INEX SUCTION CABINET
With 300 CFM Reclaimer
O. M. 21803
DATE OF ISSUE: 12/96
REVISION: F 07/16
© 2016 CLEMCO INDUSTRIES CORP.
One Cable Car Dr.
Washington, MO 63090
Phone [phone]
Fax [phone]
Email: [email protected]
www.clemcoindustries.com

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 1
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
1.0 INTRODUCTION
1.1 Scope of Manual
1.1.1 These instructions cover set-up, operation,
maintenance, troubleshooting, optional accessories, and
replacement parts for the INEX suction blast cabinet with
300 cfm pull-thru reclaimer and dust collector. Refer to
the CDC-1 dust collector manual, stock no. 28225, for
operation and maintenance of the collector.
1.1.2 These instructions also contain important
information required for safe operation of the cabinet.
Before using this equipment, all personnel associated
with the blast cabinet operation must read this entire
manual, and all accessory manuals to become familiar
with the operation, parts and terminology.
1.2 Safety Alerts
1.2.1 Clemco uses safety alert signal words, based on
ANSI Z535.4-2011, to alert the user of a potentially
hazardous situation that may be encountered while
operating this equipment. ANSI's definitions of the signal
words are as follows:
This is the safety alert symbol. It is
used to alert you to potential physical
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
NOTICE
Notice indicates information that is considered
important, but not hazard-related, if not
avoided, could result in property damage.
CAUTION
Caution indicates a hazardous situation that, if
not avoided, could result in minor or moderate
injury.
WARNING
Warning indicates a hazardous situation that, if
not avoided, could result in death or serious
injury.
DANGER
Danger indicates a hazardous situation that, if
not avoided, will result in death or serious
injury.
1.3 General Description
1.3.1 Refer to Figure 1 for arrangement of components.
INEX blast cabinets enclose the blasting environment to
provide efficient blasting while maintaining a clean
surrounding work area. Production rates are influenced
by size of nozzle, compressor output, working pressure,
type and size of media, angle and distance of the nozzle
from the blast surface. INEX cabinets consist of three
major components:
1. Cabinet Enclosure
2. Reclaimer
3. Dust Collector
1.4 Theory of Operation
1.4.1 Once the components are correctly setup and
turned ON, the cabinet is ready for operation by
actuation of the foot pedal. Fully depressing the foot pedal
causes air to flow through the blast gun. Air moving through
the gun draws media into the gun’s mixing chamber. The
media mixes with the air and is propelled out the nozzle.
After striking the object being blasted, the blast media,
fines, dust, and by-products generated by blasting, fall
through the mesh work table into the cabinet hopper.
These particles are then drawn into the reclaimer for
separation. Lightweight dust and fines remain airborne and
are drawn out to the dust collector. Heavier reusable media
fall through the screen into the reclaimer hopper for reuse.
The dust collector traps dust and fines and discharges
clean air. When the foot pedal is released, blasting stops.
1.5 Dust Collector
WARNING
Prolonged exposure to any dust could result in
serious lung disease and death. Short term
ingestion of toxic materials, such as lead dust
or dust from other heavy metals and
corrosives, could cause serious respiratory
injury or death. Identify all materials that are to
be removed by blasting. Use reverse-pulse dust
collectors with HEPA after-filters if lead coating
or any other toxic materials are being removed
by the blasting process. Do not use dust
collectors with simple cloth filters for those
applications.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 2
© 2007 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803
Figure 1
1.5.1 CDC-1 Dust Collectors: A 300 cfm dust
collector is provided with the INEX cabinet. The single
filter cartridge is cleaned by using a manually-controlled
pulse of compressed air. Refer to manual no. 28225 for
operation of the CDC-1 dust collector.
1.5.2 HEPA (high-efficiency particulate air) Filter:
HEPA after-filters provide additional filtration and must
be used with a reverse-pulse cartridge collectors when
removing lead coatings or any other toxic materials.
1.6 Nozzle Options
1.6.1 Unless otherwise specified at the time of order,
cabinets are shipped with a 5/16" orifice ceramic nozzle
and No. 5 (5/32" orifice) air jet. Optional, more durable
tungsten carbide and boron carbide nozzles are
available and shown under Accessories and
Replacement Parts in Sections 8.1 and 8.3. Use a boron
carbide nozzle when blasting with aggressive media, as
noted in Section 1.7.4.
1.7 Media
WARNING
Obtain Safety Data Sheets (SDS) for the blast
abrasive. Abrasive blasting with sands
containing crystalline (free) silica can lead to
serious or fatal respiratory disease. As NIOSH
recommends, do not use abrasives containing
more than trace amounts (more than one
percent) free silica.
NOTE: Use only abrasives specifically manufactured for
blast cleaning and are compatible with the surface being
blasted. Abrasive produced for other applications may be
inconsistent in size and shape, contain particles that could
jam the abrasive metering valve, or cause irregular wear.
1.7.1 INEX Suction Blast Cabinets utilize most common
reusable media 60 to 180-mesh that is specifically
manufactured for dry blasting. Media sizes listed are for
5" ID Flex Hose
Manual Pulse Valve
Door Interlock Valve
Air Filter
(Attachment for compressed air supply)
Pilot Operated Pressure Regulator
To Blast Gun
BNP Blast Gun
Auxiliary Air Port (plugged)
Use for pneumatic accessories
Arm Ports
Door Interlock Actuator
Metering Valve
Foot Pedal
Debris Screen
Reclaimer
Damper
4" ID Light-Lined Flex Conveying Hose
Dust Drum
Pressure Gauge
Pilot Regulator
On-Off Switch
Grounding Lug
Air Inlet Duct
CDC-1 Dust Collector
115-Volt
Power Cord

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 3
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
guidelines only. The guidelines are based on standard
nozzle size and average conditions, such as blast
pressure, media/air mixture, visibility inside the cabinet,
humidity, and reclaimer cleaning rate. Several factors
affecting the reclaimer cleaning rate include: reclaimer
size, air pressure, media/air mixture, media friability, and
contamination of parts being blasted.
As a rule, larger nozzles deliver more media, requiring
higher performance from the reclaimer. When using
larger nozzles, the maximum mesh size of media will be
smaller than those normally recommended. Using media
finer than those recommended may decrease visibility,
and increase carryover to the dust collector. Media
coarser than those recommended may be too dense for
the reclaimer to recover from the cabinet hopper.
1.7.2 Steel: Steel grit or shot should not be used with
the INEX Cabinet. The cabinet is too small to prevent
peening of the cabinet weldment, and 300 cfm
reclaimers are too small to efficiently convey metallic
media.
