Clevo 880 User manual

Preface
I
Preface
Notebook Computer
8880/888E Series
Service Manual

Preface
II
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained
herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven-
dor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are
they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or
reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publica-
tion, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of
their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement
of that product or its manufacturer.
Version 1.0
February 2003
Trademarks
Intel®and Pentium®are registered trademarks of Intel Corporation.
Windows®is a registered trademark of Microsoft Corporation.
Other brand and product names are trademarks and/or registered trademarks of their respective companies.

Preface
III
Preface
About this Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and
inspection of personal computers.
It is organized to allow you to look up basic information for servicing and/or upgrading components of the notebook PC.
The following information is included:
Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
Chapter 2, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to upgrade
elements of the system.
Appendices A & B, Part Lists
Appendices C & D, Schematic Diagrams
Appendix E, Flash ROM BIOS

Preface
IV
Preface
Related Documents
You may also need to consult the following manual for additional information:
User’s Manual on CD
This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro-
gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

Preface
V
Preface
Contents
Introduction ........................................................... 1-1
Overview ............................................................................................................. 1-1
System Specifications ......................................................................................... 1-2
Processor Options ................................................................................................ 1-2
Core Logic ........................................................................................................... 1-2
Structure .............................................................................................................. 1-2
Security ............................................................................................................... 1-3
Memory ............................................................................................................... 1-3
BIOS .................................................................................................................... 1-3
LCD ..................................................................................................................... 1-3
Display ................................................................................................................ 1-3
Storage ................................................................................................................. 1-4
Audio ................................................................................................................... 1-5
Keyboard ............................................................................................................. 1-5
PC Card ............................................................................................................... 1-5
Interface ............................................................................................................... 1-6
Communication ................................................................................................... 1-6
Power Management ............................................................................................. 1-7
Power ................................................................................................................... 1-7
Indicators ............................................................................................................. 1-7
Environmental Spec ............................................................................................ 1-7
Physical Dimensions ........................................................................................... 1-7
Weight ................................................................................................................. 1-7
Optional ............................................................................................................... 1-8
External Locator - Top Views ............................................................................. 1-9
External Locator - Front View & Left Side View ............................................. 1-10
External Locator - Right Side & Rear Views .................................................... 1-11
External Locator - Bottom View ....................................................................... 1-12
Mainboard Overview - Top ............................................................................... 1-13

Preface
VI
Preface
Key Parts ........................................................................................................... 1-13
Mainboard Overview - Bottom ......................................................................... 1-14
Key Parts ........................................................................................................... 1-14
Mainboard Overview - Top ............................................................................... 1-15
Connectors ......................................................................................................... 1-15
Mainboard Overview - Bottom ......................................................................... 1-16
Connectors ......................................................................................................... 1-16
Disassembly ............................................................ 2-1
Overview ............................................................................................................. 2-1
Maintenance Tools .............................................................................................. 2-2
Connections ......................................................................................................... 2-2
Maintenance Precautions .................................................................................... 2-3
Cleaning ...............................................................................................................2-3
Disassembly Steps ............................................................................................... 2-4
Removing the Battery ......................................................................................... 2-6
Removing the Primary Drive Bay (Bay One) CD Device .................................. 2-7
Removing the Modular Drive Bay (Bay Two) Device ....................................... 2-8
Removing the Primary Hard Disk ....................................................................... 2-9
Removing the Hard Disk Drive in Bay Two ..................................................... 2-10
Removing the Hard Disk Drive in Bay Three ................................................... 2-11
Removing the TV Tuner Module ...................................................................... 2-12
Removing the Keyboard ................................................................................... 2-13
Removing the System Memory ......................................................................... 2-14
Removing the CPU ........................................................................................... 2-15
Removing the Wireless LAN Module ............................................................... 2-17
Removing the Switch Keyboard Assembly ...................................................... 2-18
Removing the Bottom Case Assembly ............................................................. 2-19
Removing the HDD & MP3 Converter Board .................................................. 2-21
Removing the Audio Board .............................................................................. 2-22
Removing the Chip Heat Sink and Modem Module ......................................... 2-23
Removing the Mainboard .................................................................................. 2-24

