNAL HEX. SPINDLE
DRIVE SPINDLE
GEAR
SPLINE PROTECTOR CLIP
RETAINING RING
SET SCREW**
DRIVE SPINDLE
BALL
BALL BEARING
LOCK PIN SPRING*
HOUSING MAKE-UP PLATE†
HOUSING LOCK NUT†
HOUSING CLAMP RING†
PIPE PLUG
NEEDLE BEARING
SPRING RETAINER*
SOCKET LOCK PIN*
SET SCREW#
BEARING CAP
O-RING
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
24
1
1
1
1
1
1
1
1
1
1
1
1
1/4" INTERNAL HEX.
HOLD & DRIVE SPINDLE
"T" RIGHT ANGLE
HOLD & DRIVE HEAD
THE "T" HOLD & DRIVE FITS ON THE STANDARD
GEAR TRAINS.
†PARTS NOT INCLUDED IN SUBASSEMBLIES
*INCLUDED ON 203389 & 203496
**INCLUDED ON 203710
#INCLUDED ON 869013
COMPLETE ANGLE HEAD SUBASSEMBLIES:
STANDARD 3/8" SQUARE DRIVE01603
1" EXTENDED 3/8" SQUARE DRIVE01604
1/4" INTERNAL HEX. DRIVE01605
50 FT. LBS.(68 Nm) MAXIMUM
RECOMMENDED TORQUE

19
PART NO.
204343
204344
204345
204346
204347
204348
204349
204350
204355
204356
617290
622772
842160
847659
864710
864711
864712
867546
867924
867997
869880
"V" RIGHT ANGLE
HOLD & DRIVE HEAD
204347 204348847659
204343 204356 869880
204350
867546
204355
622772
204345
617290842160
864710
864711
864712
204346
867997
204344
867924
204349
DESCRIPTION
ANGLE HEAD
DRIVE SPINDLE
BEARING CAP
HOLD SPINDLE
CLAMP RING†
CLAMP NUT†
SPRING
NEEDLE BEARING
DRIVEN GEAR
PINION
"O"-RING
RETAINING RING
BALL
BALL BEARING
LOCK PIN RETAINER*
SOCKET LOCK PIN*
LOCK PIN SPRING*
PIPE PLUG
RETAINER RING
SET SCREW
ROLLER BEARING
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
22
1
1
1
1
1
1
1
1
†PARTS NOT INCLUDED IN SUBASSEMBLY
*INCLUDED ON 204346
COMPLETE ANGLE HEAD SUBASSEMBLY - 201698
110 FT. LBS. (150Nm) MAXIMUM
RECOMMENDED TORQUE

20
PART NO.
202605
203106
203107
204351
204352
204353
204354
204809
812164
832125
844774
847566
861484
861485
861486
861525
867523
867524
867526
869629
869634
55 "V" RIGHT ANGLE HOLD &
DRIVE HEAD GEAR TRAINS
844774
204353 TRANS.
204354 NON-TRANS.
832125
Part No. Model
204351 -2
204352 -3
204351 -4
204352 -6
Part No. Model
203106 -2
203107 -3
203106 -4
203107 -6 204809
Part No. Model
861525 -2
861485 -3
861484 -4
861486 -6
Part No. Model
867526 -2
867526 -3
867523 -4
867523 -6
Part No. Model
NONE -2
NONE -3
867524 -4
867524 -6
-2, -3, -4, & -6 GEAR TRAINS
869629
TRANSDUCERIZED ONLY
847566
869634
202605
812164
Part No. Model
844774 -2
844774 -3
844774 -4
844774 -6
QUANTITY
MODELS -3
1
-
-
-
1
1
1
3
1
3
9
1
-
1
-
-
-
-
3
1
1
-4
1
-
3
1
-
1
1
3
1
3
9
1
1
-
-
-
3
1
-
1
1
-6
1
-
-
-
1
1
1
3
1
3
9
1
-
-
1
-
3
1
-
1
1
-2
1
3
-
1
-
1
1
3
1
3
9
1
-
-
-
1
-
-
3
1
1
NAME OF PART
Transducer
2nd Red. Gear 18T (incl. 844774)
2nd Red. Gear 15T (incl. 844774)
2nd Red. Spider
2nd Red. Spider
Transducerized Housing
Non-Transducerized Housing
2nd Red. Gear Pin
Ring Gear Pin
Gear Pin
Gear Bearing
Transducer Bearing
Spider 13T (incl. Pin)
Spider 19T (incl. Pin)
Spider 19T (incl. Pin)
Spider 13T (incl. Pin)
1st Red. Gear 17T (incl. 844774)
Rotor Pinion 16T
1st Red. Gear 21T (incl. 844774)
Ring Gear 50T
Retainer Ring
