Clevertronics LP Argonaut Instruction Manual

1942489
V1.5
24 March 2023
Instruction Sheet Template - V1.1 – Updated 23/11/2020
Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Zoneworks, HIVE (HV/HVG) and DATA Monitored Options
Fittings with part numbers -ZW, -HV, -HVG, -DATA are fitted with Zoneworks communications modules
(nodes). These fittings are monitored using either Powerline Carrier Technology that utilize the power
cable to provide data communication, RF transceiver modules operating in the ISM band or a dedicated
data cable to/from data routers installed on a dedicated data trunk connected to a central Server (can also
be connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor,
coordinate testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a
single push of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides
a multifunction indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
ZW, HV, HVG,
DATA
Commissioned LED on Solid (Green)
ZW, DATA Un-commissioned
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV, HVG Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green
250mS, yellow 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at yellow 5s , 0ff 1s
HV, HVG
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Luminaires with part numbers having -DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the -DALI luminaire, please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The -DALI
fitting will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics.
State LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND” Lamp and Status LED Flash for 30 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
Driver Setting:
For non -SEN / -DD products
Note:
This luminaire (with reinforced insulation between control/LED terminal and AC supply) contains non-
user replaceable light source and battery - to be replaced (if required, refer installation instructions for
battery replacement) by Clevertronics service personnel/agents or a registered electrician.
LP™ Argonaut Square LED Emergency Light
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the requirements
of AS2293.3: 2018 and AS/NZS CISPR15: 2017
NOTE: Standard product codes with this symbol are
enabled with Clevertest Plus capability. Please refer to the
operation guide supplied with the product for details.
Models:
ARGOSQ-yy-LP-zz-vv
Testing:
Options:
Manual Test
zz = Blank
Microwave Sensor Hi/Lo Control
yy = SEN
Zoneworks
zz = ZW
Microwave Sensor ON/OFF
yy = MS
Z/W DATA
zz = DATA
Black Body
vv = BLK
Zoneworks HIVE
zz = HV/HVG
DALI Registered.
zz = DALI
Spare Parts:
1550230
Replacement Battery
8050785
Replacement LED Board
AUM02370390001
Replacement Emergency Driver
AUM02970040001
Replacement Emergency Driver (-HVG)
1330094
Replacement 240V Driver (-MS)
1330095
Replacement 240V Driver (-SEN)
1190312
Replacement Microwave Sensor (-MS)
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1942489
V1.5
24 March 2023
Instruction Sheet Template - V1.1 – Updated 23/11/2020
Installation:
The LP Argonaut Square can be installed either Ceiling or Wall Mounted.
•Remove the four (4) screws holding the diffuser to the base.
•Remove the four (4) screws holding the gear tray to the base.
•Determine the cable access point. There are 2 locations on opposite sides of the fitting for cable
gland/conduit entry. Entry can also be from the back of the base. Drill out the desired cable entry
point.
Note: Only round cables are to be used with the cable gland for an IP65 seal. Keep cable entry
straight and tension free. Ensure all seals are tight.
min. wire diameter 7mm, max. 12mm.
•Drill out 4 of the mounting points in the base (see image below).
•Using the base as a guide, mark the 4 holes for mounting and one for mains access if using back
cable entry.
•Mount the base using appropriate fixings and seal these fixings with appropriate sealant (also fill any
additional entry points).
•If Wall Mounted, then the installation should take place in a manner such that the Status LED is at
the bottom where it will be visible to an observer standing directly below the luminaire.
•Route the power inside the base.
•Connect the 240VAC (Lem,E,N,Lsw) supply to the terminal block of the gear tray. For fittings with
the -MS option, connect the power inputs to LEMG, E, N, LSEN terminals. Slave fittings can be
controlled via the Microwave Sensor by powering them through the output terminal SW (Live).
•Install the gear tray to the base.
•Apply power to the fitting and test per the instructions.
•If the CTP capabilities are activated, please affix the CTP status label to a visible surface and
Four Segment Marking on the product will include an ‘’F’’ in third segment block
Dimensions:
Dimensions:
Networking:
When installing the product on a monitored network, (ZONEWORKS, HIVE, DATA, DALI) simply insert
the relevant Smart Node PCA.
Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 hours after
disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails
to remain illuminated for the requisite time, remedial action must be taken to repair the situation
and once completed, the unit must pass a subsequent test. For more specific information, please
refer to the current edition of the AS 2293.3 Standard.
Maintenance:
Lamp Replacement:
•Use only the lamp(s) recommended on the
label inside the Argonaut.
•To replace the LED Panel, remove the
clips, disconnect the signal cable and install
the new Lamp Panel.
Battery Replacement:
•Use only the battery recommended on the
label inside the Argonaut and on this
instruction.
•Remove the fasteners holding the battery,
un-plug the lead from the PCB and remove
the old battery.
•Attach the new battery, route the DC cable
to the PCB and plug the new battery.
Trouble Shooting:
Below are a list of common problems and their
possible causes.
Fault: The Green LED Test Switch
indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in
emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency
mode, but only stays on for a short
period.
Check: Battery has been allowed to charge for
at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions):
Refer to the Technical Label for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
