Clevertronics LP CWP2LIFE-PRO-WPPOD Series Installation and operating instructions

1942362
V1.0
9 April 2020
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Zoneworks, HIVE and DATA Monitored Options
Fittings with part numbers -ZW, -HV, -DATA are fitted with Zoneworks communications modules (nodes).
These fittings are monitored using either Powerline Carrier Technology that utilize the power cable to
provide data communication, RF transceiver modules operating in the ISM band or a dedicated data cable
to/from data routers installed on a dedicated data trunk connected to a central Server (can also be
connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor, coordinate
testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a single push
of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides a
multifunction indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
ZW, HV, DATA
Commissioned
LED on Solid (Green)
ZW, DATA Un-commissioned Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green
250mS, yellow 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at yellow 5s , 0ff 1s
HV
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Fittings with part numbers CWP2LIFE-PRO-WPPOD-DALI are fitted with DALI modules (nodes) that
facilitate connection and integration to 3rd Party Lighting Control Systems.
Before installing the
CWP2LIFE-PRO-WPPOD-DALI please confirm that the Lighting Control System has the capability to
monitor DALI Emergency Fittings. The CWP2LIFE-PRO-WPPOD-DALI will be addressed and configured
into the cont
rol system by the Lighting Control System Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND” Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network OR a 5/6way
“structured wiring system” lead and plug facilitating the power and DALI connection. DALI connections
are marked as Da Da.
CWP2LIFE-PRO-WPPOD
Surface Mount Twin Head Emergency
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website:
www.clevertronics.com.au
Email:
[e-mail]
Phone:
[phone]
Fax:
[phone]
New South Wales
Phone:
[phone]
Fax:
[phone]
Queensland
Phone:
[phone]
Fax:
[phone]
South Australia/Northern Territory
Phone:
[phone]
Fax:
[phone]
Western Australia
Phone:
[phone]
Fax:
[phone]
New Zealand
Phone:
[phone]
Designed in Australia to comply with the requirements
of AS2293.3:2005
and AS/NZS CISPR15: 2011
NOTE: Standard product codes with this symbol are
enabled with Clevertest Plus capability. Please refer to the
operation guide supplied with the product for details.
Models: CWP2LIFE-PRO-WPPOD-xx
Testing:
Manual Test
xx = Blank
Zoneworks
xx = ZW
Z/W DATA
xx = DATA
DALI
xx = DALI
HIVE
xx = HV
Clevertest
xx = CT
(NOTE: -CT Products supplied with the Clevertest Plus Symbol are activated
with Clevertest PLUS capability. Please refer to the operation guide supplied with the
product for details).
Spare Parts:
1550050
Battery, 3.2 Volt 3.2Ah Li-ion
2750356
LP/L10 WP POD, Gen2, 2 LED, Wht LED, Sub Assy
AUM02370050001
CLIFE-PRO-CKIT-NP, Lifelight Pro, Control Only, 530mm, NP, CTP, OWC
Important
:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before
in
stallation, ensure that the electricity supply has been switched off and isolated.
Installation must be
carried out in accordance with the relevant Australian and International Standards.

1942362
V1.0
9 April 2020
Images and Dimensions:
Initial
Testing:
When the
CWP2LIFE-PRO-WPPOD unit is connected to the un-switched active, it must be allowed to
charge the battery for at least 24 hour
s. The emergency lamp only illuminates during a power failure.
Conduct the following tests:
•
During the first commissioning test the emergency lamp must illuminate for at least 2 hours after
disconnection from the main supply. The results of all tests are required to be recorded in a service
logbook, which is to be kept on-site at all times. If the unit fails to illuminate for the requisite time,
remedial action must be taken to repair the situation and once completed, the unit must pass a
subsequent test.
•
Press and hold Test Button in each POD
or switch Off Mains Supply, check that the emergency lamp
is On.
•
Release the Test Button or Switch on Mains Supply, check that the emergency lamp is Off
(Non-maintained operation).
•
Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-
site at all times. If the unit fails to
remain illuminated for the requisite time, remedial action must be taken to repair the situation and
once completed, the unit must pass a subsequent test. For more specific information, please refer
to
the current edition of the AS 2293.3 Standard.
Below are a list of common problems and their possible causes:
Fault:
The Green LED indicator is not illuminated.
Check:
A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault:
Lamp does not illuminate in emergency mode.
Check:
A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault:
Lamp illuminates in emergency mode, but only stays on for a short period.
Check:
Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions)
:
Refer to the Technical Label for classification information.
Caution:
On many
building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been se
lected to give excellent long-
life performance
in a controlled AS2293 testing environment. Excessive battery cycling will reduce through
-life
performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are spe
cifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms
-conditions-sale-australia-nz/
Installation:
This CWP2LIFE
-PRO-WPPOD Surface mount non-
maintained Emergency Luminaire can be installed
on s
olid or T-BAR ceilings or used to replace an existing unit.
•
Locate the installation position.
•
Pre-drill mounting holes per diagram below.
•
Removed fitting cover.
•
Use suitable fixings to fasten the fitting to the mounting surface.
•
Taking note of the terminal block position, drill a hole in the fitting box to suit the cable gland or
conduit to be used for power entry.
•
Terminate the supply cables to the L, N & E terminals (in the case of the –DALI or –
DATA fittings
terminate the DALI or DATA cable to the terminals marked Da Da or DATA).
•
Ensure the Batteries and POD cables are connected.
•
Screw the cover to the base.
•
If the CTP capabilities are activated, please affix the CTP status label to a visible surface and
Four Segment Marking on the product will include an ‘’F’’ in third segment block.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DAT
A, HIVE,
DALI) simply insert
the relevant Smart Node PCA.
