Clevertronics Argonaut PLUS Maintenance and service guide

1948894
V1.0
24 March 2021
UK Instruction Sheet Template – V1.1 – Updated: 20/11/2020
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
Zoneworks, HIVE and DATA Monitored Options
Fittings with part numbers -ZW, -HVG, -DATA are fitted with Zoneworks communications modules
(nodes). These fittings are monitored using either Powerline Carrier Technology that utilize the power
cable to provide data communication, RF transceiver modules operating in the ISM band or a dedicated
data cable to/from data routers installed on a dedicated data trunk connected to a central Server (can also
be connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor,
coordinate testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a
single push of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides
a multifunction indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
ZW, HVG, DATA
Commissioned
LED on Solid (Green)
ZW, DATA Un-commissioned Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HVG Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HVG Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green
250mS, yellow 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at yellow 5s , 0ff 1s
HVG
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Luminaires with part numbers having -DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the -DALI fitting please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The -DALI
fitting will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The Li-ion battery in the Exit & Emergency Unit has been selected to give
excellent long life performance in a controlled IEC 60598-2-22 testing environment. Excessive battery
cycling will reduce through-life performance and may lead to premature battery failure. Battery warranty
claims, as a result of such abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Argonaut PLUS Weatherproof Emergency LED Batten
Installation & Maintenance Instruction Leaflet
Australia (Head Office)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
UK OFFICE
Website: www.clevertronics.co.uk
362 Stockley Close
West Drayton UB7 9BL
Phone: [phone]
NOTE: Standard product codes with this symbol are
enabled with Clevertest Plus capability. Please refer to the
operation guide supplied with the product for details.
Models:
ARGOPLUS-1500-xx-yy-zz
Options:
Testing:
Microwave Sensor (HI/LO)
xx = SEN
Manual Test
zz = Blank
DALI Driver
xx = DD
DALI Registered
zz = DALI
Integrated Battery (non-POD)
yy = LP
Zoneworks
zz = ZW
Emergency POD
yy = LPPOD
Zoneworks HIVE
zz = HVG
Spare Parts:
8002753
PCA:LED Strip ARGOPLUS-1500,10P16S,3000K/5700K
1330057
LED Driver - LC 57w 800-1050mA,flexC lp
1330151
LED Driver - TCI DC MAXI JOLLY SVM 65 DALI SLIM
(DD & SEN version )
1550230
BATT:LP 3.2V 6400mAh.200mm lead.Brkt.
(Non-POD only)
1550050
BATT:LP 3.2V 3200mAh 70mm lead,no BRKT.
(POD only)
UKM02370070001
Lifelight Pro, Control Only, 475mA, LP, OWC
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant British Standards.
Note:
This luminaire (with reinforced insulation between control/LED terminal and AC supply) contains non-user
replaceable light source and battery - to be replaced (if required, refer installation instructions for battery
replacement) by Clevertronics service personnel/agents or a registered electrician.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
https://clevertronics.co.uk/product-warranty-statement/

1948894
V1.0
24 March 2021
UK Instruction Sheet Template – V1.1 – Updated: 20/11/2020
Installation:
The product can be mounted/suspended from any solid surface. Follow the below installation steps:
•Determine the installation and power entry method.
•Undo the Diffuser Clips, remove the Diffuser and Gear Tray. Position the batten base in the desired
location and Mark out the fixing points on the mounting surface.
•If the cable entry is to be via the rear of the body – Drill out a suitable entry-hole in the rear of the
batten body (must be suitably sealed after cable entry using a sealant). If the cable entry is via the
end of the batten - Install the provided cable gland, or bring in conduit, to the base as required for
the intended power access.
Note: Only round cables are to be used with the cable gland for an IP65 seal. Keep cable entry
straight and tension free. Ensure all seals are tight.
min. wire diameter 6mm, max. 12mm.
•For surface mounting -, there are 3 extrusions/posts at each end of the base. Drill out the desired
number of fixing points at each end. Fixings must only be through the extrusions/mounting
posts.
oPosition the fitting to the mounting surface and mark the mounting holes.
oCable/Gland entry to be down if mounting vertically.
oDrill the mounting holes.
oFix the base to the surface with appropriate fixings.
oSeal any penetrations/fixing points with appropriate sealant.
•For Surface Mount Clip mounting, measure/mark spacing (see Dimensions image), install
stainless steel clips to surface (use appropriate fixings), then snap batten into clips.
•For Suspension Mounting, measure/mark spacing (see Dimensions image), install suspension
device, E.G chain, and connect chain to batten base.
•Wire mains power cable, 240V 50Hz, to terminals marked Lsw (Switched Active), Lem
(Emergency/Unswitched Active), N & (and DALI Cables to terminals Da Da as applicable)
•Set Colour Switch to the desired colour (3000K / 4000K / 5700K, 4000K set as default)
•Attach Gear Tray to lanyards.
•Re-Install the Diffuser, close all the Diffuser Clips and secure with screws
Wiring:
NOTE: Refer to Microwave Sensor Supplement for wiring -SEN Products
Colour Setting:
Dimensions:
Battery Replacement (non-POD)
1. Prior to any work, isolate power to any Batten that requires battery replacement
2. Open the Diffuser by releasing the Batten Diffuser Clips
3. Remove Gear Tray by unclipping the Gear Tray Clips on each side (ensure the Gear Tray is
supported while unlocking clips)
4. Remove Battery connector from the Emergency Driver
5. Remove Battery by removing the Screw/Washer/Nuts
6. Install replacement Battery/Screw/Washer/Nuts and connect into Emergency Driver
7. Re-Install the Gear Tray onto the Gear Tray Clips
8. Re-Install the Diffuser, close all the Diffuser Clips and secure with screws
NOTE: For POD products refer to Instruction Sheet for LP POD’s provided with product
Testing Procedure:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•The emergency lamp must illuminate for at least 180 min after disconnection from the mains. If the
unit fails to illuminate for the requisite time, remedial action must be taken to repair the situation
and once completed, the unit must pass a subsequent test.
•Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