Preface
VII
Preface
Removing the Fan Module ................................................................................ 2-25
Removing the Cardbus Modules ....................................................................... 2-26
Removing the Floppy Disk Drive Assembly .................................................... 2-27
Removing the TouchPad Module ...................................................................... 2-28
Removing the Inverter Board ............................................................................ 2-29
Removing the LCD ........................................................................................... 2-30
Part Lists for 888E ............................................... A-1
Part List Illustration Location ............................................................................ A-2
Top (888E) ......................................................................................................... A-3
Bottom (888E) .................................................................................................... A-4
LCD 15" (888E) ................................................................................................. A-5
LCD 15.7" (888E) .............................................................................................. A-6
LCD 16" (888E) ................................................................................................. A-7
Battery (888E) .................................................................................................... A-8
Center Cover (888E) .......................................................................................... A-9
Center Cover Finger (888E) ............................................................................. A-10
CD-ROM Drive (888E) .................................................................................... A-11
CD-RW Drive (888E) ...................................................................................... A-12
Combo Drive (888E) ........................................................................................ A-13
DVD-ROM Drive (888E) ................................................................................ A-14
Audio DJ (888E) .............................................................................................. A-15
Floppy Disk Drive (888E) ................................................................................ A-16
First Hard Disk Drive (888E) ........................................................................... A-17
Second Hard Disk Drive (888E) ...................................................................... A-18
Third Hard Disk Drive (888E) ......................................................................... A-19
Third Hard Disk - Dummy (888E) ................................................................... A-20
IP Sharing Module (888E) ............................................................................... A-21
MP3 Player (888E) ........................................................................................... A-22
Part Lists for 8880..................................................B-1
Part List Illustration Location .............................................................................B-2

Preface
VIII
Preface
Top (8880) ...........................................................................................................B-3
Bottom (8880) .....................................................................................................B-4
LCD 15" (8880) ..................................................................................................B-5
LCD 15.7" (8880) ...............................................................................................B-6
Battery (8880) .....................................................................................................B-7
Center Cover (8880) ............................................................................................B-8
Center Cover Finger (8880) ................................................................................B-9
CD-ROM Drive (8880) .....................................................................................B-10
CD-RW Drive (8880) ........................................................................................B-11
Combo Drive (8880) .........................................................................................B-12
DVD-ROM Drive (8880) ..................................................................................B-13
Audio DJ (8880) ................................................................................................B-14
Floppy Disk Drive (8880) .................................................................................B-15
First Hard Disk Drive (8880) ............................................................................B-16
Second Hard Disk Drive (8880) ........................................................................B-17
Third Hard Disk Drive (8880) ...........................................................................B-18
Third Hard Disk - Dummy (8880) ....................................................................B-19
IP Sharing Module (8880) .................................................................................B-20
MP3 Player (8880) ............................................................................................B-21
Schematic Diagrams for 888E.............................. C-1
System Block Diagram ....................................................................................... C-2
CPU (Northwood) 1 of 2 ..................................................................................... C-3
CPU (Northwood) 2 of 2 ..................................................................................... C-4
CPU Decoupling ................................................................................................. C-5
MCH (Host, AGP, Hub) ...................................................................................... C-6
MCH (Voltage, PLL, VSS) ................................................................................. C-7
MCH (DDR) ........................................................................................................ C-8
DDR Termination ................................................................................................ C-9
DDR SODIMM ................................................................................................. C-10
CLK ................................................................................................................... C-11
Mobility M9 - P ................................................................................................. C-12

