Cleveland PowerPan SEL-30-T1 User manual

Cleveland
™
Project ________________________________
Item __________________________________
Quantity_______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
1333 East 179 St.,
Cleveland, Ohio,U.S.A. 44110
Tel: [phone]
Fax: [phone]
Web Site:www.ClevelandRange.com
Email: [e-mail]
BRAISING PANS /
TILTING SKILLETS
PowerPan™SERIES
ELECTRIC, 35" RIM HEIGHT,,
30 & 40 GALLON (110 & 150 LITER)
MODELS:cSEL-30-T1
cSEL-40-T1
Cleveland Standard Features
nAvailable in 30 & 40 gallon (115 & 150 liter) open frame
design models. Full capacity to bottom of pouring lip.
nHigh efficiency heating system with even heat distribution. 30
gallon models (115 liter) feature a 12 KW heating element
and the 40 gallon models (150 liter) feature a 18 KW heating
element.
nOpen base design for easy cleaning and maintenance.
n5/8" Stainless Steel Bead Blasted cooking surface prevents
warping and keeps food from sticking.
nDurable 12 gauge, 304 Stainless Steel pan construction.
5
/8˝(16mm) mild steel clad bottom plus a 1/16˝(1.6mm)
Stainless Steel plate for even temperature distribution.
nLow 35" rim height for easy operation and cleaning.
nSplash Proof Controls and construction.
nEasy-to-turn manual hand tilt with enclosed permantly
lubricated gearbox. Optional power tilt with manual override
available.
nGallon/Liter Markings and Vented Spring Assist Cover
standard.
nAvailable with Optional 2" Tangent Draw-OffValve.
n10°Cooking Feature. Tilt unit up to 10° without the power
being turned off.
nAdjustable, Electronic Thermostat accurately controls
temperature from 100°to 450° F.
nStandard Voltages 208-240, single and three phase.
nSpring-Assist Cover with full width handle and vent.
nTypical approvals include UL, CSA, CE and NSF.
Options & Accessories
pPower Tilt with Manual Override (PT2)
p2" (50 mm) Tangent Draw-Off Valve (TD2SK), left side only
pDouble or Single Pantry Faucet (SPS14, DPS14),
includes Faucet Mounting Bracket
pFaucet Bracket (FBKT1)
pPan Carriers (PCS), not available on 30 gallon
models with a Tangent Draw-OffValve
pVegetable Steamer Baskets (VS)
pHot & Cold Water Pre-Rinse Spray Head with Hose
(PRS-S)
pPoaching Pans (PP)
Shall be CLEVELAND, Tilting Skillet Model Number SEL-___-T1, electric
(_____ KW,_____ Volts ) holding no less than _____ gallons ( _____ liters);
Complete with Thermostatic and Safety Controls, Gallon/Liter Markings, 5/8"
Stainless Steel Clad Cooking Surface with Bead Blasted Finish, Easy to use
Manual Hand Tilt with Enclosed Permantly Lubricated Gearbox, Spring
Assist Cover with adjustable Vent, Adjustable Feet with Rear Flanged and
Front Bullet Style, Gallon/Liter Markings and Splash Proof Controls
Short Form Specifications
pProtective Control Cover (CP-PCB-T1)
pCasters, 2 swivel, 2 locking (CST1)
pHigh Wattage Option (HW)
16KW on 30 gallons, 24KW on 40 gallons
pVoltage Options:
•VOSK1, 240 Volt, 60 Hz, 3 Phase
•VOSK2, 380/415 Volt, 50 Hz, 3 Phase - for export
•VOSK3, 440/480 Volt, 60 Hz, 3 Phase
Shown with optional 2" Tangent Draw Off Valve
SECT. XII PAGE 9
0707

DPK
(OPTION)
39"
991mm
35"
889mm
(RIM
HEIGHT)
71"
1804mm
75
28 3/4"
731mm
(PAN
SURFACE)
A
H
B
(PAN SURFACE)
41"
1042mm
H C
25 15/16"
(659mm)
3 7/8" (99mm)
C
5 1/4"
(134mm)
(FAUCET
OPEN)
30"
(762mm)
5"
(127mm)
(MANUAL
TILT HANDLE)
D
RECOMMENDED FLOOR
SLOPE 1" (26mm) IN 4' (1220mm)
FLOOR DRAIN
PIPE DRAIN RECOMMENDED
MINIMUM VALVE SIZE PLUS 1" (26mm)
4" (102mm) MINIMUM
6" (153mm) RECOMMENDED
DPK
(OPTION)
LEG LOCATION &
SUGGESTED FLOOR DRAIN DETAIL
MODEL
SEL-30-T1
SEL-40-T1
A
37 7/8"
(963mm)
49 7/8"
(1267mm)
RIGHT:
4" (102mm) (manual tilt)
1" (26mm) (power tilt)
LEFT: 0", REAR: 0"
CLEARANCE
DIMENSIONS CAPACITIES
B
24 1/2"
(623mm)
36 1/2"
(928mm)
F
18 1/4"
(464mm)
24 1/4"
(616mm)
G
53/4"
(146mm)
53/4"
(146mm)
H
8"
(204mm)
8"
(204mm)
C
31 3/4"
(807mm)
43 3/4"
(1112mm)
D
12"
(305mm)
18"
(458mm)
In 4 oz. servings. Other sizes may be calculated.
