Clek Olli User manual

Olli and Ozzi
Instruction Manual
This belt-positioning booster seat (booster seat)
is designed for use by children who meet
these requirements:
March 2020
WARNING
• Read and understand all instructions in this manual and in your vehicle owner’s
manual before installing or using this booster seat.
• The child’s safety depends on you correctly installing and using this booster seat.
Failure to properly install or use this booster seat increases the risk of serious
injury or death to the child and others in a sharp turn, sudden stop or crash.
A01-0021-CA-A2
HEIGHT WEIGHT MINIMUM AGE
101–145 cm
40–57 in.
18–54 kg
40 –120 lb 4+ years

i
Checklist for Proper Use
For proper use read and understand all instructions and booster seat labels.
Child weighs between 18 and 54 kg (40 and 120 lb), height is between
101 and 145 cm (40 and 57 in.)
Child is at least 4 years of age
Child is sitting in the booster seat in a forward facing seating position in a rear seat
of the vehicle
The tops of the child’s ears are below the top of the vehicle seat back or the vehicle
seat’s fully deployed headrest
Shoulder belt crosses midpoint of the child’s chest and is not twisted
Belt is routed correctly beneath armrests and sits low and snug on the child’s hips and
is not twisted
There is no slack in the shoulder belt
Child is sitting upright and is not slouching
Booster seat is securely installed with both UAS Connectors attached to UAS
lower anchors, if available

1
Table of Contents
General Information ................................................................................................. 2
Booster Seat Features ............................................................................................... 3
Registration and Recall Information ............................................................................ 4
Registering Your Booster Seat................................................................................5
Warnings ................................................................................................................ 6
Certification ............................................................................................................. 9
Vehicle Classification ................................................................................................ 9
Height & Weight Limitations ...................................................................................... 9
American Academy of Pediatrics (AAP) Recommendations ................................... 10
Vehicle Requirements .............................................................................................. 11
UAS Anchorage System .......................................................................................... 11
Vehicle Seat Location Requirements ................................................................... 12
Vehicle Seat Belt Requirements .......................................................................... 14
Installing/Removing Booster Seat in Vehicle ........................................................ 16
Installing Booster Seat in Vehicle Using UAS Connectors ...................................... 17
Installing Booster Seat in Vehicle Without Using UAS Connectors .......................... 20
Removing Booster Seat in Vehicle ...................................................................... 21
Securing Child in Booster Seat ................................................................................. 22
Owner’s Manual Storage ........................................................................................ 27
Care & Cleaning .................................................................................................... 28
Service & Accessories ............................................................................................. 32
Warranty .............................................................................................................. 33
Limited Warranty ............................................................................................. 33
Warranty Limitations ........................................................................................ 34
Limitation of Warranties and State/Provincial Law Rights ...................................... 34
® Clek and Clek logos, Olli, Ozzi, and Oobr are registered trademarks of Clek Inc.
For a complete list of Clek Inc. trademarks please visit www.clekinc.com/trademarks.

2
General Information
clek
Designed for kids... Engineered for parents
Safety Features:
• Raises your child 10 cm (4 in.) to improve in-vehicle shoulder belt fit
• Better positions the belt on the child’s hips to improve safety
• Confirms that UAS Connectors are locked with an audible “click”
• Provides a secure, rigid UAS attachment to the vehicle’s seat structure
Convenience:
• Easy installation and removal of booster seat
• Removable and washable seat cover
• Ultra light for easy portability between vehicles
Style/Comfort:
• Plush seating surface
• Engineered energy absorbing comfort-cube construction for added comfort
• Optional seat covers available
For concerns related to the parts, use or maintenance of this product, please contact us at:
Clek Inc.
Attn: Customer Service
226 Lesmill Road
Toronto, Ontario Canada
M3B 2T5
1-866-656-2462
www.clekinc.ca

3
Booster Seat Features
1UAS Connectors
2Belt-routing surface
3Armrests
4comfort-cube
5Quick Release System*
6Removable &
washable seat cover
7drink-thingy*
8Manual Release System
*(olli model only)
WARNING
• Do not use this booster seat if it has damaged or missing parts.
• Do not attempt to make repairs to or otherwise modify or tamper with this
booster seat.
• For instructions on proper removal of the seat cover, see section titled “Care &
Cleaning” in this manual.
• Do not use this booster seat after an accident of any kind. An accident can
cause damage to the booster seat that you cannot see.
1
4
5
6
8
7
3
2