Preface
IX
Preface
Mobility M9 - P Mem A/B ................................................................................ C-13
VGA DDR DRAM Channel A ......................................................................... C-14
VGA DDR DRAM Termination ....................................................................... C-15
VGA DDR DRAM Channel B .......................................................................... C-16
Moblility M9-P Power ...................................................................................... C-17
TV CRT & LVDS ............................................................................................. C-18
ICH3 1 of 2 ........................................................................................................ C-19
ICH3 2 of 2 ........................................................................................................ C-20
USB RTC .......................................................................................................... C-21
USB 2.0 ............................................................................................................. C-22
HDD & CD-R/W & MP3 CNN & IP Share ..................................................... C-23
AMP TPA0132/ALC201A 1 of 2 ..................................................................... C-24
AMP TPA0132/ALC201A 2 of 2 ..................................................................... C-25
Audio DJ CD-ROM .......................................................................................... C-26
Fan Control ........................................................................................................ C-27
Flash ROM LPT1 .............................................................................................. C-28
LPC Bridge & Super I/O ................................................................................... C-29
I/O Connector .................................................................................................... C-30
KBC H8 ............................................................................................................. C-31
Mini PCI/MDC .................................................................................................. C-32
PCI 1520 ............................................................................................................ C-33
PCMCIA Connector .......................................................................................... C-34
1394 TSB43AB21 ............................................................................................. C-35
LAN RTL8100B ............................................................................................... C-36
LED Indicator .................................................................................................... C-37
Power Plane ....................................................................................................... C-38
TV Tuner / Fingerchip ...................................................................................... C-39
W83518D Media Reader ................................................................................... C-40
System Power 1 SCH ........................................................................................ C-41
System Power 2 SCH ........................................................................................ C-42
VCORE ............................................................................................................. C-43
Charger-PWM ................................................................................................... C-44

Preface
X
Preface
3VH8 VDD1.8 .................................................................................................. C-45
Schematic Diagrams For 8880 ............................ D-1
System Block Diagram ....................................................................................... D-2
CPU (Northwood) 1 of 2..................................................................................... D-3
CPU (Northwood) 2 of 2..................................................................................... D-4
CPU Decoupling ................................................................................................. D-5
MCH (Host, AGP, Hub)...................................................................................... D-6
MCH (Voltage, PLL, VSS)................................................................................. D-7
MCH (DDR)........................................................................................................ D-8
DDR Termination................................................................................................ D-9
DDR SODIMM ................................................................................................. D-10
CLK................................................................................................................... D-11
Mobility M7 - P................................................................................................. D-12
Mobility M7 - P Mem A/B................................................................................ D-13
VGA DDR DRAM Channel A ......................................................................... D-14
VGA DDR DRAM Channel A Termination..................................................... D-15
VGA DDR DRAM Channel B.......................................................................... D-16
VGA DDR DRAM Channel B Termination..................................................... D-17
Moblility M7-P Power ...................................................................................... D-18
TV CRT & LVDS ............................................................................................. D-19
Video In 7114.................................................................................................... D-20
ICH3 1 of 2........................................................................................................ D-21
ICH3 2 of 2........................................................................................................ D-22
USB RTC .......................................................................................................... D-23
HDD & CD-R/W & MP3 CNN & IP Share ..................................................... D-24
AMP TPA0132/ALC201A 1 of 2 ..................................................................... D-25
AMP TPA0132/ALC201A 2 of 2 ..................................................................... D-26
Audio DJ CD-ROM .......................................................................................... D-27
Fan Control........................................................................................................ D-28
Flash ROM LPT1.............................................................................................. D-29
LPC Bridge & Super I/O................................................................................... D-30

Preface
XI
Preface
I/O Connector.................................................................................................... D-31
KBC H8............................................................................................................. D-32
Mini PCI/MDC.................................................................................................. D-33
PCI 1520............................................................................................................ D-34
PCMCIA Connector.......................................................................................... D-35
1394 TSB43AB21............................................................................................. D-36
LAN RTL8100B ............................................................................................... D-37
LED Indicator.................................................................................................... D-38
Power Plane....................................................................................................... D-39
TV Tuner / Fingerchip ...................................................................................... D-40
W83518D Media Reader................................................................................... D-41
System Power 1 SCH ........................................................................................ D-42
System Power 2 SCH ........................................................................................ D-43
VCORE ............................................................................................................. D-44
Charger-PWM ................................................................................................... D-45
3VH8 VDD1.8 .................................................................................................. D-46
Updating the FLASH ROM BIOS .......................E-1

Preface
XII
Preface

Introduction
Overview 1 - 1
1.Introduction
1: Introduction
Overview
This manual covers the information you need to service or upgrade the 8880/888E series notebook computer. Informa-
tion about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about
drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.
Operating systems (e.g. DOS, Windows 9x, Windows NT 4.0, Windows 2000, Windows XP, OS/2 Warp, UNIX, etc.) have
their own manuals as do application software (e.g. word processing and database programs). If you have questions about
those programs, you should consult those manuals.
The 8880/888E series notebook is designed to be upgradeable. See “Disassembly” on page 2 - 1 for a detailed descrip-
tion of the upgrade procedures for each specific component. Please note the warning and safety information indicated by
the “” symbol.
The balance of this chapter reviews the computer’s technical specifications and features.

