Clek FLLO User manual

0012345 7
WARNING
• Read and understand product
labels and all instructions in
this manual and in your vehicle
owner’s manual before installing
or using this car seat.
• Failure to properly install or
use this car seat or follow these
warnings and those on this car
seat’s labels can result in serious
injury or death to the child
in a sharp turn, sudden stop
or crash.
C03-1422-B1-US November 2014
Fllo Instruction Manual
This car seat is designed for use either Rear-Facing or Forward-Facing by children who meet
all of the following requirements:
HEIGHT WEIGHT AGE
25 – 43 in.
64 – 110 cm 14 – 50 lb 6.4 – 22.7 kg Able to sit upright alone
HEIGHT WEIGHT AGE
30 – 49 in.
76 – 124 cm 22 – 65 lb 10 – 29.5 kg
2+ years
recommended
(min. 1 year)

i
Checklist for Proper Use
IMPORTANT: This is only a checklist — you must read and understand all of the warnings and
instructions on this car seat’s labels and in this manual before installing or using this car seat.
When Using This Car Seat in Rear-Facing Mode
√ Child weighs between 14 and 50 lb (6.4 and 22.7 kg), height is between 25 and 43 in.
(64 and 110 cm) and able to sit upright alone.
√ Car seat is securely installed in a vehicle rear seat.
– If car seat must be installed in a front seat, the front air bag for that position is
deactivated and the vehicle owner’s manual states that this is an acceptable position to
install a Rear-Facing child restraint.
√ LATCH lower anchor belt or vehicle belt is correctly routed under Seat Cushion in the Rear-
Facing belt path and there is no slack in the LATCH lower anchor belt or the vehicle belt.
– If child weighs more than 35 lb (15.9 kg), this car seat must be installed with a Vehicle
Belt.
√ Recline Foot is in the Rear-Facing position and Car Seat is reclined so that the Rear-Facing
reference line appropriate for the child’s weight is parallel to the ground.
√ The top of the child’s head is at least 1” (2.5 cm) below the top of the car seat Headrest.
√ Shoulder Harness Straps MUST be through Shoulder Harness Slots closest to and at or
below the shoulder of the child.
√ Bottom of Headrest is at or above the Shoulder Harness Slots in use.
√ Crotch Strap is through Crotch Strap Slot at or behind and closest to the child’s crotch.
√ Harness is buckled and snugly adjusted on child.

ii 1 ii
When Using This Car Seat in Forward-Facing Mode
√ Child weighs between 22 and 65 lb (10 and 29.5 kg), height is between 30 and 49 in. (76
to 124 cm) and is at least 1 year of age.
√ Car seat is securely installed in a vehicle rear seat without the Anti-Rebound Bar.
– If car seat must be installed in a front seat, the front air bag for that position is
deactivated, check the vehicle owner’s manual for proper use of a child restraint in
that position.
√ Car seat is correctly attached to the vehicle using either the LATCH Belt and Top Tether, or
the vehicle belt and Top Tether.
– If child weighs more than 40 lb (18.1 kg), this car seat
must be installed with the Vehicle Belt and the Top
Tether.
√ Recline Foot is in the Forward-Facing position.
√ The top of the child’s ears are at or below the top of the
car seat Headrest.
√ Shoulder Harness Straps MUST be through Shoulder
Harness Slots closest to and at or above shoulders of child.
√ Bottom of Headrest is at or above the Shoulder Harness
Slots in use.
√ Crotch Strap is through Crotch Strap Slot at or behind and
closest to the child’s crotch.
√ Harness is buckled and snugly adjusted on child.
For concerns related
to parts or the use and
maintenance of this
product, please contact
us at:
Clek Inc.
Attn: Customer Service
226 Lesmill Rd.
Toronto, Ontario
Canada M3B 2T5
1-866-656-2462
www.clekinc.com
Table of Contents
Checklist for Proper Use ....................................................................................... i
When Using This Car Seat in Rear-Facing Mode ............................................... i
When Using This Car Seat in Forward-Facing Mode ......................................... ii
Car Seat Features .............................................................................................. 3
Registration & Recall Information ......................................................................... 5
Registering Your Car Seat ............................................................................. 6
Warnings ......................................................................................................... 7
Certification .................................................................................................... 12
Size & Age Limitations ...................................................................................... 12
AAP Recommendations ............................................................................... 13
When Using This Car Seat in Rear-Facing Mode ............................................ 13
When Using This Car Seat in Forward-Facing Mode ....................................... 15
Adjusting Car Seat to Fit Your Child .................................................................... 16
Installing Headrest ..................................................................................... 16
Adjusting Headrest ..................................................................................... 17
Crotch Strap Adjustment ............................................................................. 18
To Lengthen the Crotch Strap ................................................................ 19
Shoulder Harness Adjustment ...................................................................... 20
Shoulder Harness Slot Selection ............................................................ 21
Shoulder Harness Unthreading .............................................................. 21
Shoulder Harness Rethreading .............................................................. 23
To Lengthen/Shorten the Shoulder Harness Webbing ......................... 24
Vehicle Information .......................................................................................... 26
Vehicle Child Restraint Anchorage System (LATCH) ......................................... 26
Vehicle Seat Location Requirements .............................................................. 27
® Clek and Clek logos, Olli, Ozzi, Oobr, Foonf and Fllo are registered trademarks of Clek Inc.
For a complete list of Clek Inc. trademarks please visit clekinc.com/trademarks.

