Project ________________________________
Item __________________________________
Quantity_______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio,U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site:www.ClevelandRange.com
Email: [e-mail]
MODULAR BASES
MODELS:c36-EM-K11-24
c42-EM-K111-24
Cleveland Standard Features
n24 KW Electric Steam Generator base with full width Drain
Trough, Grate and a 11⁄2" drain.
nEasy-Access Swing-Type Hinged Doors.
nAutomatic Generator Fill at start-up.
nAutomatic Generator Drain upon shutdown.
n10 PSI operating pressure control.
nServiceable from the front.
n80 oz. tilting Oyster Kettles with Lift-Off Covers.
n50 PSI Steam Jacket Rating for kettles.
nFactory installed Steam Control Kit
nMirror Finish on kettles
nCold Water Faucet with Swing Spout.
nCabinet Base Console includes a Pressure Gauge, Two
Rocker Type Power Switches: one, red color light for water
fill to generator; one, amber color light for power supply to
generator.
nSolid State Water Level Control that includes a LowWater
Safety Shut-Off.
nGenerator Drain Cycle includes water cooling "Jet Rinsing"
drain cleaning feature.
nSteam Generator includes a large Access Cover and Sight
Glass Gauge as required byASME codes.
nSecondary Low Water Cut-Off, factory installed (CAL-E)
Required for AZ, CA, CO, CT, FL, GA, IL, IA, MA, MN, NE,
NV, RI, SD, TN, WA, Houston, TX.)
nNSF Approved 6" Stainless Steel Adjustable Legs: provides
one inch level adjustment.
nAvailable in most voltages – 1 or 3 phase.
Applications
nQuick, single-serving items for display cooking.
nPasta with sauces and other ingredients.
nClassic Asian stir-fry.
nNoodles featuring Asian, American or Italian styles.
nSeafood items featuring oysters, shrimp and scampies.
nOmelets and scrambled eggs.
nVegetable sautés.
Shall be CLEVELAND, Oyster Bar, Model _____ -EM-K _____ -24;
_____ volts, _____ Hz, _____ phase, _____ KW, steam generator base
with drain trough, splashguard and cold water faucet(s). To
include, factory mounted, 80 oz. tilting oyster kettles with steam
control kit and lift-off covers. Electric steam generator with solid
state water level controls, pressure limit controls, sight glass and 15
psi safety valve. Automatic steam generator (boiler) blow-down
and refill on start-up.
Options & Accessories
pVoltages other than standard.
115 – 480/60/3 (VOS-2)
220 – 380/50/3 (VOS-3)
240 – 415/50/3 (VOS-4)
500 – 600/60/3 (VOS-5)
p36 or 48 KW Generator Power Options.
pType 316 Stainless Steel Liner, 6 gallon kettle (each, 316G).
pStainless Steel Frame (FSS).
pMineral Purge Cycle (MPC).
ShortForm Specifications
2-3 OYSTER KETTLES
ELECTRIC STEAM GENERATOR 24KW
36" (900MM) or 42" (1050MM)
CABINET BASE
SECT. VII PAGE 37
0707

KW 280V 220V 240V 480V
24 3PHASE 57 63 52 26
1PHASE 99 N/A 89 45
36 3PHASE 100 80 87 44
48 3PHASE 119 127 107 53
ELECTRIC WATER DRAINAGE CLEARANCE
C
D
1
⁄ 4 "NPT cold water inlet
3
⁄ 8 "NPT hot and
cold water for kettles
35 psi minimum
60 psi maximum
11⁄2"IPS common drain
The Floor Drain must be
located outside the
confines of the
equipment base.
Do not connect any
other units to this drain.
RIGHT = 4.00"
LEFT = 0.00"
REAR =0.00"
Allow 6.00" minimum
from rear and sides
when located near
combustible walls.
H
C
C
H
AMPS
PER
LINE
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are ASME/N. Bd, UL, CSA and NSF.
(NOT TO SCALE)
SECT
.VII P AGE 38
0707
Litho in U.S.A.
WATER QUALITY REQUIREMENT
The recommended minimum water quality standards whether untreated or pre-treated,
based upon 10 hours of use per day, and a Daily Blowdown, are as follows:
TOTAL DISSOLVED SOLIDS less than 60 parts per million
TOTAL ALKALINITY less than 20 parts per million
SILICA less than 13 parts per million
pH FACTOR greater than 7.5
CHLORINE less than 30 parts per million
Consult a local water treatment specialist for an on site water analysis for recommendations
concerning steam generator feed water treatment (if required), in order to remove or
reduce harmful concentrations of minerals. The use of highly mineralized water will mean
that more frequent servicing of the steam generator will be necessary. The fact that a water
supply is potable is not proof that it will be suitable for the generator.