Introduction
1 - 2 System Specifications
1.Introduction
System Specifications
The differences between the 8880 and 888E notebook computer series are as follows:
Table 1 - 1 - Model Differences
Processor Options
• Intel Pentium® 4 Processor - 2.0/ 2.2/ 2.4/2.6 GHz (400MHz FSB)
•(
µ0.13) 0.13 Micron Process Technology
• CPU Package - FC-PGA2 (478-pin)
• 512K L2 Cache (on die)
• Intel Pentium® 4 Processor - 2.26/ 2.4/ 2.53/ 2.66/ 2.8/ 3.06* GHz (533MHz FSB*)
•(
µ0.13) 0.13 Micron Process Technology
• CPU Package - FC-PGA2 (478-pin)
•512KL2Cache
*Only 888E notebooks with processors of 3.06GHz support Hyper-Threading (see “Hyper-Threading” on page E - 2).
Core Logic
• Intel® 845E + ICH3
Structure
• Fully PC99 Compliant
• ACPI 1.0B Compliant
• PC2001 Compliant
Feature 8880 Series 888E Series
Video Card ATI Radeon7500 ATI Radeon 9000
Direct X Compliance Direct X 6 Direct X 8.1
USB Port Type 1.1 2.0

Model Differences
You may identify if the
computer is an 8880 or
888E from the video
card. After you have in-
stalled the video driver
go to the Advanced
Display Properties
and check the card
type. If the card is a
MOBILITY RADEON
7500, then the ma-
chine is an 8880. If the
video card is a MOBIL-
ITY RADEON 9000
then the machine is an
888E, and supports
USB 2.0.

Introduction
System Specifications 1 - 3
1.Introduction
Security
• Security (Kensington® Type) Lock Slot
• BIOS Password
Memory
• 64 bit data bus system memory
• Two 200-pin DDR SODIMM sockets, supporting DDR SDRAM SODIMM (2.5V) - DDR200 or DDR266 compliant
• Expandible memory up to 1GB (128/256/512MB SODIMM Modules)
BIOS
• One 256KB Flash ROM
• Insyde BIOS with smart battery
• Plug and Play (1.0a), ACPI 1.0B
LCD
• 15.0" 1600 x 1200 UXGA TFT (8880)
• 15.7" 1280 x 1024 SXGA TFT (8880 & 888E)
• 16.0" 1600 x 1200 UXGA TFT (888E)
• 16.0" 1280 x 1024 SXGA TFT (888E)
Display
• ATI Mobility M7 (8880)
• ATI Mobility M9 (888E)
64MB DDR graphic memory on board
OR
128MB DDR graphic memory on board
4 * UltraAGP™
128-bit 2D/3D graphics engine
Motion compensation and IDCT for DVD content playback
accelerator
Fully DirectX 6 compliant graphics engine (8880)
Fully DirectX 8.1 compliant graphics engine (888E)
CRT resolution up to 1920*1200 * 16M

Model Differences
You may identify if the
computer is an 8880 or
888E from the video
card. After you have in-
stalled the video driver
go to the Advanced
Display Properties
and check the card
type. If the card is a
MOBILITY RADEON
7500, then the ma-
chine is an 8880. If the
video card is a MOBIL-
ITY RADEON 9000
then the machine is an
888E, and supports
USB 2.0.

Introduction
1 - 4 System Specifications
1.Introduction
Storage
• One fixed FDD 9.5/12.7mm
• One changeable 2.5" 9.5mm primary HDD
• Changeable primary drive (Bay One) for one of the following:
DVD-ROM (12.7mmH) 8X
CD-ROM (12.7mmH) 24X
CD-RW (12.7mmH) 8X/ 4X/ 24X
Combo Drive (DVD-ROM + CD-RW) 8X/ 8X/ 8X/ 24X
DVD-RW (12.7mmH) 1X/1X/12X/16X/24X
• Built-in modular drive (Bay Two) for one of the following:
DVD-ROM (12.7mmH) 8X
CD-ROM (12.7mmH) 24X
CD-RW (12.7mmH) 8X/ 4X/ 24X
Combo Drive (DVD-ROM + CD-RW) 8X/ 8X/ 8X/ 24X
DVD-RW (12.7mmH) 1X/1X/12X/16X/24X
3rd HDD
IP sharing module
• Changeable drive (Bay Three) for one of the following:
2nd HDD (optional)
TV-Tuner (optional)
• One portable MP3 player (optional)