30gallons / 115 Liters.............960
40gallons / 150 Liters...........1280
SEL-30-T1
390 LBS. (178 KG.)
SEL-40-T1
410 LBS. (187 KG)
APPROXIMATE
SHIPPING WEIGHTS
91/2" (241mm)
(PAN DEPTH)
NOTE: OPTIONAL 2" TD VALVE SHOWN IN GRAY
FOR OPTIONAL 2" TD VALVE
INCREASE FLOOR
DRAIN GRATE SIZE TO
24" x 20" (610mm x 508mm)
FLOOR
DRAIN
GRATE
12" x 20"
(305mm x
508mm)
H C
2 1/4"
(57mm)
7/16"Ø, 3 HOLES
ON 3 1/8" (80mm) B.C.D.
FLANGED FOOT DETAIL
(REAR LEGS ONLY )
120°120°
4 7/8" (124mm)
9/16" (15mm)
1" (26mm)
(MAXIMUM
ADJUSTMENT
2" (51mm)
38"
966mm
TD 2 OUTLET
42 3/4"
1086mm
TD 2
23"
585mm
SECT.XII PAGE 10
0707
Litho in U.S.A.
(NOT TO SCALE)
NOTES:
Cleveland Range reserves right of design improvement or modification, as warranted.
Many regional, state and local codes exist and it is the responsibility of the owner and installer to comply with the codes.
Cleveland Range equipment is built to comply with applicable standards for manufacturers. Included among those approval agencies are U.L., NSF, CGA, CSA, ETL and others.
Volts Ph Hz Total Amps Wire
Watts Size
SEL-30-T1 (Standard Wattage)
208 1 60 12000 57.7 4
208 3 60 12000 33.3 8
240 1 60 12000 50.0 6
240 3 60 12000 28.9 8
380 1 50 10013 26.3 8
380 3 50 10013 15.2 12
416 1 50 12000 28.8 8
416 3 50 12000 16.7 10
480 1 60 12000 25.0 8
480 3 60 12000 14.4 12
SEL-30-T1 (High Wattage)
208 1 60 16020 77.0 3
208 3 60 16020 44.5 6
240 1 60 16020 66.8 4
240 3 60 16020 38.5 6
380 1 50 13367 35.2 8
380 3 50 13367 20.3 10
416 1 50 16020 38.5 6
416 3 50 16020 22.2 10
480 1 60 16020 33.4 8
480 3 60 16020 19.3 10
Volts Ph Hz Total Amps Wire
Watts Size
SEL-40-T1 (Standard Wattage)
208 1 60 18000 86.5 2
208 3 60 18000 50.0 6
240 1 60 18000 75.0 3
240 3 60 18000 43.3 6
380 1 50 15019 39.5 6
380 3 50 15019 22.8 10
416 1 50 18000 43.3 6
416 3 50 18000 25.0 8
480 1 60 18000 37.5 6
480 3 60 18000 21.7 10
SEL-40-T1 (High Wattage)
208 3 60 24000 66.6 4
240 3 60 24000 57.7 4
380 3 50 20026 30.4 8
416 3 50 24000 33.3 8
480 3 60 24000 28.9 8
ELECTRICAL
