Clevo M540J User manual

Preface
I
Preface
Notebook Computer
M540J/M545J/M550J/M555J
Service Manual

Preface
II
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Information contained
herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven-
dor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are
they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated, transmitted or
reduced to any machine readable form without prior consent from the vendor, manufacturer or creators of this publica-
tion, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered trademarks of
their respective companies. They are mentioned for identification purposes only and are not intended as an endorsement
of that product or its manufacturer.
Version 1.0
February 2006
Trademarks
AMD Turion™and AMD Sempron™are trademarks of Advanced Micro Devices, Inc.
Windows®is a registered trademark of Microsoft Corporation.
Other brand and product names are trademarks and./or registered trademarks of their respective companies.

Preface
III
Preface
About this Manual
This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and
inspection of personal computers.
It is organized to allow you to look up basic information for servicing and/or upgrading components of the M540J/
M545J/M550J/M555J series notebook PC.
The following information is included:
Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
Chapter 2, Disassembly, provides step-by-step instructions for disassembling parts and subsystems and how to upgrade
elements of the system.
Appendix A, Part Lists
Appendix B, Schematic Diagrams

Preface
IV
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per-
sons when using any electrical equipment:
1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of elec-
trical shock from lightning.
3. Do not use the telephone to report a gas leak in the vicinity of the leak.
4. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
5. This product is intended to be supplied by a Listed Power Unit (DC Output 20V, 3.25A (65W) minimum AC/DC
Adapter.
CAUTION
Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment.
TO REDUCE THE RISK OF FIRE, USE ONLY NO. 26 AWG OR LARGER,
TELECOMMUNICATION LINE CORD
This Computer’s Optical Device is a Laser Class I Product

Preface
V
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating element. This
is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
3. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save
your work. Remember to periodically save your data as data may be lost if the battery is depleted.
Do not expose the computer
to any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy
on the computer.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place
where foreign matter or mois-
ture may affect the system.
Don’t use or store the com-
puter in a humid environment.
Do not place the computer on
any surface which will block
the vents.
Do not turn off the power
until you properly shut down
all programs.
Do not turn off any peripheral
devices when the computer is
on.
Do not disassemble the com-
puter by yourself.
Perform routine maintenance
on your computer.

Preface
VI
Preface
4. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag-
netic fields. These can hinder proper performance and damage your data.
5. Take care when using peripheral devices.
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can support the total current load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external power supplies.
Use only approved brands of
peripherals.
Unplug the power cord before
attaching peripheral devices.
Do not plug in the power
cord if you are wet.
Do not use the power cord if
it is broken.
Do not place heavy objects
on the power cord.

Power Safety
Warning
Before you undertake
any upgrade proce-
dures, make sure that
you have turned off the
power, and discon-
nected all peripherals
and cables (including
telephone lines). It is
advisable to also re-
move your battery in
order to prevent acci-
dentally turning the
machine on.

Preface
VII
Preface
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or qualified service
personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries may explode
or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.

Battery Disposal
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of
its useful life, under various state and local laws, it may be illegal to dispose of this battery into the municipal
waste stream. Check with your local solid waste officials for details in your area for recycling options or proper
disposal.
Caution
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommend-
ed by the manufacturer. Discard used battery according to the manufacturer’s instructions.

Preface
VIII
Preface
Related Documents
You may also need to consult the following manual for additional information:
User’s Manual on CD
This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro-
gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