Jumper Settings for
Multiple Hard Disk
Use
If you are using more
than one hard disk in
your computer, make
sure to set the jumpers
on all your hard disks
to the cable select op-
tion in order for the
system to recognize all
the disks (see your
hard disk manual or
the information printed
on the hard disk itself
for details on the jump-
er settings).

Software Installation Warning
Make sure the MP3 player is not in the slot when installing operating systems, and any of the drivers listed in User’s Manual.

Introduction
System Specifications 1 - 5
1.Introduction
Audio
• AC'97 2.2 compliant interface
• Compatible with Sound-Blaster PRO™ 16
• S/PDIF Digital output (5.1 CH) for DVD content and Stereo Audio
• Built-in microphone
•AudioDJ
• Advanced Wavetable Synthesizer
• 2 built-in speakers
• Virtual AC3
• Full Duplex
• Direct Sound™ 3D Accelerator
Keyboard
• “Win Key” keyboard including a numeric keyboard
• Built-in 3 instant keys, www, email, and player
PC Card
• Two type II PCMCIA 3.3V/5V sockets, OR one type III PCMCIA 3.3V/5V socket (no Zoomed Video support)

Introduction
1 - 6 System Specifications
1.Introduction
Interface
• Built-in TouchPad (PS/2)
• Four USB ports
USB 2.0 ports for 888E (USB 1.1 compatible)
USB 1.1 ports for 8880
• One IEEE 1394 port
• One S-Video-Out jack for TV output
• One S-Video-In jack (The S-Video in jack will only be available if you have the Optional TV Tuner installed.)
• One parallel port (LPT1), supporting ECP / EPP 1.7 and 1.9
• One COM port
• Fast Infrared (FIR) file transfer IrDA 1.1
• One external CRT monitor
• One external keyboard/mouse (through Y cable) PS/2 port
• One line-in jack
• One microphone-in jack
(You must use the Y-cable provided to enable the S/PDIF Out and Microphone-In functions (S/PDIF connection is to
the longer end of the cable.)
• One Sony Memory Stick™ socket
• One RJ-11 jack for 56k MDC modem
• One RJ-45 jack for 100M/10M LAN
• One S/PDIF out port
(You must use the Y-cable provided to enable the S/PDIF Out and Microphone-In functions (S/PDIF connection is to
the longer end of the cable.)
• DC-in jack
Communication
• Wireless Infrared transfer IrDA 1.1, 1cm~1M operating distance, 4Mbps FIR
• 10/100Mb Ethernet LAN built-in
• 802.11b Wireless LAN, Mini-PCI interface (optional)
• 56K MDC modem V.90 compliant (V.92 software driver upgradeable)
• IP sharing module for xDSL or Cable Modem (optional)

Introduction
System Specifications 1 - 7
1.Introduction
Power Management
• Supports ACPI v1.0B
• Supports APM v1.2
• Soft Off by system power button
• Supports suspend to disk
• Battery low suspend
• Resume from alarm
• Close-cover switch
Power
• Full Range 120 watts AC adapter - AC in 100~240V, 47~63Hz
• Supports Smart Lithium-Ion battery 12 cells
Indicators
• LED indicator (HDD, power status, Num Lock, Caps Lock, Scroll Lock, AC-In, battery charging, e-mail)
• Audio DJ control display (power, MP3, Audio, Play/Pause, FWD, RWD, Stop, Volume+, Volume-, EQ)
Environmental Spec
• TemperatureRelative Humidity
• Operating: 5°C~ 35°C Operating: 20% ~ 80%
• Non-Operating: -20°C ~ 60°CNon-Operating: 10% ~ 90%
Physical Dimensions
• 329 (w) x 299 (d) x 54.5 (h) mm
Weight
• 4.9 kg with 12-cell Lithium-Ion battery
