Clevertronics LP CBS4N Series Installation and operating instructions

1942409 V1.1 3 June 2021
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or Red
flashing for a period up to 2 minutes.
Zoneworks, HIVE and DATA Monitored Options
Fittings with part numbers -ZW, -HV, -DATA are fitted with Zoneworks communications modules (nodes).
These fittings are monitored using either Powerline Carrier Technology that utilize the power cable to
provide data communication, RF transceiver modules operating in the ISM band or a dedicated data cable
to/from data routers installed on a dedicated data trunk connected to a central Server (can also be
connected via Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor, coordinate
testing and collate test data from each fitting. Zoneworks Fittings can be commissioned by a single push
of the test switch or by scanning the supplied barcode. The LED Test Switch indicator provides a
multifunction indication of the status of the fitting during testing and normal operation:
Option
State
LED Operation
ZW, HV, DATA
Commissioned
LED on Solid (Green)
ZW, DATA
Un-commissioned
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV
Un-commissioned
With network connectivity
Batt plugged-in: yellow 1s, green 1s
Batt unplugged: red 1s, off 1s
HV
Un-commissioned
Without network connectivity
Batt plugged-in: yellow 250mS, green
250mS, yellow 250mS, green 250mS,
green 1s
Batt unplugged: red 250mS, off
250mS, red 250mS,off 250mS, off 1s
ZW, DATA
Emergency Light Test In Progress
LED flashes at yellow 5s , 0ff 1s
HV
Emergency Light Test In Progress
LED flashes at yellow 1s , 0ff 1s
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl. DATA
version)
DALI EM Option
Fittings with part numbers CBS4N-DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the CBS4N -DALI please confirm
that the Lighting Control System has the capability to monitor DALI Emergency Luminaires. The CBS4N-
DALI will be addressed and configured into the control system by the Lighting Control System
Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network OR a 5/6way
“structured wiring system” lead and plug facilitating the power and DALI connection. DALI connections
are marked as Da Da.
.
LP™ Non-Maintained Batten
Surface Mount Emergency Luminaire
Installation & Maintenance Instruction Leaflet
Designed in Australia to comply with the
requirements of AS2293.3: 2005 and AS/NZS
CISPR15: 2017.
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability.
Please refer to the operation guide supplied with
the product for details.
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Models: CBS4N-xx-yy-zz
Testing:
Options:
Manual Test
xx = Blank
Black Colour
zz = BLK
Zoneworks
xx = ZW
Flex & Plug with Flat Earth
yy=FPF
Zoneworks DATA
xx = DATA
DALI
xx = DALI
HIVE
xx = HV
Clevertest
xx = CT (NOTE: Products supplied with the Clevertest Plus Symbol are activated
with Clevertest PLUS capability. Please refer to the operation guide supplied with the
product for details).
Spare Parts:
1550230
Battery, LP 3.2V 6400mAh, 200mm Lead Bracket
1100866
Lifelight Pro Head Assembly, Ld:500mm, Rnd, LT, Gen 2
AUM02370050001
CLIFE-PRO-CKIT-NP, Lifelight Pro, Control Only, 530mm, NP, CTP, OWC
Important:
It is illegalfor anyone, except for alicensed electrician toinstall ormaintainthis product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1942409 V1.1 3 June 2021
Installation:
This CBS4N Surface mount non-maintained Emergency Luminaire can be installed on solid surface or
used to replace an existing unit.
•Locate the installation position.
•Refer Images and Dimensions below for the Cut-out Hole and other dimensions.
•Pre-drill mounting holes.
•Mount base plate and use suitable fixings to secure the base plate into the pilot holes
•Bring in supply cables via the rear entry hole or via the end of the base plate (surface mount
conduit entry)
•Terminate the supply cables to the L, N & E terminals (in the case of the –DALI or –DATA fittings
terminate the DALI or DATA cable to the terminals marked Da Da or DATA).
•Install the top cover, containing the LifeLight Pro heads, ensuring to reconnect the Heads assembly
to the Control Gear.
•Ensure the Battery is connected
•Screw the cover to the base plate.
•If the CTP capabilities are activated, please affix the CTP Status Label to a visible surface and
Four Segment Marking on the product will include an ‘’F’’ in third segment block.
Networking:
When installing the product on a monitored network, (ZONEWORKS, DATA, HIVE, DALI) simply insert
the relevant Smart Node PCA.
Images and Dimensions:
Initial Testing:
When the CBS4N unit is connected to the un-switched active, it must be allowed to charge the battery
for at least 24 hours. The emergency lamp only illuminates during a power failure. Conduct the following
tests:
•During the first commissioning test the emergency lamp must illuminate for at least 2 hours after
disconnection from the main supply. The results of all tests are required to be recorded in a service
logbook, which is to be kept on-site at all times. If the unit fails to illuminate for the requisite time,
remedial action must be taken to repair the situation and once completed, the unit must pass a
subsequent test.
•Press and hold Test Button for each LED head or switch Off Mains Supply, check that the
emergency lamps are On.
•Release the Test Button or Switch on Mains Supply, check that the emergency lamp is Off (Non-
maintained operation).
Below are a list of common problems and their possible causes:
Fault: The Green LED indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer
to spacing tables for installation positions):
Refer to the Technical Label on the Product for classification information.
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any fittings Units, on these circuits, will have their batteries discharged or
“cycled”. The Li-ion battery in the Fitting has been selected to give excellent long-life performance in a
controlled IEC 60598-2-22 testing environment. Excessive battery cycling will reduce through-life
performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
Cable entry points
End view
Chain suspension points
Surface suspension points