1.7.3 Sand and Slag: Sand should NEVER be used
because of the respiratory hazards associated with
media containing free silica. Slags are not recommended
because they rapidly breakdown and are not recyclable,
making them unsuitable for cabinet applications.
1.7.4 Silicon Carbide, Aluminum Oxide, and
Garnet: These are the most aggressive of the commonly
used media. Aggressive media may be used
occasionally by installing an optional aluminum oxide kit.
The kit includes rubber curtains for the cabinet interior
and a boron carbide lined nozzle. The service life of any
equipment components exposed to the media will be
reduced. To avoid unscheduled down time, periodically
inspect the reclaimer wear plate, flex hoses, blast hose,
and nozzle for abrasive wear. Using aggressive media
on a regular bases will cause rapid wear on the
reclaimer.
1.7.5 Glass Bead: Recommended bead sizes are No.
6 through No. 12. Most beads are treated to ensure free-
flow operation even with moderately high-humidity. Glass
beads subjected to excessive moisture may be reused
after thorough drying and breaking up of any clumps.
1.7.6 Lightweight and Fine-mesh Media: When
using lightweight (such as agricultural) media or fine
mesh (180-mesh and finer) media, the reclaimer inlet
baffle may need to be removed to retain media and
avoid carryover. On reclaimer models with bolt-on
removable tops, baffle removal and replacement is
easily accomplished. Reclaimers with welded-on tops
require grinding to remove the baffle and once it is
removed it cannot be replaced.
1.7.7 Plastic Media: Plastic and similar lightweight
and/or non-aggressive media are generally not
recommended for suction-style cabinets because the
lower blast velocity of suction blasting combined with the
softer and lighter weight media, do not provide the
media impact for productive blasting. Best performance
from plastic media is achieved with pressure blasting,
requiring a pressure vessel with a 60-degree conical
bottom. Refer to Clemco’s AEROLYTE cabinet line.
1.7.8 Bicarbonate of Soda: Bicarbonate of soda is
not recommended for use in standard cabinets. Bicarb is
a one-use media usually used and will quickly saturate
the filter cartridge(s). Best performance from bicarb
media is achieved with pressure blasting, requiring a
pressure vessel. Refer to Clemco’s AEROLYTE cabinet
line for cabinets that are specifically designed for use
with bicarbonate of soda.
1.8 Compressed Air Requirements
1.8.1 The size of the compressor required to operate
the cabinet depends on the size of the air jet and
blasting pressure. Unless otherwise specified, cabinets
are supplied with a No. 5 (5/32" orifice) jet. Refer to the
table in Figure 2 to determine cfm requirements. Consult
with a compressor supplier for suggested compressor
size based on the air consumption. NOTE: A separate
air line is required for the reverse-pulse dust
collector. If preferred, remove the plug from the
auxiliary air-port (shown in Figure 3) and connect a
1/4″ID or larger air line to the dust collector pulse
reservoir/manifold.
Compressed-Air Consumption in CFM
BNP Gun Jet Nozzle CFM PSI
No. 4 1/8" 5/16" 21 80
No. 5 5/32" 5/16" 32 80
No. 6 3/16" 3/8" 47 80
*No. 7 7/32" 7/16" 62 80
*No. 8 1/4" 1/2" 86 80
* Using this combination could affect usable media size,
refer to Section 1.7.
Figure 2
1.8.2 The air filter at the air inlet connection reduces
condensed water from the compressed air. Its use is
especially important in areas of high humidity, or when
using fine-mesh media. Moisture causes media to clump
and inhibits free flow through the feed assembly. If the
filter does not remove enough moisture to keep media
dry and flowing, it may be necessary to install an air
dryer or aftercooler in the air supply line.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 4
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
1.9 Electrical Requirements
All wiring external to the cabinet is provided by the user
to comply with local electrical codes.
1.9.1 Electrical requirements depend on the size and
phase of the dust collector exhauster motor. NOTE: Full
load amps (FLA) shown below are for the motor only; the
lights draw less than one amp. Standard cabinets are
supplied as follows:
300 cfm 1/2 HP, 115/208/230V, 1-PH, 60 HZ
115, FLA 115/7, 208/3.4, 230/3.5.
Refer to Section 2.5 to connect electrical service
2.0 INSTALLATION
2.1 General Installation Notes
2.1.1 Refer to Figure 1 for the general arrangement
and place all components in a convenient location where
compressed air and electrical service are available. The
cabinet location must comply with OSHA and local safety
codes. Allow for full access to all doors and service areas,
and for efficient handling of large parts. Provide enough
clearance at the dust collector for maintenance and to
remove the dust container. Determine the best location for
all components and position them before making
compressed air connections, electrical connections, and
attaching flex hose.
2.1.2 Refer to the CDC-1 dust collector manual, stock
no. 28225 to set up the dust collector and prepare it for
operation.
2.2 Connect Conveying Hose
2.2.1 Connect the 4″diameter flex hose between the
cabinet hopper pipe adaptor and reclaimer inlet adaptor,
and connect the 5″diameter hose between the reclaimer
outlet and dust collector inlet. It is easier to slip the hose
over the adaptors and create a tighter seal if the first two
or three inches of wire are removed from the inside of the
hose. Use care not to damage the hose. Clamp flex hose
securely in position with worm clamps provided. NOTE:
The hose wire helps dissipate static electricity in the
conveying hose, and also helps ground each segment.
In order for the hose wire to dissipate static electricity,
the wire must touch the metal of each segment.
2.3 Connect Compressed Air Supply Line(s)
WARNING
Failure to observe the following before
connecting the equipment to the compressed
air source could cause serious injury or death
from the sudden release of compressed air.
•Lockout and tagout the compressed air supply.
•Bleed the compressed air supply line.
WARNING
To avoid the risk of injury from compressed air,
install an isolation valve and bleed-off valve
where the air supply is tapped into the
compressed air system. This enables
depressurization of the compressed-air line
before performing maintenance.
2.3.1 Refer to Paragraph 2.3.2 to determine the
recommended air supply hose size, then refer to Figure
3 and apply thread sealant to the male threads of an air
fitting that is compatible with the air supply hose fitting,
and install it onto the 1/2-NPT air filter located under the
cabinet hopper. Note that the style of connection
shown in Figure 3 is for reference only.
Figure 3
2.3.2 Refer to the table in Figure 4 to determine the
minimum ID air supply line to the cabinet air inlet. A
smaller diameter hose may reduce blasting efficiency.
MINIMUM COMPRESSED AIR LINE ID
Air Jet Size
Air Line Length No. 4 No. 5 No. 6
25 feet 3/4" 3/4" 1"
50 feet 3/4" 3/4" 1"
75 feet 3/4" 1" 1"
100 feet 3/4" 1" 1"
Figure 4
Plugged Auxiliary Port
Air Fitting
Safet
y
Lock-Pins
Air Supply Hose

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 5
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
2.3.3 Connect the air line from the air source to the air
filter inlet.