23
Vehicle Belt Requirements ........................................................................... 29
Vehicle Belt Systems ................................................................................... 30
Installing/Removing Rear-Facing Car Seat ............................................................ 33
Installing Rear-Facing Car Seat With LATCH .................................................. 35
Removing Rear-Facing Car Seat Installed With LATCH ..................................... 42
Installing Rear-Facing Car Seat With Vehicle Belt ........................................... 43
Removing Rear-Facing Car Seat Installed With Vehicle Belt ............................... 51
Installing/Removing Forward-Facing Car Seat ...................................................... 52
Installing Forward-Facing Car Seat With LATCH ............................................. 54
Removing Forward-Facing Car Seat Installed With LATCH ................................ 61
Installing Forward-Facing Car Seat With Vehicle Belt ...................................... 63
Removing Forward-Facing Car Seat Installed With Vehicle Belt ........................ 69
Securing Your Child in Car Seat .......................................................................... 71
Removing Your Child From Car Seat ............................................................. 77
Operation and Adjustments ............................................................................... 78
Removing/Installing Seat Cushion ................................................................ 78
Installing/Removing Anti-Rebound Bar ........................................................... 79
LATCH Belt Storage ................................................................................... 82
Top Tether Storage .................................................................................... 84
Instruction Manual Storage ......................................................................... 84
Aircraft Installation .......................................................................................... 85
Care and Cleaning ........................................................................................... 86
Removing/Installing Shoulder Harness Covers ................................................ 86
Removing/Installing Seat Cushion Cover ....................................................... 87
Car Seat Cleaning ..................................................................................... 89
Recycling Your Car Seat ............................................................................. 90
Troubleshooting ............................................................................................... 91
Accessories ..................................................................................................... 91
Warranty ....................................................................................................... 92
Car Seat Features – Front
1 Seat Cushion
2 Shoulder Harness Slots
3 Shoulder Harness Covers
4 Shoulder Harness Straps
5 Chest Clip
6 Buckle Tongues
7 Buckle
8 Crotch Strap
9 Buckle Pad
10 Harness Adjuster
11 Harness Adjuster Strap
12 Seat Base
13 Rear Facing Belt Path
14 Headrest
15 Headrest Adjuster
16 LATCH Belt Storage (under Seat Cushion)
17 Crotch Strap Slots
18 LATCH Belt
19 LATCH Push on Connector
20 Rear-Facing Belt Lock-offs
2
4
18
16
17
33
5
19
19
20
20
7
8
9
1
10
11
6
15
14
13
12