Preface
IX
Preface
Contents
Introduction ..............................................1-1
Overview .........................................................................................1-1
System Specifications ................................. 1-2
External Locator - Top View with LCD Panel Open ......................1-5
External Locator - Front & Right side Views .................................1-6
External Locator - Left Side & Rear View .....................................1-7
External Locator - Bottom View .....................................................1-8
M540J Mainboard Overview - Top (Key Parts) .............................1-9
M540J Mainboard Overview - Bottom (Key Parts) ......................1-10
M540J Mainboard Overview - Top (Connectors) .........................1-11
M540J Mainboard Overview - Bottom (Connectors) ...................1-12
M550J Mainboard Overview - Top (Key Parts) ...........................1-13
M550J Mainboard Overview - Bottom (Key Parts) ......................1-14
M550J Mainboard Overview - Top (Connectors) .........................1-15
M550J Mainboard Overview - Bottom (Connectors) ...................1-16
Disassembly ...............................................2-1
Overview .........................................................................................2-1
Maintenance Tools ..........................................................................2-2
Connections .....................................................................................2-2
Maintenance Precautions .................................................................2-3
Disassembly Steps ...........................................................................2-4
Removing the Battery ......................................................................2-5
Removing the Hard Disk Drive .......................................................2-6
Removing the System Memory (RAM) ..........................................2-8
Removing the Optical (CD/DVD) Device ....................................2-10
Removing the Processor ................................................................2-11
Removing the Keyboard ................................................................2-13
Removing the Wireless LAN Module ...........................................2-14
Removing the Modem and Bluetooth Modules ............................2-15
Part Lists ..................................................A-1
Part List Illustration Location ........................................................ A-2
Top (M550J) .................................................................................. A-3
Top (M555J) .................................................................................. A-4
Bottom (M550J/M555J) ................................................................ A-5
LCD (M550J) ................................................................................. A-6
LCD (M555J) ................................................................................. A-7
DVD-RW Drive (M550J) .............................................................. A-8
Top (M540J) .................................................................................. A-9
Top (M545J) ................................................................................ A-10
Bottom (M540J/M545J) .............................................................. A-11
LCD (M540J) ............................................................................... A-12
LCD (M545J) ............................................................................... A-13
Combo Drive (M540J) ................................................................ A-14
Schematic Diagrams................................. B-1
System Block Diagram ...................................................................B-2
ATHLON 64 1/4 .............................................................................B-3
ATHLON 64 2/4 .............................................................................B-4
ATHLON 64 3/4 .............................................................................B-5
ATHLON 64 4/4 .............................................................................B-6
DDR SO-DIMM .............................................................................B-7
DDR TERMINATION ...................................................................B-8
PANEL, INVERTER, FAN ............................................................B-9
C15 HT CPU .................................................................................B-10
C51 HT MCP ................................................................................B-11
C51 PCI EXPRESS ......................................................................B-12
C51 DAC / IFP .............................................................................B-13
C51 PWR / GND - DECOUPLING .............................................B-14
MCP51 HT ....................................................................................B-15

Preface
X
Preface
MCP51 PCI .................................................................................. B-16
MCP51 SATA / IDE .................................................................... B-17
MCP51 AUDIO / USB / MISC .................................................... B-18
MCP51 RGMII ............................................................................. B-19
MCP51 PWR / GND .................................................................... B-20
MINI PCI, USB2.0*2 ................................................................... B-21
SIO, SATA HDD, CD-ROM ....................................................... B-22
LAN RTL8201CL ........................................................................ B-23
FWH, TOUCHPAD, LED ........................................................... B-24
IEEE 1394 VT6307S .................................................................... B-25
H8/2111 ........................................................................................ B-26
MDC, USB BT, PWRGD, DDB CON ......................................... B-27
AZALIA CODEC ALC880 ......................................................... B-28
AUDIO AMP, USB2.0* 2 ............................................................ B-29
PCMCIA ENE CB714B ............................................................... B-30
PCM SOCKET, 3-IN-1 SOCKET ............................................... B-31
SYSYEM POWER, BRIDGE BATT .......................................... B-32
+2.6V, +1.3V, +1.2V ................................................................... B-33
+VCORE ...................................................................................... B-34
+1.2VS_ADJ, +1.0V_ADJ ........................................................... B-35
+VDD3, +VDD5, +VDD12 ......................................................... B-36
D/D BD (RGB & TV OUT MUXES) .......................................... B-37
D/D BD (CRT, S-VIDEO, RJ-11) ............................................... B-38
D/D BD (CHARGER, DC IN) ..................................................... B-39
AUDIO BD (PHONE JACK, USB) ............................................. B-40
HOT KEY BD (HOT KEY, LED) ............................................... B-41
LED BOARD ............................................................................... B-42
CLICK BOARD ........................................................................... B-43
RJ-45 BOARD ............................................................................. B-44
USB DONGLE BOARD .............................................................. B-45

Introduction
Overview 1 - 1
1.Introduction
Chapter 1: Introduction
Overview
This manual covers the information you need to service or upgrade the M540J/M545J/M550J/M555J series notebook
computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual.
Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.
Operating systems (e.g. DOS, Windows 9x, Windows NT 4.0, Windows 2000, Windows XP, OS/2 Warp, UNIX, etc.) have
their own manuals as do application software (e.g. word processing and database programs). If you have questions about
those programs, you should consult those manuals.
The M540J/M545J/M550J/M555J series notebook is designed to be upgradeable. See “Disassembly” on page 2 - 1 for
a detailed description of the upgrade procedures for each specific component. Please note the warning and safety infor-
mation indicated by the “” symbol.
The balance of this chapter reviews the computer’s technical specifications and features.