WARNING
If twist-on type air hose couplings are used,
they must be secured by safety pins or wires to
prevent accidental disconnection while under
pressure. Hose disconnection while under
pressure could cause serious injury.
2.3.4 Refer to the dust collector owner’s manual and
connect a compressed-air line to the pulse manifold.
2.4 Ground Cabinet
2.4.1 To prevent static electricity build up, attach an
external grounded wire from an earth ground to the
grounding lug on the left rear of the cabinet.
2.5 Connect Electrical Service to Dust Collector.
WARNING
Shorting electrical components could result in
serious electrical shocks, or equipment
damage. Electrical power must be locked out
and tagged out before performing any electrical
work. All electrical work or any work done
inside a control panel or junction box must be
performed by a qualified electrician, and
comply with applicable codes.
All wiring external to the cabinet is provided by the user
to comply with local electrical codes.
2.5.1 Standard INEX cabinet and 300 cfm dust
collectors are 115-volt single phase. Incoming power to
the cabinet is supplied by a U-ground plug; plug it into a
115-volt outlet.
WARNING
Do not use electrical adaptors that eliminate
the ground prong on 115 volt plugs. Doing so
could cause electric shock and equipment
damage.
2.5.2 Refer to the wiring schematic in Figure 5 and
wire the dust collector motor per instruction on the motor
data-plate, to the junction box mounted on the cabinet.
When wired as noted in Figure 5, the dust collector
exhauster motor will start when the cabinet light switch
is turned ON, and stop when the switch is turned OFF.
2.5.3 Check Motor Rotation
2.5.3.1 After wiring is completed, observe the warning
that follows and check the motor rotation. To check
rotation, turn the On-Off switch ON and quickly turn it
OFF, causing the motor to rotate slowly. Look through the
slots in the motor fan housing where rotation of the fan
can easily be observed. Proper rotation is indicated by the
arrow on the exhauster housing; the fan should rotate
toward the exhauster outlet. If it rotates in reverse, change
the wires as noted on the motor plate to reverse rotation.
WARNING
Do not look into the exhauster outlet while the
paddle wheel is turning. Injury to the eye or
face could occur from objects being ejected
from the exhauster.
Figure 5
115 VOLT, 1PH WIRING FOR CABINET AND DUST COLLECTOR MOTOR

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 6
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
2.6 Final Assembly
2.6.1 Position the foot pedal on the floor at the front of
the cabinet.
2.6.2 A package of five view-window cover-lenses is
supplied with the cabinet. Install a cover lens per Section
6.3. When the cover lens becomes pitted or frosted,
replace it.
3.0 OPERATION
3.1 Media Loading and Unloading
3.1.1 Media Loading: With the exhauster OFF, add
clean dry media to the reclaimer hopper by pouring it
through the reclaimer door. Do not fill above the cone on
the reclaimer. Do not pour media directly into the
cabinet hopper, as overfilling may occur. Overfilling
will result in media carryover to the dust collector and
possible blockage in the conveying hose. Refill only after
all media has been recovered from the cabinet. The
minimum amount of media to charge the system is
approximately 10 Lbs.
3.2 Loading and Unloading Parts
WARNING
Use solid fixturing to hold heavy parts in place.
Do not remove lift equipment until the part is
adequately supported to prevent movement.
Moving heavy, unsupported parts may cause
them to shift or topple, and cause severe injury.
This is especially important with the use of
turntables and turntables with tracks.
3.2.1 Load and unload parts through either door.
3.2.2 Parts must be free of oil, water, grease, or other
contaminants that will clump media or clog filters.
3.2.3 When blasting small parts or objects having small
pieces that could become dislodged and fall off, place an
appropriately-sized screen over the grate (or under the
grate when frequently blasting small parts) to prevent
parts from falling into the hopper.
3.2.4 Close door; the door interlock system will
prevent blasting if either door is open.
3.3 Blasting Operation
CAUTION
Always close cabinet, reclaimer and dust
collector doors before blasting. Keep all
doors closed during blasting.
Always wear blast gloves.
Avoid pointing the blast nozzle toward the
view window.
After blasting, keep doors closed and
exhauster running until the cabinet is clear
of all airborne dust.
Stop blasting immediately if dust leaks are
detected.
3.3.1 Slowly open the air valve on the air supply hose
to the cabinet. Check for air leaks on the initial start up
and periodically thereafter.
3.3.2 Turn ON the lights and exhauster. The ON/OFF
switch located on the light shield performs both
functions.
3.3.3 Load parts.
3.3.4 Close door; the door interlock system will
prevent blasting if either door is open.
3.3.5 Insert hands into gloves.
3.3.6 To blast, hold the gun firmly, point the gun
toward the object to be blasted, and apply pressure to
the foot pedal; blasting will begin immediately.
WARNING
Shut down the cabinet immediately if dust
discharges from the dust collector or cabinet.
Check to make sure the dust collector filters are
correctly seated and not worn or damaged.
Prolonged breathing of any dust could result in
serious lung disease or death. Short term
ingestion of toxic dust such as lead, poses an
immediate danger to health. Toxicity and health
risk vary with type of media and dust generated
by blasting. Identify all material being removed
by blasting, and obtain a safety data sheet
(SDS) for the blast media.
3.3.7 Adjust the pilot pressure to the required blast
pressure per Section 4.1. The regulator is located on the
top, left side of the cabinet.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 7
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
NOTE: When blasting parts off the grate, use a solid
conductive back rest to support the part. Without this
assist, especially with longer blasting operations, the
operator will tire easily from resisting blast pressure, and
static electricity could build up in the ungrounded part
and cause static shocks. Whenever possible avoid
holding small parts that require blasting into the glove.
3.3.8 If an object should fall through the grate, stop
blasting immediately and retrieve it.
3.4 Stop Blasting
3.4.1 To stop blasting, remove pressure from the foot
pedal.
3.4.2 Keep doors closed and exhauster running until
the cabinet is clear of all airborne dust.
3.4.3 Unload parts. Shut off the air supply valve, drain
the air filter, and switch OFF the lights and exhauster.
3.5 Blasting Technique
3.5.1 Blasting technique is similar to spray painting
technique. Smooth continuous strokes are most
effective. The distance from the part affects size of blast
pattern. Under normal conditions, hold the nozzle
approximately 3" to 6" from the surface of the part.