45 4
Car Seat Features – Back
21 Seat
22 Top Tether
23 Tether Adjuster
24 Tether Hook
25 Tether Storage (behind manual)
26 Forward-Facing Shoulder Belt Lock-offs
27 Forward Facing Belt Guides
28 Shoulder Harness Access Panel
29 Shoulder Harness Straps
30 Metal Harness Plate
31 Instruction Manual (stored in Shoulder
Harness Access Panel)
32 Recline Foot (Shown in Rear-Facing
Position)
33 Anti-Rebound Bar
34 Anti-Rebound Bar Locking Pins and
Locking Pin Clips
21
22 23
24
26
28
29
27 27
30
29
25
0012345 7
WARNING
• Read and understand product
labels and all instructions in
this manual and in your vehicle
owner’s manual before installing
or using this car seat.
• Failure to properly install or
use this car seat or follow these
warnings and those on this car
seat’s labels can result in serious
injury or death to the child
in a sharp turn, sudden stop
or crash.
C03-1422-US Ju ne2014
Fllo Instruction Manual
This car seat is designed for use either Rear-Facing or Forward-Facing by children who meet
all of the following requirements:
HeigHt WeigHt Age
25 – 43 in.
64 – 110 cm
14 – 50 lb
6.4 – 22.7 kg
Able to sit
upright alone
HeigHt WeigHt Age
30 – 49 in.
76 – 124 cm
22 – 65 lb
10 – 29.5 kg
2+ years
recommended
(min. 1 year)
31
33
34 34
lowered recline foot
Raised recline foot
32
Registration & Recall Information
WARNING
• Child restraints could be recalled for safety reasons. You must register this
restraint (car seat) to be reached in a recall.
Model Name: _____________________________________________________________________
Serial Number: ___________________________________________________________________
Manufactured In: __________________________________________________________________
(yyyy/mm/dd)
Date of Purchase: __________________________________________________________________
FLLO

67 6
Registering Your Car Seat
Please ll in the information on the previous page for your
records. The model name, serial number and manufacturing
date can be found on a label afxed to the back of this Car
Seat.
Fill out the prepaid registration postcard attached to the
car seat and mail it today.
Child restraints could be recalled for safety reasons. You must
register this restraint to be reached in a recall. Send your
name, address, e-mail address if available, and the restraint’s
model number and manufacturing date to:
Clek Inc.
226 Lesmill Rd.
Toronto, Ontario, Canada M3B 2T5
or call 1-866-656-2462
or register online at http://www.clekinc.com/register
For recall information, call the U.S. Government’s Vehicle
Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153), or
go to http://www.NHTSA.gov.
Warnings
WARNING — DEATH or
SERIOUS INJURY can occur
Failure to properly install or use this car seat or follow these warnings and
instructions and those on this car seat’s labels can result in serious injury or
death of the child in a sharp turn, sudden stop or crash.
• Do not install or use this car seat until you read and understand the
instructions in this manual and in your vehicle owner’s manual. Do not let
others install or use this car seat unless they understand how to correctly
install and use it.
• Never use this car seat Rear-Facing in a vehicle front seating location with
an air bag.
• Use only with children who weigh between 14 and 65 lb (6.4 – 29.5
kg) and whose height is 49 in. (124 cm) or less and who are capable of
sitting upright alone.
• Use only in a Rear-Facing position when using this car seat with an infant
less than one year old and weighing less than 22 lb (10 kg).
• Failure to choose the correct car seat mode (Rear-Facing or Forward-
Facing) and to properly secure this car seat and your child can increase
the risk of injury or death.

89 8
WARNING — DEATH or
SERIOUS INJURY can occur (continued)
• Never use this car seat with children not able to sit upright alone. Their
head may fall forward, which could restrict their ability to breathe.
• Discontinue Rear-Facing use when:
– Child’s weight exceeds 50 lb (22.7 kg).
– Child’s height exceeds 43 in. (110 cm).
– Child’s head is less than 1” (2.5 cm) from the top of the car seat’s
Headrest in its highest adjustment position.
• Discontinue Forward-Facing use when:
– Child’s weight exceeds 65 lb (29.5 kg).
– Child’s shoulders are above the top Shoulder Harness Slots.
– Top of child’s ears are above the top of the car seat’s Headrest in its
highest adjustment position.
• This car seat must be installed by an adult.
• Never allow the child to buckle themselves in this car seat.
• Snugly adjust Harness provided with this car seat around child.
WARNING — DEATH or
SERIOUS INJURY can occur (continued)
• Always use the Buckle Pad supplied with this car seat for children
weighing up to 22 lb (10 kg).
• Never use the longer Crotch Strap length in the rear Crotch Strap Slot.
• Never use this seat without the Headrest.
• Do not use this child restraint with motorized or door mounted belt
systems.
• Secure this child restraint with the vehicle’s child restraint anchorage system
if available or with a vehicle belt as shown in this instruction manual.
• LATCH Belt or vehicle belt must stay tightly adjusted on car seat at all
times.
• When using this car seat in Rear-Facing mode with a child weighing more
than 35 lb (15.9 kg), this car seat must be installed with a Vehicle Belt.
• When using this car seat in Forward-Facing mode with a child weighing
more than 40 lb (18.1 kg), this car seat must be installed with a Vehicle
Belt and Top Tether.
• ALWAYS secure the Top Tether provided with this car seat when installing
Forward-Facing with the LATCH Belt or a lap belt. NEVER use this car
seat, when installing Forward-Facing with the LATCH Belt or a lap belt,
without the Top Tether.