4
Registration and Recall Information
WARNING
Child restraints could be recalled for safety reasons. You must register this
restraint (booster seat) to be reached in a recall.
Model Name: _____________________________________________________________________
Serial Number: ___________________________________________________________________
Date of Manufacture: _______________________________________________________________
(yyyy/mm/dd)
Date of Purchase: _________________________________________________________________

5
Registering Your Booster Seat
Please fill in the information on page 4 for your records. The model name, serial
number and manufacturing date can be found on a label affixed to the underside of the
booster seat frame, as shown in Figure 1.
Fill out the prepaid registration postcard attached to the seat and mail it today.
Child restraints could be recalled for safety reasons. You MUST register this restraint
(booster seat) to be reached in a recall. Send your name, address and the restraint’s
model number and manufacturing date to:
For recall information in Canada, call Transport Canada’s Road Safety Information Centre
at 1-800-333-0371, or go to:
www.tc.gc.ca/en/services/road/defects-recalls-vehicles-tires-child-car-seats/stay-informed.html
Serial No.: 814735 00101
Figure 1
Clek Inc.
226 Lesmill Road
Toronto, Ontario, Canada, M3B 2T5
or call 1-866-656-2462
or register online at: www.clekinc.ca/register

6
Warnings
WARNING
Failure to properly use this booster seat or follow these warnings can result in
serious injury or death of the child. Please read and follow all booster seat and
vehicle instructions carefully.
• Do not install or use this booster seat until you read and understand the instructions
in this manual and in your vehicle owner’s manual. Do not let others install or use
this booster seat unless they understand how to correctly install and use it.
• The child’s safety depends on you correctly installing and using this booster seat.
Failure to properly install or use this booster seat increases the risk of serious injury
or death to the child and others in a sharp turn, sudden stop or crash.
• To avoid injury, this booster seat must be installed by an adult. NEVER allow the
child to buckle themselves in this booster seat.
• Only use this booster seat with children who weigh between 18–54 kg
(40 - 120 lb) and whose height is between 101–145 cm (40 - 57 in.). Using this
booster seat with a child who does not meet these requirements will increase the
risk of serious injury or death to the child.
• Do not use this booster seat after an accident of any kind. An accident can cause
damage to the booster seat that you cannot see.
• Do not use this booster seat if the tops of the child’s ears are above the top of the
vehicle seat back or a fully deployed head restraint on the vehicle seat. Severe
head or neck injuries could result without proper head support.
• NEVER use a seat belt extender with this booster seat.

7
WARNING
• WARNING! Use only the vehicle’s lap and shoulder belt system when restraining
the child in this booster seat. You must properly route the seat belt underneath the
armrests on this booster seat. Do not use this booster seat with motorized, door
mounted, or lap-only belt systems.
• According to accident statistics, children are safer when properly restrained in
rear vehicle seating positions, rather than front seating positions. Before using this
booster seat please reference your vehicle owner’s manual for information about
air bags and booster seat use. NEVER use this booster seat in a front vehicle seat
location unless recommended by your vehicle owner’s manual.
• Install this booster seat only on vehicle seats that face forward. Do not install this
booster seat on vehicle seats facing sideways or backwards.
• ALWAYS secure this booster seat to the vehicle’s UAS anchorage system if
available. This booster seat may still be used in vehicles or rear seat positions
without a UAS anchorage system provided the booster seat is properly positioned
on the vehicle seat and the child and the booster seat are properly secured using
the vehicle’s seat belts.
• Do not use this booster seat in a seating position where the seat belt buckle is not
easily accessible with the booster seat latched in place.
• NEVER leave this booster seat unsecured in your vehicle. This booster seat must
remain connected to the UAS lower anchors in the vehicle or secured by the
vehicle’s seat belt even when not in use. In a sharp turn, crash or sudden stop, an
unsecured booster seat can be thrown around and could severely injure vehicle
occupants.
• NEVER leave the child unattended. NEVER take the child out of the booster seat
or try to tend to the child’s needs while the vehicle is moving.