4.0 ADJUSTMENTS
4.1 Blasting Pressure
4.1.1 The pilot regulator located on the top, left side of
the cabinet, enables the user to adjust blasting pressure
to suit the application. The suitable pressure for most
purposes is about 80 psi. Lower pressures may be
required on delicate substrates, and will reduce media
breakdown. Higher pressure may be required for difficult
blasting jobs on durable substrates, but will increase
media break down. If pressure is too high, suction in
media hose will decrease, and if high enough, cause
blow-back in the hose. Optimal production can only be
achieved when pressure is carefully monitored.
4.1.2 To adjust pressure, unlock the knob by pulling it
out as shown in Figure 6, and turn it clockwise to
increase pressure or counter-clockwise to decrease
pressure. Pressure will usually drop from closed-line
pressure when blasting is started. Once operating
pressure is set, lock the knob to maintain the setting.
Figure 6
4.2 Air Jet Adjustment, Figure 7
4.2.1 Thread the air jet 4-1/2 to 5 full turns into the
gun body. Doing so will leave 3-1/2 to 4 threads exposed
past the lock nut. Tighten the lock nut to maintain the
setting. Refer to Section 8.3 for optional adjusting tool,
which correctly positions the jet.
`
Figure 7
4.3 Media/Air Mixture, Figure 8
4.3.1 Check the media stream for correct media/air
mixture; media flow should be smooth and appear as a
light mist coming from the nozzle.
4.3.2 If media does not flow smoothly, loosen the
locking nut, and adjust the metering screw until the upper
holes in the metering stem are closed-off, and the lower
holes are fully open, as shown in Figure 8. This
adjustment is a starting point.
4.3.3 If pulsation occurs in the media hose, either media
is damp and caked, or not enough air is entering the
media stream. While blasting, loosen the locking nut and
slowly turn the adjusting screw out (counterclockwise
when viewed from the top) until the media flows smoothly.
Tighten the locking nut finger-tight to maintain the setting.
4.3.4 If media flow is too light, decrease air in the
mixture by turning the metering screw in (clockwise when
viewed from the top) covering more of the holes so less air
Push knob in to lock
Pull knob out to unlock
When viewed from the knob end,
turn clockwise to increase pressure
turn counterclockwise to decrease pressure
Adjustment Knob
Blast Pressure Regulator
Located on top left
side of cabinet
Lock Nut
Air Jet
3-1/2 to 4 threads between
lock nut and air jet hex

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 8
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
enters the media hose. Tighten the locking nut finger-tight
to maintain the setting.
Figure 8
4.4 Reclaimer Static Pressure
4.4.1 Correct static pressure requirements vary with
size, weight and type of media.
4.4.2 Adjust static pressure by opening (handle inline
with air flow) or closing (handle perpendicular to air flow)
the dust collector ventilation-damper. Refer to the dust
collector owner’s manual, the damper is located on the
CDC-1 dust collector inlet. If the damper is not opened
far enough, the reclaimer will not remove fines, resulting
in dusty media, poor visibility, and possible media
blockage in the conveying hose. If the damper is opened
too far, it may cause carryover (usable media carried
into the dust collector) and result in excessive media
consumption. Open only as far as necessary to obtain a
balance of dust removal without media carryover.
4.4.3 A manometer is useful when adjusting or
monitoring static pressure. The manometer kit is listed
under Optional Accessories in Section 8.1. Refer to
Section 4.6 for manometer operation. The following are
static pressure starting points for given media. Static
pressure may need to be lower with finer media, higher
with coarser media. Run the media through several blast
cycles allowing the reclaimer to function with these
settings. Inspect the media in the reclaimer and fines in
the dust collector as noted in Paragraph 4.4.2. Continue
adjusting static pressure until optimum media cleaning
without carryover is attained.
Glass Bead No. 6 and 7 ................................ 3" to 3-1/2"
Glass Bead No. 8 to 13 ..................................... 2-1/2 - 3"
Alox. 60 & coarser ................................................... 4 - 5"
Alox. 80 & finer .................................................. 2-1/2 - 3"
4.5 Door Interlocks, Figure 9
WARNING
Never attempt to override the interlock system.
Doing so could result in injury from unexpected
blasting.
4.5.1 The door interlocks disable the blasting control
circuit when the doors are open. To enable blasting, the
door interlock switches must be engaged when the
doors are closed. The interlocks are set at the factory
and do not usually require field adjustment unless parts
are replaced. When adjustment is required, proceed as
follows.
4.5.2 Close cabinet doors.
4.5.3 Loosen the actuator bracket screws and
adjusting screw nut. Move the actuator adjusting bracket
up or down, and the adjusting screw sideways, to center
the adjusting screw on the over-travel stop. Tighten the
bracket screws.
Figure 9
4.5.4 Turn the adjusting screw in or out as required to
engage the switch without applying excessive pressure
on it. Tighten the adjusting screw nuts.
4.5.5 Test the operation with the doors open and then
again closed. Point the nozzle away from the door during
the tests, and only open the door enough to disengage
Ad
j
ustin
g
Screw
Lockin
g
Nut
Lower holes full
y
o
p
en
Upper holes
fully Closed
Adjust the screw to depress
the over-travel stop when
door is closed.
Actuator Bracket
Over-travel Stop
Adjusting Screw Nut
Loosen both nuts and move
screw sideways as needed
to center adjusting screw-
head on the over-travel stop.
Loosen bracket screws and
move bracket up or down as
needed to center adjusting
screw-head on the over-
travel stop.
Bracket Screws
Cabinet Door

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 9
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
the interlock switch. The interlocks should stop the
blasting when the doors are opened, and permit blasting
when the doors are closed. NOTE: Negative pressure
inside the cabinet may cause the doors to flex inward.
Tests should be performed with the exhauster ON.
4.6 Optional Manometer
These instructions show several methods of taking
static-pressure readings (negative pressure) on cabinet
reclaimers, using a flexible tube manometer. Use the
method best suited for the application. The instruction
explains the processes for taking periodic readings and
shows how to permanently install the manometer for
taking frequent readings. Permanent fittings should be
installed when rigid ducting is used, or when the
manometer installation is permanent. Use silicone sealer
or other sealant to seal around the fitting to prevent
leaks. The fitting should be capable of being capped
when the manometer tube is removed. Capping the
fitting will prevent leaks that alter the reclaimer’s
separation efficiency. The readings are reference points
so it doesn’t matter where the readings are taken as
long as they are always taken at the same location.
Taking readings at different locations could produce
different results. Static-pressure readings at the door are
generally .5" to 1" lower than those taken above the
reclaimer.
4.6.1 Refer to directions packed with the manometer
for preparation and operating instructions for the
manometer.
4.6.2 Connect one end of the 3/16" ID tubing to one of
the tubing connectors (elbow) at the top of the
manometer by pushing it over the barbed adaptor.