10 11
WARNING — DEATH or
SERIOUS INJURY can occur (continued)
• ALWAYS secure the Top Tether provided with this car seat when installing
Forward-Facing with lap/shoulder belt unless no Top Tether anchorage is
available.
• When using this seat Forward-Facing with a child up to 40 lbs (18.1 kg)
and installing with a vehicle belt, without a Top Tether:
– NEVER attach the Metal Harness Plate to the loops for larger children
at the ends of the Shoulder Harness Straps. Always attach the Metal
Harness Plate to the loops, for smaller children, further in from the end
of the Shoulder Harness Straps.
– ALWAYS use the Buckle Pad supplied with this Car Seat.
• Do not use this car seat after a crash of any kind. A crash can cause
damage to this car seat that you cannot see.
• Always securely attach this car seat to the vehicle, even when not
occupied. An unsecured car seat can injure other occupants in a crash.
• Never leave child unattended.
• Never leave child in car seat when Harness is not buckled and properly
adjusted, children can strangle on loose Harness straps.
WARNING — DEATH or
SERIOUS INJURY can occur (continued)
• Do not use this car seat after nine (9) years from the date of manufacture.
The date of manufacture can be found on the label afxed to the back of
this car seat’s base.
• Do not use accessories or parts with this car seat other than those
provided by Clek Inc. Use of accessories or parts from other manufacturers
could alter the performance of this car seat.
• Do not attempt to make repairs to or otherwise modify or tamper with this
car seat.
• Never use this car seat if it is damaged or is missing parts.
• Keep this manual in the storage compartment located on the back of this
car seat for future use.
• Never use a second-hand car seat or a car seat whose history you do not
know.
• Register your child restraint with Clek Inc.
• Avoid burn injury — always touch the surfaces that will contact your child
rst before putting them in this car seat. This car seat can become very hot
if left in the sun and can burn your child’s skin.

12 13
Certification
• This child restraint system conforms to all applicable Federal Motor Vehicle Safety
Standards.
• This restraint is certied for use in Motor Vehicles and Aircraft.
Size & Age Limitations
WARNING
• Use only in a Rear-Facing position when using this car seat with an infant
less than one year old and weighing less than 22 lb (10 kg).
• Failure to choose the correct car seat mode (Rear-Facing or Forward-
Facing) and to properly secure this seat and your child can increase the
risk of injury or death.
• Never use this seat with children not able to sit upright alone. Their head
may fall forward, which could restrict their ability to breathe.
When Using This Car Seat in Rear-Facing Mode
• All infants less than one year old or 22 lb
(10 kg) MUST be Rear-Facing.
• Child’s weight is between 14 and 50 lb
(6.4 and 22.7 kg), AND
• Child’s height is between 25 and 43 in.
(64 and 110 cm), AND
• Child is able to sit upright alone, AND
• If child weighs more than 35 lb (15.9 kg),
this car seat must be installed with the
vehicle belt.
American Academy of Pediatrics (AAP) Recommendation
The AAP advises parents to keep their toddlers in Rear-Facing car seats until age 2, or until
they reach the maximum height and weight for their seat.

