Clevertronics Trade TS CIRCLITE ECLLED Series Installation and operating instructions

1948344
V1.3
12 January 2022
Instruction Sheet Template - V1.2 –Updated 06/10/2021
Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 hours after
disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails
to remain illuminated for the requisite time, remedial action must be taken to repair the situation
and once completed, the unit must pass a subsequent test. For more specific information, please
refer to the current edition of the AS 2293.2 Standard.
Trouble Shooting:
Below are a list of common problems and their possible causes.
Fault: The Green LED Test Switch indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency mode, but only stays on for a short period.
Check: Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Fault: Green LED flashes once every 5 seconds-Battery is disconnected
Check: Battery is connected.
Fault: Green LED blinks off once every 5 seconds- Charging very flat battery
Allow 20min to recover battery then recheck
Fault: Green LED flashes at 2Hz (Fast flash)- Faulty battery
Replace battery
Battery Replacement
1. Disconnect power.
2. Remove the battery plug from the PCA
3. Remove the battery mounts
4. Remove the old battery
5. Fit the new battery and fix in position
6. Reconnect the battery to the PCA.
Emergency Classification in accordance with AS2293.1 (refer to spacing tables for
installation positions):
Please refer to the technical label on the product for classification.
Trade Series LED CIRCLITE Luminaire
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
Website: www.clevertronics.com.au
Email: [e-mail]
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the
requirements of AS2293.3: 2005 and AS/NZS
CISPR15: 2017
Models:
ECLLED-xx-xx
ECLLED-LI
Economy LED Circlite
ECLLED-LI-MS
Economy LED Circlite with microwave movement
sensor
ECLLED-LI-WW
Economy LED Circlite - Warm White
ECLLED-LI-WW-MS
Economy LED Circlite with microwave movement
sensor - Warm White
Spare Parts:
1560280
Battery, Eco Lith, 3.2V 3.0Ah
8003070
PCA ECLLED-LI #CT10626
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.

1948344
V1.3
12 January 2022
Instruction Sheet Template - V1.2 –Updated 06/10/2021
Installation:
A. Surface Mount
1. Disassemble the diffuser and LED panel.
2. Pull the power cord through the
grommet.
3. Fix the base to the surface.
4. Connect the power cord.
5. Assemble the LED panel and diffuser.
B. Semi recessed Mount (special option)
1. Cut a 320mm hole into the mounting surface.
2. Disassemble the diffuser and LED panel.
3. Place the metal frame above the hole in the
mounting surface.
4. Pull the power cord through the grommet.
5. Insert the base into the mounting hole and
attach to the frame with 2 x 4mm screws.
6. Assemble the LED panel and diffuser.
Power Supply Connection, 240V, 50Hz: Connect power to the fitting as shown.
ECLLED-LI—MS ECLLED-LI- (no sensor)
Note: Link 1&2 for permanent on or use switch for on/off
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz/