4.6.3 Leave the needle protector on the needle and
insert the needle into the other end of the tubing. The
ends of the tubing must fit tight on the manometer and
needle; leaks will give inaccurate readings.
4.6.4 Open both manometer valves (elbows) per the
instructions provided with the manometer.
4.6.5 Magnets on the manometer hold it in position on
the reclaimer body. The manometer must be vertically-
plumb so the fluid is level on both sides.
4.6.6 Adjust the slide rule to align the zero with the
fluid level. Refer to Figure 11
4.6.7 Needle placement: Ref. Figure 10.
4.6.7.1 Taking readings in the flex hose: Remove the
needle protector, and insert the needle into the flex hose
approximately 8" from the top of the reclaimer.
4.6.7.2 Taking readings at the reclaimer door: Open
the reclaimer fill door, remove the needle protector and
place the needle so the point is inside the door opening.
Carefully close the door on the needle. The side of the
needle will embed into the rubber, creating an airtight
seal.
4.6.8 Turn the exhauster ON. The negative (static)
pressure will move fluid in the tube. NOTE: Readings
must be taken with the cabinet doors open, and with
the exhauster running.
Figure 10
4.6.9 To find the static pressure, add the number of
inches the fluid travels up one column to the inches the
fluid travels down the other column. Refer to the
example in Figure 11.
4.6.10 After the readings are taken, replace the needle
protector. Close the manometer valves and store the
manometer in the original container in a clean area.
8
Insert the needle into
straight section of flex
hose, about 8-inches above
the top of the reclaimer.
Place the needle so the
point is inside the door
opening. Carefully close
the door on the needle.
Reclaimers are for reference and
may differ from those shown.
For taking frequent readings,
install a permanent fitting in
the reclaimer wall, just below
the inner cone as shown.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 10
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
NOTE: If the manometer installation is permanent, the
manometer may remain on the reclaimer body after the
valves are closed.
Figure 11
5.0 PREVENTIVE MAINTENANCE
NOTE: To avoid unscheduled downtime, establish an
inspection schedule. Inspect all parts subjected to media
contact, including; the gun, nozzle, media hose, flex
hose, wear plate, plus all items covered in this section.
5.1 Daily
5.1.1 Check media level in reclaimer and refill as
necessary.
5.1.2 Check reclaimer debris screen for debris. The
screen is accessible through the reclaimer door. With
the exhauster OFF, remove the screen and empty it
daily or when loading media. Empty the screen more
often if part blasted causes excessive debris. Do not
operate the machine without the screen in place.
5.1.3 The cabinet is equipped with a manual-drain air
filter. Drain the filter at least once a day, and more often
if water is present. Moist air inhibits the flow of media.
Drain the air line and receiver tank regularly. If the filter
does not remove enough moisture to keep media dry
and flowing, it may be necessary to install an air dryer or
aftercooler in the compressed-air supply line.
5.1.4 Refer to the dust collector owner’s manual and
empty dust containers. Adjust intervals based on filling
rate.
5.1.5 Refer to the dust collector owner’s manual and
drain the pulse manifold at the end of each shift.
5.1.6 Refer to the CDC-1 dust collector manual for
pulsing instructions and pulse the cartridge at least
every half hour of blasting and before turning OFF the
exhauster. Dusty blasting conditions will require more
frequent pulsing. RPC and RPH dust collectors are
automatically pulsed at timed intervals.
5.2 Weekly
5.2.1 Inspect view window cover lens, Replace as
needed per Section 6.3.
5.2.2 Inspect gloves for wear. The first sign of
deterioration may be excessive static shocks. Replace
as needed per Section 6.1.
5.2.3 Inspect internal parts of the BNP gun for wear.
Replace parts as needed per Section 6.2.
5.2.4 Inspect flex hoses for wear.
5.2.5 During operation, inspect cabinet door seals for
media leaks.
The manometer must be vertical
when taking pressure readings.
With the exhauster OFF,
slide the rule to align the
zero with the fluid level.
In the example shown, fluid traveled up
the right column 1-3/4 inch,
and down the left column 1-3/4 inch.
Static pressure is determined by adding
the columns together. In the example,
the static pressure is 3-1/2 inches.
To obtain the pressure reading: With
the exhauster ON, add the number of
inches the fluid travels up the column,
to the inches the fluid travels down the
other column. The total is the static
pressure reading.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 11
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
5.2.6 Inspect the media hose for thin spots, by
pinching it every 6 to 12 inches. Replace the hose when
it becomes soft.
5.3 Monthly
5.3.1 Inspect reclaimer wear plate for wear through
the inlet adaptor. Replace as necessary per Section 6.5.
5.3.2 Inspect reclaimer door gasket for wear or other
damage.
5.4 Dust Collector
Reverse-pulse dust collectors are covered in a separate
manual. Refer to Section 1.1.1.
6.0 SERVICE MAINTENANCE
6.1 Gloves
6.1.1 Special static-dissipating gloves are provided for
operator comfort. It will be necessary to change gloves
periodically as they wear. The first sign of deterioration
may be excessive static shocks.
6.1.2 Band-clamp type: Band-clamp type gloves are
held in place by metal band-clamps on the inside of the
cabinet. To replace, loosen the clamps with a
screwdriver, replace the gloves, and tighten the clamps.
6.1.3 Quick-Change type, clampless installation:
Quick-change gloves are held in place using spring rings
sewn into to the attachment end of the glove. To install,
insert the glove into the arm port, so one spring is on the
inside of the port and the other is on the outside,
sandwiching the arm port between both spring rings.
6.2 BNP Gun Assembly, Figure 12
Figure 12
6.2.1 Replace the nozzle when its diameter has
increased by 1/16", or when suction diminishes
noticeably. To change the nozzle, unscrew the holding
nut from the gun end, and pull the nozzle from the gun.
Inspect the nozzle o-ring and replace if worn or
damaged. Insert a new nozzle, placing the tapered end
toward the jet. Screw the holding nut onto the gun.
6.3 View Window Cover Lens
6.3.1 Rapid frosting of the view window can be
avoided by directing ricocheting media away from the
window, and by installing a cover lens on the inside
surface of the window. Using cover lenses prolongs the
life of the view window.
6.3.2 To install a cover lens, remove the adhesive
backing and apply the lens to the clean, dry, inner
surface of the view window. When the cover lens
becomes pitted or frosted, peel it off and replace it.
6.4 View Window Replacement
WARNING
Do not use plate glass for replacement view
windows. Plate glass shatters on impact and
could cause severe injury. Use only genuine
replacement parts.
6.4.1 Swing the light shield up and tie it in place, as
shown in Figure 13.
6.4.2 Remove the filler strip by pulling it out of the
window molding, as shown if Figure 13.