Introduction
1 - 2 System Specifications
1.Introduction
System Specifications
Feature Specification
Processor Mobile AMD Turion™ 64 Processor (35W),
754-pin Micro-PGA Package, 64bit
Models ML-30/ ML-34/ ML-37/ ML-40/ ML-44
(µ0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process
Technology, 1MB L2 Cache
1.6GHz/ 1.8GHz/ 2.0GHz/ 2.2GHz/ 2.4GHz
Mobile AMD Turion™ 64 Processor (35W),
754-pin Micro-PGA Package, 64bit
Models ML-28/ ML-32/ ML-42
(µ0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process
Technology, 512KB L2 Cache
1.6GHz/ 1.8GHz/ 2.4GHz
Mobile AMD Turion™ 64 Processor (25W),
754-pin Micro-PGA Package, 64bit
Models MT-30/ MT-34/ MT-37/ MT-40/ MT-44
(µ0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process
Technology, 1MB L2 Cache
1.6GHz/ 1.8GHz/ 2.0GHz/ 2.2GHz/ 2.4GHz
Mobile AMD Turion™ 64 Processor (25W),
754-pin Micro-PGA Package, 64bit
Models MT-28/ MT-32/ MT-42
(µ0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process
Technology, 512KB L2 Cache
1.6GHz/ 1.8GHz/ 2.4GHz
Mobile AMD Sempron™ Processor (25W),
754-pin Micro-PGA Package, 32bit
Models 2800+/ 3100+
(µ0.13) 0.13 Micron Silicon-On-Insulator (SOI) Process
Technology, 256KB L2 Cache
1.6GHz/ 1.8GHz
Mobile AMD Sempron™ Processor (25W),
754-pin Micro-PGA Package, 32bit
Models 2600+/ 3000+/ 3300+
(µ0.09) 0.09 Micron Silicon-On-Insulator (SOI) Process
Technology, 128KB L2 Cache
1.6GHz/ 1.8GHz/ 2.0GHz
Core Logic nVIDIA C51MV + MCP51M
Memory 64-bit Wide DDR Data Channel
Two 200 Pin SO-DIMM Sockets Supporting DDR 333 / 400 MHz
Memory Expandable up to 2GB (256/ 512/ 1024 MB DDR Modules)
(Note: Do Not Use Other Module Types)
Security Security (Kensington® Type) Lock Slot BIOS Password
BIOS One 4MB Flash ROM Phoenix™ BIOS, Plug and Play

Introduction
System Specifications 1 - 3
1.Introduction
LCD M550J:
15.0" XGA (1024*768) Flat Panel TFT
OR
15.0" SXGA+ (1400*1050) Flat Panel TFT
M540J:
14.0" WXGA (1280*768) Flat Panel TFT
Video Adapter nVIDIA C51MV Integrated Graphics Adapter
Shared Memory Architecture of up to 128MB of Video Memory
Supports Analog Monitor Pixel Resolution up to 2048 * 1536 at 75Hz
Integrated High Quality 3D Graphics Engine Accelerator
Supports Microsoft DirectX 9.0 Vertex Shader 3.0
Storage One Changeable 12.7mm(h) Optical Device (CD/DVD) Type Drive
(see “Optional” on page 1 - 4 for drive options)
Easy Changeable 2.5" 9.5 mm (h) HDD with SATA (Serial) Interface
Audio Integrated AZALIA Compliant Interface (HDA)
3D Stereo Enhanced Sound System
Sound-Blaster PRO™ Compatible
2 * Built-In Speakers
Built-In Microphone
Note: External 7.1 CH Audio Output Support Configurable through Headphone, Microphone, Line-In and S/PDIF Jacks
Keyboard &
Pointing Device
Winkey Keyboard Built-In TouchPad with Scrolling Function
PCMCIA One Type-II PCMCIA CardBus PC Card Slot
Interface Three USB 2.0 Ports
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One Line-In Jack
One Serial Port
One S/PDIF Output Jack (5.1CH)
One RJ-11 Jack for Plug & Play Fax/Modem
One RJ-45 Jack for 10Mb/ 100Mb/ 1000Mb Fast Ethernet
One DC-in Jack
Card Reader Embedded 4-in-1 Card Reader (MS/ MS PRO/ SD/ MMC)
Feature Specification