8
WARNING
• NEVER allow any child to play with this booster seat.
• Do not use this booster seat after nine (9) years from the date of manufacture.
The date of manufacture can be found on the label affixed to the underside of the
booster seat frame.
• Do not attempt to make repairs to or otherwise modify or tamper with this booster
seat. For instructions on proper removal of the seat cover, see section titled “Care
& Cleaning.”
• NEVER use this booster seat if it has damaged or missing parts. Do not use a cut,
damaged, frayed or inoperable vehicle seat belt.
• Do not use accessories or parts with this booster seat other than those provided
by Clek Inc. Use of accessories or parts from other manufacturers could alter the
performance of the booster seat.
• This booster seat can become very hot if left in the sun and can burn the child’s
skin. ALWAYS touch the surfaces of the parts first before putting the child in the
booster seat.
• Keep this manual in the storage pouch located on the bottom of the booster seat
for future use.
• NEVER use a second-hand booster seat or a booster seat whose history you do
not know.
• Register your booster seat with Clek Inc.
• To avoid injury, the child must remain buckled with the vehicle lap and shoulder
belt properly positioned and snugly adjusted on child. If the child is unable to
remain still enough to keep the belt properly positioned, they should be moved to
a properly fitting harness seat.

9
Certification
• This booster seat conforms to all applicable requirements of Canadian Motor Vehicle
Safety Standard 213.2 and is certified for use in motor vehicles
• This booster seat is not certified for aircraft use because aircraft seats do not have
shoulder belts
Vehicle Classification
This booster seat is for use only in the following classes of vehicle: passenger cars, trucks,
and multi-purposes vehicles, such as SUVs (sport utility vehicles).
Height and Weight Limitations
WARNING
• Do not use this booster seat if the child does not meet all of the child size
requirements listed on the following page. Using this booster seat with a child
who does not meet these requirements will increase the risk of serious injury or death
to the child.

10
The child MUST meet ALL of the following
requirements to use this booster seat:
Child’s weight is between 18 and 54 kg
(40 - 120 lb), and
Child’s height is between 101 and 145
cm (40 - 57 in.), and
Child is at least 4 years of age, and
The tops of the child’s ears MUST be
below the top of the vehicle seat back or
a fully deployed headrest on the vehicle
seat, below the RED zone as shown, and
When sitting on the booster seat, the
shoulder belt MUST lie snug across the
mid point of the child’s chest and across
the GREEN zone as shown. The lap
portion of the seat belt MUST be
positioned low and snug on the child’s
hips. See section titled “Securing Child in
Booster Seat.”
Top of ear
American Academy of Pediatrics (AAP) Recommendation
The AAP advises parents to keep their children in a car seat with a harness for as long
as possible, until they reach the maximum height and weight limit for their seat.
Children who have exceeded the limits of their harnessed car seat should use a booster
seat until the vehicle’s lap and shoulder seat belt fit properly.
HEIGHT WEIGHT MINIMUM AGE
101–145 cm
40–57 in.
18–54 kg
40 –120 lb 4+ years

11
Vehicle Requirements
Vehicle Universal Anchorage System (UAS)
(applicable only if installing booster seat
in vehicle using UAS Connectors)
• UAS stands for Universal Anchorage System. This
term refers to the pair of fixed lower anchors built
into the crease between the seat back and seat
cushion, as shown in Figure 2. The clek booster
seat has been designed to attach securely to the
vehicle’s UAS lower anchors.
• 2003 model year vehicles or newer have at least
two seating locations with a UAS anchorage
system. Some 2001 & 2002 model year vehicles
have UAS anchorage systems. 2000 model year
vehicles or older do not have UAS anchorage
systems. See your vehicle owner’s manual if you
are unsure if your vehicle is equipped with a UAS
anchorage system.
• If not readily visible, the UAS lower anchors may
be noted by a symbol located near the crease
between the seat back and seat cushion, as shown
in Figure 3.
Figure 2
Figure 3