Figure 13
6.4.3 Place an arm into a glove, and push the bottom
edge of the window out of the molding, as shown in
Figure 14, while supporting the top of the window with
the other hand.
The wider tapered-end of the
nozzle inserts into the gun.
O-Ring
Media Hose
Air Jet Cover
Nozzle
Nozzle Holding Nut Filler Strip

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 12
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
Figure 14
6.4.4 Pull the window downward to remove the
window from the molding, as shown if Figure 15.
Figure 15
6.4.5 If the window molding needs replacing, replace
it in the same manner as the old; the narrow channel fits
over the metal edge of the opening, as shown in Figure
16. The molding ends should meet in the middle of the
top straight section of the opening. Molding should be
compressed so the ends are tightly sealed.
Figure 16
6.4.6 Spray silicone or other lubricant into the window
channel (wide channel) on the molding, and slide the
window into the channel, as shown in Figure 17. Place
an arm into a glove to support the top edge of the
bottom side of the window with one hand, while guiding
the top edge into the molding with the other.
Figure 17
6.4.7 Use a nylon window installation stick, Stock No.
22933, as shown in Figure 18, and work the window
channel lip over the glass. When this is done, the
window should be entirely within the molding’s window
channel.
Figure 18
6.4.8 Attach the appropriate tip to the optional
installation tool as shown in Figure 19.
Cabinet Wall
View Window Filler Strip channel
Filler Strip
Rounded side up
Narrow Channel
Wide Channel
Installation Stick

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 13
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
Figure 19
6.4.9. Wipe, or spray the filler strip with silicone or
other lubricant to reduce friction. Insert about 2-inches of
the strip into the installation tool, as shown in Figure 20.
Figure 20
6.4.10 Insert the tool tip and filler strip into the filler strip
channel of the molding, at the opposite side of the
opening from the window molding ends, as shown in
Figure 21. The rounded side of the filler strip faces up.
Figure 21
6.4.11 Hold short end of the filler strip and feed the
strip into the channel by pushing the tool through the top
of the channel, as shown in Figure 21. Rotate the tip as
needed, if the light shield or other obstructions interfere
with moving the installation tool around turns. Continue
feeding the strip into the channel, as shown in figure 22
until the end of the strip is in place at the starting point.
Figure 22
6.4.12 Use the window stick to push the filler strip into
the molding at any spot the strip is not fully seated.
Place the light shield in its normal position.
6.5 Reclaimer Wear plate Replacement
6.5.1 Remove the reclaimer inlet adaptor and old
wear plate. The wear plate is held in place by screws
attached from the outside of the reclaimer; remove the
screws and pull out the wear plate from the reclaimer
inlet.
6.5.2 Angle the new wear plate into the reclaimer inlet
until it is in position with the straight end at the reclaimer
inlet. Insert a board or similar object for leverage and pry
the wear plate against the inner wall of the reclaimer.
While forcing the wear plate against the reclaimer wall,
install sheet metal screws through the old screw holes to
secure Caulk seems between the wear plate and
reclaimer to prevent rapid wear in those areas.
6.6 CDC-1 Dust Collector
6.6.1 Refer to the CDC-1 dust collector manual, stock
no. 28225, for maintenance of the collector.
Installation Tool
Stock No. 12176
Shield Shaped
Opening
Half Circle Shaped
Opening
Install tip with
shield-shaped
opening toward
front.
Insert filler strip
rounded side up.
Filler Strip
Moldin
g
Ends
Insert tool tip and filler
strip on opposite side of
moldin
g
end.
Push the tip through
the channel to embed
the strip.
Shown without light shield for clarity

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 14
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
7.0 TROUBLESHOOTING
WARNING
To avoid serious injury, observe the following
when troubleshooting.
•Turn OFF the air, and lockout and tagout the
air supply.
•If checking the controls requires air, always
enlist the aid of another person to:
Hold the blast gun securely.
Operate the foot pedal.
•Never bypass the foot pedal or wedge it in
the operating position.
•Never override the door interlock system.
7.1 Poor visibility
7.1.1 Dirty filter cartridge. Pulse cartridge and empty
dust container regularly.
7.1.2 Exhauster motor not operating. Check voltage to
motor and motor wiring.
7.1.3 Check rotation of exhauster motor; the motor
should rotate as indicated by the arrow on the housing. If
it does not rotate in the proper direction, lockout and
tagout power and switch the motor leads as shown on
the motor plate. Refer to Section 2.5.4.
7.1.4 Using friable media that rapidly breaks down, or
using media that is too fine or worn out.
7.1.5 Dust collector damper closed too far restricting
air movement in cabinet. Adjust static pressure per
Section 4.4.
7.1.6 Blocked air inlet duct. Blockage in the air intake
ducts restricts incoming air and reduces air movement in
the cabinet.
7.1.7 Reclaimer door open.
7.1.8 Hole worn in flex hose between cabinet hopper
and reclaimer inlet or between the reclaimer and dust
collector. Replace hose and route it with as few bends
as possible to prevent wear.
7.1.9 Obstruction in flex hose between the cabinet
hopper and reclaimer inlet.
7.2 Abnormally high media consumption
7.2.1 Door on reclaimer open or worn door gasket. Air
entering the reclaimer around the door will cause media
carryover to the dust collector. DO NOT operate unless
all doors are closed.
7.2.2 Dust collector damper open too far. Adjust static
pressure per Section 4.4.
7.2.3 Media may be too fine or worn-out.
7.2.4 Using friable media that rapidly breaks down.
7.2.5 Blast pressure too high for the media, causing
media to break down.
7.2.6 Hole worn in reclaimer, or leak in reclaimer
seams. Check entire reclaimer for negative-pressure
leaks.
7.2.7 If using media finer than 180-mesh, the
reclaimer inlet baffle may need to be removed. Refer to
Section 1.7.6.
7.3 Reduction in blast cleaning rate
7.3.1 Low media level reducing media flow. Check
media level; add media or change media as needed.
7.3.2 Media/air mixture out of adjustment. Adjust
metering valve per Section 4.3.
7.3.3 Reduced air pressure. This may be caused by a
malfunctioning regulator, a dirty filter element in the air
filter, partially-closed air valve, leaking air line, or other
air tools in use.
7.3.4 Blockage in media hose or gun. Blockage may
occur as a result of a damaged or missing reclaimer
screen or heavy media flow. Inspect reclaimer screen
and adjust media flow per Section 4.3.
7.3.5 Worn gun parts such as nozzle or air jet. Inspect
gun and replace all worn parts.
7.3.6 Worn media hose. Check hose for leaks and
soft spots. Replace worn or damaged hose.
7.3.7 Air jet in gun out of adjustment. Check
adjustment per Section 4.2.