Introduction
1 - 4 System Specifications
1.Introduction
Communication AZALIA 56K Plug & Play Fax/Modem v.90/92 Compliant
10Mb/ 100Mb/ Fast Ethernet
802.11g Mini-PCI Wireless LAN Module
(Factory Option) Bluetooth Module - Version 2.0
(Factory Option) PC Camera with USB Interface
Power
Management
Supports ACPI 2.0
Power Button as Sleep/Resume Key
Supports Hibernate Mode
Supports Standby
Supports Battery Low Suspend
Supports Resume from Modem Ring
Supports Wake on LAN
Power Full Range AC/DC Adapter 20V, 5.25A (65 Watts), 100~240V, 47~63Hz
6 Cell Smart Lithium-Ion Battery Pack, 4000mAH (44.4W)
6 Cell Smart Lithium-Ion Battery Pack, 4400mAH (48.8W)
Environmental
Spec
Temperature
Operating: 5°C ~ 35°C
Non-Operating: -20°C ~ 60°C
Relative Humidity
Operating: 20% ~ 80%
Non-Operating: 10% ~ 90%
Physical
Dimensions &
Weight
M550J:
333mm (w) * 276mm (d) * 24-33mm (h)
2.4 kg Without Battery
M540J:
333mm (w) * 243mm (d) * 24-33mm (h)
2.2 kg Without Battery
Optional Optical Drive Module Options:
DVD/CD-RW Combo Drive Module
DVD-Dual Drive Module
Battery Charger Box
Port Replicator (10/100 Base-T Ethernet Port, 4 * USB
2.0 Ports, Serial Port, Parallel Port, External Monitor Port,
DC-In Jack)
(Note: Port Replicator requires the supplied 90W
power adapter)
(Factory Option) PC Camera with USB Interface
(Factory Option) Bluetooth V2.0 Module
(Factory Option) 802.11g Mini-PCI Wireless LAN Module
Feature Specification

Introduction
External Locator - Top View with LCD Panel Open 1 - 5
1.Introduction
External Locator - Top View with LCD Panel Open Figure 1
Top View
1. Optional Built-In
PC Camera
2. LCD
3. LED Status
Indicators
4. Speakers
5. LED Power &
Communication
Indicators
6. Power Button
7. Keyboard
8. Built-In
Microphone
9. TouchPad and
Buttons
10. AP-Key Buttons
2
6
3
1
7
10
8
5
6
9
1
2
3
5
7
89
10
66
33
10 10
M550J M540J
4

Introduction
1 - 6 External Locator - Front & Right side Views
1.Introduction
External Locator - Front & Right side Views
Figure 2
Front Views
1. LED Power &
Communication
Indicators
2. LCD Latch
(M550J Only)
3. 4-in-1 Card
Reader (M540J
Only)
Figure 3
Right Side Views
1. Headphone-Out
Jack
2. Microphone-In
Jack
3. USB 2.0 Port
4. RJ-11 Modem
Jack
5. Optical Device
Drive Bay
6. DC-In Jack
12
M550J
13
M540J
1 4 5
6
32

Introduction
External Locator - Left Side & Rear View 1 - 7
1.Introduction
External Locator - Left Side & Rear View
4
1 2
3 3 56
7
M550J
Figure 4
Left Side View
1. RJ-45 LAN Jack
2. Vent/Fan Intake
3. 2 * USB 2.0 Ports
4. S/PDIF-Out Jack
5. Line-In Jack
6. PC Card Slot
7. 4-in-1 Card
Reader (M550J
Only)
114
23 3 5
6
M540J
Figure 5
Rear View
1. External Monitor
Port
2. Serial Port
3. Security Lock Slot
4. Battery
4
123

Introduction
1 - 8 External Locator - Bottom View
1.Introduction
External Locator - Bottom View
Figure 6
Bottom View
1. Vent/Fan Intake
2. Battery
3. Memory (RAM)/
WLAN Module/
CPU Cover
4. Hard Disk Cover
5. Speakers
(M550J Only)

Overheating
To prevent your com-
puter from overheating
make sure nothing
blocks the vent/fan in-
takes while the com-
puter is in use.
1
2
4
3
1
55
2
4
3
1
M550J
M540J
1
1