14 15
• The top of the child’s head must be at
least 1” (2.5 cm) below the top of the car
seat’s Headrest, as shown in Figure 1.
If the top of the child’s head is less than
1” (2.5 cm) below the top of the Headrest
in the highest adjustment position, your
child is too large for using this car seat
Rear-Facing and must be transitioned to
Forward-Facing use with this car seat.
• The Shoulder Harness Straps must be
through Shoulder Harness slots at or below
and closest to the child’s shoulders, as
shown in Figure 2.
Figure 1
Figure 2
1”
When Using This Car Seat in Forward-Facing Mode
• Child’s weight is between 22 and 65 lb
(10 and 29.5 kg), AND
• Child’s height is between 30 and 49 in.
(76 and 124 cm), AND
• Child is at least 1 year of age, AND
• The tops of the child’s ears MUST be below
the top of the car seat’s Headrest, as shown
in Figure 3. If the tops of the child’s ears
are above the top of this car seat’s Headrest
in the highest adjustment position, your
child is too large for this car seat.
• The Shoulder Harness Straps must be
through Shoulder Harness slots at or above
and closest to the child’s shoulders, as
shown in Figure 4. If the child’s shoulders
are above the highest set of Shoulder
Harness Slots in the car seat’s seat back,
your child is too large for this car seat.
• If child weighs more than 40 lb (18.1 kg),
this car seat must be installed with the
vehicle belt and Top Tether.
Figure 3 Figure 4

16 17
Adjusting Car Seat to Fit Your Child
WARNING — DEATH or
SERIOUS INJURY can occur
• Never use this car seat without the Headrest.
Figure 5
IMPORTANT: This Car Seat is shipped
without the Headrest attached. The Headrest
must be installed on the seat prior to use.
Installing Headrest
Insert the Headrest support rods into the
Headrest guides in the top of the seat back
as shown in Figure 5 and push the headrest
down until it locks into position.
NOTE: It may be necessary to rock the
Headrest back and forth from front to back in
order to get the support rods into the guides.
Figure 6
Adjusting Headrest
Step 1
Press the button on the Headrest Adjuster
on the right-hand side of the seat (when
facing front of seat) (1) and raise or lower
the Headrest into the desired position (2) as
shown in Figure 6.
Step 2
Check for proper adjustment of Headrest.
The bottom of the Headrest must always be
at or above the Harness Slots in use.
Rear-Facing: The top of the child’s head must
be at least 1” (2.5 cm) below the top of the
car seat’s Headrest, as shown in Figure 7.
If the top of the child’s head is less than 1”
(2.5 cm) below the top of the Headrest in the
highest adjustment position, your child is too
large for using this car seat Rear-Facing and
must be transitioned to Forward-Facing use
with this car seat.
Forward-Facing: The tops of the child’s ears
MUST be below the top of the car seat’s
Headrest, as shown in Figure 8. If the tops
of the child’s ears are above the top of this
car seat’s Headrest in the highest adjustment
position, your child is too large for this car
seat.
2
1
Figure 8
Figure 7
1”

18 19
Figure 9
Crotch Strap Adjustment
Check position of Crotch Strap:
• The Crotch Strap must be through the
Crotch Strap Slot located at or behind
and closest to the front of the child’s
crotch as shown in Figure 9.
Step 1
Remove the Seat Cushion, see “Removing/
Installing Seat Cushion” on page 78.
Step 2
To move the Crotch Strap from one position
to the other:
• Slide the belt to one side of the Crotch
Strap Slot and push the edge of the
belt into the adjustment slot as shown in
Figure 10.
• Slide the Crotch Strap into the other
Crotch Strap Slot as shown in Figure
11, ensuring that the red release button
on the buckle faces out of the seat as
shown in Figure 12.
Figure 10
Figure 11 Figure 12
Step 3
NOTE: For larger children, the Crotch Strap
can be lengthened and installed in the
forward Crotch Strap Slot.
IMPORTANT: NEVER use the longer Crotch
Strap length in the rear Crotch Strap Slot.
TO LENGTHEN THE CROTCH STRAP
• Slide the belt to one side of the Crotch
Strap Slot and push the edge of the
belt into the adjustment slot as shown in
Figure 13.
• Slide the crotch strap out of the Crotch
Strap Slot as shown in Figure 14.
• Select the longer Crotch Strap length
and slide the crotch strap into the outer
Crotch Strap Slot as shown in Figure
15, ensuring that the red release button
on the buckle faces out of the seat as
shown in Figure 16.
Step 4
Install the Seat Cushion, see “Removing/
Installing Seat Cushion” on page 78.
Figure 14
Figure 13
Figure 15 Figure 16