7.3.8 Moist media. Frequent bridging or blockage in
the area of the metering valve can be caused by
moisture. Refer to Section 7.5.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 15
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
7.4 Plugged nozzle
7.4.1 A damaged or missing reclaimer screen will
allow large particles to pass and block the nozzle.
Replace or reinstall as necessary.
7.4.2 Media mixture too rich. Adjust media/air mixture
per Section 4.3.
7.5 Media bridging
7.5.1 Frequent bridging or blockage in the media
metering valve can be caused by damp media. Media
becomes damp by blasting parts that are slightly oily,
from moisture in the compressed-air line, or from
absorption from ambient air.
7.5.2 To avoid contaminating media from the
workpiece, all parts put into the cabinet should be clean
and dry. If parts are oily or greasy, degrease and dry
them prior to blasting.
7.5.3 Moist compressed air may be due to a faulty
compressor that overheats, or pumps oil or moisture into
the air line, too long an air line permitting moisture to
condense on the inside, and from high humidity. Drain
the air filter and receiver tank regularly. Ongoing
problems with moist air may require the installation of an
air dryer or aftercooler in the air supply line.
7.5.4 Absorption. Some media types tend to absorb
moisture from the air, especially fine-mesh media in
areas of high humidity. Empty the media and store it in
an airtight container when cabinet is not in use.
7.5.5 A vibrator attached to the reclaimer cone or
media metering valve may help to prevent bridging of
fine-mesh media. NOTE: To avoid the possibility of
compressing media, a vibrator should be setup to start
only when the foot pedal is pressed.
7.6 Blasting does not begin when the foot pedal
is pressed.
7.6.1 Door interlocks not engaging. Check adjustment
per Section 4.5.
7.6.2 Blocked or leaking control lines. Check all
urethane tubing for blockage or leaks.
7.6.3 Foot pedal valve malfunction. Check foot pedal
alignment, and inlet and outlet lines for pressure.
7.6.4 Make sure lines are not reversed on the foot pedal
or pilot regulator. Refer to the schematic in Figure 29.
7.6.5 Pressure regulator may be set too low or OFF.
Check pressure on pilot regulator.
7.6.6 Make sure that the air compressor is operating
and air supply valves are open.
7.6.7 Check the nozzle to see if it is plugged. Refer to
Section 7.4.
7.7 Blasting continues when the foot pedal is
released
7.7.1 Make sure the 3-way valve in the foot pedal
exhausts air when the pedal is released. If it does not
exhaust, check the inbound air line for blockage, if no
blockage, replace the valve.
7.8 Blockage in Media Hose
7.8.1 Media obstructions. Usually caused when the
media mixture is too rich. Adjust media/air mixture per
Section 4.3.
7.8.2 Wet or damp media. See Section 7.5.
7.9 Media surge
7.9.1 Heavy media flow. Adjust per Section 4.3.
7.10 Poor suction in media hose
7.10.1 Refer to the tables in Paragraphs 1.8.1 and
2.3.2 and make sure cfm and air hose requirements are
met.
7.10.2 Air jet needs adjustment. Check adjustment per
Section 4.2.
7.10.3 Nozzle is worn. Replace if worn 1/16" or more.
7.10.4 Blockage in media hose or nozzle. Refer to
Sections 7.4 and 7.8.
7.10.5 Air jet and nozzle combination may be wrong.
Refer to the table in Paragraph 1.8.1.
7.10.6 Air jet sleeve extends past end of air jet. Cut the
sleeve to align with the air jet.
7.10.7 Blast pressure too high, refer to Section 4.1.
7.10.8 Nozzle inserted backward; the tapered end of
the nozzle should face toward the air jet.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 16
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
7.11 Air only (no abrasive) from nozzle
7.11.1 Low media level in reclaimer. Check media level
and replenish as needed.
7.11.2 Make sure the air hose and media hose are not
reversed; the green air hose attaches to the back of the
gun and the clear media hose attaches to the bottom of
the gun’s grip. Refer to Figure 25.
7.12 Blow-back through media hose
7.12.1 Blockage in nozzle. Remove the nozzle and
check blockage.
7.12.2 Air jet may be too large for nozzle. Refer to the
table in Paragraph 1.8.1.
7.12.3 Blast pressure too high, refer to Section 4.1.
7.13 Media buildup in cabinet hopper, does not
convey to reclaimer
NOTE: Do not pour media directly into the cabinet
hopper, as overfilling may occur. Overfilling will result
in media carryover to the dust collector and possible
blockage in the conveying hose.
7.13.1 Exhauster motor rotating backwards. The motor
should rotate as indicated by the arrow on the exhauster
housing. If it does not rotate in the proper direction,
lockout and tagout electrical power and switch the
motor leads as shown on the motor plate. Refer to the
system’s wiring schematic. Refer to Sections 2.5.4.
7.13.2 Dust collector ventilation damper closed too far
restricting air movement through cabinet. Adjust static
pressure per Section 4.4.
7.13.3 Dust collector filter cartridge blinded. Refer to
the CDC-1 dust collector manual, stock no. 28225.
7.13.4 Hole worn in flex hose between cabinet hopper
and reclaimer inlet or between the reclaimer outlet and
dust collector inlet. Replace hoses and route them with
as few bends as possible to prevent wear.
7.13.5 Reclaimer door open. DO NOT operate unless
door is closed.
7.13.6 Obstruction flex hose. Remove hoses and check
for blockage.
7.14 Static shocks
7.14.1 Cabinet and/or operator not grounded. Abrasive
blasting generates static electricity. The cabinet must be
earth-grounded to prevent static buildup. Refer to
Section 2.4. If shocks persist, the operator may be
building up static. Attach a small ground wire, such as a
wrist strap, from the operator to the cabinet.
7.14.2 Gloves wearing thin. Inspect gloves and replace
them as needed.
7.14.3 Avoid holding parts off the grate. Static will
buildup in the part if not dissipated through the metal
cabinet.
7.15 Dust leaking from cabinet
7.15.1 Refer to Section 7.13.
7.16 Dust leaking from dust collector
7.16.1 Damaged or loose filters cartridge. Inspect filter
and replace as needed.
7.16.2 Refer to the CDC-1 dust collector owner’s
manual, stock no. 28225, for operation of the dust
collector.

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 17
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
8.0 ACCESSORIES AND REPLACEMENT PARTS
8.1 Optional Accessories
Conversion kits, push-thru reclaimer to pull-thru
Description Stock No.
Conversion kit to convert push-thru reclaimer to pull-thru.
to convert from dry filter to CDC-1 dust collector
Kit includes outlet adaptor pipe, gasket, and fasteners.
for 300 cfm reclaimer ...................................... 28962
Description Stock No.
