Clevertronics Trade Series Installation and operating instructions

1942257
V1.2
30 September 2022
Instruction Sheet Template - V1.2 – Updated 06/10/2021
THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK
Trade Series LIFELIGHT Surface Mount Weatherproof
Emergency Luminaire
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements of
AS2293.3: 2005 and AS/NZS CISPR15: 2017
Models:
ELIFE-X-LI-SM-WP
Spare Parts:
1560160
Replacement Battery
8050174
Replacement Emergency LED Board
8002986
Replacement Emergency Driver
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1942257
V1.2
30 September 2022
Instruction Sheet Template - V1.2 – Updated 06/10/2021
Installation:
Please follow the steps below to correctly install the product;
•Remove the Lid from the Base by using a flat screwdriver to release the snap fits (see below)
•Cut/Drill out Cable Entry points (A=End Entry, B=Rear Entry)
•Drill out the required fixing holes on the Base (see image below, C=Junction Box fixing)
•Mark holes on mounting surface (use drilled out holes on the Base as a template)
•Insert Mains Cables & mount Base using appropriate fixings to ensure a secure installation
(mounting points must be sealed appropriately to ensure proper protection from water ingress)
•Terminate the Mains Cables into terminal block. Ensure Active, A & Neutral, N wires are connected
as per Terminal Block Label.
•Re-attach Lid Assembly, ensuring to align Mains Connector Pins into Terminal Block
Dimensions:
Lid Removal / Lens Replacement:
STEP 1 – Insert flat screw driver and lever to remove
lid
STEP 2 – Remove the two coloured screws
and push out Bezel/Lens
STEP 3 – Release Lens from the Bezel
STEP 4 – Insert required Lens followed by
Bezel and re-insert coloured screws and Lid
Note: for Corridor Lens ensure the two pins
engage into the PCA
Testing:
When the unit is connected to the un-switched active, it must be allowed to charge the battery for at
least 24hours. The emergency lamp only illuminates during a power fail. Conduct the following tests:
•The emergency lamp must illuminate for at least 2 hours after disconnection from the mains. The
results of all tests are required to be recorded in a service logbook, which is to be kept on-site at all
times. If the unit fails to illuminate for the requisite time, remedial action must be taken to repair the
situation and once completed, the unit must pass a subsequent test.
•Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off (Non
maintained operation)
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1, not applicable
for –TH (theatre) version (refer to spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