20 21
WARNING — DEATH or
SERIOUS INJURY can occur
• To prevent ejection in a crash, the loops at the end of the Shoulder
Harness Straps must be properly attached to the Metal Harness Plate.
• To prevent loose Harness and risk of ejection in a crash, Harness must be
properly routed under bottom of seat back cover.
• To prevent loose Harness and risk of ejection in a crash, the Shoulder
Harness Straps must be routed through Shoulder Harness Slots at the
same height on each side and in the pad and seat back.
Shoulder Harness Adjustment
Figure 18
Figure 17
Figure 19
SHOULDER HARNESS SLOT SELECTION
Place child in seat and select the appropriate
set of Shoulder Harness Slots for the direction
child is facing.
For Rear-Facing Use: Choose the Shoulder
Harness Slots at or just below and closest
to the shoulders of your child as shown in
Figure 17.
For Forward-Facing Use: Choose the
Shoulder Harness Slots at or just above
and closest to the shoulders of your child as
shown in Figure 18.
SHOULDER HARNESS UNTHREADING
Step 1
Loosen Harness to largest size:
• While lifting up on Harness Adjuster
Tab, pull out on Shoulder Harness Straps
until they stop as shown in Figure 19.

22 23
Step 2
Remove Top Tether from storage. See “Top
Tether Storage” on page 84.
Step 3
Remove Shoulder Harness Access Panel from
back of car seat:
• Twist the access panel lock counter-
clockwise and pull to remove as shown
in Figure 20.
Step 4
Remove loops at ends of Shoulder Harness
Straps from Metal Harness Plate by sliding
strap out through slot in Metal Harness Plate
as shown in Figure 21.
Step 5
From front of car seat, pull Shoulder Harness
Straps out of seat back.
Figure 21
Figure 20 Figure 22
SHOULDER HARNESS RETHREADING
Step 1
Check that Harness Straps are not twisted
and from front of seat, insert Shoulder
Harness Straps through the chosen Shoulder
Harness Slots as shown in Figure 22. Straps
MUST go through the Shoulder Harness Slots
at the same height on each side
Step 2
Route Shoulder Harness under bottom of seat
back cover (1) as shown in Figure 23.
1
Figure 23

24 25
Figure 24
Step 3
Attach desired loops at end of Shoulder
Harness Straps to Metal Harness Plate by
sliding strap into slot in plate as shown in
Figure 24.
TO LENGTHEN THE SHOULDER
HARNESS WEBBING
For larger children: to make the
Harness longer, attach the Metal
Harness Plate to the loop at the end of
the Shoulder Harness Strap as shown in
Figure 25.
IMPORTANT: Never use this harness
position when using with a child up to
40lb (18.1kg) and installing forward-
facing without a top tether.
TO SHORTEN THE SHOULDER HARNESS
WEBBING
For smaller children: to make the
Harness shorter, attach the Metal
Harness Plate to the loop further in from
the end of the Shoulder Harness Strap
as shown in Figure 26.
Figure 25
Figure 26
Figure 28
Check that both Shoulder Harness Straps are
attached to the Metal Harness Plate on the
same loop while ensuring that each Shoulder
Harness Strap is completely inside the slot in
metal Harness Plate as shown in Figure 27.
Step 4
Reattach Shoulder Harness Access Panel to
back of car seat:
• Insert the access panel and twist the
access panel lock clockwise as shown in
Figure 28.
Step 5
If installing this car seat rear-facing, store
the Top Tether. See “Top Tether Storage” on
page 84.
Figure 27