Tungsten carbide nozzle
No. 5 ................................................................ 13118
Boron carbide nozzle
No. 5 ................................................................ 11935
No. 6 ................................................................ 11936
Wide spray nozzle
Tungsten carbide
No. 6 ......................................................... 11947
Boron carbide
No. 6 ......................................................... 11934
NOTE: Wide spray nozzles require the following
accessories:
Wide spray nozzle nut ..................................... 11916
Wide spray retaining ring ................................ 12038
Wide spray nozzle guard ................................. 12295
Lock pins (pkg of 25) for twist-on hose couplings .. 11203
Manometer kit ........................................................ 12528
Armrest assembly .................................................. 24900
Anti-fatigue floor-mat, for front of cabinet .............. 24744
Optional Extension Nozzles, Figure 23
Item Description Stock No.
1. 3" Straight extension nozzle
No. 5, 5/16" orifice ................................. 11921
No. 6, 3/8" orifice ................................... 11922
No. 7, 7/16" orifice ................................. 11923
2. 6" Straight extension nozzle
No. 5, 5/16" orifice ................................. 11927
No. 6, 3/8" orifice ................................... 11928
No. 7, 7/16" orifice ................................. 11929
3. 9" Straight extension nozzle
No. 5, 5/16" orifice ................................. 11924
No. 6, 3/8" orifice ................................... 11925
No. 7, 7/16" orifice ................................. 11926
4. Side-angle extension nozzle assemblies
with No. 5 orifice, includes 5, 6, 7, and 8
4″long assembly ................................... 21311
6" long assembly ................................... 12374
9" long assembly ................................... 12373
5. Side angle extension nozzle casing
4″long casing ........................................ 11943
6" long casing ........................................ 11940
9" long casing ........................................ 11939
6. Tip, side-angle extension .......................... 12173
7. Snap ring, side-angle extension ............... 12040
8. O-ring, side-angle extension .................... 08977
Figure 23
5
Standard Nozzle
1, 2, 3
NOTE:
Leave the standard nozzle in the
gun, slip the nozzle holding nut
over the extension nozzle, and
tighten onto the gun body
4
6 87
Extension Nozzle

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 18
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
8.2 Cabinet Replacement Parts, Figure 24
Item Description Stock No.
1. Gasket, door, adhesive-backed, per foot,
10-ft. per door, specify feet required ......00187
2. Light shield assembly with switch .............11601
3. Window glass, 12.5" x 19.5" ......................12212
4. Gasket, window molding, 6 ft. required ........ 12435
5. Filler strip, window molding, 6 ft. required . .. 12436
6. Cover lens, pkg. of 5 .................................06190
7. Grate, 3048 ...............................................10761
8. Latch assembly, door ................................10908
9. Glove set
Band-clamp attachment .........................11215
Quick-Change (clampless attachment) ....28820
10. Glove, left hand only
Band-clamp attachment ..........................12710
Quick-Change (clampless attachment) ....28638
11. Glove, right hand only
Band-clamp attachment ..........................12711
Quick-Change (clampless attachment) ....28639
12. Clamp, glove .............................................11576
13. Hose, 4" ID light-lined flex, 7 ft. required ...12466
14. Clamp, 4" flex hose ...................................11577
15. Grommet, media/air hose ..........................11798
16. Actuator, door interlock .............................19152
17. Over-travel stop, door interlock .................20004
18. Detent sleeve, door interlock .....................15042
19. Air valve, 3 way, door interlock .................12202
20. Regulator, 1/8" NPT pilot ...........................12715
21. Gauge, pressure, 1/8" NPT cbm ................01908
22. Regulator, 1/2" pilot operated ...................11345
23. Bushing 1/2"x 1/8" NPT .............................11350
24. Bushing 1/4"x 1/8" NPT .............................02010
25. Bracket, mounting .....................................19231
26. Filter, 1/2" air .............................................01308
27. Fitting, 1/8" NPT elbow x 1/8" barb ...........11733
28. Foot pedal assembly, less tubing ..............20483
29. Cord with plug, 115 volt..............................11669
30. Support bracket, each ...............................24757
Figure 24
Some parts rotated or removed for clarity
13
5
6
3
28
16
42
1
8
20 19
12
29
14
7
15
11
10 9
11
10 9
1817
21
27
30
30
23, 24
22 25
26
27

INEX SUCTION BLAST CABINET with 300 CFM RECLAIMER Page 19
© 2016 CLEMCO INDUSTRIES CORP. www.clemcoindustries.com Manual No. 21803, Rev. F 07/16
8.3 BNP Gun and Feed Assembly, Figure 25
Item Description Stock No.
(-) BNP Gun assemblies less nozzle, includes
items 1 (brass) through 7
No. 4 Gun .............................................. 12301
No. 5 Gun .............................................. 12302
No. 6 Gun .............................................. 12303
No. 7 Gun .............................................. 12304
No. 8 Gun .............................................. 12305
1. Nut, nozzle holding
Standard, knurled brass ........................ 11914
Urethane covered .................................. 11574
2. O-ring ........................................................ 08975
3. Gun body .................................................. 11802
4. Lock nut, air jet ......................................... 11913
5. Rubber sleeve ........................................... 12097
6. Air jet assembly w/ Item 5
No. 4 ...................................................... 12342
No. 5 ...................................................... 12343
No. 6 ...................................................... 12344
No. 7 ...................................................... 12345
No. 8 ...................................................... 12346
7. Fitting, hose, 3/8" NPT x 1/2" barb ........... 06369
8. Hose end, 1/2" barb x 1/2" fem. swivel ..... 15002
9. Nozzle, ceramic
No. 5 ...................................................... 11930
No. 6 ...................................................... 11931
No. 7 ...................................................... 11932
Nozzle, boron carbide
No. 5 ...................................................... 11935
No. 6 ...................................................... 11936
No. 7 ...................................................... 11937
No. 8 ...................................................... 12894
Nozzle, tungsten carbide
No. 5 ...................................................... 13118
No. 7 ...................................................... 12882
No. 8 ...................................................... 11942
10. Hose, 1/2" air, six feet required ................ 12472
11. Hose, media, clear urethane,
six feet required ..................................... 12476
12. Wide spray nozzle
Tungsten carbide, No. 6 ........................ 11947
Boron carbide
No. 6 ...................................................... 11934
No. 8 ...................................................... 11944
13. Wide spray nozzle nut
Knurled brass ........................................ 11916
Urethane covered .................................. 12906
14. Wide spray retaining ring .......................... 12038
15. Wide spray nozzle guard .......................... 12295
16. Adjusting tool, air jet ................................. 19041
Figure 25
1
9
2
3
4
5
6
8
7
1
13
16
14
13
12
10
Green air hose
11
Clear media hose
15