12
• According to accident statistics, children are safer when properly restrained in rear
vehicle seating positions, rather than front seating positions, as shown in Figure 4. NEVER
use this booster seat in a front vehicle seat location unless recommended by your vehicle
owner’s manual. Whenever possible secure the booster seat in the center position of the
seat directly behind the front seats. However, this position is often equipped with a lap
belt only and cannot be used with this booster seat.
WARNING
Improper placement of the booster seat in your vehicle increases the risk of serious
injury or death. Some seating positions in your vehicle may not be safe for this
booster seat. Some vehicles do not have any seating positions that can be used
safely with the booster seat. If you are not sure where to place the booster seat in
your vehicle, consult your vehicle owner’s manual or call 1-866-656-2462.
Vehicle Seat Location Requirements
Figure 4

13
• Install this booster seat only on vehicle seats that face forward. DO NOT install this
booster seat on vehicle seats facing sideways or backwards, as shown in Figure 5.
• Only use the booster seat on vehicle seats with seat backs that lock in an upright
position. Check that the seat back is locked.
Figure 5

14
WARNING
• Many seat belt systems are not safe to use with this booster seat. Pay careful
attention to these systems; some of the seat belts that are not safe to use look very
much like seat belts that are safe to use. If you are unsure, consult your vehicle
owner’s manual or call 1-866-656-2462.
• NEVER use this booster seat if it has damaged or missing parts. Do not use a cut,
damaged, frayed or inoperable vehicle seat belt.
• Use only the vehicle’s lap and shoulder belt system when restraining the child in this
booster seat, as shown in Figure 6.
• Design and operation of vehicle seat belt systems
vary from vehicle to vehicle and from seating
location to seating location in the same vehicle.
Refer to your vehicle owner’s manual for proper
use, placement and adjustment of the vehicle’s
lap and shoulder belts.
SAFE VEHICLE SEAT BELT SYSTEMS
• Use ONLY the vehicle’s lap and shoulder
belt system when restraining the child in this
booster seat, as shown in Figure 6.
Figure 6
Vehicle Seat Belt Requirements

15
WARNING
• NEVER use a lap-only belt. Use with a lap-only belt could result in serious injury or
death to the child, as shown in Figure 7a.
• NEVER use a passive restraint – lap or shoulder belt mounted on door, as shown in
Figure 7b.
• NEVER use a passive restraint – lap belt with motorized shoulder belt, as shown in
Figure 7c.
• NEVER use vehicle belts that are attached to the door in any way or that move
along a track to automatically surround the passenger when the door is closed,
as shown in Figures 7b and 7c.
Figure 7a Figure 7b Figure 7c
UNSAFE VEHICLE SEAT BELT SYSTEMS

16
Installing/Removing Booster Seat
in Vehicle
WARNING
• The child’s safety depends on you correctly installing and using this booster seat.
Failure to properly install or use this booster seat increases the risk of serious
injury or death to the child and others in a sharp turn, sudden stop or crash.
• This booster seat is designed to be used with the vehicle’s UAS anchorage
system. ALWAYS secure this booster seat to the vehicle’s UAS anchorage system if
available. This booster seat may still be used in vehicles or rear seat positions
without a UAS anchorage system provided the booster seat is properly positioned
on the vehicle seat and the child and the booster seat are properly secured using
the vehicle’s seat belts.
• To avoid injury this booster seat must be installed by an adult.

17
Installing Booster Seat in Vehicle
using UAS Connectors
Step 1
Select a forward facing
vehicle position which has
a lap and shoulder belt.
Locate the UAS lower
anchors (as explained
in the “UAS Anchorage
System” section of this
manual or refer to your
vehicle owner’s manual), as
shown in Figures 8 and 9.
Step 2
Line up the UAS Connectors
of the booster seat with the
UAS lower anchors on the
vehicle seat, as shown in
Figures 10 and 11.
Figure 8
Figure 10 Figure 11
Figure 9

18
Step 3
Press the UAS Connectors
against the UAS lower anchors
until you hear each UAS
Connector click, as shown in
Figures 12 and 13.
If UAS Connectors fail to connect to the UAS lower anchors, you can still use this
seat by securing the vehicle seat belt underneath the armrests. See section titled
“Installing Booster Seat in Vehicle Without Using UAS Connectors”. However,
please notify us if the Connectors fail to latch by calling 1-866-656-2462.
Step 4
Once the UAS Connectors are fully connected
to the UAS lower anchors, pull forward on the
booster seat to make sure it is securely attached,
as shown in Figure 14. If not, start over at Step 1.
click
click click
Figure 12 Figure 13
Figure 14