26 27 26
Vehicle Information
Vehicle Child Restraint Anchorage System (LATCH)
• LATCH stands for Lower Anchors and Tethers for Children.
This term refers to the anchors built into a vehicle for
attaching child restraints and consists of two lower anchors
at the crease between the vehicle seat back and vehicle
seat cushion and a top tether anchor behind the vehicle
seat as shown in Figure 29.
• 2003 or newer model year vehicles have at least two
seating locations with a LATCH Anchorage System.
Some 2001 and 2002 model year vehicles have LATCH
Anchorage Systems. 2000 model year vehicles or older
DO NOT have LATCH Anchorage Systems. See your
vehicle owner’s manual if you are unsure if your vehicle is
equipped with a LATCH Anchorage System.
• See your vehicle owner’s manual for seating positions
which can be used with LATCH.
• If not readily visible, the LATCH lower anchors may be
noted by a symbol located near the crease between the
vehicle seat back and vehicle seat cushion, as shown in
Figure 30.
• If covered, the LATCH top tether anchor locations may be
identied by a symbol as shown in Figure 31.
Figure 29
Figure 30
Figure 31
Vehicle Seat Location Requirements
• Before using this car seat, reference your vehicle owner’s
manual for:
– Car seat installation instructions
– Information about air bags and car seat use
• For a toddler over one year old and Forward-Facing, if a
vehicle front seat location with an air bag must be used,
follow the vehicle manufacturer’s instructions for child
restraint use and move the vehicle seat back as far as
possible.
WARNING
• According to accident statistics,
children 12 and under are safer
when properly restrained in rear
vehicle seating positions, rather
than front seating positions.

28 29 28
WARNING — DEATH or
SERIOUS INJURY can occur
• Do not use this child restraint Rear-Facing in a front
vehicle seat location with an air bag. Child’s head
and neck may be seriously injured when an inating
air bag hits back of child restraint.
• Never use this car seat in a front vehicle seat location
unless recommended by your vehicle owner’s manual.
• Improper placement of this car seat in your vehicle
increases the risk of serious injury or death. Some
seating positions in your vehicle may not be safe for
this car seat. Some vehicles do not have any seating positions that can
be used safely with this car seat. If you are not sure where to place this
car seat in your vehicle, consult your vehicle owner’s manual or call
1-866-656-2462.
DO NOT place rear-facing child seat on front
seat with air bag. DEATH OR SERIOUS
INJURY can occur. The back seat is the safest
place for children 12 and under.
NE PAS placer un siège d’enfant faisant face à
l’arrière sur le siège avant doté d’un coussin
gonflable. LA MORT OU DES BLESSURES
GRAVES pourraient s’ensuivre. Le siège arrière
est l’endroit le plus sécuritaire pour les enfants
de 12 ans et moins.
WARNING/ADVERTENCIA/
MISE EN GARDE
NO coloque el asiento infantil para el
automóvil orientado hacia atrás en el
asiento delantero del vehículo que
tenga una bolsa neumática de
seguridad. El niño podría MORIR O
SUFRIR LESIONES GRAVES. El asiento
trasero es el lugar más seguro para los
niños de 12 años o menores.
• Install this car seat only on vehicle seats that face forward.
NEVER install this car seat on vehicle seats facing sideways
or backwards, as shown in Figure 32.
• Only use this car seat on vehicle seats with seat backs that
lock in an upright position. Check that the vehicle seat back
is locked in an upright position recommended by the vehicle
owner’s manual for use when installing a child restraint.
Figure 32
Vehicle Belt Requirements
Refer to the vehicle owner’s manual for information regarding
car seat installation and vehicle belt use with a car seat.
WARNING
• Never use this car seat with a vehicle belt that is cut, damaged, frayed or
inoperable.
• Using this car seat with a vehicle belt system unsafe for use with this car
seat can result in serious injury or death. Pay careful attention to these
systems; some of the seat belts that are not safe to use look very much
like seat belts that are safe to use. If you are unsure, consult your vehicle
owner’s manual or call 1-866-656-2462.
• Not all vehicle belts can be used with a car seat. This car seat
must be held tight at all times by the lap belt or lap portion of the
lap/shoulder belt.
• Never use an inatable vehicle belt to secure this car seat.

