Clevertronics L10 Ultrablade Pro LUBPRO-SM Series Installation and operating instructions

1943052 V1.3 June 2019
Testing:
Once connected to the 240V mains supply, the unit must be allowed to charge the battery for at least 24
hours. Conduct the following tests:
•For the first test, the emergency lamp must remain illuminated for at least 2 hours after
disconnection from the mains supply.
•Subsequent tests require the unit to illuminate for at least 90 minutes. The results of all tests are
required to be recorded in a service logbook, which is to be kept on-site at all times. If the unit fails
to remain illuminated for the requisite time, remedial action must be taken to repair the situation and
once completed, the unit must pass a subsequent test. For more specific information, please refer
to the current edition of the AS 2293.3 Standard.
Ultrablade Maintenance:
LED Lamp Replacement:
•Use only the LED Strip recommended in the
Spares Parts list of this instruction.
•Disconnect battery from LED driver.
•Remove the screw holding the driver PCA.
Remove the PCA.
•Remove the 4 screws holding the battery
bracket. Remove the bracket with the
battery.
•Disconnect the signal cable from LED strip.
•Remove 4 self-tapping screws and unclip
the LED strip.
•Install the new LED strip following the
above procedure in reverse.
Battery Replacement:
•Use only the battery recommended in the
Spares List on this instruction.
•Remove the battery from battery
compartment, un-plug the lead from the
battery connector remove the old battery.
•Plug the new battery into the battery
connector.
•Secure the battery into the battery
compartment
Trouble Shooting:
Below are a list of common problems and their
possible causes.
Fault: The Green LED Test Switch
indicator is not illuminated.
Check: A.C. is connected and is turned on.
Battery is connected
Test Switch for damage.
Fault: Lamp does not illuminate in
emergency mode.
Check: A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault: Lamp illuminates in emergency
mode, but only stays on for a short
period.
Check: Battery has been allowed to charge for
at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output in accordance with AS2293.1 (refer to
spacing tables for installation positions), not Included –TH version:
C0=E6.3 (8m) C90=E6.3 (8m)
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Exit & Emergency Units, on these circuits, will have their batteries
discharged or “cycled”. The battery in this fitting has been selected to give excellent long-life
performance in a controlled AS2293 testing environment. Excessive battery cycling will reduce through-
life performance and may lead to premature battery failure. Battery warranty claims, as a result of such
abuse, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms-conditions-sale-australia-nz
L10™Ultrablade Pro Surface Mount LED Exit
Installation & Maintenance Instruction Leaflet
Victoria (Head Office & Manufacturing)
195 Chesterville Rd
Moorabbin VIC 3189
Phone: [phone]
Fax: [phone]
New South Wales
Phone: [phone]
Fax: [phone]
Queensland
Phone: [phone]
Fax: [phone]
South Australia/Northern Territory
Phone: [phone]
Fax: [phone]
Western Australia
Phone: [phone]
Fax: [phone]
New Zealand
Phone: [phone]
Designed in Australia to comply with the
requirements of AS2293.3:2005 and AS/NZ CISPR:15
Models: LUBPRO-SM-ww-xx-yy-zz
Testing:
Options:
Manual Test
xx = Blank
Black
zz = BLK
Zoneworks
xx = ZW
Theatre
ww = TH
Z/W DATA
xx = DATA
Running Man
yy = R
DALI Comp.
xx = DALI
Running Man Left Arrow
yy = RL
Clevertest
xx = CT
Running Man Right Arrow
yy = RR
Double Side Running Man
yy = DS-R
Double Side Running Man with Arrow
yy = DS-RAOW
Special Purpose Sign
yy = SP
(NOTE: -CT Products supplied with the Clevertest Plus Symbol are activated with Clevertest PLUS
capability. Please refer to the operation guide supplied with the product for details).
Spare Parts:
1530030 –Battery, 3.3 Volt 2.5Ah Li-ion
8002178 –PCA: UBP LED strip PCB Assy
8002940 - PCA: LUBPRO #CT10142-L8 CTP
Important:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before installation,
ensure that the electricity supply has been switched off and isolated. Installation must be carried out in
accordance with the relevant Australian and International Standards.
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability. Please
refer to the operation guide supplied with the product
for details.

1943052 V1.3 June 2019
Clevertest and Clevertest Plus
Refer to the supplementary operation guide supplied with the Product.
After Power ON, the Status LED on a Clevertest Plus enabled fitting will display a rapid Green or
Red flashing for a period up to 2 minutes.
Zoneworks and DATA Monitored Options
Ultrablades with part numbers -ZW, -DATA are fitted with Zoneworks communications modules
(nodes). These fittings are monitored using either Powerline Carrier Technology that utilises the
power cable to provide data communication or a dedicated data cable to/from data routers installed
on a dedicated data trunk connected to a central Server (can also be connected via
Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor, coordinate testing and
collate test data from each Ultrablade and can be commissioned by a single push of the test switch,
or scanning of the suppliedbarcode. The LEDTest Switch indicator provides a multifunction indication
of the status of the Ultrablade during testing and normal operation:
State
LED Operation
Commissioned
LED on Solid (Green)
Un-commissioned
LED flashes at 0.5Hz (0.5s Green, 0.5s Yellow)
Emergency Light Test In Progress
LED flashes at 3s On (Yellow) & 0.5s Off
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the
connection to the DATA network via a multi-drop bus (daisy chain connection). For further
information of installation of a Zoneworks LW system, please refer to the Zoneworks Users Guide
and Commissioning Guide (incl. DATA version)
DALI EM Option
Ultrablades with part numbers -DALI are fitted with DALI modules (nodes) that facilitate connection
and integration to 3rd Party Lighting Control Systems. Before installing the –DALI fitting please
confirm that the Lighting Control System has the capability to monitor DALI Emergency Luminaires.
The –DALI fitting will be addressed and configured into the control system by the Lighting Control
System Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned
LED on Solid (Green)
Emergency Light Test in progress
LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND”
Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network. DALI
connections are marked as Da Da.
Networking:
When installing the L10 Ultrablade PRO on a monitored network, (ZONEWORKS, DATA, DALI) simply
insert the relevant Smart Node PCA.
Installation:
The L10 Ultrablade Pro Surface Mount LED Exit (LUBPRO-SM) is a surface mount fitting. The LUBPRO-
SM can be attached directly to any solid surface. Please follow the steps below to install the LUBPRO Exit:
•Open the fitting using the 2 screws on either side of the blade.
•Locate the mounting surface.
•Drill holes in the mounting base to suit the mounting method, Ceiling or Wall (see images below).
•Use the mounting bracket to mark-out the mounting holes for Ceiling or Wall Mount.
•Drill power access hole as required.
•Mount the fitting using appropriate fixings.
•Route the power to the mains connection and connect the 240VAC supply.
•Attach the blade assembly to the bracket and tighten the 2 mounting screws.
•Apply power to the fitting and test.
•If the CTP capabilities are activated, please affix the CTP Status Label to a visible surface.
Changing EXIT Legend Inserts:
The Ultrablade Pro Exit comes with an assortment of standard legends.
1. To remove the legend, grasp the centre of the bottom trim piece and pull down slightly to expose
the legend edge. See photo.
2. Grasp the bottom edge of the legend and slide the existing legend out of the blade, while working
the edges out along the sides.
3. Slide the new legend into the blade, ensuring to fit the edges into the sides then slide the legend to
the top of the blade. Insert one bottom corner then the other. Slide the legend down into the
bottom trim.