30 31 30
Figure 34
Vehicle Belt Systems
• NEVER use a passive restraint — lap or shoulder belt
mounted on door, as shown in Figure 33.
• NEVER use a passive restraint — lap belt with a motorized
shoulder belt, as shown in Figure 34.
• NEVER use an inatable vehicle belt.
– Check the belt for labels and refer to your vehicle
owner’s manual.
• Buckle/Lap Belt Anchor Forward of Seat Bight – lap belt or
lap belt portion of a lap/shoulder belt or buckle comes out
of vehicle seat bottom forward of the seat back, as shown
in Figure 35.
– May not allow for secure installation of this car seat
in some cases. Check for movement of car seat after
installation. If car seat is not secure, DO NOT use this
vehicle belt.
Figure 33
Figure 35
Figure 36
Figure 37a
Figure 37
• Retractable Lap Belts – Lap belt is mounted on a retractor
which automatically pulls the lap belt back in when
released, as shown in Figure 36.
– If this type of lap belt is equipped with an Emergency
Locking Retractor (ELR) it should NEVER be used with a
car seat.
– If this type of lap belt is equipped with an Automatic
Locking Retractor (ALR), or a Switchable Locking
Retractor (SLR), it can be used. See your vehicle owner’s
manual for more information on SLR retractor belts. To
check if your retractable lap belt is equipped with an
ALR retractor:
1. Pull the belt all the way out until it stops.
2. Allow the belt to pull back in about 6 in. (15 cm).
3. Pull out on belt again. If the belt will not pull out
again, it is equipped with an ALR retractor.
• Manually Adjustable Lap Belts, see Figure 37 – Length can
be manually adjusted. Does not retract into the vehicle.
– Most manually adjustable lap belts will allow for secure
installation, but if the locking latch plate slides, not
allowing for a secure installation, it may be necessary
to ip the locking latch plate over to get a secure
installation as shown in Figure 37a.

32 33 32
• Lap/Shoulder belts with a sliding latchplate – Shoulder
belt is mounted on a retractor which automatically pulls the
shoulder belt back in when released as shown in Figure
38. Latchplate slides freely along the webbing of the
vehicle belt as shown in Figure 38a.
– If this type of lap/shoulder belt is equipped with an
Emergency Locking Retractor (ELR), it may be used.
– If this type of lap/shoulder belt is equipped with an ELR/
ALR Switchable Locking Retractor (SLR), it can be used.
To check if your lap/shoulder belt is equipped with an
SLR:
1. Slowly pull the shoulder belt all the way out until it
stops.
2. Allow the shoulder belt to pull back in about 6 in.
(15 cm).
3. Pull out on shoulder belt again. If the belt will not pull
out again, it is equipped with a SLR
NOTE: Some vehicle seat belt systems may have a lap/
shoulder belt equipped with a latchplate which appears to
hold the lap portion at a xed length when the belt is pulled
tight. This type of lap/shoulder belt is compatible. It may still
have a switchable locking retractor (SLR).
See your vehicle owner’s manual for more information on
installing a child seat using the vehicle belt.
Figure 38
Figure 38a
Installing/Removing Rear-Facing Car Seat
WARNING — DEATH or
SERIOUS INJURY can occur
• Never use this car seat Rear-Facing in a vehicle front seating location with
an air bag.
• LATCH or vehicle belt must be routed through Rear-Facing Belt Path when
using car seat Rear-Facing.
• LATCH or vehicle belt must stay tightly adjusted around car seat at
all times.
• Failure to properly install or use this car seat increases the risk of serious
injury or death to the child and others in a sharp turn, sudden stop
or crash.
• Recline Foot must be in the Rear-Facing position when this seat is used
Rear-Facing.
• Seat must be installed at the recline angle appropriate for the child’s
weight when using seat Rear-Facing.
• To avoid injury this car seat must be installed by an adult.

34 35
WARNING — DEATH or
SERIOUS INJURY can occur (continued)
• Never leave this car seat unsecured in your vehicle. This car seat must
remain secured even when not in use. In a sharp turn, crash or sudden
stop, an unsecured car seat can be thrown around and could severely
injure vehicle occupants.
• When installing this child restraint Rear-Facing, it must be secured by the
LATCH belt or vehicle seat belt as shown in this instruction manual.
Installing Rear-Facing Car Seat With LATCH
WARNING — DEATH or
SERIOUS INJURY can occur
• Only use the car seat LATCH system in vehicle seating locations
designated by the vehicle manufacturer for use with LATCH and that have
a standard anchor spacing of 11in (280 mm).
• LATCH Push-on Connectors must be secured to the vehicle LATCH lower
anchors only. Connection to other vehicle anchors or vehicle components
could result in the anchor tearing free in a crash.
• Never attach more than one push-on connector to a vehicle lower anchor
unless recommended by the vehicle owner’s manual for that vehicle.
• LATCH belt must be routed through Rear-
Facing Belt Path.
• Do NOT install by this method for a child
weighing over 35 lb (15.9 kg).
LATCH
